Frigidaire FFGS3025L S User manual

frigidaire.com
Drop-In Cooktop
FPEC3085K S 30" Electric
Slide-In Ranges
FFGS3025L S / W/ B 30" Gas
Signature Features
Large Capacity
Our large capacity oven gives you
room to cook more at once.
Continuous
Cast Iron Grates
Continuous Grates make it easy to
move heavy pots and pans between
burners without lifting.
Ready-Select™ Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.
One-Touch Self Clean
Start the self-cleaning cycle with
just the touch of a button.
Product Dimensions
Height (Adjustable) 35-5/8" – 36-5/8"
Width 30"
Depth 28-5/16"
More Easy-To-Use Features
Sealed Gas Burners
Enjoy easier cleanup and a burner
that stays looking great.
Black Matte Finish with
Cast Iron Grates
A premium finish to complement
the durable burner grates.
Quick Boil
Boil water faster with our
15,000 BTU burner.
Low Simmer Burner
Perfect for delicate foods and sauces.
Even Baking Technology
Our latest technology ensures
even baking every time.
Store-More™ Storage Drawer
Our convenient drawer gives you
extra storage space in your kitchen.
Quick Clean
For a quick, light oven cleaning.
Attractive Stainless Steel Exterior1
LP Gas Conversion Option
A.D.A. Compliant2
Sabbath Mode (Star-K® Certified)
Available in:
1Select model only.
2
When properly installed, meets the appliance
standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility
Guidelines as published by the United States
Access Board on June 23, 2004, as amended
August 5, 2005.
Stainless
(S)
White
(W)
Black
(B)
Burners
Right Front
Right Rear
Left Front
Left Rear
BTU
15,000
5,000
9,500
9,500

Slide-In Ranges
FFGS3025L S / W/ B 30" Gas
Specifications
subject to change.
1 When properly installed, meets the appliance standards in the Americans
with Disabilities Act and the Architectural Barriers Act Accessibility
Guidelines as published by the United States Access Board on June 23,
2004, as amended August 5, 2005.
2 For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
Features
Oven Control / Timing System
Surface Type
Grates
Window
Exterior Door Finish
Handle Design
Exterior Finish
Convection System
Cleaning System
Drawer Functionality
Oven Controls
Bake
Broil
Add-a-Minute
Delay Bake
Self Clean
Quick Clean
Delay Clean
Kitchen Timer
Timed Cook Option
Auto Oven Shuto
Cooktop Features
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Extra Zone Burner (BTU)
Oven Features
Capacity (Cu. Ft.)
Oven Light
Rack Configuration
Even Baking System
Broiling System
Bake Burner / Broil Burner (BTU)
Certifications
A.D.A. Compliant1
Sabbath Mode (Star-K® Certified)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Gas Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts 2
Amps @ 120 Volts
Shipping Weight (Approx.)
Installation accessories available
on the web at frigidaire.com
Ready-Select™ Controls
Deep-Well Black Porcelain ( S ),
Deep-Well Color-Coordinated
Porcelain ( W / B )
Continuous Cast Iron
with Black Matte Finish
Extra-Large
Stainless Steel ( S ),
Color-Coordinated ( W / B )
Stainless Steel ( S ),
Color-Coordinated ( W / B )
Black ( S ),
Color-Coordinated ( W / B )
Self Clean
Storage
Yes
Low and High
Yes
2, 3 Hours (Scroll Thru)
Yes
Yes
Yes
Yes
12 Hours
15,000
5,000
9,500
9,500
4.2
Yes
2 Handle Racks
Yes
Vari-Broil™ Hi / Lo
18,000 / 11,500
Yes
Yes
16-1/2" x 24-1/8" x 18-1/32"
Left Bottom Rear
Right Bottom Rear
120V / 60 Hz / 15A
.7
6
250 Lbs.
*Cutout and countertop cutout width should match.
**24" with optional backguard installed.
Cutout Dimensions
Height
Width
Depth
35-7/8" min.
36-5/8" max.
30-1/16" max.*
21-3/4" min
22-1/8" max.**
Product Dimensions
A - Height (Adjustable)
B - Width
C - Depth
Depth with Door Open 90˚
35-5/8" – 36-5/8"
30"
28-5/16"
45-1/2"
NOTE: Always consult local and national electric and gas codes. Refer to Product
Installation Guide for detailed installation instructions on the web at frigidaire.com.
Slide-In Gas Ranges
Frigidaire Baseline
B
AExtreme
protrusion
C
USA
•
250 Bobby Jones Expressway
•
Martinez, GA 30907
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFGS3025L 02/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
