;;ii;;iii
6
Lce Controls ............... 8
Oven Control Functions ................ 9
Setting Oven Controls ............ 10-12
Self Cleaning ........................... 13-14
General Care & Cleaning ....... 15-18
Adjusting Oven Temperature ....... 18
Before You Call
Solutions to Common Problems .................... 19
Warranty ......................... Back Page
READ AND SAVE THESE INSTRUCTIONS pin 316417140 (0803)
Congratulations on your purchase of a new range! At Electrolux Home Products, we are very proud of our product and are
completely committed to providing you with the best service possible. Your satisfaction isour number one priority.
We know you'll enjoy your new range and Thank You for choosing our product. We hope you consider us for future purchases.
PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating instructions for your model. Use your range only as instructed in this
manual. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and
caution must be practiced when installing, operating and maintaining any appliance.
Please record your model and serial numbers below for future reference.
Model Number:
Serial Number:
Purchase Date:
Product Registration
(
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should befilled
in completely, signed and returned to Electrolux Home Products.
This Use & Care Manual contains general operating instructions for
your range and feature information for several models, Your range may
not have all the described features, The graphics shown are
representational. The graphics on your range may not look exactly like
those shown.
Serial plate location;
Open storage drawer (some models)
or remove outer lower panel (some models).
© 2008 Electrolux Home Products, Inc.
All rights reserved. 2
Important Safety instructions
Read all instructions before using this appliance. Save these instructions for future reference.
This manual contains important safety symbols and instructions.Please payattention to these symbols and follow all instructionsgiven.
This symbol will help alert you to situations that may cause senous bodily harm, death or property damage.
This symbol will help alert you to situations that may cause bodily injury or property damage.
If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
-- WHAT TO DO IF YOU SMELL GAS:
.Do not try to light any appliance.
.Do not touch any electrical switch; do not use any
phone in your building.
.immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
.If you cannot reach your gas supplier, call the fire
department.
-- installation and service must be performed by a
qualified installer, servicer or the gas supplier.
•Remove all tape and packaging before using the range.
Destroy the carton and plastic bags after unpacking the
range. Never allow children to play with packaging material.
• Proper Installation--Be sure your appliance is properly
installed and grounded by a qualified technician in
accordance with the National Fuel Gas Code ANSi
Z223.- latest edition, or in Canada CAN/CGA B149.1, and
CAN/CGA B149.2, and the the National Electrical Code
ANSI/NFPA No.70-1atest edition, or in Canada CSA
Standard C22.1, Canadian Electrical Code, Part 1, and
local code requirements. Install only per installation
instructions provided in the literature package for this range.
Ask your Sears dealer to recommend a qualified technician
and an authorized Sears repair service. Know how to disconnect
the power to the range at the circuit breaker or fuse box in
case of an emergency.
• User servicing--Do not repair or replace any part of the
appliance unless specifically recommended in the
manuals. All other servicing should be done only by a
qualified technician, This may reduce the risk of personal
injury and damage to the range.
•Never modify or alter the construction of a range by
removing leveling legs, panels, wire covers, anti-tip
bracketslscrews, or any other part of the product.
•Air curtain or other overhead range hoods, which
operate by blowing a downward air flow on to a range,
shall not be used in conjunction with gas ranges other
than when the hood and range have been designed,
tested and listed by an independent test laboratory for
use in combination with each other.
f
• All ranges can tip.
• Injury to persons could result.
• Install anti-tip device packed with range.
• See Installation Instructions.
_To reduce the risk of
tipping, the rangemust be secured by
properly installed anti-tip bracket provided
with the range. To check if the bracket is
installed properly, visually check that rear
leveling leg is inserted into and fully
secured by the anti-tip bracket by
removing lower panel or storage drawer.
For models with a warmer drawer, grasp
the top rear edge of the range and
carefully attempt to tilt it forward. Refer to
the installation instructions for proper anti-
_. tip bracket installation. _,
Stepping, leaning or sitting on the doors
or drawers of this range can result in serious injuries
and also cause damage to the range. Do not allow
children to climb or play around the range. The weight of a child
on an open door may cause the range to tip, resulting in
serious burns or other injury.
NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning.
NEVER cover any slots, holes or passages
in the oven bottom or cover an entire rack with materials
such as aluminum foil. Doingso blocksair flow throughthe
oven and may cause carbon monoxide poisoning.Aluminum foil
linings may trap heat, causing a fire hazard.
