Frigidaire FGFL83D User manual

FGFL83D.eps T24G0014.eps T24B0004.eps T24V0025.eps T24T0028.eps T24D0005.eps
316417805d.eps 316417805s.eps
Product No. FGFL83DQA FGFL83DSA
Series 30" f/s gas 30" f/s gas
Color bisque white
Market North America North America
Wiring Diagram 316417805 316417805
Owner's Guide 316417102 316417102
Installation Instructions 316259336 316259336
Service Data Sheet 316417603 316417603
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995420469
04/10/29
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGFL83D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995420469 FGFL83D
10/04 2
BACKGUARD

FGFL83D Publication No: 5995420469
# Functional Parts 3 10/04
* Non-Illustrated Parts
BACKGUARD
Model Index: AFGFL83D (FGFL83DSA)
BFGFL83D (FGFL83DQA)
POS. NO PART NO. DESCRIPTION
1 316416100 A B Shield, backguard, rear wall
2 316051600 A B Shield, backguard, inner
2A 316235100 A B Shield, top, inner
15 316411403 A - Support, backguard, white, RH
15 316411407 - B Support, backguard, bisque, RH
15A 316411402 A - Support, backguard, white, LH
15A 316411406 - B Support, backguard, bisque, LH
19 316424187 A - Panel, control, white
19 316424189 - B Panel, control, bisque
20 # 316418309 A B Clock/Timer, electronic, ES340
20A 316419304 A - Overlay, clock, white, ES340
20A 316419305 - B Overlay, clock, bisque, ES340
36 316220000 A - Knob, top valve, white, (4)
36 316220003 - B Knob, top valve, bisque, (4)
40 316204920 A - Panel, manifold, white
40 316204922 - B Panel, manifold, bisque
42 316416201 A - Trim, extrusion, gray
42 316416202 - B Trim, extrusion, tan
56 316230701 A B Shield, backguard, inner
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black

Publication No: 5995420469 FGFL83D
10/04 4
BURNER

FGFL83D Publication No: 5995420469
# Functional Parts 5 10/04
* Non-Illustrated Parts
BURNER
Model Index: AFGFL83D (FGFL83DSA)
BFGFL83D (FGFL83DQA)
POS. NO PART NO. DESCRIPTION
1 # 316219500 A B Pipe, manifold
2 # 5303935233 A B Valve, 17K burner, w/mtg screw
2A # 5303935235 A B Valve, 5K burner, w/mtg screw
2B # 5303935232 A B Valve, 9.5k/12k burner, w/mtg screw
2C # 5303935234 A B Valve, 9.5K burner, w/mtg screw
* 316215600 A B Screw, valve mtg., 1/4 - 20
3 # 316219004 A B Wiring Harness, w/igntr switch
8 # 316135701 A B Module, spark
10 # 316223300 A B Burner, sealed, 17K
10A# 316206400 A B Burner, sealed, 5K
10B# 316212300 A B Burner, sealed, 12K
10C# 316212400 A B Burner, sealed, 9.5K
11 # 316430500 A B Ignitor/orifice assy., top burner, right front, 16K, w/holder, tube
11A# 316430800 A B Ignitor/orifice assy., top burner, right rear, 5K, w/holder, tube
11B# 316430401 A B Ignitor/orifice assy., top burner, left rear, 12K, w/holder, tube
11C# 316430600 A B Ignitor/orifice assy., top burner, left front, 9.5K, w/holder, tube
13 # 316405300 A B Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 A B Regulator, pressure
14* 316021104 A B Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 A B Bracket, regulator
16 # 316405500 A B Tube, valve to regul., 3/8
17 # 316404900 A B Valve, safety
17* 08068018 A B Shield, wire, safety valve
18 # 316404400 A B Burner, oven
19 # 316428500 A B Ignitor, oven burner
20 316401401 A B Baffle, oven burner
21 5303013272 A B Nut, hex head sems
22 # 316405400 A B Tube, valve to mixer
23 # 316404300 A B Burner, broiler
24 # 316409700 A B Elbow, mixer
25 316401301 A B Baffle, broil burner
26 # 316428600 A B Ignitor, burner
26* 316401500 A B Cover, broil Ignitor
37 316240600 A B Screw, assy mtg, ignitor/orifice
44 316237912 A B Orifice, top burner, 16K
44A 316237903 A B Orifice, top burner, 5K
44B 316237901 A B Orifice, top burner, 12K
44C 316237902 A B Orifice, top burner, 9.5K
47 GRLP2 A B LP Conversion Kit, w/instructions
47* 316248105 A B Instructions, LP kit
* # 316253700 A B Wiring Harness, ignitor module
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995420469 FGFL83D
10/04 6
BODY

