Frigidaire FEFS52D User manual

FEFS52D.eps L20G0037.eps T20V0037.eps T20T0001.eps T20D0004.eps
316417700d.eps 316417700s.eps
Product No. FEFS52DQA FEFS52DSA
Series 30" f/s elec 30" f/s elec
Color bisque white
Market North America North America
Wiring Diagram 316417700 316417700
Owner's Guide 316417000 316417000
Installation Instructions 316259206 316259206
Service Data Sheet 316218513 316218513
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995416756
04/09/21
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEFS52D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995416756 FEFS52D
09/04 2
BACKGUARD

FEFS52D Publication No: 5995416756
# Functional Parts 3 09/04
* Non-Illustrated Parts
BACKGUARD
Model Index: AFEFS52D (FEFS52DSA)
BFEFS52D (FEFS52DQA)
POS. NO PART NO. DESCRIPTION
1 316239900 A B Shield, backguard, rear wall
11 316241000 A B Shield, end cap, RH
11A 316241001 A B Shield, end cap, LH
14 316022500 A B Light/Lamp, indicator, 125 V
15 316220214 A - Support, backguard, white, RH
15 316220218 - B Support, backguard, bisque, RH
15A 316220215 A - Support, backguard, white, LH
15A 316220219 - B Support, backguard, bisque, LH
18 316240900 A - End Cap, white, RH
18 316240906 - B End Cap, bisque, RH
18A 316240901 A - End Cap, white, LH
18A 316240907 - B End Cap, bisque, LH
19 316244485 A - Panel, backguard, white
19 316244487 - B Panel, backguard, bisque
20 # 316418200 A B Clock/Timer, electronic, ES300
20A 316419104 A - Overlay, clock, white, ES300
20A 316419105 - B Overlay, clock, bisque, ES300
23 316245900 A B Bracket, clock mtg
24 316246000 A - Switch, rocker, white, oven light
24 316246002 - B Switch, rocker, bisque, oven light
31 316223000 A - Knob, control, white
31 316223003 - B Knob, control, bisque
46 316040201 A B Lens, indicator light, red
54 # 316021500 A B Switch, infinite, small element
54A# 316021501 A B Switch, infinite, large element
56 316234001 A - Shield, backguard, white, inner
56 316234004 - B Shield, backguard, bisque, inner
69 5303288565 A B Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black

Publication No: 5995416756 FEFS52D
09/04 4
BODY

FEFS52D Publication No: 5995416756
# Functional Parts 5 09/04
* Non-Illustrated Parts
BODY
Model Index: AFEFS52D (FEFS52DSA)
BFEFS52D (FEFS52DQA)
POS. NO PART NO. DESCRIPTION
1 316401800 A B Panel, main back
3 316400102 A - Panel, bodyside, white, RH
3 316400103 A - Panel, bodyside, white, LH
3 316400106 - B Panel, bodyside, bisque, RH
3 316400107 - B Panel, bodyside, bisque, LH
4 316201401 A B Burner Box
5 316272900 A B Screw, leveling, plastic, rear, (2)
5A 316407200 A B Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B Rack, oven
8 316400601 A B Panel, oven bottom
12 # 316407101 A B Switch, oven light/door
14 316116400 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, oven light
16 08011086 A B Lens, oven light, glass
17 316087500 A B Retainer, lens
18 # 316405800 A B Latch Assembly, oven door
21 316408000 A B Clip, bodyside
25 3200848 A B Shield, heat, lower
28 316045000 A B Clip, wiring harness, green, main top
29 316407300 A B Glide, drawer, front
37 # 316217001 A B Probe, oven temp
42 316407700 A B Shield, wool, lower
57 316422400 A B Cover, access
58 316403800 A B Insulation, oven bottom
58A 316406600 A B Insulation, oven wrapper
58B 316406500 A B Insulation, oven back
59 316073606 A B Tube, oven vent
62 5303935238 A B Terminal Block Kit, w/ground plate
62* 316085600 A B Insulator
62* 316205500 A B Nut, hex flange, 3/8 10-32
63 316278800 A B Plate, grounding strap
66 # 316203200 A B Element, broil
67 316075103 A B Element, bake
68 316404000 A B Support, element, broil
71 316422300 A B Shield, rear wall
86 316407000 A B Receptacle, hinge
86* 316418901 A B Screw, trilobe, 10-32 x 5/16"
87 316081200 A B Bracket, cable mtg
88 316203500 A B Rod, auto latch
89 # 316415400 A B Motor, latch/lock
151 316404600 A B Shield, bodyside
170 5303935180 A B Anti-tip Kit, w/bracket, screw
170* 316107200 A B Bracket, anti-tip
170* 316112500 A B Template, anti-tip
170* 316116000 A B Screw, concrete, 1.75", anti-tip brkt
* # 316416401 A B Harness, wiring, main
* 3203550 A B Plug, button, oven bottom
* 5303305324 A - Paint, touch-up, white
* 5304414035 - B Paint, touch-up, bisque
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B Screw, 8-18 x 0.5, black
* 316089500 A B Screw, 10-16 x .486
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black
* 5308014215 A B Screw, 6-20 x 0.312

