Frigidaire GLCS376A User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
GLCS376ABA GLCS376A 37956383G1061 black North America
GLCS376ABB GLCS376A 37956383G1062 black North America
GLCS376ASA GLCS376A 37956383G1011 white North America
GLCS376ASB GLCS376A 37956383G1012 white North America
Publication No.
5995363131
020102
-EN/SERVICE /ECL
377
DUAL FUEL
RANGE
Model No.
GLCS376A
©2002 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318045050 = A/#318045072 = B
OWNER’S GUIDE - # 318200861
TIMER INSTRUCTION SHEET - # 318200191
INSTALLATION INSTRUCTIONS - # 318201657
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

01/02 2
Publication No. GLCS376A
5995363131
BACKGUARD

# = Functional Parts 3 01/02
* = Non-Illustrated Parts
GLCS376A Publication No.
5995363131
BACKGUARD
A = GLCS376A (GLCS376ASA)
B = GLCS376A (GLCS376ASB)
C = GLCS376A (GLCS376ABA)
D = GLCS376A (GLCS376ABB)
POS. NO PART NO DESCRIPTION
14 # 318076700 A B C D Light,indicator ,125v
18 5303304668 A B - - End Cap,white ,RH
18 5303300160 - - C D End Cap,black ,RH
18A 5303304671 A B - - End Cap,white ,LH
18A 5303300161 - - C D End Cap,black ,LH
19 318182943 A B - - Panel,control mtg. ,white
19 318182944 - - C D Panel,control mtg. ,black
20 # 318185416 A B - - Clock/Timer,electronic ,white
20 # 318185417 - - C D Clock/Timer,electronic ,black
21 318027804 A B - - Trim,backguard ,white ,top
21 318027803 - - C D Trim,backguard ,black ,top
23 318015040 A - C - Bracket,clock mtg ,upper
23 318015042 - B - D Bracket,clock mtg ,upper
23A 318015041 A - C - Bracket,clock mtg ,lower
23A 318015043 - B - D Bracket,clock mtg ,lower
24 # 316005607 A B - - Switch,rocker ,white
24 # 316005602 - - C D Switch,rocker ,black
24C# 316114000 A B - - Switch,speed bake,white
24C# 316114002 - - C D Switch,speed bake,black
42 318106924 A B - - Trim,backguard ,white ,bottom
42 318106927 - - C D Trim,backguard ,black ,bottom
46 5303297274 A B C D Lens,indicator light
* 08002868 A B C D Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 08016432 A B C D Screw,truss head ,8-18 x 0.375
* 5303211311 A B C D Screw,8 x 0.500
* 5303311306 A B C D Screw,8-18 x 0.375

01/02 4
Publication No. GLCS376A
5995363131
BURNER

# = Functional Parts 5 01/02
* = Non-Illustrated Parts
GLCS376A Publication No.
5995363131
BURNER
A = GLCS376A (GLCS376ASA)
B = GLCS376A (GLCS376ASB)
C = GLCS376A (GLCS376ABA)
D = GLCS376A (GLCS376ABB)
POS. NO PART NO DESCRIPTION
1 # 318177301 A B C D Manifold Pipe
2 # 5303935042 A B C D Valve,top burner ,2-position ,9100 BTU
2A # 318087001 A B C D Valve,top burner ,5000 BTU
2B # 318087040 A B C D Valve,top burner ,13000 BTU
3 # 316032002 A B C D Switch,ignitor
4 # 318167703 A B C D Tube,burner ,RF
5 # 318167700 A B C D Tube,burner ,LF
6 # 318167702 A B C D Tube,burner ,RR
7 # 318167701 A B C D Tube,burner ,LR
8 # 316135701 A B C D Module,spark
10 # 318148001 A B C D Burner,top ,9100 BTU ,medium LF & LR
10A# 318148002 A B C D Burner,top ,13000 BTU ,large RF
10B# 318148000 A B C D Burner,top ,5000 BTU ,small RR
13 318054503 A B C D Connector,manifold tube
14 # 318122700 A B C D Regulator,pressure
15 318122900 A B C D Bracket,regulator
33 318171500 A B C D Bracket,burner
35 318146300 A B C D Bushing
72 5303323141 A B C D Screw,valve mtg ,1/4-20 x 5/16
73 318080100 A B C D Plate,spark module
74 # 318148700 A B C D Ignitor,top burner
75 318148800 A B C D Clip,electrode
76 # 318167801 A B C D Tube,mixing ,medium & large
76A# 318167800 A B C D Tube,mixing ,small
77 318112010 A B C D Bracket,burner mtg ,medium & large
77A 318112000 A B C D Bracket,burner mtg ,small
77B 318180900 A B C D Bracket,burner tube
* 318052148 A B C D Harness,wiring
* # 318127701 A B C D LP Conversion Kit
* 08002868 A B C D Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 08011955 A B C D Screw,10-24 x 0.375 ,square drive
* 316048200 A B C D Screw,hex washer head ,1/4-20 x 0.31 ,vlv mtg,w/gasket
* 5303211311 A B C D Screw,8 x 0.500
* 5304403558 A B C D Screw,10-16 x 0.250

