Frigidaire FEF355BF User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF355BFDB FEF355BFDB almond USA
FEF355BFDC FEF335BF almond USA
FEF355BFWB FEF355BF white USA
FEF355BFWC FEF355BF white USA
Publication No.
5995309019
980619
-EN/SERVICE /CML
369
ELECTRIC - RANGE
Model No.
FEF355BF
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
WIRING DIAGRAM # -316002622
OWNER’S MANUAL # -316000262
INSTALLATION INSTR. # -316003018
104 Warren Road
Augusta, Georgia 30907-3755

BACKGUARD
Publication No. FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW
5995309019
06/98 2

A = FEF355BF (FEF355BFWB)
B = FEF355BF (FEF355BFWC)
C = FEF355BF (FEF355BFDB)
D = FEF355BF (FEF355BFDC)
POS. NO PART NO DESCRIPTION
* 316003018 A B C D Instructions,installation
* 316021105 A B C D Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316071902 A B C D Gasket-edge
1 316081601 A B C D Shield-backguard,rear wall
2 316015907 A B C D Shield-backguard,inner
11 316083719 A B C D Trim-wrapper,textured ,black
14 316022503 A B C D Light/Lamp,indicator ,yellow ,250 V
15 316023108 A B C D Support-backguard,RH
15A 316023109 A B C D Support-backguard,LH
19 316024494 A B C D Panel-control,metal
20 # 316101001 A B C D Clock/Timer,electronic
20* 316101503 A B C D Overlay-clock
23 316100300 A B C D Bracket-clock mtg
24 # 316005602 A B C D Switch-rocker,oven light ,black
36 316025100 A B C D Knob-control,infinite sw
40 316025800 A B C D Panel-manifold
46 316040201 A B C D Lens-light/lamp,indicator ,red
54 # 316021500 A B C D Switch-6" element,(2)
54A# 316021501 A B C D Switch-8" element,(2)
69 5303292005 A B C D Screw-switch mtg,8-32 x 5/32
BACKGUARD
FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW Publication No.
5995309019
# = Functional Part 3 06/98
* = Non-Illustrated Part

BODY
Publication No. FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW
5995309019
06/98 4

A = FEF355BF (FEF355BFWB)
B = FEF355BF (FEF355BFWC)
C = FEF355BF (FEF355BFDB)
D = FEF355BF (FEF355BFDC)
POS. NO PART NO DESCRIPTION
* 3203550 A B C D Plug-button
* 316021105 A B C D Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 5303051099 A B C D Nut,hex ,#10-32
1 316080804 A B C D Back-main, short,dipped ,black
3 316081028 A B - - Panel-bodyside,white ,RH
3 316081030 - - C D Panel-bodyside,almond ,RH
3* 316081029 A B - - Panel-bodyside,white ,LH
3* 316081031 - - C D Panel-bodyside,almond ,LH
4 5303271756 A B C D Burner Box
5 5303203397 A B C D Screw-leveling
5* 3934058 A B C D Anti-tip Kit
5* 316078600 A B C D Screw,anti-tip ,(4)
5A 5303288460 A B C D Nut,T-type ,leveling screw
6 316067902 A B C D Rack-oven
7 316007002 A B C D Hinge-oven door,(2)
8 3203540 A B C D Panel-oven bottom
9 316073800 A B C D Pan-broiler
10 3205234 A B C D Insert-broiler pan
12 # 316027701 A B C D Switch-oven light
13 316026800 A B C D Rod-light switch /door
14 3014073 A B C D Socket-light/lamp,oven
15 5303013071 A B C D Light Bulb/Lamp
16 08011086 A B C D Lens-light/lamp,glass ,oven
17 316087500 A B C D Retainer-lens
18 # 316036300 A B C D Latch-door
21 3014099 A B C D Spacer-bodyside,(8)
25 3200848 A B C D Shield-heat,lower
29 3051162 A B C D Glide-drawer,front
30 5303283574 A B C D Bracket-hinge,main top RH
30A 5303283575 A B C D Bracket-hinge,main top LH
37 # 316111200 A B C D Probe-oven temp
41 3131570 A B C D Cover-hinge cutout
44 3131903 A B C D Bumper-door/drawer,rubber
57 316081101 A B C D Cover-access
58 3200847 A B C D Insulation,oven bottom
58A 316047708 A B C D Insulation,oven wrapper
58B 316054200 A B C D Insulation,oven back
58C 3131304 A B C D Insulation,oven top
59 316073600 A B C D Tube-oven vent
62 # 5303935061 A B C D Terminal Block
63 5301145190 A B C D Plate-ground strap
66 # 5303051140 A B C D Element-broil
67 # 316075102 A B C D Element-bake,lower oven
68 316075300 A B C D Support-element
71 316015805 A B C D Shield-rear wall
72 5303285692 A B C D Cover-light/switch rod
82 5303289913 A B C D Shield-insulation
87 316081200 A B C D Bracket-cable mtg
88 316026400 A B C D Rod-latch,auto
89 # 316028101 A B C D Motor-latch/lock
BODY
FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW Publication No.
5995309019
# = Functional Part 5 06/98
* = Non-Illustrated Part

