Frigidaire CGEF3031K User manual

LGEF3031KBA.eps CFGEF3031KBA.eps VCGEF3031KBA.eps TFGEF3031KBA.eps
DLGEF3031KBB.eps
Product No. CGEF3031KBA CGEF3031KWA
Series 30" f/s elec 30" f/s elec
Color black white
Market Canada Canada
Owner's Guide 316902301 316902301
Installation Instructions 316259203 316259203
Service Data Sheet 316905027 316905027
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4 Publication No.
5995549093
09/08/13
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
CGEF3031K
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995549093 CGEF3031K
08/09 2
BACKGUARD
13A 14
14
14
54B
54
31
31
54
54B
14
1414
CFGEF3031KBA
56
1
15A
15
19
20A
20
69
31
21
46

CGEF3031K Publication No: 5995549093
# Functional Parts 3 08/09
* Non-Illustrated Parts
BACKGUARD
Model Index: ACGEF3031K (CGEF3031KWA)
BCGEF3031K (CGEF3031KBA)
POS. NO PART NO. DESCRIPTION
1 316557600 A B Shield, rear wall
13A# 316095503 A B Switch, infinite, warmer
14 316022500 A B Light/Lamp, indicator, 125 V
15 316546704 A - Cap, backguard, white, RH end
15 316546702 - B Cap, backguard, black, RH end
15A 316546705 A - Cap, backguard, white, LH end
15A 316546703 - B Cap, backguard, black, LH end
19 316572419 A - Panel, backguard, white
19 316572420 - B Panel, backguard, black
20 # 316418300 A B Clock/Timer, electronic, ES330
20A 316419338 A - Overlay, clock, white, ES330
20A 316419339 - B Overlay, clock, black, ES330
21 316546602 A - Cap, backguard, white, top
21 316546601 - B Cap, backguard, black, top
31 316544206 A - Knob, control, white, (5)
31 316564402 - B Knob, control, black, (5)
46 316557300 A B Lens-light/lamp, indicator, clear
54 316436000 A B Switch, infinite, small element
54B# 316436001 A B Switch, infinite, large element
56 316234012 A - Shield, backguard, white, inner
56 316234013 - B Shield, backguard, black, inner
69 5303288565 A B Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B Screw, 8-18 x 0.5, black
* 316089500 A B Screw, 10-16 x .486

Publication No: 5995549093 CGEF3031K
08/09 4
BODY
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
66
68
10
9
37
8
67
8A
58
6
42
170
3
151
43
VCGEF3031KBA
59
59A
45
25
17
16
15
14
29
44
44
62
6
6A
39

CGEF3031K Publication No: 5995549093
# Functional Parts 5 08/09
* Non-Illustrated Parts
BODY
Model Index: ACGEF3031K (CGEF3031KWA)
BCGEF3031K (CGEF3031KBA)
POS. NO PART NO. DESCRIPTION
1 316401801 A B Panel, main back
3 316400116 A - Panel, bodyside, white, RH
3 316400117 A - Panel, bodyside, white, LH
3 316400118 - B Panel, bodyside, black, RH
3 316400119 - B Panel, bodyside, black, LH
5 316272900 A B Screw, leveling, plastic, rear, (2)
5A 316498900 A B Leveling Leg Assy, metal, front, (2), bracket & leg
6 316496202 A B Rack, oven, (1)
6A 316496206 A B Rack, oven, (1)
8 316400601 A B Panel, oven bottom
8* 316064600 A B Support, oven bottom
8A 316411104 A B Base, bake element
9 316081900 A B Pan, broiler, OPTIONAL ACCESS0RY
10 316082000 A B Insert, broiler pan, OPTIONAL ACCESS0RY
12 # 316445500 A B Switch, oven light, door frame
14 # 316116400 A B Receptacle, oven light
15 # 316538901 A B Lamp, oven light
16 318406100 A B Lens, oven light, glass
17 316087500 A B Retainer, lens
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black
18 # 316405800 A B Latch Assembly, oven door
21 316408000 A B Clip, bodyside
25 316406200 A B Shield, heat, lower
29 316407301 A B Glide, drawer, front
37 # 316490000 A B Probe, oven temp
39 # 318113111 A B Cord, electric
42 316407700 A B Shield, wool, lower
43 3131732 A B Screw, 8-18 x 1.438, oven bottom
44 316517600 A B Spacer, oven door
45 316234100 A B Shield, wire, vent tube
57 316457801 A B Cover, access
58 316403802 A B Insulation, oven sump
58A 316406601 A B Insulation, oven wrapper
58B 316406500 A B Insulation, oven back
59 316208401 A B Vent Tube, assembly, w/catalyst
* 316089500 A B Screw, 10-16 x .486
59A 316208304 A B Tube, oven vent, upper
62 5303935061 A B Terminal Block Kit
62* 316001003 A B Screw, ground wire
62* 316205500 A B Nut, hex flange, 3/8 10-32
66 # 316203301 A B Element, broil
67 # 316413800 A B Element, bake, hidden
68 316404000 A B Support, element, broil
71 316422304 A B Shield, rear wall
86 316537400 A B Receptacle, hinge, (2)
* 316418900 A B Screw, sims lp, #8-32 x 5/16", black
87 316081202 A B Bracket, cable mtg
88 316203500 A B Rod, auto latch
89 # 316464300 A B Motor-latch
151 316404600 A B Shield, bodyside
170 316112004 A B Anti Tip Kit, assembly
170* 316107200 A B Bracket, anti-tip
170* 316116000 A B Screw, concrete, 1.75", anti-tip brkt
170* 316541700 A B Template, anti-tip
* # 316506248 A B Wiring Harness, main
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B Screw, 8-18 x 0.5, black
* 316418901 A B Screw, trilobe, 10-32 x 5/16", black