FGFL83D Publication No: 5995420469
# Functional Parts 7 10/04
* Non-Illustrated Parts
BODY
Model Index: AFGFL83D (FGFL83DSA)
BFGFL83D (FGFL83DQA)
POS. NO PART NO. DESCRIPTION
1 316401601 A B Back, main
2 316402201 A B Shield, oven top
2* 316437100 A B Brace, oven top
3 316400102 A - Panel, bodyside, white, RH
3 316400103 A - Panel, bodyside, white, LH
3 316400106 - B Panel, bodyside, bisque, RH
3 316400107 - B Panel, bodyside, bisque, LH
4 316201403 A B Burner Box
5 316272900 A B Screw, leveling, plastic, rear, (2)
5A 316407200 A B Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B Rack, oven
8 316400603 A B Panel, oven bottom
12 # 316407100 A B Switch, oven light/door
14 316116400 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, oven light
16 08011086 A B Lens, oven light, glass
17 316087500 A B Retainer, lens
18 # 316405800 A B Latch Assembly, oven door
21 316408000 A B Clip, bodyside
25 316406200 A B Shield, heat, lower
29 316407301 A B Glide, drawer, front
30 316217700 A B Bracket, hinge, RH, main top
30A 316217701 A B Bracket, hinge, LH, main top
33 316405900 A B Shield, rear wall
35 316116600 A B Gasket, flue
36 316208901 A B Flue
37 # 316217001 A B Probe, oven temp
39 3202006 A B Cord, electric power
42 316400703 A B Shield, wool, lower
43 3131732 A B Screw, 8-18 x 1.438, oven bottom
44 316246501 A B Spacer, oven door
49 316234200 A B Clip, maintop mtg, (2)
54 316404200 A B Shield, heat
55 316404800 A B Shield, flue
58A 316403700 A B Insulation, oven wrapper
58B 316403600 A B Insulation, oven back
58G 08067973 A B Insulation, main front
82 316400801 A B Shield, bake burner
82* 316432800 A B Clip, wire
86 316407000 A B Receptacle, hinge
86* 316418901 A B Screw, trilobe, 10-32 x 5/16"
87 316401200 A B Bracket, harness
88 316232700 A B Rod, auto latch
89 # 316415400 A B Motor, latch/lock
90 316401100 A B Shield, main front
91 316401000 A B Shield, front, burner
151 316404600 A B Shield, bodyside
170 5303935180 A B Anti-tip Kit, w/bracket, screw
170* 316107200 A B Bracket, anti-tip
170* 316112500 A B Template, anti-tip
170* 316116000 A B Screw, concrete, 1.75", anti-tip brkt
* 316416604 A B Harness, wiring, main
* 5303305324 A - Paint, touch-up, white
* 5304414035 - B Paint, touch-up, bisque
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B Screw, 8-18 x 0.5, black
* 316089500 A B Screw, 10-16 x .486
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420469 FGFL83D
10/04 8
TOP/DRAWER

FGFL83D Publication No: 5995420469
# Functional Parts 9 10/04
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFGFL83D (FGFL83DSA)
BFGFL83D (FGFL83DQA)
POS. NO PART NO. DESCRIPTION
1 316408701 A B Drawer, utility
2 316403200 A B Liner, drawer
4 316403401 A - Panel, drawer, white, front
4 316403403 - B Panel, drawer, bisque, front
7 316407400 A B Glide, drawer, rear
16 316411212 A - Maintop, white
16 316411213 - B Maintop, bisque
20 316424605 A - Grate, gray, (2)
20 316424604 - B Grate, brown, (2)
20A 316424705 A - Grate, center, gray
20A 316424704 - B Grate, center, brown
22 316271901 A - Cap, 17K burner, gray
22 316271902 - B Cap, 17K burner, brown
22A 316206601 A - Cap, 5K burner, gray
22A 316206602 - B Cap, 5K burner, brown
22B 316213601 A - Cap, 12K burner, gray
22B 316213603 - B Cap, 12K burner, brown
22C 316213501 A - Cap, 9.5K burner, gray
22C 316213503 - B Cap, 9.5K burner, brown
88 316099500 A B Pin, guide, (2)
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black

Publication No: 5995420469 FGFL83D
10/04 10
DOOR

FGFL83D Publication No: 5995420469
# Functional Parts 11 10/04
* Non-Illustrated Parts
DOOR
Model Index: AFGFL83D (FGFL83DSA)
BFGFL83D (FGFL83DQA)
POS. NO PART NO. DESCRIPTION
3 316402001 A - Trim, oven door, white
3 316402003 - B Trim, oven door, bisque
4 316402600 A - Glass, door, white
4 316402602 - B Glass, door, bisque
6 316402307 A B Shield, wool
7 316403900 A B Insulation, oven door
8 316117500 A B Glass, oven door, heat barrier
9 316423801 A B Liner, oven door
10 316422204 A B Screw, 10-24 x 2.02", (2)
10B 316008401 A B Washer, 3/4 OD x 1/4 ID, steel
12 316403101 A B Seal, oven door
17 316402403 A B Spacer, door glass, (2)
23 316406909 A B Hinge, oven door
23* 316418900 A B Screw, sims lp, #8-32 x 5/16", black
39 316203001 A - Handle, door, white
39 316203003 - B Handle, door, bisque
52 316405100 A - Cap, door trim, white
52 316405102 - B Cap, door trim, bisque
54 316427801 A B Deflector, door hinge, (2)
60B 316021110 A B Screw, 8-18 x 0.5, black
* 316433603 A B Label, anti-tip
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420469 FGFL83D
10/04 12
WIRING SCHEMATIC

FGFL83D Publication No: 5995420469
# Functional Parts 13 10/04
* Non-Illustrated Parts
WIRING DIAGRAM