01/02 6
Publication No. GLCS376A
5995363131
BODY

# = Functional Parts 7 01/02
* = Non-Illustrated Parts
GLCS376A Publication No.
5995363131
BODY
A = GLCS376A (GLCS376ASA)
B = GLCS376A (GLCS376ASB)
C = GLCS376A (GLCS376ABA)
D = GLCS376A (GLCS376ABB)
POS. NO PART NO DESCRIPTION
1 318066402 A B C D Panel,main back
1A 318070910 A B C D Panel,main back ,upper
2A 318108600 A B C D Shield,oven top
3 318159800 A B C D Panel,body side ,upper
3A 318160004 A B C D Panel,lower side ,RH
3B 318160005 A B C D Panel,lower side ,LH
4 318073900 A B C D Panel,subtop
5 318175503 A B C D Screw,leveling
6 5303310522 A B C D Rack,shelf ,30" ,oven
9 5303317977 A B C D Pan,broiler
10 5303317976 A B C D Insert,broiler pan
12 318089910 A B C D Switch,oven light ,door frame
14 # 5308011085 A B C D Receptacle,oven light
15 # 3201908 A B C D Light,oven
16 3201911 A B C D Cover,oven light ,glass
17 5304400195 A B C D Retainer,light cover
25 318179107 A B C D Panel,heat shield ,sm oven bottom
37 # 318198500 A B C D Probe,oven temp
41 5303310526 A B C D Cover,hinge cutout
54 5303310514 A B C D Housing,oven light
56 318002612 A B - - Trim,oven ,white ,front
56 318002611 - - C D Trim,oven ,black ,front
58A 318133744 A B C D Insulation,oven wrapper
58B 318133769 A B C D Insulation,oven back
59 318072519 A B C D Tube,oven vent ,upper
59A 318072520 A B C D Tube,oven vent ,lower
62 # 5303310518 A B C D Terminal Block
62* 5303308427 A B C D Nut,hex ,10-32
63 5303310517 A B C D Plate,ground strap
66 # 5303310513 A B C D Element,broil ,2750 W
67 # 5303310512 A B C D Element,bake ,3000 W
68 5304403015 A B C D Support,element hanger
70 318194400 A B C D Shield,insulation
70A 318199801 A B C D Deflector
71 5303310515 A B C D Panel,wiring cover ,rear
76 318124100 A B C D Front,oven
80 5303320846 A B C D Plate,oven mtg
81 318192400 A B C D Spring,oven
83 318089609 A B C D Liner,oven
86 5303310524 A B C D Receptacle,hinge
87 318111803 A B C D Plate,mounting
88 318118904 A B C D Rod,latch
89 # 318095936 A - C - Motor,latch assy ,w/brkt & switch
89 # 318095937 - B - D Motor,latch assy ,w/brkt & switch
89*# 318120710 A B C D Switch,cooktop shutoff
102 5303311142 A B C D Support,oven front
107 318119600 A B C D Cover,fan
108# 318073012 A B C D Motor,blower
109 316136400 A B C D Blade,fan
111 316136600 A B C D Nut,fan retainer
114 318175100 A B C D Plate,filler
125# 316234601 A B C D Motor,fan
127 5303310542 A B C D Adapter,vent tube ,with converter
128 5303311163 A B C D Bushing
129 5303311164 A B C D Spring
141# 5303284446 A B C D Switch,thermal cutout
142 318123901 A B C D Deflector
170 5304405244 A B C D Anti-tip & accessories
177 5303324040 A B C D Gasket,vent
191 5303304030 A B C D Bracket,angle ,corner
217 316042300 A B C D Plate,warning
219# 318005000 - B - D Thermostat,safety ,for fan
222 318080000 A B C D Plate,oven temp probe
223 318038400 A B C D Cover,tube
263 316136500 A B C D Washer,fan motor
264 318077602 A B C D Cover,wire
* 318082956 A - C - Harness,main wiring
* 318082975 - B - D Harness,main wiring
* 5303311207 A B C D Tube,protector