Do not use the oven or warmer drawer
(if equipped) for storage.
.Storage in or on Appliance--Flammable materials
should not be stored in an oven, warmer drawer, near
surface burners or in the storage drawer. This includes
paper, plastic and cloth items, such as cookbooks, plasticware
and towels, as well as flammable liquids. Do not store
explosives, such as aerosol cans, on or near the range.
Do not store items of interest to children
in the cabinets above a range or on the backguard of
a range. Children climbing on the range to reach items could
be seriously injured.
lmportant Safety instructions
•Do Not Leave Children Alone--Children should not be left
alone or unattended inthe area where appliance isin use.They
should never be allowed to sit or stand on any part of the
appliance.
•DO NOT TOUCH SURFACE BURNERS, AREAS NEAR THESE
BURNERS, OVEN BURNERS OR iNTERiOR SURFACES OF
THE OVEN. Both surface and oven burners may be hot even
though flames are not visible. Areas near surface burners may
become hot enough to cause burns. During and after use, do not
touch, or let clothing or other flammable materials touch these
areas until they have had sufficient time to cool. Among these
areas are the cook top, surfaces facing the cook top, the oven vent
openings and surfaces near these openings, oven door and
window.
• Wear Proper Apparel--Loose=fitting or hanging garments
should never be worn while using the appliance. Do not let
clothing or other flammable materials contact hot surfaces.
•Do Not Use Water or Flour on Grease Fires--Smother the fire
with a pan lid, or use baking soda, a dry chemical or foam=type
extinguisher.
•When heating fat or grease, watch it closely. Fat or grease may
catch fire if allowed to become too hot.
•Use Only Dry Potholders--Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let potholders
touch hot heating burners. Do not use atowel or other bulky cloth
instead of a potholder.
•Do Not Heat Unopened Food Containers--Buildup of pressure
may cause container to burst and result in injury.
• Remove the oven door from any unused range if it is to be
stored or discarded.
IMPORTANT--ELECTRIC IGNITION MODELS ONLY: Do not
attempt to operate the oven during a power failure. If the power fails,
always turn off the oven. Ifthe oven is not turned off and the power
resumes, the oven will begin to operate again. Once the power
resumes, reset the clock and oven function.
iMPORTANT iNSTRUCTiONS FOR USINGYOUR
COOKTOP
Use Proper Flame Size--Adjust flame size so it
does not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to flame will also improve efficiency.
• Knowwhich knob controls each surface burner. Place a pan of
food on the burner before turning it on, and turn the burner off
before removing the pan.
•Always turn knob to the full LITE position when igniting top
burners. Visually check that burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
• Utensil Handles Should BeTurned Inward and Not Extend Over
Adjacent Surface Burners--To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
that it isturned inward, and does not extend over adjacent surface
burners.
• Never Leave Surface Burners Unattended at High Heat
Settings--Boilovers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
•Protective Liners--Do not use aluminum foil to line surface
burner pans, or oven bottom, except as suggested in this manual.
Improper installation of these liners may result in risk of electric
shock, or fire.
• Glazed Cooking Utensils--Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cooktop service without breaking due to the sudden
change in temperature. Check the manufacturer's
recommendations for cooktop use.
iMPORTANT iNSTRUCTiONS FOR USING YOUR OVEN
• Use Care When Opening Oven Door or Warmer Drawer--
Stand to the side ofthe range when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace food in
the oven.
• Keep Oven Vent Ducts Unobstructed. The oven vent is located
below the backguard. Touching the surfaces inthis area when the
oven is operating may cause severe burns. Also, do not place
plastic or heat-sensitive items on or near the oven vent. These
items could melt or ignite.
• Placement of Oven Racks. Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot use extreme caution. Use potholders and grasp the rack with
both hands to reposition. Do not let potholders contact the hot
heating elements in the oven. Remove all utensils from the rack
before moving.
• Do not usethe broiler pan without its insert. The broiler pan and
its insert allow dripping fat to drain and be kept away from the high
heat of the broiler.
• Do not cover the broiler insert with aluminum foil. Exposed fat
and grease could ignite.
