Frigidaire FEFB55CH User manual

.
PRODUCT NO. FACTORY NO. COLOR MARKET
FEFB55CHSA 38354335C9011 WHITE U.S.A.
Publication No.
5995321436
990421
-EN/SERVICE/MG
377
ELECTRIC - RANGE
Model No.
FEFB55CH
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
WIRING DIAGRAM # -318045259
OWNERS GUIDE #-318200407
INSTALLATION INSTRUCTION #-318154300
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA L5T1K6
TEL :[phone]

04/99 2
Publication No. FEFB55CH
5995321436 BACKGUARD
46
46
93
24
18
36
36
32
21
18A
LA9923CG47
54
54
54
54
86
19
16
64
69
14
14
20
98

# = Functional Part 304/99
* = Non-Illustrated Part
FEFB55CH Publication No.
5995321436
POS. NO PART NO. DESCRIPTION
14 3200297 ALight-indicator
16 318117426 APlate, instrument mtg
18 318118300 AEnd Cap,white ,RH
18A 318118301 AEnd Cap,white ,LH
19 318117181 APanel-control metal
20 # 318013054 AElectronic timer
21 318118000 ATrim-canopy white
24# 316005607 ASwitch-oven light, rocker type
32 316101401 AKnob-thermostat white
36 318017110 AKnob-control
46 5303297274 ALens-light
54 # 318120500 ASwitch-surface unit
64 318112200 ASpacer rocker switch
69 5303305528 AScrew,switch mtg. ,8-32 x 3/16
86 318111201 APlate-connecting
93# 3202388 ASwtich-thermal/ Interrupteur
98 318092405 A Wiring harness
*08016432 AScrew truss head, 8-18 x 3/8
*5303310510 AScrew 10-24 x 5/8
*5303320848 A Screw, 6-20 X 1/4
*3201885 ANut
*5303323134 AScrew, 8-32 X 3/16
BACKGUARD
A= FEFB55CH (FEFB55CHSA)

04/99 4
Publication No. FEFB55CH
5995321436 BODY
4
59
3
3
74
170
170A
14
54 15
67
66
10
9
6
25
166
166
165
183
5
76
182
86 86
83
1
57
71
58A
58B
80
68
127
30
30
88
LA9923CV13
141
171
62
62
63
184
162
163 12
11
99
16
17
37
129
128
89

# = Functional Part 504/99
* = Non-Illustrated Part
FEFB55CH Publication No.
5995321436
POS. NO PART NO DESCRIPTION
1 318108100 ABack-main
3 318025601 APanel-bodyside,white
4318073801 ABurner box
5 318175500 AScrew leveling
6 5303310522 ARack-oven
9 5303317977 APan-broiler
10 5303317976 AInsert-broiler pan
11 318086100 ABracket-light switch
12 # 318089800 ASwitch-door
14 5308011085 ASocket-light/lamp
15 3201908 ALamp-oven light
16 3201911 AGlass-oven light lens
17 5304400195 ARetainer lens
25 318108700 AShield-heat lower
30 318110800 ABracket-hinge, main top
37 # 316111203 AProbe-oven temp
54 5303310514 AHousing-oven light
57 318036500 ACover-access
58A 5303324419 AInsulation,oven wrapper
58B 5303324420 AInsulation,oven back
59 318072517 ATube oven vent
62 # 5303310518 ATerminal Block
63 5303310517 APlate-ground strap
66 # 5303310513 AElement-broil
67 # 5303310512 AElement-bake
68 5304403015 ASupport-element
71 318086600 AShield wire
74 318141900 ABumper bodyside
76 318108502 AFrame-front, wheels incl
80 5303324473 ABracket-oven
83 318109405 ALiner-oven assy
86 5303310524 AChannel-hinge
88 318118902 ARod-latch
89 # 318095900 AMotor-latch assy
89* 318120702 ASwitch latch
89* 318120704 ASwitch latch
99 318126101 ASupport side
127 5303310542 AAdapter assy
128 5303311163 ABushing
129 5303311164 ASpring
141# 5303302280 AThermostat-safety
162 318096401 AConnection box
163 318135802 ACover connection box
165 318003100 AShield-plate
166 318111000 ABracket-bearing
170 3203575 AAnti-tip bracket
170A 3203576 AAnti-tip bracket
171 318111202 APlate-connecting
182 316042300 APlate-warning
183 5303323140 AScrew ground
184 3201885 ANut
*5303211311 AScrew, #8 x ½
*5303307980 AScrew, 8-32 x 7/16
* 5303131801 AScrew,10 x 3/8
*5303308449 A Fastener
*5303311528 AScrew, 6-20 x 5/8
*5303323129 AScrew, 8 X ¾
*5303323133 AScrew, 8-18 X ½
*5303323139 AScrew, 10-24 X 29/32
*5303323144 ANut (10-32)
*5303325980 AScrew, 10-32 X 0.437
*5304400427 AScrew, 6-20 X ½
BODY
A= FEFB55CH (FEFB55CHSA)

