Frigidaire FEF336WH User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF336WHSC FEF336WH white\white USA
Publication No.
5995343281
000912
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEF336WH
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - #316002707
OWNER’S GUIDE - # 316000290
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

01/01 2
Publication No. FEF336WHSC
5995343281
BACKGUARD

# = Fast-moving Parts 3 01/01
* = Non-Illustrated Parts
FEF336WHSC Publication No.
5995343281
BACKGUARD
POS. NO PART NO DESCRIPTION
1 316081600 Shield-backguard,galv steel ,rear wall
2 316015905 Shield-backguard,inner
11 316083721 Trim-wrapper,textured ,white ,w/switch hole
12 # 316032405 Thermostat,oven ,non self-clean
13 # 316032500 Switch-selector
14 316022503 Light/Lamp, indicator , surface ,250 V
15 316023108 Support-backguard,RH
15A 316023109 Support-backguard,LH
19 316100546 Panel-control,backguard ,white
20 # 316120500 Clock-timer
20* 316098008 Overlay-clock,white
23 316033204 Bracket-timer
24 # 316118101 Switch-oven light,rocker ,white
31 316109603 Knob-selector,white
32 316109601 Knob-thermostat,white
36 316025106 Knob-control,infinite sw ,white
40 316025808 Panel-manifold,white
46 316040201 Lens-light/lamp,indicator ,red
54 # 316021500 Switch,infinite , 6" element
54A# 316021501 Switch,infinite , 8" element
69 5303292005 Screw,8-32 x 5/32 ,switch/handle
* 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrme,hinge,ind light,manifold panel
* 316021110 Screw,8-18 x 0.500 ,black

01/01 4
Publication No. FEF336WHSC
5995343281
BODY

# = Fast-moving Parts 5 01/01
* = Non-Illustrated Parts
FEF336WHSC Publication No.
5995343281
BODY
POS. NO PART NO DESCRIPTION
1 316080803 Panel-main back,galv steel ,short
* 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside
3 316081034 Panel-bodyside,white ,RH
3 316081035 Panel-bodyside,white ,LH
5 316129200 Screw-leveling,plastic ,with stop
6 316067902 Rack-oven
7 316007003 Hinge-oven door,assembly
8 3203540 Panel-oven bottom
* 3203550 Plug-button,oven bottom
9 316081900 Pan-broiler
10 316082000 Insert-broiler pan
14 316116400 Socket-light/lamp,oven
15 5303013071 Light Bulb/Lamp
21 3014099 Spacer-bodyside, (8)
27 5303284616 Clip-thermo bulb
29 3051162 Glide-drawer,front
30 5303283574 Bracket-hinge,main top RH
30A 5303283575 Bracket-hinge,main top LH
41 3131570 Cover-hinge cutout
45 316066100 Shield-wire,s/t vent
57 316081100 Cover-access
58 3200847 Insulation,oven bottom
58A 316047707 Insulation, 1" ,oven wrapper
58B 316054202 Insulation, 1" ,oven back
59 316073603 Tube-oven vent
59A 316023600 Tube-oven vent,upper
59B 316040100 Bracket-mounting,vent tube
62 # 5303935061 Terminal Block Kit
63 5301145190 Plate-ground strap
66 # 5303051140 Element-broil,2950 W
67 # 316075103 Element-bake,67
68 316075300 Support-element, broil
71 316015804 Shield-rear wall,galv steel
82 5303289913 Shield-insulation
87 316081200 Bracket-cable mtg
170 5303935180 Anti-tip Kit,w/bracket,screw
170* 316107200 • Bracket,anti-tip
170* 316116000 • Screw,concrete tpg ,1.75 inch ,anti-tip brkt
170* 316112500 • Template, Anti-tip bracket
* 316045000 Clip-wiring harness,retainer ,green ,main top
* 5303308427 Nut,hex ,10-32

01/01 6
Publication No. FEF336WHSC
5995343281
TOP/DRAWER

# = Fast-moving Parts 7 01/01
* = Non-Illustrated Parts
FEF336WHSC Publication No.
5995343281
TOP/DRAWER
POS. NO PART NO DESCRIPTION
1 316011501 Drawer-utility
* 316089600 Spacer-drawer,(2)
2 5303288582 Shield-drawer,liner ,galv steel ,front panel
4 316084405 Panel-drawer front,white
7 3051163 Glide-drawer,rear
15 # 318178100 Element-surface,radiant ,small/6 inch ,1200 W
15A# 318178101 Element-surface,radiant ,large/8 inch ,2100 W
16 316098105 Panel-main top,white ,smooth top assy
18 5303273062 Hinge-main top,RH
18A 5303273063 Hinge-main top,LH
26 316099100 Channel-support,element ,galv steel ,(2)
26A 316099200 Bracket-support,chassis ,galv steel
48 316100200 Shield-wire,main top
51 # 316105100 Light/Lamp,hot surface ind ,assy
52 316099400 Clip-spring, element mtg,(8)
53 316099300 Bracket-indicator light,hot surface ,4 hole
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrme,hinge,ind light,manifold panel
88 316099500 Pin-guide, (2)
* 316045000 Clip-wiring harness,retainer ,green ,main top
* 316112101 Cleaner-cooktop
* 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside
* 316021110 Screw,8-18 x 0.500 ,black
* 316021112 Screw,8-18 x 0.500 ,white
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)
* 5308014215 Screw,6-20 x 0.312

01/01 8
Publication No. FEF336WHSC
5995343281
DOOR

# = Fast-moving Parts 9 01/01
* = Non-Illustrated Parts
FEF336WHSC Publication No.
5995343281
DOOR
POS. NO PART NO DESCRIPTION
5 316050300 Glass-oven door, white , outer
6 316088403 Shield-wool
7 316076401 Insulation,oven door
8 316088600 Glass-oven door,inner
9 316066610 Liner-oven door
10 5303280308 Screw-handle mtg,wafer hd sq dr ,10-24T x 2.00
10* 316008401 Washer,3/4 OD x 1/4 ID ,steel
12 5303202011 Seal-oven door,non self-clean
13 3017081 Panel-oven door,white
20 316133601 Spacer-handle,white ,(2)
22 5303272476 Retainer-glass,angle ,(2)
39 316091115 Handle-door,white ,oven
* 5303292005 Screw,8-32 x 5/32 ,switch/handle
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
* 08068008 Washer,black
* 316021110 Screw,8-18 x 0.500 ,black
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.500 ,burner box
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)

01/01 10
Publication No. FEF336WHSC
5995343281
WIRING DIAGRAM