• Cold temperatures can damage the electronic control. When
using the appliance for the first time, or when the appliance has
not been used for an extended period of time, be certain the unit
has been in temperatures above 32°F (0°C) for at least 3 hours
before turning on the power to the appliance.
iMPORTANT iNSTRUCTiONS FOR CLEANING
YOUR RANGE
• Clean the range regularly to keep all parts free of grease that
could catch fire. Pay particular attention to the area underneath
each surface element. Do not allow grease to accumulate. Refer
to the range manufacturer's instructions for cleaning.
•Kitchen cleaners and aerosols--Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and injury.
SELF CLEANING OVENS
• Clean in the self=cleaning cycle only the parts listed in this
Owner's Guide. Before self cleaning the oven, remove the broiler
pan and any utensils or foods from the oven.
• Do Not Use Oven Cleaners--No commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
• Do Not Clean Door Gasket--The door gasket is essential for a
good seal. Care should be taken not to rub, damage or move the
gasket.
important Safety Notice
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn
customers of potential exposure to such substances.
Grounding type
wall receptacle GROUNDING INSTRUCTIONS
(electric ignition models only)
Do not, under any
circumstance, cut,
remove, or bypass
the grounding prong,
Power supply cord
with 3=prong
grounding plug
Seethe INSTALLATION INSTRUCTIONS packaged with this range
for complete installation and grounding instructions,
Avoid fire hazard or electrical shock. Do not use
an adapter plug, an extension cord, or remove grounding prong
from electrical power cord. Failure to followthis warning can cause
serious injury, fire or death.
This appliance is equipped with a 3-prong
grounding plug for your protection against shock hazard and
should be plugged directly into a properly grounded receptacle.
DO NOT cut or remove the grounding prong from this plug.
For personal safety, the range must be properly grounded. For
maximum safety, the power cord must be plugged into an electrical
outlet that is correctly polarized and properly grounded.
If a 2-prong wall receptacle is the only available outlet, it is the
personal responsibility of the consumer to have it replaced with a
properly grounded 3-prong wall receptacle installed by a qualified
electrician.
Conversion to Liquefied Petroleum Gas (or L.R Gas)
The natural gas range is designed to allow for conversion to
Liquefied Petroleum (L.P.) Gas.
If L.P. conversion is needed, contact your local appliance
dealer for assistance. The L.P. Conversion Kit may be
obtained from your appliance dealer and should be installed
by a qualified service technician. Before installing the kit be
sure to follow the L.P. Installation Instructions carefully.
Personal injury or death from electrical
shock may occur if the range is not installed by a qualified
installer or electrician.
Any additions, changes or conversions
required in order for this appliance to satisfactorily meet the
application needs must be made by a qualified technician.
........ _o_ '_ii_ii' _ii_
YourGas Range Features include:
1. Electronic Oven Control with Kitchen Timer.
2. Left Front Burner Valve & Knob.
3. Left Rear Burner Valve & Knob.
4. Right Rear Burner Valve & Knob.
5. Right Front Burner Valve & Knob.
6. Center Burner Valve & Knob.
7. Easy to clean Upswept Cooktop
8. Dishwasher safe Burner Grates (colors vary).
9. Self-Clean Oven Door Latch.
10. Manual Oven Light Switch (some models).
11. Automatic Oven Door Light Switch (some models).
12. Oven Interior Light with Shield (some models).
13. Self-Cleaning Oven interior.
14. Adjustable Oven Rack(s).
15. Large 1 piece Oven Door Handle.
16. Full width Oven Door (styles vary with model).
17. Storage Drawer with integrated Handle (some models) or lower
cover panel (some models).
18. 5,000 BTU Simmer Burner (some models).
19. 9,500 BTU Burner (some models).
20. 12,000 BTU Power Plus Burner (some models).
21. 14,000 BTU Power Plus Burner (some models).
22. Broil Pan (some models).
23. Broil Pan Insert (some models).
24. Leveling Legs and Anti-tip Bracket (included).
NOTE: The features of your range may
vary according to model type & color.
,::;_ I_
@
Before Setting Oven Controls
OVEN VENT
Fig. 1
Fig. 2
Oven Vent Location
The oven vent is located below the backguard (See Fig. 1). When the oven is on,
warm air is released through this vent. This venting is necessary for proper air
circulation in the oven and good baking results. DO NOT BLOCK THE VENT.
Removing & Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front of rack and slide out. To
replace, fit the rack onto the guides on the oven walls. Tilt the front of the rack
upward and slide the rack back into place.
Arranging Oven Racks
ALWA YS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO
OPERATING THE OVEN). Always use oven mitts when using the oven.
