Frigidaire FEFD67CH User manual

.
PRODUCT NO. FACTORY NO. COLOR MARKET
FEFD67CHSA 38354336C9011 WHITE U.S.A.
FEFD67CHBA 38354336C9061 BLACK U.S.A.
Publication No.
5995324729
990611
-EN/SERVICE
377
ELECTRIC - RANGE
Model No.
FEFD67CH
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
WIRING DIAGRAM # -318045253
OWNERS GUIDE #-318200407
INSTALLATION INSTRUCTION #-318154300
TIMER GUIDE # - 318092102
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA L5T1K6
TEL :[phone]
SELF-CLEANING OVEN
OFF
3
OFF
3
OFF
3
OFF
3
LEFTFRONT LEFTREAR RIGHTREAR RIGHT FRONT
SURFACE
OVENLIGHT
SURFACE
CANCELBAKE
VARI-BROIL CLEAN
CLOCK BAKETIME
STOPTIMETIMER
ON/OFF
PREHEA T
OVEN
LOCKED
HOT CHAUD

06/99 2
Publication No. FEFD67CH
5995324729 BACKGUARD
46
46
24
20
18
36
36
36
36
21
18A
LAP23CG082
54
54
54
54
86
64
19
16
69
14
14
98

# = Functional Part 306/99
* = Non-Illustrated Part
FEFD67CH Publication No.
5995324729
POS. NO
PART NO. DESCRIPTION
14 3200297 A B Light-indicator
16 318117426 A B Plate, instrument mtg
18 318118300 AEnd Cap white,RH
18 318118304 BEnd Cap, black RH
18A 318118301 AEnd Cap white,LH
18A 318118305 BEnd Cap black, LH
19 318117186 APanel-control white
19 318117187 BPanel-control black
20 # 318013011 AElectronic timer
20 # 318013006 BElectronic timer
21 318118000 ATrim-canopy white
21 318118002 BTrim-canopy black
24# 316005607 ASwitch-oven light, rocker type
24# 316005602 BSwitch-oven light, rocker type
36 318017110 AKnob-control white
36 318017111 BKnob-control black
46 5303297274 A B Lens-light
54 # 318120500 A B Switch-surface unit
64 318112200 A B Spacer rocker switch
69 5303323134 A B Screw switch mtg 8-32 x 3/16
86 318111201 A B Plate-connecting
98 318092405 A BWiring harness
*08016432 A B Screw truss head, 8-18 x 3/8
*5303310510 A B Screw 10-24 x 5/8
*3201885 A B Nut (10-24)
BACKGUARD
A= FEFD67CH (FEFD67CHSA)
B= FEFD67CH (FEFD67CHBA)

06/99 4
Publication No. FEFD67CH
5995324729 BODY
170
170A
183
3
3
59
74
178
177 166
166
14
54 15
67
66
10
9
6
25
166
166
165
5
76
182
86 86
83
1
57
71
58A
58B
80
68
127
30
30
88
99
LA9923CV14
141
171
62
62
63
184
162
163 12
11
16
17
37
129
128
89

# = Functional Part 506/99
* = Non-Illustrated Part
FEFD67CH Publication No.
5995324729
POS. NO PART NO DESCRIPTION
1 318108100 A B Back-main
3 318025601 APanel-bodyside,white
3318025603 BPanel-bodyside, black
5 318175503 A B Screw leveling
6 5303310522 A B Rack-oven
9 5303317977 A B Pan-broiler
10 5303317976 A B Insert-broiler pan
11 318086100 A B Bracket-light switch
12 # 318089800 A B Switch-door
14 5308011085 A B Socket-light/lamp
15 3201908 A B Lamp-oven light
16 3201911 A B Glass-oven light lens
17 5304400195 A B Retainer lens
25 318108700 A B Shield-heat lowerà
30 318110800 A B Bracket hinge main top
37 # 316111203 A B Probe-oven temp
54 5303310514 A B Housing-oven light
57 318036500 A B Cover-access
58A 5303310539 A B Insulation,oven wrapper
58B 5303310538 A B Insulation,oven back
59 318072518 A B Tube oven vent
62 # 5303310518 A B Terminal Block
63 5303310517 A B Plate-ground strap
66 # 5303310513 A B Element-broil
67 # 5303310512 A B Element-bake
68 5304403015 A B Support-element
71 318086600 A B Shield wire
74 318141900 A B Bumper bodyside
76 318108502 A B Frame-front, wheels incl
80 5303324473 A B Bracket-oven
83 318109405 A B Liner-oven assy
86 5303310524 A B Channel-hinge
88 318118902 A B Rod-latch
89 # 318095900 A B Motor-latch assy
89* 318120702 A B Switch latch
89* 318120704 A B Switch latch
99 318126101 A B Support side
127 5303310542 A B Adapter assy
128 5303311163 A B Bushing
129 5303311164 A B Spring
141# 5303302280 A B Thermostat-safety
162 318096401 A B Connection box
163 318135802 A B Cover connection box
165 318003100 A B Shield-plate
166 318111000 A B Support base
170 318175700 A B Anti-tip bracket
170A 318175701 A B Anti-tip bracket
171 318111202 A B Plate-connecting
177 5303324040 A B Gasket vent
178 318125700 A B Bracket vent
182 316042300 A B Plate-warning
183 5303323140 A B Screw
184 5303323144 A B Nut (10-32)
*5303211311 A B Screw, #8 x ½
*5303307980 A B Screw, 8-32 x 7/16
* 5303131801 A B Screw,10 x 3/8
*5303308449 A BFastener
*5303311528 A B Screw, 6-20 x 5/8
*5303323129 A B Screw, 8 X ¾
*5303323133 A B Screw, 8-18 X ½
*5303323139 A B Screw, 10-24 X 29/32
*5303325980 A B Screw, 10-32 X 0.437
*5304400427 A B Screw, 6-20 X ½
BODY
A= FEFD67CH (FEFD67CHSA)
B= FEFD67CH (FEFD67CHBA)

