Frigidaire FEF376A User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF376AQE FEF376A bisque North America
FEF376ASE FEF376A white North America
Publication No.
5995362810
011219
-EN/SERVICE /ECL
369

BACKGUARD

A = FEF376A (FEF376ASE)
B = FEF376A (FEF376AQE)
POS. NO PART NO DESCRIPTION
1 316239900 A B Shield,backguard ,rear wall
14 316022503 A B Light/Lamp,indicator ,surface ,250 V
14A 316022500 A B Light/Lamp,warmer,indicator ,drawer/zone,125 V
15 316220202 A - Support,backguard ,white ,RH
15 316220208 - B Support,backguard ,bisque ,RH
15A 316220203 A - Support,backguard ,white ,LH
15A 316220209 - B Support,backguard ,bisque ,LH
19 316232697 A - Panel,backguard ,white
19 316232699 - B Panel,backguard ,bisque
20 # 316222907 A B Clock/Timer,electronic
20A 316220804 A - Overlay,clock ,white
20A 316220806 - B Overlay,clock ,bisque
24 # 316246000 A - Switch,rocker ,white ,oven light
24 # 316246002 - B Switch,rocker ,bisque ,oven light
24C# 316114000 A - Switch,speed bake,white
24C# 316114004 - B Switch,convection ,bisque
31 316223000 A - Knob,control ,white
31 316223003 - B Knob,control ,bisque
46 316040201 A B Lens,indicator light ,red
54 # 316021500 A B Switch,infinite ,small element
54A# 316021501 A B Switch,infinite ,large element
56 316234001 A - Shield,backguard ,white ,inner
56 316234004 - B Shield,backguard ,bisque ,inner
69 5303288565 A B Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
BACKGUARD

BODY

A = FEF376A (FEF376ASE)
B = FEF376A (FEF376AQE)
POS. NO PART NO DESCRIPTION
1 316201300 A B Back,main
3 316230102 A - Panel,bodyside ,white ,RH
3 316230103 A - Panel,bodyside ,white ,LH
3 316230108 - B Panel,bodyside ,bisque ,RH
3 316230109 - B Panel,bodyside ,bisque ,LH
5 316129200 A B Screw,leveling ,plastic ,with stop
6 316067902 A B Rack,oven
6A 316214401 A B Rack,oven sump
7 316212900 A B Hinge,oven door ,RH
7A 316212901 A B Hinge,oven door ,LH
8 316201501 A B Panel,sump ,oven bottom
9 316081900 A B Pan,broiler
10 316082000 A B Insert,broiler pan
12 # 316027701 A B Switch,oven light
13 316238800 A B Rod,light switch
14 316116400 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 08011086 A B Lens,oven light ,glass
17 316087500 A B Retainer,lens
18 # 316213900 A B Latch,oven door
21 3014099 A B Spacer,bodyside
25 3200848 A B Shield,heat ,lower
26 316206300 A B Support,chassis ,(2)
29 3051162 A B Glide,drawer ,front
30 316217700 A B Bracket,hinge ,RH ,main top
30A 316217701 A B Bracket,hinge ,LH ,main top
37 # 316233900 A B Probe,oven temp
41 316233400 A B Cover,hinge cutout ,RH
41A 316233500 A B Cover,hinge cutout ,LH
42 316206200 A B Shield,wool ,lower
44 316246500 A B Spacer,oven door
45 316234100 A B Shield,wire ,vent tube
57 316081100 A B Cover,access
58 316240300 A B Insulation,oven bottom
58A 316047708 A B Insulation,2" ,oven wrapper
58B 316240102 A B Insulation,oven back
58C 316240400 A B Insulation,oven sump
59 316208200 A B Tube,oven vent ,lower
59A 316208300 A B Tube,oven vent ,upper
59B 316247300 A B Catalyst,oven vent ,ceramic
62 # 5303935061 A B Terminal Block Kit
62* 316085600 A B Insulator
62* 5303308427 A B Nut,hex ,10-32
63 5301145190 A B Plate,grounding strap
66 # 316203300 A B Element,broil
67 # 316202200 A B Element,bake
68 316203400 A B Support,broil element
71 316015810 A B Shield,rear wall ,galv steel
72 316234500 A B Cover,rod end ,light switch
87 316081200 A B Bracket,cable mtg
88 316203500 A B Rod,auto latch
89 # 316135202 A B Motor,latch/lock
89A 316245800 A B Bracket,latch ,rear
106 316026600 A B Bracket,motor mtg
107 316026701 A B Cover,fan
108# 316136300 A B Motor,fan
109 316136400 A B Blade,fan
110 316136500 A B Washer,fan motor
111 316136600 A B Nut,fan retainer
BODY