Recommended Rack Positions for Broiling, Baking & Roasting:
Food Rack Position
Broiling hamburgers & steaks See Broil Section
Broiling meats, chicken or fish See Broil Section
Cookies, cakes, pies, biscuits & muffins 2 or 3
Frozen pies, angel food cake, 1 or Roasting Shelf
yeast, bread, casseroles, small
cuts of meat or poultry
Turkey, roast or ham 1 or Roasting Shelf
Oven Racks
Your range isequipped with one or more Flat Oven Rack(s). Place the Oven
Rack(s) into the positions shown in Fig. 2. See the Recommended Rack
Positions in the chart above.
Baking Layer Cakes with 1 or 2 Oven Racks
For best results when baking cakes using 2 oven racks, place cookware on rack
positions 1& 4 (See Figs. 2 &4). For best results when using a single oven Flat Rack,
place cookware on rack position 2 or 3 (See Figs. 2 & 5).
Air Circulation in the Oven
For best air circulation and baking
results allow 2-4" (5-10 cm) around
the cookware for proper air
circulation and be sure pans and
cookware do not touch each other,
the oven door, sides or back of the
oven cavity. The hot air must be able
to circulate around the pans and
cookware in the oven for even heat
to reach around the food. Fig. 4
Flat Oven Rack
Fig. 3
Fig. 5
Do not place plastic
items such as salt and pepper shakers,
spoon holders or plastic wrappings
on top of the range when it is in use.
These items could melt or ignite.
Potholders, towels or wood spoons could
catch fire if placed too close to a flame.
Inthe event of an electrical power outage,
the surface burners can be lit manually.
To light a surface burner, hold a lit match
to the burner head, then slowly turn the
surface control knob to LITE. After burner
lights push in and turn knob to desired
setting. Use caution when lighting surface
burners manually.
OFF ..LITE..hi 6 5 4 3 2 Io
Setting Surface Controls
Your range may be equipped with different sized surface burners. The ability to heat
food quicker and in larger volumes increases as the burner size increases.
The SIMMER burner (some models) is best used for simmering delicate sauces,
etc.
The standard burners can be used for most surface cooking needs.
The POWER PLUS burner(s) (some models) are best used for bringing large
quantities of liquid to temperature and when preparing larger quantities of food.
Regardless of size, always select cookware that is suitable for the amount and
type of food being prepared. Select a burner and flame size appropriate tothe pan.
Never allow flames to extend beyond the outer edge of the pan.
Operating the Gas Surface Burners:
1. Place cooking utensil on surface burner.
2. Push the surface control knob in and turn counterclockwise out of the OFF
position.
3. Release the knob and rotate to the LITE position. Note: All four electronic
surface ignitors will spark at the same time. However, only the burner you are
turning on will ignite.
3. Visually check that the burner has lit.
4. Push the control knob in and turn counterclockwise to the desired flame size.
The control knobs do not have to be set at a particular setting. Use the guides
and adjust the flame as needed. DO NOT cook with the surface control knob
in the LITE position. (The electronic ignitor will continue to spark if the knob is
left in the LITE position.)
Setting Proper Surface Burner Flame Size
For most cooking, start on the highest control setting and then turn to a lower
one to complete the process. Use the recommendations below as a guide for
determining proper flame size for various types of cooking. The size and type of
utensil used and the amount of food being cooked will influence the setting
needed for cooking.
INCORRECT
*Flame Size
High Flame
Medium Flame
LowFlame
Type of Cooking
Start most foods; bring water to a boil; pan broiling.
Maintain a slow boil; thicken sauces, gravies; steaming.
Keep foods cooking; poach; stewing.
Never extend the flame beyond the outer
edge ofthe utensil. A higher flame simply
wastes heat and energy, and increases
your r sk of be ng burned by the fame.
Fordeep fatfrying, use a thermometer and adjust the surface control knob
accordingly. If the fat is too cool, the food will absorb the fat and be greasy. If
the fat is too hot, the food will brown so quickly that the center will be
undercooked. Do not attempt to deep fat fry too much food at once as the food
will neither brown nor cook properly.
*These settings are based on using medium-weight metal or aluminum pans with lids. Settings may vary when using
other types of pans. The color ofthe flame is the key to proper burner adjustment. A good flame isclear, blue and hardly visible
in a well-lighted room. Each cone of flame should be steady and sharp. Adjust or clean burner if flame is yellow-orange.
