Frigidaire FEF362BXA User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF362BXAWA FEF362BXA black/white North America
Publication No.
5995373965
020610
-EN/SERVICE /ECL
369

06/02 2
BACKGUARD

FEF362BXAWA Publication No.
5995373965
POS. NO PART NO DESCRIPTION
1 316239900 Shield,backguard ,rear wall
11 316241000 Shield,end cap ,RH
11A 316241001 Shield,end cap ,LH
14 316022500 Light/Lamp,warmer,indicator ,drawer/zone,125 V
15 316220216 Support,backguard ,black ,RH
15A 316220217 Support,backguard ,black ,LH
18 316240904 End Cap,black ,RH
18A 316240905 End Cap,black ,LH
19 316244496 Panel,backguard ,black
20 # 316207502 Clock/Timer,electronic
20A 316220805 Overlay,clock ,black
24 # 316246001 Switch,rocker ,black ,oven light
31 316223002 Knob,black
46 316040201 Lens,indicator light ,red
54 # 316021500 Switch,infinite ,small element
54A# 316021501 Switch,infinite ,large element
56 316234003 Shield,backguard ,black ,inner
69 5303288565 Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
BACKGUARD

06/02 4
BODY

FEF362BXAWA Publication No.
5995373965
POS. NO PART NO DESCRIPTION
1 316201300 Back,main
3 316230102 Panel,bodyside ,white ,RH
3 316230103 Panel,bodyside ,white ,LH
5 316129200 Screw,leveling ,plastic ,with stop
6 316067902 Rack,oven
7 316212906 Hinge,oven door ,RH
7A 316212907 Hinge,oven door ,LH
8 3203540 Panel,oven bottom
9 316081900 Pan,broiler
10 316082000 Insert,broiler pan
12 # 316027701 Switch,oven light
13 316238800 Rod,light switch
14 # 316116400 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
16 08011086 Lens,oven light ,glass
17 316087500 Retainer,lens
18 # 316213900 Latch,oven door
21 3014099 Spacer,bodyside
25 3200848 Shield,heat ,lower
26 316206300 Support,chassis ,(2)
29 3051162 Glide,drawer ,front
30 5303283574 Bracket,hinge ,main top RH
30A 5303283575 Bracket,hinge ,main top LH
37 # 316233900 Probe,oven temp
41 316233400 Cover,hinge cutout ,RH
41A 316233500 Cover,hinge cutout ,LH
42 316206200 Shield,wool ,lower
44 316246500 Spacer,oven door
45 316234100 Shield,wire ,vent tube
57 316081100 Cover,access
58 3200847 Insulation,oven bottom
58A 316047708 Insulation,2" ,oven wrapper
58B 316240100 Insulation,oven back
59 316208200 Tube,oven vent ,lower
59A 316208300 Tube,oven vent ,upper
59B 316247300 Catalyst,oven vent ,ceramic
62 # 5303935061 Terminal Block Kit
62* 316085600 Insulator
62* 316205500 Nut,hex flange ,3/8 10-32
63 5301145190 Plate,grounding strap
66 # 316203200 Element,broil
67 # 316075103 Element,bake
68 316203400 Support,broil element
71 316015810 Shield,rear wall ,galv steel
72 316234500 Cover,rod end ,light switch
87 316081200 Bracket,cable mtg
88 316203500 Rod,auto latch
89 # 316135202 Motor,latch/lock
89A 316245800 Bracket,latch ,rear
170 5303935180 Anti-tip Kit,w/bracket,screw
170* 316107200 Bracket,anti-tip
170* 316112500 Template,anti-tip
170* 316116000 Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253232 Wiring Harness,main
* 3203550 Plug,button ,oven bottom
* 5303305324 Paint,touch-up ,white
* 5303305345 Paint,touch-up ,black
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021123 Screw,8-18 X 3/8-8 ,TRUSS HD BLACK
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 Screw,6-20 x 0.312
BODY

06/02 6
TOP/DRAWER

FEF362BXAWA Publication No.
5995373965
POS. NO PART NO DESCRIPTION
1 316011503 Drawer
2 316231500 Liner,drawer
4 316231305 Panel,drawer ,white
7 3051163 Glide,drawer ,rear
15 # 316010206 Element,surface ,8" ,2200 W ,radiant
15A# 316010205 Element,surface ,6" ,1200 W ,radiant
16 316098183 Main Top,white
18 316235900 Hinge,main top ,RH
18A 316235901 Hinge,main top ,LH
26 316099100 Channel,element support ,galv steel ,(2)
26A 316099200 Bracket,chassis support ,rear
26B 316264200 Bracket,chassis support ,front
52 316099400 Clip,element mtg
88 316099500 Pin,guide ,(2)
* # 316253523 Wiring Harness,surface element
* 316264000 Cleaner,cooktop
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 Screw,6-20 x 0.312
TOP/DRAWER

06/02 8
DOOR

FEF362BXAWA Publication No.
5995373965
POS. NO PART NO DESCRIPTION
3 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil
4 5303935203 Glass,door kit ,black ,outer ,w/foil tape
5 316088700 Glass,oven door ,airwash
6 316222706 Shield,wool ,oven door
7 316236800 Insulation,oven door
8 316088600 Glass,oven door ,inner
9 316230604 Liner,oven door
10 316001014 Screw,waf hd sq ,10-24 x 1.6 ,handle ,(2)
10B 316008401 Washer,3/4 OD x 1/4 ID ,steel
12 316230900 Seal,oven door
14 316102208 Foil,1.5" x 29" ,aluminum ,black
14A 5303208655 Reflector,aluminum foil ,black door
15 316081403 Bracket,glass mtg
16 316085701 Glass,oven door ,heat barrier
20 316248400 Spacer,handle ,black ,(2)
39 316248300 Handle,oven door ,black
52 316201005 Cap,door trim ,black
60B 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 316065306 Plate,warning/caution
* 3203618 Rivet,pop
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
DOOR

06/02 10
WIRING DIAGRAM