BODY

A = FEF376A (FEF376ASE)
B = FEF376A (FEF376AQE)
POS. NO PART NO DESCRIPTION
151 316239300 A B Shield,bodyside
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template,anti-tip
170* 316116000 A B Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253216 A B Wiring Harness,main
* 316231800 A B Cover,hole ,conv. element
* 5303305324 A - Paint,touch-up ,white
* 5304414035 - B Paint,touch-up ,bisque
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 A B Screw,6-20 x 0.312
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
BODY

TOP/DRAWER

TOP/DRAWER
A = FEF376A (FEF376ASE)
B = FEF376A (FEF376AQE)
POS. NO PART NO DESCRIPTION
1 316011503 A B Drawer
2 316231500 A B Liner,drawer
4 316231305 A - Panel,drawer ,white
4 316231309 - B Panel,drawer ,bisque
7 3051163 A B Glide,drawer ,rear
15 # 316010206 A B Element,surface ,8" ,2200 W ,radiant
15A# 316010205 A B Element,surface ,6" ,1200 W ,radiant
15B# 316224200 A B Element,surface ,9" ,2500W ,radiant
16 316251942 A - Main Top Assy,glass/steel ,white
16 316251943 - B Main Top Assy,glass/steel ,bisque
18 316235900 A B Hinge,main top ,RH
18A 316235901 A B Hinge,main top ,LH
26 316230200 A B Channel,element support ,(2)
26A 316099200 A B Bracket,chassis support ,rear
26B 316214200 A B Bracket,chassis support ,front
52 316099400 A B Clip,element mtg
88 316099500 A B Pin,guide ,(2)
* 316253515 A B Wiring Harness,surface element
* 316112101 A B Cleaner,cooktop
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 A B Screw,6-20 x 0.312

DOOR

DOOR
A = FEF376A (FEF376ASE)
B = FEF376A (FEF376AQE)
POS. NO PART NO DESCRIPTION
3 5303935192 A - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935193 - B Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - Glass,door kit ,white ,outer ,w/ foil tape
4 5303935202 - B Glass,door kit ,bisque ,outer ,w/ foil tape
5 316237000 A B Glass,oven door ,heat barrier
6 316222707 A B Shield,wool ,oven door
7 316236700 A B Insulation,oven door
8 316237100 A B Glass,oven door ,clear ,inner
9 316230605 A B Liner,oven door
10 316001013 A B Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10* 316001016 A B Screw,handle mtg ,10-12 X .750
10B 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 316230900 A B Seal,oven door
14 316102207 A B Foil,1.5" x 29" ,aluminum ,clear
14A 316102202 A B Foil,4" x 5.5" ,aluminum ,clear ,(2)
15 316237201 A B Bracket,glass support ,(2)
16 316117500 A B Glass,oven door ,heat barrier
17 316117701 A B Spacer,door glass ,(2)
39 316203001 A - Handle,door ,white
39 316203003 - B Handle,door ,bisque
52 316201000 A - Cap,door trim ,white
52 316201007 - B Cap,door trim ,bisque
60B 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
* 316065306 A B Plate,warning/caution
* 3203618 A B Rivet,pop
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black

WIRING DIAGRAM