READTHE iNSTRUCTiONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use ofyouroven, become familiar with
the various pad functions of the oven as described below.
BROIL PAD-- Used to UP and DOWN ARROW PADS-- Used along
select the variable broil with the function pads to select oven
function, temperature, time of day, clean time and minute
timer, is in use.
,
to set the time of day.
PAD-- Used to set or ............ .....
cancel the minute
timer. The minute timer
does not start or stop
cooking. Also,
TIMER ON/OFF pad is
used to set the
Continuous Bake
feature.
O ® O Oven
SELF-CLEAN PAD--
Used to select the
Self-Cleaning cycle. A
2 or 3 hour Self-Clean
time may be selected.
OVEN, PREHEAT & DOOR LOCKED LIGHTS* --The "OVEN" light
will glow each time the oven turns on to maintain the set oven
temperature. The "PREHEAT" light will glow when the oven is first
set to operate, or if the desired temperature is reset higher than the
actual oven temperature. The "DOOR LOCKED" light will flash
when the oven door locks and unlocks or when using the Self-
Clean cycle or the oven door lockout is activated.
FEATURE INDICATOR LIGHTS--
These light to show which feature
BAKE PAD--Used
to select the bake
function.
CLEAR/OFF PAD-- Used
to clear any function
previously entered
except the time of day
and minute timer. Press
CLEAR/OFF to stop
cooking. Also the CLEAR/
OFF pad is used to
activate oven door
lockout setting.
*Note: The OVEN indicat0r light on the electronic diSplay will tUrn ON and OFF When using the Bake feature and during
preheaL This isnormal and indicates that the oven is Cyclingt0 maintain the selected baking temperatu re. When the
preheat indicator light turns OFF, your 0yen is ready:
Temperature conversion
The electronic oven control is set to operate in °F (Fahrenheit) when shipped from the factory. The oven can be programmed
for any temperature from 170°F to 550°F (77°C to 287°C).
To change the temperature to °C (Celsius) or from °C to °F (control should not be in a Bake or Clean mode):
1. Press _. "----" appears in the display.
2. Press and hold the /_, until "HI" appears in the display.
3. Press and hold _ until °F or °C appears in the display.
4. Press the ,_ or V to change °F to °C or °C to °F.
5. Press any control pad to return to normal operating mode.
/\
/
_,4iiiiiiiiiii_i_iiiii!!iii_i{_i_,__
J
ii
\.
0 0 • Oven
® Door locked
• • • Self-Cleaning Oven • • .
" ..... ............................................................................................................................................................................ /
Note: The time of day must first beset in order to operate the oven!
To Set the Clock
When the range is first plugged in, or when the power supply to the range has been interrupted, the display will flash
"12:00".
once (do not hold pad down).
1. Press
2. Within 5 seconds, press and hold the ,/_ or v until the correct time of day appears in the display.
Note: The clock cannot be changed during any timed bake or Self-Clean cycle.
To Set the Minute Timer:
1. Press _.
2. Press the /_ to increase the time in one minute increments. Press and hold the /_ to increase the time in 10 minute
increments. The timer can be set for any amount of time from 1 minute to 11 hours and 59 minutes.
Note: If the V pad is pressed first, the timer will advance to 11 hours and 59 minutes.
3. The display shows the timer countdown in minutes until 1 minute remains. Then the display will countdown in seconds.
4. When the set time has run out, the timer will beep 3 times, it will then continue to beep 3 times every 60 seconds until
is pressed,
Note: The indicator light located above the_ pad will glow while the minute timer is active.
Note: The minute timer does not start or stop cooking. It serves as an extra timer in the kitchen that will beep when the set
time has run out. The minute timer can be used alone or during any of the other oven functions. When the minute timer is in
use with any other function, the minute timer will be shown in the display. To view other functions, press the pad for that
function.
To Change the Minute Timer while it is in use:
While the timer is active and shows in the display, press and hold the ,/_ or V to increase or decrease the time.
To Cancel the Minute Timer before the set time has run out: Press _0_.
NOte: TOtUrnthe time of day diSplay OFF or ON in the diSplay press @ and hold for15 seCOndS(the control Willbeep once)
and then releasei This featu redoes not remove the set time ofd ayfrom the memory of the control, When the display isturned
OFF the time Ofday will re:appear for a few Seconds anytime the _pad is touche&
10
