FACTORY PARTS CATALOG
GAS RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FGF376CETK FGF376CETK ALMOND/ALMOND USA
FGF376CETL FGF376CETL ALMOND/ALMOND USA
Publication No.
5995310967
980731
-EN/SERVICE /VLM
369
WIRING DIAGRAM # - 316002165
OWNER’S GUIDE # - 316000251
INSTALLATION GUIDE # - 316102979 GAS - RANGE
FGF376CETK
FGF376CETL

6/98 2
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316021117 A B Screw-8-18X1/2 #5 Head Almond
* # 316001420 A B Harness-wiring,backguard
1 316028701 A B Shield-backguard,rear wall
2 316051600 A B Shield-backguard, inner
2A 316053800 A B Shield-backguard,inner top
3 3131275 A B Lamp-fluorescent,backguard
4 3051222 A B Receptacle-lamp,RH
4A 3051223 A B Receptacle-lamp,LH
5 # 316053200 A B Receptacle-starter
6 # 3206218 A B Starter-lamp
10 # 316099800 A B Ballast-lamp
13A 316095500 A B Switch-warmer,infinite ,drawer/zone
14 316022500 A B Light/Lamp,indicator ,125 V
15 316049104 A B Support-backguard,RH
15A 316049105 A B Support-backguard,LH
18 316026906 A B End Cap,almond ,RH
18A 316026907 A B End Cap,almond ,LH
19 316024535 A B Panel-control,metal
20 # 316080011 A B Clock/Timer,slew
20* 316089308 A B Overlay-clock
21 316024903 A B Trim-canopy/shield,almond
22 316059903 A B Support-receptacle
23 316060002 A B Bracket-clock mtg
24 # 316005608 A B Switch-rocker,oven light ,almond
31A 316095602 A B Knob-warmer,almond ,(2)
36 316109504 A B KNOB-TOP VALVE ALM
40 316086823 A B Panel-manifold
42 316055301 A B Trim-vent
46 316040201 A B Lens-light/lamp,indicator ,red
56 316074907 A B Deflector-flue,black
58 316043400 A B Insulator-ballast,(2)
60 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside
60 5303288574 A B Screw,truss head ,8-10 x 0.375 ,handle
64 316062400 A B Retainer plate

6/98 4
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
BURNER

# - Fast Moving Parts
* - Non Illustrated Parts 5 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2
1 # 316066201 A B Manifold Pipe
2 # 5303935130 A B Valve-top burner
2* 316048200 A B Screw-top valve mtg,hex washer head ,
1/4-20 x 0.31,w/gasket
2A # 5303935132 A B Valve-top burner,large ,(2)
3 # 316103600 A B Switch-ignitor,(4)
4 # 316059612 A B Tube-burner,red ,RF
5 # 316059613 A B Tube-burner,green ,LF
6 # 316059614 A B Tube-burner,nat. ,RR
7 # 316059615 A B Tube-burner,black ,LR
8 # 5303280394 A B Spark Module
8* 5303289034 A B Harness-wiring,module/igniter
10 # 5303935025 A B Burner Assy-top,sealed ,small ,9000 BTU
10A 5303935075 A B Burner Assy-top,sealed ,large ,
1,100 BTU,(2), includes ,
11,37,44,45
11 # 316011200 A B Ignitor-top burner,(4) ,w/mtg bracket
13 # 316065005 A B Tube,aluminum ,rgltr to manf ,
with fittings
14 # 316091706 A B Regulator-pressure
14* 316021104 A B Screw-regulator/brkt,hex ,8-18 x 3/8
15 316091600 A B Bracket-regulator
16 # 316065003 A B Tube-valve to rgltr,3/8
17 # 5303208499 A B Valve-safety,dual
18 # 3131290 A B Burner-oven
19 # 5303935066 A B Ignitor-oven
20 3131284 A B Baffle-oven burner
21 5303013272 A B Nut,hex head sems
22 # 316065002 A B Tube-valve to mixer
23 # 316087900 A B Burner-broiler
24 # 316070400 A B Mixer Elbow
25 5303210379 A B Baffle-broiler
26 # 5308067970 A B Ignitor-broiler
37 316069301 A B Screw-burner mtg
44 5303210090 A B Orifice-top burner,small
44A 316010804 A B Orifice-top burner,large
45 316011100 A B Screw-ignitor mtg,self-tapping ,M3x5.8
46 316074700 A B Plate-burner tube
47 5303307190 A B LP Conversion Kit
BURNER

