Frigidaire FES367CE User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FES367CESC 37956336G6013 WHITE U.S.A.
FES367CESE 37956336G6015 WHITE U.S.A.
FES367CEBC 37956336G6063 BLACK U.S.A.
FES367CEBE 37956336G6065 BLACK U.S.A.
FES367CETC 37956336G6033 ALMOND U.S.A.
FES367CETE 37956336G6035 ALMOND U.S.A.
ELECTRIC - RANGE
Model No.
FES367CE
©1998 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC SLIDE-IN RANGE
WIRING DIAGRAM # - 318045022
OWNER’S GUIDE # - 318200806
TIMER INSTRUCTION GUIDE # - 318130805
INSTALLATION INSTR. # - 318104602
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995315347
981124
-EN/SERVICE
377

Publication No. FES367CES/C/B
5995315347
11/98 2
BACKGUARD
20
LAP23G0047F
54
54
14
14
23
69
18A
54
54
21
102
19
64 18
36
36
36
36
42
242424B
46
46

FES367CES/B/T Publication No.
5995315347
# = Functional Part 311/98
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
14 5303051533 AB C D E F Light/Lamp/ Lampe témoin
18 5303304668 AB End Cap white RH/ Embout dosseret
18 5303300160 C D End Cap black RH/ Embout dosseret
18 5303304669 E F End Cap almond RH/ Embout dosseret
18A 5303304671 AB End Cap white LH/ Embout dosseret
18A 5303300161 C D End Cap black LH/ Embout dosseret
18A 5303304672 E F End Cap almond LH/ Embout dosseret
19 318005509 AB Panel-control/ Tableau commande
19 318005511 C D Panel-control/ Tableau commande
19 318005510 E F Panel-control/ Tableau commande
20 # 318012912 AB Clock/Timer/ Minuterie électronique
20# 318012914 C D Clock/Timer/ Minuterie électronique
20# 318012913 E F Clock/Timer/ Minuterie électronique
21 318027801 ATrim-backguard/ Moulure supérieure
21 318027804 B Trim-backguard/ Moulure supérieure
21 318027800 C Trim-backguard/ Moulure supérieure
21 318027803 D Trim-backguard/ Moulure supérieure
21 318027802 E Trim-backguard/ Moulure supérieure
21 318027805 F Trim-backguard/ Moulure supérieure
23 318015505 AC E Bracket-clock mtg/ Support minuterie
23 318015020 B D F Bracket-clock mtg/ Support minuterie
24 # 316005607 AB Switch-rocker / Interrupteur bascule
24# 316005612 C D Switch-rocker / Interrupteur bascule
24# 316005608 E F Switch-rocker/ Interrupteur bascule
24B# 316076301 A B Switch-rocker white/ Interrupteur bascule
24B# 316076300 C D Switch-rocker grey/ Interrupteur bascule
24B# 316076302 E F Switch-rocker almond/ Interr. bascule
36 318016300 AB Knob-surface unit white/ Bouton & coller.
36 318016302 C D Knob-surface unit black/ Bouton & coller.
36 318016304 E F Knob-surface unit almond/ Bouton & col.
42 318106901 ATrim-vent/ Moulure inférieure
42 318106904 B Trim-vent/ Moulure inférieure
42 318106900 C Trim-vent/ Moulure inférieure
42 318106903 D Trim-vent/ Moulure inférieure
42 318106902 E Trim-vent/ Moulure inférieure
42 318106905 F Trim-ven/ Moulure inférieure
46 5308006417 AB C D E F Lens-light/lamp/ Lentille lampe témoin
54 # 318120501 AB C D E F Switch-surface unit/ Com. Réglage cont.
64 318112200 AB C D E F Plate/ Plaque montage interrupteur
69 5303323134 AB C D E F Screw, 8-32 X 3/16/ Vis
102 318055600 AB C D E F Bracket-mounting/ Support
*5303211311 AB C D E F Screw, #8 X ½/ Vis
*08016432 AB C D E F Screw, 8-18 X 3/8 Vis
*5303323145 AB C D E F Nut/ Écrou
*08002868 AB C D E F Screw, 10-24 x ½/ Vis
* 5303311124 A B C D E F Screw, clock (4)/ Vis
A= FES367CE (FES367CESC)
B= FES367CE (FES367CESE)
C= FES367CE (FES367CEBC)
D= FES367CE (FES367CEBE)
E= FES367CE (FES367CETC)
F= FES367CE (FES367CETE)

FES367CES/B/T Publication No.
5995315347
11/98 4
BODY
63
68
170
170A
5
3B
102
191
62
71
87
80
LAP23V0072D
6
67
25
83
58B
142
58A
2A
88
89 108
59
141
10
9
37
12
129
128
70
3
70
114
114
1A
62
14
54 15 16
17
81
81
1
56
56
41
86
86
76 41
217
127 66
3A
5
102
5
177
39

