Frigidaire GLGF388C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
GLGF388CQA GLGF388C Gallery bisque North America
GLGF388CSA GLGF388C Gallery white North America
Publication No.
5995386611
030226
-EN/SERVICE /ECL
369
GAS
RANGE
Model number
GLGF388C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 316255207
SERVICE DATA SHEET - # 316259130
OWNER’S GUIDE - # 316257504
INSTALLATION INSTRUCTIONS -# 316259316

02/03 2
Publication No. GLGF388C
5995386611
BACKGUARD

# = Fast-moving Parts 3 02/03
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
BACKGUARD
A = GLGF388C (GLGF388CSA)
B = GLGF388C (GLGF388CQA)
POS. NO PART NO DESCRIPTION
1 316239900 A B Shield,backguard ,rear wall
2 316051600 A B Shield,backguard ,inner
2A 316235100 A B Shield,top ,inner
15 316220214 A - Support,backguard ,white ,RH
15 316220218 - B Support,backguard ,bisque ,RH
15A 316220215 A - Support,backguard ,white ,LH
15A 316220219 - B Support,backguard ,bisque ,LH
19 316233841 A - Panel,backguard ,white
19 316233843 - B Panel,backguard ,bisque
20 # 316207603 A B Clock/Timer,EOC
20A 316243300 A - Overlay,clock ,white
20A 316243302 - B Overlay,clock ,bisque
23 316220900 A B Bracket,clock mtg
36 316220000 A - Knob,top valve ,white ,(4)
36 316220003 - B Knob,top valve ,bisque ,(4)
40 316204920 A - Panel,manifold ,white
40 316204922 - B Panel,manifold ,bisque
42 316236601 A B Trim,extrusion ,chrome
56 316230701 A B Shield,backguard ,inner
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black

09/02 4
Publication No. GLGF388C
5995386611
BURNER

# = Fast-moving Parts 5 02/03
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
BURNER
A = GLGF388C (GLGF388CSA)
B = GLGF388C (GLGF388CQA)
POS. NO PART NO DESCRIPTION
1 # 316204000 A B Pipe,manifold
2 # 5303935210 A B Valve,12K top burner ,w/mtg screw
2A # 5303935211 A B Valve,14K top burner ,w/mtg screw
2B # 5303935212 A B Valve,5K top burner ,w/mtg screw
2C # 5303935213 A B Valve,9.5K top burner ,w/mtg screw
* 316134300 A B Screw,10-24 ,valve mounting
3 # 316219004 A B Wiring Harness,w/igntr switch
8 # 316135701 A B Module,spark
10 # 316212300 A B Burner,sealed ,12K
10A# 316212500 A B Burner,sealed ,14K
10B# 316206400 A B Burner,sealed ,5K
10C# 316212400 A B Burner,sealed ,9.5K
11 # 316237702 A B Ignitor/orifice assy.,top burner ,rear ,12K,w/holder ,tube
11A# 316237802 A B Ignitor/orifice assy.,top burner ,front ,14K,w/holder ,tube
11B# 316237700 A B Ignitor/orifice assy.,top burner ,rear ,5K,w/holder ,tube
11C# 316237800 A B Ignitor/orifice assy.,top burner ,front ,9.5K,w/holder ,tube
13 # 316207000 A B Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 A B Regulator,pressure
14* 316021104 A B Screw,hex ,8-18 x 3/8 ,nick ,(3) ,regulator brkt
15 316091600 A B Bracket,regulator
16 # 316065003 A B Tube,valve to regul. ,3/8
17 # 5303208499 A B Valve,safety ,dual
17* 08068018 A B Shield,wire ,safety valve
18 # 3131290 A B Burner,oven
19 # 5303935066 A B Ignitor,oven kit ,w/nut & instr
20 3131284 A B Baffle,oven burner
21 5303013272 A B Nut,hex head sems
22 # 316065002 A B Tube,valve to mixer
23 # 08067935 A B Burner,broiler
24 # 316070400 A B Elbow,mixer
24* 316113400 A B Spacer,mixer elbow
25 5303210379 A B Baffle,broiler
26 # 316119302 A B Ignitor,broiler
37 316240600 A B Screw,assy mtg ,ignitor/orifice
44 316237901 A B Orifice,top burner ,12K
44A 316237900 A B Orifice,top burner ,14K
44B 316237903 A B Orifice,top burner ,5K
44C 316237902 A B Orifice,top burner ,9.5K
47 GRLP1 A B LP Conversion Kit,w/instructions
47* 316248105 A B Instructions,LP kit
* # 316253700 A B Wiring Harness,ignitor module

