Frigidaire FEF369CG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
FEF369CGSE FEF369CG Frigidaire white/white USA
FEF369CGTE FEF369CG Frigidaire almond/almond USA
Publication No.
5995345377
001020
-EN/SERVICE/KHB
369
ELECTRIC
RANGE
Model No.
FEF369CG
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - #316002714
OWNER’S GUIDE - # 316135911
SERVICE DATA SHEET - # 316097866
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

01/01 2
Publication No. FEF369CG
5995345377
BACKGUARD

# = Fast-moving Parts 3 01/01
* = Non-Illustrated Parts
FEF369CG Publication No.
5995345377
BACKGUARD
A = FEF369CG (FEF369CGSE)
B = FEF369CG (FEF369CGTE)
POS. NO PART NO DESCRIPTION
1 316081600 A B Shield-backguard,galv steel ,rear wall
2 316015905 A B Shield-backguard,inner
11 316083721 A - Trim-wrapper, textured, white, w/switch hole
11 316083720 - B Trim-wrapper ele w/hole,almond
13A# 316095500 A B Switch-warmer, infinite , drawer/zone
14 316022503 A B Light/Lamp, indicator , surface ,250 V
14A 316022500 A B Light/Lamp, warmer, indicator, drawer/zone, 125 V
15 316023108 A B Support-backguard,RH
15A 316023109 A B Support-backguard,LH
19 316100541 A - Panel-Bkgd, white
19 316100542 - B Panel-Bkgd, almond
20 316131605 A B Clock/Timer,electronic
20* 316101502 A - Overlay-clock,white
20* 316101504 - B Overlay-clock,almond
23 316100301 A B Bracket-timer
24 # 316118101 A - Switch-oven light,rocker ,white
24 # 316118102 - B Switch-oven light,rocker ,almond
24B# 316086901 A - Switch-rocker,dual element ,white
24B# 316086902 - B Switch-rocker,dual element ,almond
24C# 316114000 A - Switch-Speed Bake,white
24C# 316114001 - B Switch-Speed Bake, almond
31A 316095601 A - Knob-warmer,white
31A 316095602 - B Knob-warmer,almond
36 316025106 A - Knob-control,infinite sw ,white
36 316025107 - B Knob-control,infinite sw ,almond ,(4)
40 316025808 A - Panel-manifold,white
40 316025809 - B Panel-manifold,almond
46 316040201 A B Lens-light/lamp,indicator ,red
54 # 316021500 A B Switch,infinite , 6" element
54A# 316021501 A B Switch,infinite , 8" element
54B# 316049800 A B Switch, infinite , dual element
69 5303292005 A B Screw,8-32 x 5/32 ,switch/handle
* 316021105 A B Screw,hex head cup pt,8-18 x 0.375,blk, back/bodyside
* 316021108 A B Screw,cup pt,8-18 x 0.375,chrom, hing,ind lgt,manifld pnl
* 316021110 A B Screw,8-18 x 0.500 ,black
* # 316001759 A B Wiring Harness,surface element
* 316085600 A B Insulator

01/01 4
Publication No. FEF369CG
5995345377
BODY

# = Fast-moving Parts 5 01/01
* = Non-Illustrated Parts
FEF369CG Publication No.
5995345377
A = FEF369CG (FEF369CGSE)
B = FEF369CG (FEF369CGTE)
POS. NO PART NO DESCRIPTION
1 316080803 A B Panel-main back,galv steel ,short
3 316081034 A - Panel-bodyside,white ,RH
3 316081035 A - Panel-bodyside,white ,LH
3 316081036 - B Panel-bodyside,almond ,RH
3 316081037 - B Panel-bodyside,almond ,LH
5 316129200 A B Screw-leveling,plastic ,with stop
6 316067902 A B Rack-oven
7 316007002 A B Hinge-oven door,(2)
8 3203540 A B Panel-oven bottom
9 316081900 A B Pan-broiler
10 316082000 A B Insert-broiler pan
12 # 316027701 A B Switch-oven light
13 316026800 A B Rod-light switch /door
14 316116400 A B Socket-light/lamp,oven
15 5303013071 A B Light Bulb/Lamp
16 08011086 A B Lens-light/lamp, glass , oven
17 316087500 A B Retainer-lens
18 # 316036300 A B Latch-door
21 3014099 A B Spacer-bodyside, (8)
25 3200848 A B Shield-heat,lower
29 3051162 A B Glide-drawer,front
37 # 316134900 A B Probe-oven temp
41 3131570 A B Cover-hinge cutout
44 3131903 A B Bumper-door/drawer, rubber
45 316066100 A B Shield-wire,s/t vent
57 316081100 A B Cover-access
58 3200847 A B Insulation,oven bottom
58A 316047708 A B Insulation, 2" ,oven wrapper
58B 316054201 A B Insulation,oven back
59 316073602 A B Tube-oven vent
59A 316023600 A B Tube-oven vent,upper
59B 316040100 A B Bracket-mounting,vent tube
62 # 5303935061 A B Terminal Block Kit
62* 316085600 A B Insulator
62* 5303308427 A B Nut,hex ,10-32
63 5301145190 A B Plate-ground strap
66 # 5303051140 A B Element-broil,2950 W
67 # 316075103 A B Element-bake,67
68 316075300 A B Support-element, broil
71 316015804 A B Shield-rear wall,galv steel
72 5303285692 A B Cover-rod end,lt switch rod
82 5303289913 A B Shield-insulation
87 316081200 A B Bracket-cable mtg
88 316026400 A B Rod-latch,auto
89 # 316135200 A B Motor-latch/lock
106 316026600 A B Bracket-motor mtg
107 316026701 A B Cover-fan
108# 316136300 A B Motor-fan
109 316136400 A B Fan Blade
110 316136500 A B Washer,fan motor
111 316136600 A B Nut-fan retainer
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template, Anti-tip bracket
170* 316116000 A B Screw,concrete tpg ,1.75 inch, anti-tip brkt
* 3203550 A B Plug-button,oven bottom
* 316001583 A B Harness-main
* 316021105 A B Screw,hex head cup pt, 8-18 x 0.375, blk,back/bodyside
* 316021108 A B Screw,cup pt,8-18 x 0.375,chrom,hing,ind lgt,manifld pnl
* 316045000 A B Clip-wiring harness, retainer, green, main top
* 5303051099 A B Nut,hex ,#10-32
BODY

