Frigidaire FGGF3054KB - Gallery - Convection Gas Range Installation instructions

frigidaire.com
Signature Features
30" Gas
Quick Preheat
Preheat in less than six minutes.
1
True Convection
Multi-rack baking is faster and more
even with True Convection.
Express-Select® Controls
Easily go from warm to boil.
Quick Boil
Boils water faster.
Product Dimensions
Height (Max.) 47-1/2"
Width 29-7/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
One-Touch Options
Our ovens feature easy-to-use one
touch buttons so you can cook pizza
or chicken nuggets — or even add a
minute to the timer — with the touch
of a button.
SpaceWise® Half Rack
Flexible rack system that adjusts to
cook multiple dishes at once. Remove
the half rack and you’ll have extra
height for tall dishes.
Fits-More™ Cooktop
The Fits-More™ cooktop features five
burners so you can cook more at once.
Eortless™ Oven Rack
Bottom rack extends when you open
the door for easy access.
Real Stainless Steel2
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
Eortless™ Convection
Takes the guesswork out of convection
cooking — our oven does the converting
for you.
Low Simmer Burner
Perfect for delicate foods and sauces.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(F)
White
(W)
Black
(B)
Burners
Right Front
Right Rear
Left Front
Left Rear
Center Extra Zone
BTU
17,000
5,000
9,500
15,000
10,000
1Based on single rack cooking performance,
not set temperature, using Quick Preheat.
2Select model only.
Freestanding Ranges
FGGF3054K F/ W/ B

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGGF3054K 01/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Freestanding Ranges
FGGF3054K F/ W/ B 30" Gas
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
47-1/2"
29-7/8"
28-1/2"
46-5/8"
30" Gas Freestanding Ranges
Frigidaire Baseline
C
A
36"
(Adjustable)
B
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
1For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
Features
Oven Control / Timing System
Surface Type
Sealed Gas Burners
Grates
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self Clean
Quick Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shuto
Lower Drawe r Control
Cooktop Features
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Extra Zone Burner (BTU)
Oven Features
Capacity (Cu. Ft.)
Oven Light
Rack Configuration
Baking System
Broiling System
Bake Burner / Broil Burner (BTU)
Drawer Racks
Optional Accessories
LP Gas Conversion Kit
Certifications
Sabbath Mode (Star-K® Cert.)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Gas Supply Connection Location
Voltage Rating
Conn. Load (kW Rating) @ 120 Volts1
Amps @ 120 Volts
Shipping Weight (Approx.)
Express-Select® Controls
Black Porcelain (F),
Color-C. Porc. (W/B)
Yes
Continuous Cast Iron
w/ Black Matte Finish
Extra-Large
Real Stainless Steel (F),
Color-Coordinated (W/B)
Stainless Steel (F),
Color-Coordinated (W/B)
Black (F),
Color-Coordinated (W/B)
True Convection
Self Clean
Storage
Yes / Variable
(400 – 500 °F)
Yes
Yes / No / Yes
Yes
Yes
Yes
Yes
Yes
Yes
2, 3, 4 Hours
Yes
Yes
Yes / Yes
6 Hours
17,000
5,000
9,500
15,000
Oval 10,000
5.0
1
1 Heavy Duty, 1 SpaceWise®
Half Rack, 1 Eortless™
Even Baking Technology
Even Broil
18,000 / 13,500
PN # GRLP3
Yes
17-5/8" x 24-3/8" x 19-3/4"
Left Bottom Rear
Right Bottom Rear
120V / 60Hz / 15A
1.8
15
220 Lbs.

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