TOP/DRAWER
Publication No. FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW
5995309019
06/98 6

A = FEF355BF (FEF355BFWB)
B = FEF355BF (FEF355BFWC)
C = FEF355BF (FEF355BFDB)
D = FEF355BF (FEF355BFDC)
POS. NO PART NO DESCRIPTION
* 3203618 A B C D Rivet-pop,warning-plate
* 316001725 A B C D Harness-wiring,surface element
* 316021105 A B C D Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316021112 A B - - Screw-8-18x1/2 Tr Sqd White
* 316021113 - - C D Screw-8-18x1/2 Tr Sqd Almond
* 316058601 A B C D Clip-surface element,(4)
* 316089600 A B C D Spacer-drawer,(2)
* 5303280311 A B C D Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5308014215 A B C D Screw,#6-20 x 5/16 ,(4)
1 316011501 A B C D Drawer-utility
2 3131975 A B C D Shield-panel
4 316084405 A B - - Panel-drawer,white
4 316084406 - - C D Panel-drawer,almond
4* 08067785 - - C D Screw,hex washer head ,8-18AB x 1/2
7 3051163 A B C D Glide-drawer,rear
15 # 316048600 A B C D Element-surface,large/8 inch
15A# 316048500 A B C D Element-surface,small/6 inch
16 316020907 A B - - Main Top,white
16 316020908 - - C D Main Top,almond
17 316057601 A B C D Rod-maintop support
17* 316089500 A B C D Screw,10-16X.486
18 5303273062 A B C D Hinge-main top,RH
18A 5303273063 A B C D Hinge-main top,LH
19 # 5303935053 A B C D Pan-surface element,large/8 inch ,(2)
19A# 5303935055 A B C D Pan-surface element,small/6 inch ,(2)
27 # 5303912666 A B C D Terminal Block Kit,surface element
28 5303017715 A B C D Medallion,1 1/2"dia ,black ,
surface element
28 5303296595 A B C D Medallion,3/4"dia ,surface element
44 3131903 A B C D Bumper-door/drawer,rubber
TOP/DRAWER
FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW Publication No.
5995309019
# = Functional Part 7 06/98
* = Non-Illustrated Part

DOOR
Publication No. FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW
5995309019
06/98 8

A = FEF355BF (FEF355BFWB)
B = FEF355BF (FEF355BFWC)
C = FEF355BF (FEF355BFDB)
D = FEF355BF (FEF355BFDC)
POS. NO PART NO DESCRIPTION
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316065301 A B C D Plate warning/caution
* 5303212671 A - C - Screw,cr pan hd sems ,8-32BP x 1.00
* 5303212762 - - C D Screw,8-18 X 1/2
* 5303280311 A B C D Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5303285179 A B C D Screw-oven door,wafer head ,8-32T x 1/2
3 316067802 A B C D Trim-oven door,black
4 316089000 A B C D Glass-oven door,black ,outer
5 316088700 A B C D Glass-oven door,inner
6 316088401 A B C D Shield-wool
7 316076403 A B C D Insulation-door
8 316088600 A B C D Glass-oven door,airwash
9 316066610 A B C D Liner-oven door
10 5303280308 A B C D Screw-handle mtg,wafer head ,10-24T x 2
12 # 5303131601 A B C D Seal-oven door
14 5303208656 A B C D Reflector,aluminum foil
14A 5303208655 A B C D Reflector,aluminum foil ,(2)
15 316081401 A - C - Bracket-glass mtg
15 316081403 - B - D Bracket-glass mtg
16 316085700 A - C - Glass-oven door,heat barrier
16 316085701 - B - D Glass-oven door,heat barrier
39 316091114 A B C D Handle-door,black ,oven
39* 316008401 A B C D Washer,3/4 x 1/4 ,steel ,(2)
52 316081303 A B C D Shield-oven door,black ,top
DOOR
FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW Publication No.
5995309019
# = Functional Part 9 06/98
* = Non-Illustrated Part

WIRING DIAGRAM
Publication No. FEF355BFWB,FEF355BFWC,FEF355BFDB,FEF355BFDW
5995309019
06/98 10