Publication No: 5995416756 FEFS52D
09/04 6
TOP/DRAWER

FEFS52D Publication No: 5995416756
# Functional Parts 7 09/04
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFEFS52D (FEFS52DSA)
BFEFS52D (FEFS52DQA)
POS. NO PART NO. DESCRIPTION
1 316408701 A B Drawer, utility
2 316403301 A B Liner, drawer
4 316403501 A - Panel, drawer front, white
4 316403503 - B Panel, drawer front, bisque
7 316407400 A B Glide, drawer, rear
15 # 3051450 A B Element, surface, 8" large
15A# 3051449 A B Element, surface, 6" small
16 316202307 A - Main Top, white
16 316202309 - B Main Top, bisque
17 316057601 A B Rod, support, main top
18 316235900 A B Hinge, main top, RH
18A 316235901 A B Hinge, main top, LH
19 5303935054 A B Pan, surface element, large/8 inch
19A 5303935057 A B Pan, surface element, small/6 inch
27 # 5303912666 A B Terminal Block Kit, surface element
28 5303017715 A B Medallion, 1 1/2"dia, black, surface element
* # 316253501 A B Wiring Harness, surface element
* 316058600 A B Clip, surface element, chrome, (4)
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black
* 5308014215 A B Screw, 6-20 x 0.312

Publication No: 5995416756 FEFS52D
09/04 8
DOOR

FEFS52D Publication No: 5995416756
# Functional Parts 9 09/04
* Non-Illustrated Parts
DOOR
Model Index: AFEFS52D (FEFS52DSA)
BFEFS52D (FEFS52DQA)
POS. NO PART NO. DESCRIPTION
3 5303935243 A - Trim kit-door, 3 sided, white, w/tape
3 5303935244 - B Trim kit-door, 3 sided, bisque, w/tape
4 316406403 A - Glass, oven door, white, outer
4 316406405 - B Glass, oven door, bisque, outer
6 316406305 A B Shield, wool
7 316405601 A B Insulation, oven door
8 316427700 A B Glass, oven door, inner
9 316406005 A B Liner, oven door
10 316001009 A B Screw, waf hd sq, 10-24 x 1.88, (2), handle mtg
10B 316008401 A B Washer, 3/4 OD x 1/4 ID, steel
12 316405000 A B Seal, oven door
17 316408801 A B Spacer, door glass, (2)
20 316248401 A B Spacer, handle, white, (2)
23 316406910 A B Hinge, oven door
23* 316418900 A B Screw, sims lp, #8-32 x 5/16", black
39 316248301 A - Handle, oven door, white
39 316248304 - B Handle, oven door, bisque
52 316405100 A - Cap, door trim, white
52 316405102 - B Cap, door trim, bisque
54 316427801 A B Deflector, door hinge, (2)
60B 316021110 A B Screw, 8-18 x 0.5, black
* 316433603 A B Label, anti-tip
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995416756 FEFS52D
09/04 10
WIRING SCHEMATIC