6/98 6
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 7 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
1 316029412 A B Back-main
2 3131314 A B Shield-oven top
3 316081030 A B Panel-bodyside,almond ,RH
3* 316081031 A B Panel-bodyside,almond ,LH
4 316011914 A B Burner Box
5 5303203397 A B Screw-leveling
5* 3934058 A B Anti-tip Kit
5* 316078600 A B Screw,anti-tip ,(4)
5A 5303288460 A B Nut,T-type ,leveling screw
6 316067902 A B Rack-oven
7 316007002 A B Hinge-oven door,(2)
7* 5303012323 A B Clip,hinge ,(4)
8 5303212540 A B Panel-oven bottom
8* 316064600 A B Support-oven bottom
9 316073800 A B Pan-broiler
10 3205234 A B Insert-broiler pan
12 # 316027701 A B Switch-oven light
13 316026800 A B Rod-light switch /door
14 3014073 A B Socket-light/lamp,oven
15 5303013071 A B Light Bulb/Lamp
16 08011086 A B Lens-light/lamp,glass ,oven
17 316087500 A B Retainer-lens
18 # 316036300 A B Latch-door
21 3014099 A B Spacer-bodyside,(8)
25 316092300 A B Shield-warmer,upper
28 3011813 A B Clip-wire,bodyside
30 316059200 A B Bracket-main top,RH
30A 316059201 A B Bracket-main top,LH
33 316014401 A B Shield,rear wall
35 08067965 A B Gasket-flue
36 5303272844 A B Flue
37 # 316111200 A B Probe-oven temp
38 316051700 A B Shield-heat
38A 316097100 A B Insulator,shield
39 # 3131425 A B Cord-electric power
39* 08067961 A B Fastener-power cord
40 3200836 A B Shield-heat baffle
40* 5303288570 A B Screw-heat shield,hd shldr sqdr, 8-18 X 1/2
41 3131570 A B Cover-hinge cutout
42 5303288578 A B Shield-bake burner
43 3131732 A B Screw-oven bottom,8-18 x 1.438
44 3131903 A B Bumper-door/drawer,rubber
49 3051124 A B Clip-spring mtg
53 5303288579 A B Shield-main front
53A 08067992 A B Shield-insulation
55 316107800 A B Shield-flue
58A 316047705 A B Insulation,oven wrapper
58B 316054200 A B Insulation,oven back
58G 08067973 A B Insulation,main front
60 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside
72 5303285692 A B Cover-light/switch rod

6/98 8
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 9 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
77 316094900 A B Rail-drawer RH,RH, outer
77A 316094901 A B Rail-drawer,lh,outer
88 316026400 A B Rod-latch,auto
89 # 316028103 A B Motor-latch/lock
155 316095201 A B Shield-drawer,front warmer

6/98 10
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 11 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
* 3203618 A B Rivet-pop,warning-plate
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316021113 A B Screw-8-18x1/2 Tr Sqd Almond
* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)
1 316094601 A B Drawer-warmer
4 316056202 A B Panel-drawer,almond
10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2
13 316096500 A B Channel-drawer,rh,inner
13A 316096501 A B Channel drawer,lh,inner
14 3206216 A B Plug-button,glide
16 5303307710 A B Main Top,almond
19 # 316011414 A B Pan-burner,almond ,small ,(2)
19A# 316011418 A B Pan-burner,almond ,large ,(2)
20 # 316085304 A B Grate,(4)
22 # 316098508 A B Cap-burner,small ,gray
22A# 316098509 A B Cap-burner,gloss gray
39 316026107 A B Handle-drawer,almond
44 3131903 A B Bumper-door/drawer,rubber
48 316077401 A B Shield-maintop,(2)
60 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside
60 5303288574 A B Screw,truss head ,8-10 x 0.375 ,handle
77 316094900 A B Rail-drawer RH,RH, outer
80 316109700 A B Seal-door,warmer drawer
81 # 316093100 A B Element,warmer drawer
82 316093200 A B Bracket-mounting,warmer element
83 316093300 A B Shield-terminal,warmer
84 316093500 A B Thermo disc,warmer
85 316093600 A B Rack,warmer drawer
86 316095800 A B Clip-hold down,warmer element
87 316091900 A B Base-warmer
87 316091902 A B Base-warmer

6/98 12
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 13 6/98
Publication number
FGF376CETK, FGF376CETL 599531096
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FGF376CE (FGF376CETK)
B = FGF376CE (FGF376CETL)
POS. NO PART NO DESCRIPTION
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316065301 A B Plate warning/caution
* 5303212671 A - Screw,cr pan hd sems ,8-32BP x 1.00
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2
* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5303285179 A B Screw-oven door,wafer head ,8-32T x 1/2
3 316067803 A B Trim-oven door,almond
4 316089004 A B Glass-oven door,almond ,outer
5 316088700 A B Glass-oven door,inner
6 316088401 A B Shield-wool
7 316076400 A - Insulation,oven door
7 316076403 A B Insulation-door
8 316088600 A B Glass-oven door,airwash
9 316066610 A B Liner-oven door
10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2
12 # 5303131601 A B Seal-oven door
14 3131361 A B Reflector,aluminum foil
14A 3131360 A B Reflector,aluminum foil ,(2)
15 316081401 A - Bracket-glass mtg
15 316081403 - B Bracket-glass mtg
16 316085700 A - Glass-oven door,heat barrier
16 316085701 - B Glass-oven door,heat barrier
39 316091116 A B Handle-door,almond ,oven
39* 316008401 A B Washer,3/4 x 1/4 ,steel ,(2)
52 316081302 A B Shield-oven door,almond ,top

6/98 14
Publication number
599531096 FGF376CETK, FGF376CETL
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