FES367CES/B/T Publication No.
5995315347
# = Functional Part 511/98
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
15303310527 AB C D E F Back-main/ Panneau arrière
1A 5303311161 AB C D E F Panel back/ Panneau arrière supérieur
2A 318108600 AB C D E F Shield-oven top/ Panneau isolant sup.
35303300143 AB C D E F Panel-bodyside/ Panneau sup. Latéral
3A 5303280349 AB C D E F Panel-bodyside RH/ Panneau latéral
3B 5303280351 AB C D E F Panel-bodyside LH/ Panneau latéral
5318175500 AB C D E F Screw leveling/ Vis nivellement
65303310522 AB C D E F Rack oven/ Grille four
95303317977 AB C D E F Pan broiler/ Lechefrite
10 5303317976 AB C D E F Insert-broiler pan/ Couvercle lechefrite
12# 318089910 AB C D E F Switch-light/ Interrupteur lumière
14 5308011085 AB C D E F Socket-light/lamp/ Douille lumière
15 3201908 AB C D E F Lamp-oven light/ Ampoule électrique
16 3201911 AB C D E F Glass-oven light lens/ Protège-lampe
17 5304400195 AB C D E F Retainer-lens/ Broche retenue
25 5303311141 AB C D E F Shield-heat/ Panneau isolant dessous
37 # 316111201 AB C D E F Probe-oven temp/ Sonde
41 5303310526 AB C D E F Cover-hinge cutout/ Plaque déc. charn.
54 5303310514 AB C D E F Housing-oven light/ Boîtier lumière four
56 318002602 AB Trim-oven front white/ Moul. devant four
56 318002601 C D Trim-oven front black/ Moul. devant four
56 318002603 E F Trim-oven front almond/Moul. Dev. four
58A 5303310539 AB C D E F Insulation/ Isolant
58B 5303310538 AB C D E F Insulation oven back/ Isolant
59 318072502 AB C D E F Tube-oven vent/ Tube ventilation
62 # 5303310518 AB C D E F Terminal Block/ Bloc connexion
63 5303310517 AB C D E F Plate-ground strap/Plaque mise a la terre
66 # 5303310513 AB C D E F Element-broil/ Élément grillage
67 # 5303310512 AB C D E F Element-bake/ Élément cuisson
68 5304403015 AB C D E F Support-element/ Support élément
70 5303300142 AB C D E F Shield-insulation/ Panneau isolant latéral
71 5303310515 AB C D E F Cover-wiring/ Panneau recouvrement
76 318124100 AB C D E F Front-oven/ Encadrement avant four
80 5303324473 AB C D E F Bracket-oven / Support de four
81 5303301261 AB C D E F Spring-oven/ Attache four
83 318089608 AB C D E F Liner-oven/ Ass. four
86 5303310524 AB C D E F Channel-hinge/ Réceptacle charnière
87 318111800 AB C D E F Plate-mounting/Plaque mtg cordon d’alim
88 5303311160 AB C D E F Rod-latch/ Tige-verrou
89 # 5304404899 AB C D E F Motor-latch/ Ass. Moteur & came
89 * 318120702 AB C D E F Switch latch/ Commutateur moteur
102 5303311142 AB C D E F Support-oven front/ Support avant
108# 318073001 AB C D E F Motor-fan/ Soufflerie
114 3051827 AB C D E F Plate-filler/ Plaque
127 5303310542 AB C D E F Adapter assy/ Ass. adapteur
128 5303311163 AB C D E F Bushing/ Bague
129 5303311164 AB C D E F Spring/ Ressort
141 # 5303284446 AB C D E F Switch/ Protecteur thermique
142 318123901 AB C D E F Deflector/ Déflecteur
170 3203576 AB C D E F Anti-tip bracket right/ Sup. anti-basculant
170A 3203575 AB C D E F Anti-tip bracket left/ Sup. Anti-basculant
177 5303324040 AB C D E F Gasket-vent/ Joint d’étanchéité
191 5303304030 AB C D E F Bracket / Support
217 316042300 AB C D E F Warning plate/ Plaque d’avertissement
* 5303211311 AB C D E F Screw #8 X ½/ Vis
*5303311124 AB C D E F Screw clock/ Vis
A= FES367CE (FES367CESC)
B= FES367CE (FES367CESE)
C= FES367CE (FES367CEBC)
D= FES367CE (FES367CEBE)
E= FES367CE (FES367CETC)
F= FES367CE (FES367CETE)

FES367CES/B/T Publication No.
5995315347
11/98 6
TOP/DRAWER
2
6
6
1
LAP23T0005
4
11
11
13
70
72
13A
72
71
51
53
15B
15A
15B
55
55
55
55
56
56
52 52
52
15
16

