Frigidaire FEC32S6ABF Instruction Manual

FEC32S6A.eps LA01CP80323-1B.eps MFEC32S6ASF.eps 318046807-1.eps
318046807-2.eps
Product No. FEC32S6ABF FEC32S6ASF
3805432341066 3805433341016
Series 32" elec 32" elec
Color black white
Market North America North America
Wiring Diagram 318046807 318046807
Owner's Guide 318200612 318200612
Installation Instructions 318201426 318201426
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995476891
06/10/17
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
FEC32S6A
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995476891 FEC32S6A
10/06 2
CONTROL PANEL

FEC32S6A Publication No: 5995476891
# Functional Parts 3 10/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEC32S6A (FEC32S6ASF)
BFEC32S6A (FEC32S6ABF)
POS. NO PART NO. DESCRIPTION
16 318096300 A B Plate, instrument mtg
36 318196633 A - Knob, control, white
36 318196634 - B Knob, control, black
51 # 318044820 A - Light, indicator, red
51 # 318044822 - B Light, indicator, clear
54 # 318369609 A B Switch, surface unit, small, single
54A# 318369610 A B Switch, surface unit, large, single
69 5303323134 A B Screw, 8-32 x 0.188
74 318148900 A B Bushing, switch
* 5303300265 A B Screw, 8-18 X 1/2, (2)
* 5303323140 A B Screw, ground, 10-32 x 0.375

Publication No: 5995476891 FEC32S6A
10/06 4
MAIN TOP/SURFACE UNITS

FEC32S6A Publication No: 5995476891
# Functional Parts 5 10/06
* Non-Illustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AFEC32S6A (FEC32S6ASF)
BFEC32S6A (FEC32S6ABF)
POS. NO PART NO. DESCRIPTION
15 # 318198830 A B Element, surface, 6", 1200 W, (2)
15A# 318198834 A B Element, surface, large/8", 2200 W
15B# 318198835 A B Element, surface, 9", 2500 W
16 318079349 A - Main Top Assy, glass/steel, white
16 318079350 - B Main Top Assy, glass/steel, black
20 318121902 A B Bracket, retainer
23 5303297401 A B Panel, service
30 318052604 A B Gasket, glass, 20.25", side, (2)
31 318052605 A B Gasket, glass, 30.25", front/back, (2)
46 318077201 A B Burner Box
52 318122006 A B Spring, element mtg, small
52A 318122007 A B Spring, element mtg, large
52B 318122010 A B Spring, element mtg, 3000W
159 318125101 A B Deflector
162 318125200 A B Deflector
163 318014110 A B Spacer, (6)
164 318125302 A B Plate, connection
* # 318078525 A B Box & wires assy
* # 318199474 A B Harness, wiring, main
* 318231847 A B Harness, wiring, limiter
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303300265 A B Screw, 8-18 X 1/2, (2)
* 5303323129 A B Screw, 8 X 0.750
* 5303323140 A B Screw, ground, 10-32 x 0.375

Publication No: 5995476891 FEC32S6A
10/06 6
WIRING DIAGRAM

FEC32S6A Publication No: 5995476891
# Functional Parts 7 10/06
* Non-Illustrated Parts
WIRING DIAGRAM