01/01 6
Publication No. FEF369CG
5995345377
TOP/DRAWER

# = Fast-moving Parts 7 01/01
* = Non-Illustrated Parts
FEF369CG Publication No.
5995345377
TOP/DRAWER
A = FEF369CG (FEF369CGSE)
B = FEF369CG (FEF369CGTE)
POS. NO PART NO DESCRIPTION
1 316011501 A B Drawer-utility
2 5303288582 A B Shield-drawer,liner ,galv steel, front panel
4 316084405 A - Panel-drawer front,white
4 316084406 - B Panel-drawer front,almond
4* 316021112 A - Screw,8-18 x 0.500 ,white
4* 316021113 - B Screw,8-18 x 0.500 ,almond
7 3051163 A B Glide-drawer,rear
15 # 316010206 A B Element-surface,radiant, large/8 inch, 2100 W
15A# 316010205 A B Element-surface,radiant, small/6 inch, 1200 W
15B# 316049705 A B Element-surface,dual ,9", 2100W/1000W
15C# 316098201 A B Element-warmer,100 W ,120 V
16 316098139 A - Maintop & glass assy,glass ,white
16 316098140 - B Main Top Assy,glass/steel, enamel, almond
18 5303273062 A B Hinge-main top,RH
18A 5303273063 A B Hinge-main top,LH
26 316099100 A B Channel-support, element, galv steel, (2)
26A 316099200 A B Bracket-support,chassis ,galv steel
44 3131903 A B Bumper-door/drawer, rubber
48 316100200 A B Shield-wire,main top
51 # 316001759 A B Wiring Harness,surface element
52 316099400 A B Clip-spring, element mtg,(8)
53 316099300 A B Bracket-indicator light, hot surface, 4 hole
88 316099500 A B Pin-guide, (2)
* 5303280308 A B Screw-handle mtg, wafer hd sq dr, 10-24T x 2.00
* 316021105 A B Screw,hex hd cup pt,8-18 x 0.375, blk,back/bodyside
* 316021108 A B Screw,cup pt,8-18 x 0.375,chrom,hing,ind lgt,manifld pnl
* 316021110 A B Screw,8-18 x 0.500 ,black
* 316045000 A B Clip-wiring harness,retainer, green, main top
* 316089600 A B Spacer-drawer,(2)
* 316112101 A B Cleaner-cooktop
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312, (2)

01/01 8
Publication No. FEF369CG
5995345377
DOOR

# = Fast-moving Parts 9 01/01
* = Non-Illustrated Parts
FEF369CG Publication No.
5995345377
DOOR
A = FEF369CG (FEF369CGSE)
B = FEF369CG (FEF369CGTE)
POS. NO PART NO DESCRIPTION
3 316067804 A - Trim-oven door,white
3 316067803 - B Trim-oven door,almond
4 316089005 A - Glass-oven door,white ,outer
4 316089004 - B Glass-oven door,almond ,outer
5 316088700 A B Glass-oven door,airwash
6 316088401 A B Shield-wool
7 316076403 A B Insulation-door
8 316088600 A B Glass-oven door,inner
9 316066610 A B Liner-oven door
10 5303280308 A B Screw-handle mtg, wafer hd sq dr, 10-24T x 2.00
10* 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 A B Seal-oven door
14 3131361 A B Reflector,aluminum foil
14A 3131360 A B Reflector,aluminum foil ,(2)
15 316081403 A B Bracket-glass mtg
16 316085701 A B Glass-oven door,heat barrier
39 316091115 A - Handle-door,white ,oven
39 316091116 - B Handle-door,almond ,oven
52 316081301 A - Shield-oven door,white ,top
52 316081302 - B Shield-oven door,almond ,top
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black
* 3203618 A B Rivet-pop,warning-plate
* 316021110 A B Screw,8-18 x 0.500 ,black
* 316065306 A B Plate-warning/caution
* 316132100 A B Spacer,sponge pad
* 3131737 A B Washer-hinge,black

01/01 10
Publication No. FEF369CG
5995345377
WIRING DIAGRAM
