Frigidaire FEF366C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
FEF366CBA FEF366C 30" f/s elec black North America
FEF366CQA FEF366C 30" f/s elec bisque North America
FEF366CSA FEF366C 30" f/s elec white North America
Publication No.
5995389581
030429
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEF366C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERVICE DATA SHEET - # 316218506
WIRING DIAGRAM - #316255173
OWNER’S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200

04/03 2
Publication No. FEF366C
5995389581
BACKGUARD

# = Fast-moving Parts 3 04/03
* = Non-Illustrated Parts
FEF366C Publication No.
5995389581
A = FEF366C (FEF366CSA)
B = FEF366C (FEF366CBA)
C = FEF366C (FEF366CQA)
POS. NO PART NO DESCRIPTION
1 316239900 A B C Shield,backguard ,rear wall
14 316022500 A B C Light/Lamp,indicator ,125 V
15 316220214 A - - Support,backguard ,white ,RH
15 316220216 - B - Support,backguard ,black ,RH
15 316220218 - - C Support,backguard ,bisque ,RH
15A 316220215 A - - Support,backguard ,white ,LH
15A 316220217 - B - Support,backguard ,black ,LH
15A 316220219 - - C Support,backguard ,bisque ,LH
19 316233859 A - - Panel,backguard ,white
19 316233860 - B - Panel,backguard ,black
19 316233861 - - C Panel,backguard ,bisque
20 # 316207502 A B C Clock/Timer,electronic ,ES300
20A 316220804 A - - Overlay,clock ,white
20A 316220805 - B - Overlay,clock ,black
20A 316220806 - - C Overlay,clock ,bisque
23 316220900 A B C Bracket,clock mtg
24 316246000 A - - Switch,rocker ,white ,oven light
24 # 316246001 - B - Switch,rocker ,black ,oven light
24 316246002 - - C Switch,rocker ,bisque ,oven light
31 316223000 A - - Knob,control ,white
31 316223002 - B - Knob,black
31 316223003 - - C Knob,control ,bisque
46 316040201 A B C Lens,indicator light ,red
54 # 316021500 A B C Switch,infinite ,small element
54A# 316021501 A B C Switch,infinite ,large element
56 316234001 A - - Shield,backguard ,white ,inner
56 316234003 - B - Shield,backguard ,black ,inner
56 316234004 - - C Shield,backguard ,bisque ,inner
69 5303288565 A B C Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
BACKGUARD

04/03 4
Publication No. FEF366C
5995389581
BODY

# = Fast-moving Parts 5 04/03
* = Non-Illustrated Parts
FEF366C Publication No.
5995389581
A = FEF366C (FEF366CSA)
B = FEF366C (FEF366CBA)
C = FEF366C (FEF366CQA)
POS. NO PART NO DESCRIPTION
1 316201300 A B C Back,main
3 316216402 A - - Panel,bodyside ,white ,RH
3 316216403 A - - Panel,bodyside ,white ,LH
3 316216404 - B - Panel,bodyside ,black ,RH
3 316216405 - B - Panel,bodyside ,black ,LH
3 316216406 - - C Panel,bodyside ,bisque ,RH
3 316216407 - - C Panel,bodyside ,bisque ,LH
3* 316021131 A - C Screw,bodyside ,8-18 X 11/16 ,white
3* 316021132 - B - Screw,bodyside ,8-18 X 11/16 ,black
5 316129200 A B C Screw,leveling ,plastic ,with stop
6 316067902 A B C Rack,oven
6A 316262900 A B C Rack,oven sump
7 316216500 A B C Hinge,oven door ,RH
7A 316216501 A B C Hinge,oven door ,LH
8 316201501 A B C Panel,sump ,oven bottom
9 316081900 A B C Pan,broiler
10 316082000 A B C Insert,broiler pan
12 # 316209901 A B C Switch,oven light/door
14 316116400 A B C Receptacle,oven light
15 5303013071 A B C Bulb/Lamp,oven light
16 08011086 A B C Lens,oven light ,glass
17 316087500 A B C Retainer,lens
18 # 316213900 A B C Latch,oven door
21 3014099 A B C Spacer,bodyside
25 3200848 A B C Shield,heat ,lower
26 316206300 A B C Support,chassis ,(2)
29 3051162 A B C Glide,drawer ,front
30 316217700 A B C Bracket,hinge ,RH ,main top
30A 316217701 A B C Bracket,hinge ,LH ,main top
37 # 316233900 A B C Probe,oven temp
41 316233400 A B C Cover,hinge cutout ,RH
41A 316233500 A B C Cover,hinge cutout ,LH
42 316206200 A B C Shield,wool ,lower
44 316246500 A B C Spacer,oven door
45 316234100 A B C Shield,wire ,vent tube
57 316081100 A B C Cover,access
58 316240300 A B C Insulation,oven bottom
58A 316047708 A B C Insulation,2" ,oven wrapper
58B 316240100 A B C Insulation,oven back
58C 316240400 A B C Insulation,oven sump
59 316208200 A B C Tube,oven vent ,lower
59A 316208302 A B C Tube,oven vent ,upper
59B 316247300 A B C Catalyst,oven vent ,ceramic
62 # 5303935061 A B C Terminal Block Kit
62* 316085600 A B C Insulator
62* 316205500 A B C Nut,hex flange ,3/8 10-32
63 316208500 A B C Plate,grounding strap
66 # 316203200 A B C Element,broil
67 # 316225000 A B C Element,bake
68 316203400 A B C Support,broil element
71 316015810 A B C Shield,rear wall ,galv steel
87 316081200 A B C Bracket,cable mtg
88 316203500 A B C Rod,auto latch
89 # 316137500 A B C Motor,latch
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template,anti-tip
170* 316116000 A B C Screw,concrete ,1.75" ,anti-tip brkt
* # 316253252 A B C Wiring Harness,main
* 5303305324 A - - Paint,touch-up ,white
* 5303305345 - B - Paint,touch-up ,black
* 5304414035 - - C Paint,touch-up ,bisque
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
BODY