FES67CES/B/T Publication No.
5995315347
# = Functional Part 711/98
* = Non-Illustrated Part
TOP/DRAWER
POS. NO PART NO DESCRIPTION
1 5303310500 AB C D E F Drawer-utility/ Tiroir
2318108000 AB C D E F Liner Drawer/ Panneau int. tiroir
4 5303311126 AB Panel-drawer/Panneau avant tiroir
45303311178 C D Panel-drawer/ Panneau avant tiroir
45303311131 E F Panel-drawer/ Panneau avant tiroir
65303311190 AB C D E F Support-element/ Support élément
11 5303311125 AB C D E F Bracket-drawer/ Cornière tiroir
13 5303311129 AB C D E F Channel-drawer RH/ Glissière tiroir
13A 5303311130 AB C D E F Channel-drawer LH/ Glissière tiroir
15# 318178002 AB C D E F Element-surface dual/ Élém.1000/2000W
15A# 318178101 AB C D E F Element-surface/ Ass. Élément 2100W
15B# 318178100 AB C D E F Element-surface/ Ass. Élément 1200W
16 318079501 AB Main Top white/ Table de cuisson
16 318079503 C D Main Top black/ Table de cuisson
16 318079502 E F Main Top black/ Table de cuisson
51# 5303297484 AB C D E F Light-indicator/ Lampe témoin
52 5303317177 AB C D E F Spring-element mtg/ Ressort
53 318125910 AB C D E F Bracket-indicator light/ Support
55 5303317178 AB C D E F Spacer-element/ Entretoise
56 5303317179 AB C D E F Screw, 6 X ¾/ Vis
70 5303311143 AB C D E F Bracket-slide/ Support arrière glissière
71 5303311144 AB C D E F Magnet & spring assy/ Aimant & ressort
72 5303311145 AB C D E F Bracket & wheel assy/ Ass. Sup. & roulette
*5303211311 AB C D E F Screw, #8 X ½/ Vis
A= FES367CE (FES367CESC)
B= FES367CE (FES367CESE)
C= FES367CE (FES367CEBC)
D= FES367CE (FES367CEBE)
E= FES367CE (FES367CETC)
F= FES367CE (FES367CETE)

Publication No. FES367CES/B/T
5995315347
11/98 8
DOOR
3
23
17
23
9
6
3A
3B
54
1
39
42
18
12
4
10
A23CD018
29
29
16
20
20
31
16
7

FES367CES/B/T Publication No.
5995315347
# = Functional Part 911/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
1 318043100 AB C D E F Bracket-trim/ Support montage
3 318049206 AB Trim-oven door white/ Moulure lat. porte
3318049205 C D Trim-oven door black/ Moulure lat. Porte
3318049207 E F Trim-oven door almond/ Moul. Lat. porte
3A 318028900 AB C D E F Trim-oven door/ Moulure sup. pan. verre
3B 318049020 AB Trim-oven door white/ Moulure sup. porte
3B 318049019 C D Trim-oven door black/ Moulure sup. Porte
3B 318049021 E F Trim-oven door almond/ Moul. Sup. porte
4 318041102 AB Glass-oven door white / Pan. Ver. déco.
4318041105 C D Glass-oven door black / Pan. Verre déco
4318041103 E F Glass-oven door almond/ Pan. Verre déco
6 318056802 AB C D E F Shield-insulation/ Déflecteur porte
7 318106001 AB C D E F Insulation-door/ Isolant
9 318048802 AB C D E F Liner-oven door/ Ass. Contre-porte
10 5303324305 AB C D E F Screw 10-24 X 5/8/ Vis
12 318053103 AB C D E F Seal-oven door/ Joint contre-porte
16 318041603 AB C D E F Glass-oven door/ Panneau verre
17 318042102 AB C D E F Spacer-glass/ Encadrement intérieur
18 318053001 AB C D E F Seal-window/ Joint
20 318014301 AB Spacer-handle white/ Entretroise poignée
20 318014300 C D Spacer-handle black/ Entretoise poignée
20 318014302 E F Spacer-handle almond/ Entretoise poignée
23 5303311215 AB C D E F Hinge-oven door/ Ass. charnière
23* 3201899 AB C D E F Washer/ Rondelle plate
29 5303310535 AB C D E F Bumper base/ Entretoise caoutchouc
31 5303310536 AB C D E F Latch-door/ Gâche porte
39 316091119 AB Handle-door white/ Poignée porte blanche
39 316091121 C D Handle-door black/ Poignée porte noire
39 316091120 E F Handle-door almond/ Poignée porte aman.
42 5303311194 AB Trim-oven door white/ Moulure inf. porte
42 5303311200 C D Trim-oven door black/ Moulure inf. Porte
42 5303311198 E F Trim-oven door almond/ Mou. Inf. porte
54 5303317175 AB Screw 8-18 X ½ white/ Vis
54 5303308456 C D Screw, 8-18 X ½ black/ Vis
54 5303300265 E F Screw, 8-18 X ½/ Vis
*08016432 AB C D E F Screw, 8-18 X 3/8/ Vis
*5303211311 AB C D E F Screw, #8 X ½/ Vis
*5303307980 AB C D E F Screw, 8-32 X 7/16/ Vis
A= FES367CE (FES367CESC)
B= FES367CE (FES367CESE)
C= FES367CE (FES367CEBC)
D= FES367CE (FES367CEBE)
E= FES367CE (FES367CETC)
F= FES367CE (FES367CETE)

Publication No. FES367CES/B/T
5995315347
11/98 10
WIRING DIAGRAM
