© 2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF375BHBA FEF375BH BLACK USA
FEF375BHBB FEF375BH BLACK USA
FEF375CHSA FEF375CH WHITE/WHITE USA
FEF375CHSB FEF375CH WHITE/WHITE USA
Publication No.
5995340964
000711
-EN/SERVICE /CML
369
WIRING DIAGRAM # - 316002682
OWNER’S GUIDE # - 316135911
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF375BHBA
FEF375BHBB
FEF375CHSA
FEF375CHSB
07/00 2
Publication number
5995340964 FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB 5995340964
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF375BH (FEF375BHBA)
B = FEF375BH (FEF375BHBB)
C = FEF375CH (FEF375CHSA)
D = FEF375CH (FEF375CHSB)
POS. NO PART NO DESCRIPTION
* 316021105 A B C D Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl
* 316021110 A B - - Screw,semi gim ,8-18 X 1/2 ,black
* 316021122 - - C D Screw,8-18 x 0.375 ,truss hd white
* 316112500 A B C D Template, Anti-tip bracket
1 316081601 A B C D Shield-backguard,rear wall
2 316015905 A B C D Shield-backguard,inner
11 316061851 A B - - Trim-wrapper,textured ,black
11 316061852 - - C D Trim-wrapper,textured ,white
13A 316095500 A B C D Switch-warmer, infinite , drawer/zone
14 316022503 A B C D Light/Lamp, indicator , surface ,250 V
14A 316022500 A B C D Light/Lamp, warmer,indicator,drawer/zone,125 V
15 316023108 A B C D Support-backguard,RH
15A 316023109 A B C D Support-backguard,LH
18 5303935172 - - C D Kit-End caps, white
18 5303935174 A B - - Kit-End caps, black
19 316123613 A B C D Panel-backguard,alum
20 # 316101001 A B C D Clock/Timer,electronic
20* 316101502 - - C D Overlay-clock
20* 316101503 A B - - Overlay-clock
23 316131501 A B C D Bracket-control timer
24 # 316118100 A B - - Switch-rocker, black
24# 316118101 - - C D Switch-rocker,oven light ,white
24B# 316086901 - - C D Switch-rocker,dual element ,white
24B# 316086903 A B - - Switch-rocker,dual element ,black
31A 316025106 - - C D Knob-control,infinite sw,white
31A 316025108 A B - - Knob-control,infinite sw,black
36 316025106 - - C D Knob-control,infinite sw ,white
36 316025108 A B - - Knob-control, infinite sw, black
40 316064009 A B - - Panel-manifold,black
40 316064030 - - C D Panel-manifold,white
46 316040201 A B C D Lens-light/lamp,indicator ,red
54 # 316021500 A B C D Switch-infinite, 6" element
54A# 316021501 A B C D Switch-infinite, 8" element
54B# 316049800 A B C D Switch, infinite , dual element
69 5303292005 A B C D Screw-switch mtg,8-32 x 5/32
100 316128300 A B C D Shield-backguard,RH
100A 316128301 A B C D Shield-backguard,LH
07/00 4
Publication number
5995340964 FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB
CAUTION: Use the part number on all orders, not the position number.
