Frigidaire CFEF3014LW User manual

frigidaire.ca
Drop-In Cooktop
FPEC3085K S 30" Electric30" Electric
Signature Features
Large Capacity
Our large capacity oven gives you
room to cook more at once.
Ready-Select™ Controls
Select options or control cooking
temperature with our easy-to-use
controls.
Product Dimensions
Height 47"
Width 29-7/8"
Depth 28-1/2"
More Easy-To-Use Features
Store-More™ Storage Drawer
Our convenient drawer gives you extra
storage space in your kitchen.
Quick Clean
For a quick, light oven cleaning.
Extra-Large Window
Our extra-large oven window lets you
easily see what’s inside.
Hi /Lo Broil Option
Offers two-position broiling and
variable temperature control for
more control.
Auto Shut-Off
As an extra safety measure, the oven will
automatically shut off after 12 hours.
Timed Cook Option
Bright Lighting
Our bright lighting makes it easy
to see what’s inside.
Available in:
Even Baking Technology
Our latest technology ensures
even baking every time.
One-Touch Self Clean
Start the self-cleaning cycle with
just the touch of a button.
Freestanding Ranges
CFEF3014LW
Elements
Right Front
Right Rear
Left Front
Left Rear
Watts
1,250
1,250
2,100
2,100
Size
6"
6"
8"
8"
White
(W)

Cutout Dimensions
Height
Width
Depth
36"
30"
24"
Product Dimensions
A - Height
B - Width
C - Depth
Depth with Door Open 90˚
47"
29-7/8"
28-1/2"
48-3/8"
Electric Freestanding Ranges
Frigidaire Baseline
C
A
B
36"
(Adjustable)
Features
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish
Convection System
Cleaning System
Drawer Functionality
Oven Controls
Bake
Broil
Add-a-Minute
Delay Bake
Self-Clean
Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Auto Oven Shuto
Cooktop Features
Right Front Coil Element (Watts)
Right Rear Coil Element (Watts)
Left Front Coil Element (Watts)
Left Rear Coil Element (Watts)
Center Element (Watts)
Drip Bowls
Hot Surface Indicator Light
Oven Features
Capacity (Cu. Ft.)
Oven Light
Hidden Bake Element
Rack Configuration
Even Baking System
Broiling System
Bake Element / Broil Element (Watts)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Ready-Select™ Controls
Colour-Coordinated Porcelain
Extra-Large
Colour-Coordinated
Colour-Coordinated
Colour-Coordinated
Self Clean
Storage
Yes
Low and High
Yes
Yes
Yes
Yes
12 Hours
6" – 1,250
6" – 1,250
8" – 2,100
8" – 2,100
5.3
Yes
2 Standard
Yes
Vari-Broil™ Hi / Lo
2,600 / 3,000
21" x 24-3/8" x 19-1/8"
Centerline Lower Rear
240V / 208V
10.0 / 7.5
40
140 Lbs.
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
CFEF3014L 11/11 © 2011 Electrolux Major Appliances, NA Printed in Canada
Freestanding Ranges
CFEF3014LW 30" Electric
NOTE: Always consult local and national electric codes. Refer to Product Installation
Guide for detailed installation instructions on the web at frigidaire.ca.
Accessories information available
on the web at frigidaire.ca
Specifications subject to change.

30" Electric Freestanding Ranges with Storage Drawers
Baseline
Specifications subject to change.
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
CFEF3014L 11/11 © 2011 Electrolux Major Appliances, NA Printed in Canada
Freestanding Range Specifications
• Product Shipping Weight (approx.) – 140 Lbs.
• Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz,
fused on both sides of line with ground.
• Connected Load (kW Rating) @ 240 / 208 Volts = 12.5 / 9.5 kW
• Recommended Circuit Breaker – 40 Amps
• Always consult local and national electric codes.
• Make sure wall coverings around range can withstand heat generated
by range.
• Linoleum or any other synthetic floor covering located beneath range,
must be capable of withstanding minimum heat of 90° F above room
temperature without shrinking, warping or discolouring. Insulating
pad or 1/4"-thick plywood required between range and a carpeted
floor.
• Floor beneath range MUST be solid and level.
• Overhead cabinetry should not exceed a 13" maximum depth.
• Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum
width of appliance.
• Range can be installed flush to wall with 0" minimum rear clearance.
• Minimum 1" clearance required from edge of rangetop to nearest
combustible wall on either side of range above 36" height.
• Allow 30" minimum clearance between top of cooking surface and
bottom of unprotected wood or metal overhead cabinet; or 24"
minimum clearance when bottom of wood or metal overhead cabinet
is protected by not less than 1/4" flame retardant millboard covered
with not less than No. 28 MSG sheet steel, 0.015" stainless steel,
0.024" aluminum or 0.020" copper.
• To reduce risk of fire when using overhead cabinetry, install
range hood that projects horizontally a recommended minimum
of 5" beyond bottom of cabinets.
• Follow all dimension requirements provided to prevent property
damage, potential fire hazard, and incorrect countertop and
cabinet cuts.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.ca for detailed instructions.
Freestanding Ranges
CFEF3014LW 30" Electric