01/02 8
Publication No. GLCS376A
5995363131
TOP/DRAWER

# = Functional Parts 9 01/02
* = Non-Illustrated Parts
GLCS376A Publication No.
5995363131
TOP/DRAWER
A = GLCS376A (GLCS376ASA)
B = GLCS376A (GLCS376ASB)
C = GLCS376A (GLCS376ABA)
D = GLCS376A (GLCS376ABB)
POS. NO PART NO DESCRIPTION
1 5303310500 A B C D Drawer
4 318134011 A B - - Panel,drawer ,white ,front
4 318134012 - - C D Panel,drawer ,black ,front
11 5303311125 A B C D Bracket,drawer
13 5303311129 A B C D Channel,drawer ,RH
13A 5303311130 A B C D Channel,drawer ,LH
16 318079224 A B - - Main Top,glass ,white
16 318079225 - - C D Main Top,glass ,black
19 318168116 A B - - Pan,burner ,white ,medium
19 318168114 - - C D Pan,burner ,black ,medium
19A 318168126 A B - - Pan,burner ,white ,large
19A 318168124 - - C D Pan,burner ,black ,large
19B 318168106 A B - - Pan,burner ,white ,small
19B 318168104 - - C D Pan,burner ,black ,small
20 318120104 A B - - Grate,grey ,(4)
20 318120103 - - C D Grate,black ,(4)
22 318076411 A B - - Cap,burner ,grey ,medium LF & LR
22 318076410 - - C D Cap,burner ,black ,medium LF & LR
22A 318076421 A B - - Cap,burner ,grey ,large RF
22A 318076420 - - C D Cap,burner ,black ,large RF
22B 318076401 A B - - Cap,burner ,grey ,small RR
22B 318076400 - - C D Cap,burner ,black ,small RR
31A 318053901 A B C D Gasket,burner pan
43 318196100 A B - - Knob,control ,white
43 318196101 - - C D Knob,control ,black
45 318146200 A B C D Bushing
70 5303311143 A B C D Bracket,slide ,rear
71 5303311144 A B C D Magnet & spring assy
72 5303311145 A B C D Bracket & wheel assy
* 5303325171 A B C D Washer,plastic
* 5303325173 A B C D Cap,plug
* 08002868 A B C D Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 08016432 A B C D Screw,truss head ,8-18 x 0.375
* 5303211311 A B C D Screw,8 x 0.500

01/02 10
Publication No. GLCS376A
5995363131
DOOR

# = Functional Parts 11 01/02
* = Non-Illustrated Parts
GLCS376A Publication No.
5995363131
DOOR
A = GLCS376A (GLCS376ASA)
B = GLCS376A (GLCS376ASB)
C = GLCS376A (GLCS376ABA)
D = GLCS376A (GLCS376ABB)
POS. NO PART NO DESCRIPTION
1 318043100 A B C D Bracket,trim ,handle ,(2)
1A 318180310 A B C D Bracket,trim mtg
2 318180312 A B C D Bracket,upper trim mtg
3 318187810 A B - - Trim,door ,white ,RH side
3 318187814 - - C D Trim,door ,black ,RH side
3A 318187811 A B - - Trim,door ,white ,LH side
3A 318187815 - - C D Trim,door ,black ,LH side
3B 318176646 A B - - Trim,door ,white ,top
3B 318176647 - - C D Trim,door ,black ,top
4 318187715 A B - - Panel,door front assy ,glass ,white ,with lower trim
4 318187714 - - C D Panel,door front assy ,glass ,black ,with lower trim
6 318056802 A B C D Shield,insulation
7 318133754 A B C D Insulation,oven door
9 318157011 A B C D Liner,door
10 5303308458 A B C D Screw,10-24 x 1/4
12 318053103 A B C D Gasket,oven door seal
16 318041603 A B C D Panel,glass ,inner oven door
17 318042102 A B C D Spacer,glass
18 318053001 A B C D Seal,window
23 318024700 A B C D Hinge,oven door
31 5303310536 A B C D Latch,oven door
39 316203001 A - - - Handle,door ,white
39 316108800 - B - - Handle,door ,white ,oven
39 316203000 - - C - Handle,door ,black
39 316108802 ---D Handle,door ,black ,oven
56 5303300265 A B C D Screw,8-18 x 0.500 ,chrome
64 5304417120 A B C D Tape,0.762 m ,Neoprene
* 08016432 A B C D Screw,truss head ,8-18 x 0.375
* 5303211311 A B C D Screw,8 x 0.500
* 5303307980 A B C D Screw,8-32 x 0.437

01/02 12
Publication No. GLCS376AB/SA
5995363131
WIRING DIAGRAM

# = Functional Parts 13 01/02
* = Non-Illustrated Parts
GLCS376AB/SB Publication No.
5995363131
WIRING DIAGRAM
