NOTICE - This service data sheet is intended for use by persons
having electrical and mechanical training and a level of knowledge
of these subjects generally considered acceptable in the appliance
repair trade. The manufacturer cannot be responsible, nor
assume any liability for injury or damage of any kind arising from
the use of this data sheet.
SAFESERVICINGPRACTICES
To avoid the possibility of personal injury and/or property damage, it is
important that safe servicing practices be observed. The following are
examples, but without limitation, of such practices.
1. Before servicing or moving an appliance remove power cord from
electrical outlet, trip circuit breaker to OFF, or remove fuse.
2. Never interfere with the proper installation of any safety device.
3. GROUNDING: The standard color coding for safety ground wires is
GREEN or GREEN WITH YELLOW STRIPES. Ground leads are not
to be used as current carrying conductors. It is extremely
important that the service technician reestablish all safety
grounds prior to completion of service. Failure to do so will
create a potential safety hazard.
p/n 316441401(0502)
SERVICE DATA SHEET
Electric Ranges with ES 340 Electronic Oven Control
RTD SCALE
Temperature (°F) Resistance (ohms)
32 ± 1.9 1000 ± 4.0
75 ± 2.5 1091 ± 5.3
250 ± 4.4 1453 ± 8.9
350 ± 5.4 1654 ± 10.8
450 ± 6.9 1852 ± 13.5
550 ± 8.2 2047 ± 15.8
650 ± 9.6 2237 ± 18.5
900 ± 13.6 2697 ± 24.4
ELECTRONICOVENCONTROLFAULTCODEDESCRIPTIONS
ELECTRONICOVENCONTROL(EOCREARVIEW)
IMPORTANT
DO NOT REMOVE THIS BAG
OR DESTROY THE CONTENTS
WIRINGDIAGRAMSANDSERVICE
INFORMATION ENCLOSED
REPLACE CONTENTS IN BAG
4. Prior to returning the product to service, ensure that:
• All electric connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges,
high-temperature components, and moving parts.
• All uninsulated electrical terminals, connectors, heaters, etc. are adequately
spaced away from all metal parts and panels.
• All safety grounds (both internal and external) are correctly and securely
reassembled.
OVEN CALIBRATION
Set the electronic oven control for normal baking at 350°F. Obtain an average oven
temperature after a minimum of 5 cycles. Press STOP/CLEAR to end bake mode.
TEMPERATUREADJUSTMENT
1. Set EOC to bake at 550°F.
2. Within 5 seconds of setting 550°F, press and hold the bake pad for approximately
15 seconds until a single beep is heard (longer may cause F11 shorted keypad
alarm).
3. Calibration offset should appear in the display.
4. Use the slew keys to adjust the oven temperature up or down 35°F in 5°F
increments.
5. Once the desired (-35° to 35°) offset has been applied, press STOP/CLEAR.
Note: Changing calibration affects normal Bake mode. The adjustments made will not
change the Self-Cleaning cycle temperature.
CIRCUITANALYSISMATRIX
P5
P8
(some models)(some models)
(some models)(some models)
(some models)
(some models)(some models)
(some models)(some models)
(some models)
SPEEDSPEED
SPEEDSPEED
SPEED
BAKEBAKE
BAKEBAKE
BAKE
INDICATORINDICATOR
INDICATORINDICATOR
INDICATOR
LIGHTLIGHT
LIGHTLIGHT
LIGHT
EOCP5CONNECTIONS
RunawayTemperature.
ShortedKeypad.
BadMicroIdentification.
BadEEPROMIdentification/Checksumerror.
Openprobeconnection.
ShortedProbeconnection.
Maximumovendoorunlocktimeexceeded.
Maximumovendoorunlockattempts exceeded.
Maximumovendooropentimeexceeded.
Maximumovendoorlock timeexceeded.
Maximumovendoorlockattemptsexceeded.
Likely Failure Condition/Cause Suggested Corrective Action
Fault Code
1.(F10only) Check RTD Sensor Probe&replaceifnecessary. If oven is overheating, disconnect
power.Ifovencontinuestooverheatwhenthepowerisreapplied,replaceEOC.Severeoverheating
may require the entire oven to be replaced should damage be extensive.
2. (F11, 12 & 13) Disconnect power, wait 30 seconds and reapply power.
3. (F11, 12 & 13) If fault returns upon power-up, replace EOC.
1.(F30orF31)Checkresistanceatroomtemperature&compareto RTDSensor resistancechart.
If resistance does not match the RTD chart replace RTD Sensor Probe. Check Sensor wiring
harness between EOC & Sensor Probe connector.
2.(F30orF31)Checkresistanceatroom temperature,if lessthan500ohms,replaceRTDSensor
Probe. Check for shorted Sensor Probe harness between EOC & Probe connector.
1. (F90, 91, 92, 93 & 94) Check the wiring between EOC & Lock Motor Micro Switch.
2. (F90, 91, 92, 93 & 94) Replace the Motor Door Latch assembly if necessary.
3.(F90,91,92,93 & 94) Check for binding of the Latch Cam, Lock Motor Rod&LockMotorCam.
4. (F90, 91, 92, 93 & 94) Check to see if Lock Motor Coil is open. If open, replace Lock Motor
Assembly.
5.(F90, 91, 92,93&94)Lock Motor continuoslyruns-if Micro Switchisopen,replace Lock Motor
Assembly.
6. (F92, 93 & 94) Check oven door Light Switch - if open, replace Switch.
7. If all situations above do not solve probem, replace EOC.
F10
F11
F12
F13
F30
F31
F90
F91
F92
F93
F94

GENERALTROUBLESHOOTING SCHEMATICGENERALTROUBLESHOOTING DIAGRAM