04/03 6
Publication No. FEF366C
5995389581
TOP/DRAWER

# = Fast-moving Parts 7 04/03
* = Non-Illustrated Parts
FEF366C Publication No.
5995389581
A = FEF366C (FEF366CSA)
B = FEF366C (FEF366CBA)
C = FEF366C (FEF366CQA)
POS. NO PART NO DESCRIPTION
1 316011503 A B C Drawer
2 316231500 A B C Liner,drawer
4 316231305 A - - Panel,drawer ,white
4 316231306 - B - Panel,drawer ,black
4 316231309 - - C Panel,drawer ,bisque
7 3051163 A B C Glide,drawer ,rear
15 # 316010205 A B C Element,surface ,6" ,1200 W ,radiant
15A# 316010206 A B C Element,surface ,8" ,2200 W ,radiant
15B# 316224200 A B C Element,surface ,9" ,2500W ,radiant
16 316251942 A - - Main Top Assy,glass/steel ,white
16 316251903 - B - Main Top Assy,glass/steel ,black
16 316251943 - - C Main Top Assy,glass/steel ,bisque
18 316235900 A B C Hinge,main top ,RH
18A 316235901 A B C Hinge,main top ,LH
26 316230201 A B C Channel,element support ,(2)
26A 316099200 A B C Bracket,chassis support ,rear
26B 316214200 A B C Bracket,chassis support ,front
52 316099400 A B C Clip,element mtg
* # 316253518 A B C Wiring Harness,surface element
* 316264000 A B C Cleaner,cooktop
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 A B C Screw,6-20 x 0.312
TOP/DRAWER

04/03 8
Publication No. FEF366C
5995389581
DOOR

# = Fast-moving Parts 9 04/03
* = Non-Illustrated Parts
FEF366C Publication No.
5995389581
A = FEF366C (FEF366CSA)
B = FEF366C (FEF366CBA)
C = FEF366C (FEF366CQA)
POS. NO PART NO DESCRIPTION
3 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935191 - B - Trim kit-door,3 sided ,black ,w/tape and foil
3 5303935193 - - C Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - - Glass,door kit ,white ,outer ,w/foil tape
4 5303935200 - B - Glass,door kit ,black ,outer ,w/foil tape
4 5303935202 - - C Glass,door kit ,bisque ,outer ,w/foil tape
5 316237000 A B C Glass,oven door ,air wash
6 316222707 A B C Shield,wool ,oven door
7 316236700 A B C Insulation,oven door
8 316237100 A B C Glass,oven door ,clear ,heat barrier
9 316230605 A B C Liner,oven door
10 316001013 A B C Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10B 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 316230901 A B C Seal,oven door
14 316102207 A - C Foil,1.5" x 29" ,aluminum ,clear
14 316102208 - B - Foil,1.5" x 29" ,aluminum ,black
14A 316102202 A - C Foil,4" x 5.5" ,aluminum ,clear ,(2)
14A 316102205 - B - Foil,4" x 5.5" ,aluminum ,black ,(2)
15 316237201 A B C Bracket,glass support ,(2)
16 316117501 A B C Glass,oven door ,inner
17 316117701 A B C Spacer,door glass ,(2)
39 316203001 A - - Handle,door ,white
39 316203000 - B - Handle,door ,black
39 316203003 - - C Handle,door ,bisque
52 316201003 A - - Cap,door trim ,white
52 316201005 - B - Cap,door trim ,black
52 316201009 - - C Cap,door trim ,bisque
60B 316021110 A B C Screw,8-18 x 0.5 ,black
* 316221001 A B C Label,anti-tip
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
DOOR

04/03 10
Publication No. FEF366C
5995389581
WIRING SCHEMATIC

# = Fast-moving Parts 11 04/03
* = Non-Illustrated Parts
FEF366C Publication No.
5995389581
WIRING DIAGRAM