06/99 6
Publication No. FEFD67CH
5995324729 TOP/DRAWER
18
52A
1
LA23CT029G
4
11
11
13
7
13A
7
16
15
15
52
52A
52
94
15A
15A
3
51
18
56

# = Functional Part 706/99
* = Non-Illustrated Part
FEFD67CBH Publication No.
5995324729
POS. NO PART NO
DESCRIPTION
1 318107103 A B Drawer-utility
3 318144321 A B Support,main top
4 318044301 APanel-drawer,white
4318044303 BPanel-drawer black
7318014800 A B Spacer
11 318107500 A B Bracket-support,drawer
13 318018100 A B Channel-drawer,RH
13A 318018101 A B Channel-drawer,LH
15 # 318178101 A B Element-surface radiant,2100W
15A# 318178100 A B Element-surface radiant, 1200W
16 318043864 AMaintop, white
16 318043865 BMaintop, black
18 318074400 A B Hinge-main top
51# 5303297484 A B Light-indicator
52 318122007 A B Spring element mtg
52A 318122006 A B Spring element mtg
56 5304400427 A B Screw, 6-20 X 1”
94 318132608 A B Insulation top
*5303211311 A B Screw, #8 X 1/2
*5304400428 A B Screw, 8-15 X 1/8
*3131048 A B Screw, 8 X 5/8
TOP/DRAWER
A= FEFD67CH (FEFD67CHSA)
B= FEFD67CH (FEFD67CHBA)

06/99 8
Publication No. FEFD67CH
5995324729 DOOR
39
20
20
3
23
17
16
23
9
6
3A
3B
54
54
54
1
42
18
12
4
10
LAP23CD015
29
29
31
16
7

# = Functional Part 906/99
* = Non-Illustrated Part
FEFD67CH Publication No.
5995324729
POS
. NO PART NO DESCRIPTION
1 318043100 A B Bracket-trim, handle
3 318049206 ATrim-oven, white
3318049205 BTrim-oven. black
3A 318028900 A B Trim-oven door,upper
3B 318049020 ATrim-oven door,white
3B 318049019 BTrim-oven door, black
4318041110 AGlass-oven door, white
4318041109 BGlass-oven door, black
6 318056802 A B Shield-wool
7 318106001 A B Insulation-door
9 318048802 A B Liner-oven door
10 5303324305 A B Screw, 10-24 X 5/8
12 318053103 A B Seal-oven door
16 318041603 A B Glass-oven door, heat barrier
17 318042102 A B Spacer-glass
18 318053001 A B Seal-rope
20 318014301 ASpacer-handle, white
20 318014300 BSpacer-handle, black
23 5303311215 A B Hinge
29 5303310535 A B Bumper door
31 5303310536 A B Latch-door
39 316091119 AHandle-door, white
39 316091118 BHandle-door, black
42 5303311194 ATrim-oven door, white
42 5303311200 BTrim-oven door, black
54 5303317175 AScrew,8-18 X ½ white
54 5303308456 BScrew, 8-18 X 0.531 black
* 5303211311 A B Screw,#8 x 1/2
*08016432 A B Screw truss head 8-18 x 3/8
*3201899 A B Washer hinge assy
DOOR
A= FEFD67CH (FEFD67CHSA)
B= FEFD67CH (FEFD67CHBA)

06/99 10
Publication No. FEFD67CH
5995324729 WIRING DIAGRAM