02/03 6
Publication No. GLGF388C
5995386611
BODY

# = Fast-moving Parts 7 09/02
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
BODY
A = GLGF388C (GLGF388CSA)
B = GLGF388C (GLGF388CQA)
POS. NO PART NO DESCRIPTION
1 316029416 A B Panel,main back
2 3131314 A B Shield,oven top
3 316216402 A - Panel,bodyside ,white ,RH
3 316216403 A - Panel,bodyside ,white ,LH
3 316216406 - B Panel,bodyside ,bisque ,RH
3 316216407 - B Panel,bodyside ,bisque ,LH
3* 316021131 A - Screw,bodyside ,8-18 X 11/16 ,white
3* 316021133 - B Screw,bodyside ,8-18 X 11/16 ,bisque
4 316201402 A B Burner Box
5 316129200 A B Screw,leveling ,plastic ,with stop
6 316067902 A B Rack,oven
6A 318219500 A B Rack,broiler pan
7 316216500 A B Hinge,oven door ,RH
7A 316216501 A B Hinge,oven door ,LH
8 5303300701 A B Panel,oven bottom
9 316081900 A B Pan,broiler
10 316082000 A B Insert,broiler pan
12 316209900 A B Switch,oven light/door
14 316116400 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 08011086 A B Lens,oven light ,glass
17 316087500 A B Retainer,lens
18 # 316213900 A B Latch,oven door
21 3014099 A B Spacer,bodyside
25A 5303288580 A B Shield,heat ,lower
28 3011813 A B Clip,wire ,bodyside
29 3051162 A B Glide,drawer ,front
30 316217700 A B Bracket,hinge ,RH ,main top
30A 316217701 A B Bracket,hinge ,LH ,main top
33 316232800 A B Shield,rear wall
35 316116600 A B Gasket,flue
36 316133002 A B Flue
37 # 316233900 A B Probe,oven temp
38 316051700 A B Shield,heat
39 # 3131425 A B Cord,electric power
40 3200836 A B Shield,heat baffle
40* 5303288570 A B Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 316233400 A B Cover,hinge cutout ,RH
41A 316233500 A B Cover,hinge cutout ,LH
42 5303288578 A B Shield,bake burner
43 3131732 A B Screw,8-18 x 1.438 ,oven bottom
44 316246500 A B Spacer,oven door
49 316234200 A B Clip,maintop mtg ,(2)
53 5303288579 A B Shield,main front
53A 08067992 A B Shield,insulation ,front frame
53B 316211100 A B Bracket,air dam
55 316107800 A B Shield,flue
58A 316047705 A B Insulation,oven wrapper
58B 316218303 A B Insulation,oven back
58G 08067973 A B Insulation,main front
88 316232700 A B Rod,auto latch
89 # 316137500 A B Motor,latch
106 316026600 A B Bracket,motor mtg
107 316026701 A B Cover,fan
108# 316234601 A B Motor,fan
109 316136400 A B Blade,fan
110 316136500 A B Washer,fan motor
111 316136600 A B Nut,fan retainer
151 316239300 A B Shield,bodyside
161# 316211603 A B Element,convection fan ,350 W
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template,anti-tip
170* 316116000 A B Screw,concrete ,1.75" ,anti-tip brkt
* # 316253413 A B Wiring Harness,main
* 5303305324 A - Paint,touch-up ,white
* 5304414035 - B Paint,touch-up ,bisque
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black

02/03 8
Publication No. GLGF388C
5995386611
TOP/DRAWER

# = Fast-moving Parts 9 02/03
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
TOP/DRAWER
A = GLGF388C (GLGF388CSA)
B = GLGF388C (GLGF388CQA)
POS. NO PART NO DESCRIPTION
1 316011503 A B Drawer
2 316231400 A B Liner,drawer
4 316231205 A - Panel,drawer ,white
4 316231209 - B Panel,drawer ,bisque
7 3051163 A B Glide,drawer ,rear
16 316202327 A - Main Top,white
16 316202329 - B Main Top,bisque
20 316248501 A - Grate,gray ,(4)
20 316248503 - B Grate,brown ,(4)
20A 316239801 A - Grate,gray ,center
20A 316239803 - B Grate,brown ,center
22 316213601 A - Cap,12K burner ,gray
22 316213603 - B Cap,12K burner ,brown
22A 316213701 A - Cap,14K burner ,grey
22A 316213703 - B Cap,14K burner ,brown
22B 316206601 A - Cap,5K burner ,gray
22B 316206602 - B Cap,5K burner ,brown
22C 316213501 A - Cap,9.5K burner ,gray
22C 316213503 - B Cap,9.5K burner ,brown
88 316099500 A B Pin,guide ,(2)
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312

02/03 10
Publication No. GLGF388C
5995386611
DOOR

# = Fast-moving Parts 11 02/03
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
DOOR
A = GLGF388C (GLGF388CSA)
B = GLGF388C (GLGF388CQA)
POS. NO PART NO DESCRIPTION
3 5303935192 A - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935193 - B Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - Glass,door kit ,white ,outer ,w/foil tape
4 5303935202 - B Glass,door kit ,bisque ,outer ,w/foil tape
5 316237000 A B Glass,oven door ,air wash
6 316222707 A B Shield,wool ,oven door
7 316236700 A B Insulation,oven door
8 316237100 A B Glass,oven door ,clear ,heat barrier
9 316230605 A B Liner,oven door
10 316001013 A B Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10B 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 316230901 A B Seal,oven door
14 316102207 A B Foil,1.5" x 29" ,aluminum ,clear
14A 316102202 A B Foil,4" x 5.5" ,aluminum ,clear ,(2)
15 316237201 A B Bracket,glass support ,(2)
16 316117501 A B Glass,oven door ,inner
17 316117701 A B Spacer,door glass ,(2)
39 316203001 A - Handle,door ,white
39 316203003 - B Handle,door ,bisque
52 316201003 A - Cap,door trim ,white
52 316201009 - B Cap,door trim ,bisque
60B 316021110 A B Screw,8-18 x 0.5 ,black
* 316221001 A B Label,anti-tip
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black

02/03 12
Publication No. GLGF388C
5995386611
WIRING DIAGRAM

# = Fast-moving Parts 13 02/03
* = Non-Illustrated Parts
GLGF388C Publication No.
5995386611
WIRING SCHEMATIC