04/99 6
Publication No. FEFB55CH
5995321436 TOP/DRAWER
17
16
19A
3
15A
28
28 27
27
27
27
93
93
93
93 28
28
15
15A
15
19
19A
19
18
18
1
LA9923CT02
4
11
11
13
7
13A
7

# = Functional Part 704/99
* = Non-Illustrated Part
FEFB55CH Publication No.
5995321436
POS. NO PART NO DESCRIPTION
1 318107103 ADrawer-utility
3 318144320 ASupport,main top
4 318044301 APanel-drawer,white
7318014800 ASpacer
11 318107500 ABracket-support,drawer
13 318018100 AChannel-drawer,RH
13A 318018101 AChannel-drawer,LH
15 # 318112300 AElement-surface,2400W
15A# 5303309000 AElement-surface, 1500W
16 318065731 AMaintop, white
17 318119100 ARod-maintop support
18 318074400 AHinge-main top,
19 318067020 APan-burner
19A 318067021 APan-burner
27# 5303323704 ATerminal block
28 5303309002 AMedaillon surface element
93 318122501 ABracket-terminal block
*5303211311 AScrew, #8 X 1/2
*5303300265 AScrew, 8-18 X ½ chrome
*5304400428 AScrew, 8-15 X 1/8
*5303324512 AScrew, 6-32 X 5/16
*5304400428 AShoulder screw, 8-15 X 1/8
TOP/DRAWER
A= FEFB55CH (FEFB55CHSA)

04/99 8
Publication No. FEFB55CH
5995321436 DOOR
39
20
20
3
23
17
16
23
9
6
3A
3B
54
54
54
1
42
18
12
4
10
LAP23CD015
29
29
31
16
7

# = Functional Part 904/99
* = Non-Illustrated Part
FEFB55CH Publication No.
5995321436
POS. NO PART NO
DESCRIPTION
1 318043100 ABracket-trim, handle
3 318049206 ATrim-oven, white
3A 318028900 ATrim-oven door,upper
3B 318049020 ATrim-oven door,white ,upper
4318041110 AGlass-oven door,white outer
6 318056802 AShield-wool
7 318106001 AInsulation-door
9 318048802 ALiner-oven door
10 5303324305 AScrew,10-24 x 5/8
12 318053103 ASeal-oven door
16 318041603 AGlass-oven door, heat barrier
17 318042102 ASpacer-glass
18 318053001 ASeal-rope
20 318014301 ASpacer-handle, white
23 5303311215 AHinge
29 5303310535 ABumper door
31 5303310536 ALatch-door
39 316091119 AHandle-door, white
42 5303311194 ATrim-oven door, white, lower
54 5303317175 AScrew,8-18 X 1/2 ,white
* 5303211311 AScrew,#8 x 1/2
* 5303307980 AScrew,8-32 x 7/16
*08016432 AScrew truss head 8-18 x 3/8
*3201899 AWasher hinge assy
DOOR
A= FEFB55CH (FEFB55CHSA)

04/99 10
Publication No. FEFB55CH
5995321436 WIRING DIAGRAM