BODY
# - Fast Moving Parts
* - Non Illustrated Parts 5 07/00
Publication number
FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB 5995340964
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF375BH (FEF375BHBA)
B = FEF375BH (FEF375BHBB)
C = FEF375CH (FEF375CHSA)
D = FEF375CH (FEF375CHSB)
POS. NO PART NO DESCRIPTION
* 316001565 A B C D Harness-main,*
* 316021105 A B C D Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl
* 316021123 A B - - Screw,8-18 X 3/8-8 ,truss HD black
* 316045000 A B C D Clip-wire,harness ,main top
* 316101600 A B C D Shield-vent,smoothtop
* 5303051099 A B C D Nut,hex ,#10-32
* 5308014215 A B C D Screw
3 316081034 - - C D Panel-bodyside,white ,RH
3* 316081035 - - C D Panel-bodyside,white ,LH
3 316081038 A B - - Penel-bodyside, black, RH
3* 316081039 A B - - Panel-bodyside, black, LH
5 316129200 A B C D Leg-leveling (plastic) w/stops
6 316067902 A B C D Rack-oven
7 316007002 A B C D Hinge-oven door,(2)
8 3203540 A B C D Panel-oven bottom
9 316081900 A B C D Pan-broiler
10 316082000 A B C D Insert-broiler pan
12 # 316027701 A B C D Switch-oven light
13 316026800 A B C D Rod-light switch /door
14 316116400 A B C D Socket-light
15 5303013071 A B C D Light Bulb/Lamp
16 08011086 A B C D Lens-light/lamp, glass , oven
17 316087500 A B C D Retainer-lens
18 # 316036300 A B C D Latch-door
21 3014099 A B C D Spacer-bodyside, (8)
25 3200848 A B C D Shield-heat,lower
29 3051162 A B C D Glide-drawer,front
37 # 316111202 A B C D Probe-oven temp
41 3131570 A B C D Cover-hinge cutout
45 316066100 A B C D Shield-wire, s/t vent
57 316081101 A B C D Cover-access
58 3200847 A B C D Insulation,oven bottom
58A 316047708 A B C D Insulation, 2" ,oven wrapper
58B 316054200 A B C D Insulation, 2" ,oven back
59 316073602 A B C D Tube-oven vent
59A 316023600 A B C D Tube-oven vent,upper
59B 316040100 A B C D Bracket-mounting,vent tube
62 # 5303935061 A B C D Terminal Block
63 5301145190 A B C D Plate-ground strap
66 # 5303051140 A B C D Element-broil
67 # 316075103 A B C D Element-bake
68 316075300 A B C D Support-element, broil
71 316015805 A B C D Shield-rear wall
72 5303285692 A B C D Cover-light/switch rod
82 5303289913 A B C D Shield-insulation
87 316081200 A B C D Bracket-cable mtg
88 316026400 A B C D Rod-latch,auto
07/00 6
Publication number
5995340964 FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB
CAUTION: Use the part number on all orders, not the position number.
BODY
# - Fast Moving Parts
* - Non Illustrated Parts 7 07/00
Publication number
FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB 5995340964
CAUTION: Use the part number on all orders, not the position number.
BODY
89 # 316028101 A B C D Motor-latch/lock
170 * 316107200 A B C D Anti-tip bracket
170* 316116000 A B C D Screw-Anti tip, 1.75" concrete
170* 5303935180 A B C D Kit-Anti-tip bracket (complete w/template & screw)
07/00 8
Publication number
5995340964 FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
# - Fast Moving Parts
* - Non Illustrated Parts 9 07/00
Publication number
FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB 5995340964
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FEF375BH (FEF375BHBA)
B = FEF375BH (FEF375BHSB)
C = FEF375CH (FEF375CHSA)
D = FEF375CH (FEF375CHSB)
POS. NO PART NO DESCRIPTION
* 316021105 A B C D Screw,hex ,8-18 x 0.375 ,back\bodyside
* 316021108 A B C D Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl
* 316021112 - - C D Screw-8-18x1/2 Tr Sqd White
* 316021110 A B - - Screw,semi gim ,8-18 X 1/2 ,black
* 316045000 A B C D Clip-wire,harness ,main top
* 316089600 A B C D Spacer-drawer,(2)
* 316112101 A B C D Cleaner-cooktop
* 5303280311 A B C D Screw, waf hd sdr , 10-32 x 5/16 , (2)
* 5308014215 A B C D Screw
1 316011501 A B C D Drawer-utility
2 3131975 A B C D Shield-panel
4 316084405 - - C D Panel-drawer,white
4 316084407 A B - - Panel-drawer,black
7 3051163 A B C D Glide-drawer,rear
15 # 316010206 A B C D Element-surface radiant, 8" 2100
15A# 316010205 A B C D Element-surface radiant, 6" 1200
15B# 316049705 A B C D Element-surface,radiant,dual,2100w/1000w,limit sw incl
15C# 316098201 A B C D Element-warmer,120V/100W
16 316098155 A B - - Main top, black,smoothtop
16 316098164 - - C D Main top, white, smoothtop
18 5303273062 A B C D Hinge-main top,RH
18A 5303273063 A B C D Hinge-main top,LH
48 316100200 A B C D Shield-wire,main top
52 316099400 A B C D Clip-spring, element mtg,(8)
88 316099500 A B C D Pin-guide, (2)
07/00 10
Publication number
5995340964 FEF375BHBA,FEF375BHBB,FEF375CHSA,FEF375CHSB
CAUTION: Use the part number on all orders, not the position number.
DOOR
