Frigidaire FGFS56F User manual

FGF366A.eps L24G0007.eps T24B0001.eps T24V0025.eps T24T0001.eps T24D0017.eps
316417800d.eps 316417800s.eps
Product No. FGFS56FSA
Series 30" f/s gas
Color white
Market North America
Wiring Diagram 316417800
Owner's Guide 316417104
Installation Instructions 316259336
Service Data Sheet 316417605
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995459202
06/01/20
(EN/SERVICE/BJH)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGFS56F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995459202 FGFS56FSA
01/06 2
BACKGUARD

FGFS56FSA Publication No: 5995459202
# Functional Parts 3 01/06
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
2 316051600 Shield, backguard, inner
2A 316235100 Shield, top, inner
15 316411403 Support, backguard, white, RH
15A 316411402 Support, backguard, white, LH
19 316445222 Panel-backguard, white
20 # 316418205 Clock/Timer, electronic, ES200
20A 316419101 Overlay, clock, white, ES200
23 316441600 Bracket-clock mtg, black
24 # 316448701 Switch, rocker, white, oven light
36 316220000 Knob, top valve, white, (4)
40 316204987 Panel, manifold, white
42 316416201 Trim, extrusion, gray
56 316230701 Shield, backguard, inner
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995459202 FGFS56FSA
01/06 4
BURNER

FGFS56FSA Publication No: 5995459202
# Functional Parts 5 01/06
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 316219500 Pipe, manifold
2C # 5303935234 Valve, 9.5K burner, w/mtg screw
3 # 316219004 Wiring Harness, w/igntr switch
8 # 316135701 Module, spark
10C# 316212400 Burner, sealed, 9.5K
11 # 316237701 Ignitor/orifice assy., top burner, rear, 9.5K, w/holder, tube
11C# 316237800 Ignitor/orifice assy., top burner, front
13 # 316405300 Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 Regulator, pressure
14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 Bracket, regulator
16 # 316405500 Tube, valve to regul., 3/8
17 # 316404900 Valve, safety
17* 08068018 Shield, wire, safety valve
18 # 316404400 Burner, oven
19 # 316428501 Ignitor, oven burner
20 316401401 Baffle, oven burner
21 5303013272 Nut, hex head sems
22 # 316405400 Tube, valve to mixer
23 # 316404300 Burner, broiler
24 # 316409700 Elbow, mixer
25 316401301 Baffle, broil burner
26 # 316428601 Ignitor, burner
26* 316401500 Cover, broil Ignitor
37 316240600 Screw, assy mtg, ignitor/orifice
44C 316237902 Orifice, top burner, 9.5K
47 GRLP2 LP Conversion Kit, w/instructions
47* 316248105 Instructions, LP kit
* # 316253700 Wiring Harness, ignitor module
* 316001003 Screw, ground wire
* 316215600 Screw, valve mtg., 1/4 - 20
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995459202 FGFS56FSA
01/06 6
BODY
5A
5A
25
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
86
58A
58B
87
18
86
17
16
15
14
37
8
6
6
42
82
91
90
58G
5
170
T24V0025
3
151
29
36
18
88
2
49
89
39
30
30A
35
4
55
54
33
1
43
44

FGFS56FSA Publication No: 5995459202
# Functional Parts 7 01/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401600 Back, main
2 316402201 Shield, oven top
2* 316437100 Brace, oven top
3 316400116 Panel, bodyside, white, RH
3 316400117 Panel, bodyside, white, LH
4 316201403 Burner Box
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316407201 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 Rack, oven
8 316400603 Panel, oven bottom
12 316445501 Switch, oven light, door frame
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
25 316406200 Shield, heat, lower
29 316407301 Glide, drawer, front
30 316217700 Bracket, hinge, RH, main top
30A 316217701 Bracket, hinge, LH, main top
33 316405900 Shield, rear wall
35 316116600 Gasket, flue
36 316208901 Flue
37 # 316217001 Probe, oven temp
39 3202006 Cord, electric power
42 316400703 Shield, wool, lower
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316246501 Spacer, oven door
49 316234200 Clip, maintop mtg, (2)
54 316404200 Shield, heat
55 316404800 Shield, flue
58A 316403700 Insulation, oven wrapper
58B 316403600 Insulation, oven back
58G 08067973 Insulation, main front
82 316400801 Shield, bake burner
82* 316432800 Clip, wire
86 316441300 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316401200 Bracket, harness
88 316232700 Rod, auto latch
89 # 316415400 Motor, latch/lock
90 316401100 Shield, main front
91 316401000 Shield, front, burner
151 316404600 Shield, bodyside
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
* # 316416600 Harness, wiring, main
* 5303321319 Paint, touch-up, white
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995459202 FGFS56FSA
01/06 8
TOP/DRAWER

FGFS56FSA Publication No: 5995459202
# Functional Parts 9 01/06
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316408701 Drawer, utility
2 316403200 Liner, drawer
4 316403401 Panel, drawer, white, front
7 316407400 Glide, drawer, rear
16 316202317 Main Top, white
20 316202400 Grate, black
22C 316213500 Cap, 9.5K burner, black
88 316099500 Pin, guide, (2)
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995459202 FGFS56FSA
01/06 10
DOOR
60B
10B
10
3
4
52
39
7
6
T24D0017
17
17
23
23
8
9
12
8

FGFS56FSA Publication No: 5995459202
# Functional Parts 11 01/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3 316402001 Trim, oven door, white
4 316402600 Glass, door, white
6 316402307 Shield, wool
7 316403900 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 316423801 Liner, oven door
10 316433300 Screw, 10-14 x 2.125", handle mtg.
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316403101 Seal, oven door
17 316402403 Spacer, door glass, (2)
23 316437702 Hinge, oven door
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316270201 Handle, door, white
52 316405100 Cap, door trim, white
60B 316021110 Screw, 8-18 x 0.5, black
* 316433603 Label, anti-tip
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995459202 FGFS56FSA
01/06 12
WIRING SCHEMATIC

FGFS56FSA Publication No: 5995459202
# Functional Parts 13 01/06
* Non-Illustrated Parts
WIRING DIAGRAM