Publication No: 5995549093 CGEF3031K
08/09 6
TOP/DRAWER
18
18
1
2
4
52
16
26
26B
26
26A
15B
15
15A
15
15C
TFGEF3031KBA
7

CGEF3031K Publication No: 5995549093
# Functional Parts 7 08/09
* Non-Illustrated Parts
TOP/DRAWER
Model Index: ACGEF3031K (CGEF3031KWA)
BCGEF3031K (CGEF3031KBA)
POS. NO PART NO. DESCRIPTION
1 316408703 A B Drawer, utility
2 316403300 A B Liner, drawer
4 316403501 A - Panel, drawer front, white
4 316403502 - B Panel, drawer front, black
7 316407400 A B Glide, drawer, rear
15 # 318198846 A B Element, surface, 6", 1200W, (2), radiant
15A# 316465001 A B Element, surface, 6"/9", 1400/3000W, radiant
15B# 318198827 A B Element, surface, 12", 2700 W
15C# 318198832 A B Element, surface, warmer, 100 W
16 316531966 A - Maintop, steel/glass, white/black
16 316531968 - B Maintop, steel/glass, black
18 316436600 A B Hinge Bracket, maintop, (2)
26 316427600 A B Channel, element support, (2)
26A 316498200 A B Bracket-support, chassis, aluminum
26B 316214202 A B Bracket, chassis support, front
* 316021109 A B Screw, 8-18 x 0.5, chrome
52 316461700 A B Clip, element mtg
52* 5308014215 A B Screw, 6-20 x 0.312
* # 316510672 A B Harness, wiring, surface
* 316468100 A B Cleaner, smoothtop, w/sponge
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B Screw, 8-18 x 0.5, black
* 316089500 A B Screw, 10-16 x .486

Publication No: 5995549093 CGEF3031K
08/09 8
DOOR
60B
10
3
4
52
39
7
6
DLGEF3031KBB
17
17
23
23
16
9
12
8

CGEF3031K Publication No: 5995549093
# Functional Parts 9 08/09
* Non-Illustrated Parts
DOOR
Model Index: ACGEF3031K (CGEF3031KWA)
BCGEF3031K (CGEF3031KBA)
POS. NO PART NO. DESCRIPTION
3 5303935318 A - Trim kit-door, 3 sided, white, w/tape
3 5303935317 - B Trim kit-door, 3 sided, black, w/tape
4 316566406 A - Glass Assembly, outer, white, w/badge
4 316566408 - B Glass Assembly, outer, black, w/badge
6 316406310 A B Shield, wool
7 316405600 A B Insulation, oven door
8 316117500 A B Glass, oven door, heat barrier
9 316423701 A B Liner, oven door
10 316433300 A B Screw, 10-14 x 2.125", handle mtg.
12 316405000 A B Seal, oven door
16 316117501 A B Glass, oven door, inner
17 316402403 A B Spacer, door glass, (2)
23 316537303 A B Hinge, oven door, red, (2)
23* 316418900 A B Screw, sims lp, #8-32 x 5/16", black
39 316544501 A - Handle, door, white
39 316544500 - B Handle, door, black
52 316468400 A - Cap, door trim, white
52 316468401 - B Cap, door trim, black
60B 316021110 A B Screw, 8-18 x 0.5, black
* 316433603 A B Label, anti-tip
* 316021109 A B Screw, 8-18 x 0.5, chrome
