Frigidaire GLGF388ABB User manual

Gas
Range
ES400 Controls, Self-Cleaning Oven
with Sealed Surface Burners
Convection Bake &Roast
@@ @
Welcome ....................... 2
Important Safety Instructions.. 3-5
rmm
Features at a Glance ........ 6-7
Setting Surface Controls .. 8-10 _1
Surface Cooking ............. 10 _i
Before Setting Oven Controls
Settlng Warmer Drawer Controls .... 11-12
Control Pad Features .......... 13
Settint,l Oven Controls .... 14-24
Self-Cleaning .............. 25-28
Adjusting Your
Oven Temperature ........... 28 m-J
Care & Cleaning .......... 29-31 r_
Before You Call
Solutlons to
Common Problems ............... 32-33
Convectlon Cooklng Tables ........... 34
Warranty ............ Back Cover
Vi$ff the Frigidaire Web Site at:
http://www.frigidaire.com
READ AND SAVE THESE INSTRUCTIONS P/N 316257504 (0108)

Questions?
1-800-944-9044
tUnited States)
1-905-585-9200
,',Canada)
Please attach sales receipt
here for future reference.
Congratulat=ons on your purchase of a new range! At Electrolux Home Products,
we are very proud of our product and are completely committed to providing you
with the best service possible.Your satisfaction is our number one priority.
We know you'll enjoy your new range and ThankYou for choosing our product.
We hope you consider us for future purchases.
PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating instructions for your model.
Use your range only as instructed in this manual. These instructions are not
meant to cover every possible condition and situation that may occur. Common
sense and caution must be practiced when installing, operating and maintaining
any appliance.
Please record your model and serial numbers below for future reference.
Model Number:
Serial Number:
Purchase Date:
Versibn en espafiol
Si desea obtener una copia en espafiol
de este Manual del Usuario, sfrvase
escribir a la direcci6n que se incluye a
continuaci6n. Solicite la P/N
316257504.
Spanish Use & Care Manual
Electrolux Home Products
P.O. Box 212378
Augusta, GA 30917
© 2001WhiteConsolidated Industries
All rights reserved
m
Serial plate IocaUon:
Open storage or warmer drawer.
Product
Registration
Register Your Product
The self-addressed PRODUCT
REGISTRATION CARD should
be filled in completely, signed
and returned to Electrolux
Home Products.
This Use & Care Manual contains general operating instructions for your range
and feature information for several models. Your range may not have all the
described features. The graphics shown are representative. The graphics on
your range may not look exactly like those shown.

Read all instructions before using this appliance.
Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given.
_tVAV-_t:t_ll_[cllThis symbol wi!lhelp alert you to situations that may cause serious bodily harm, death or property damage.
This symbol will help alert you to situations that may cause bodily injury or property damage.
_l'!_A'f-'t:t_ll:[_1If the information in this manual is not
followed exactly, afire or explosion may result
causing property damage, personal injury or death.
FOR YOUR SAFETY:
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
-- WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use
any phone in your building.
•Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the
firedepartment.
-- Installation and service must be performed by a
qualified installer, servicer or the gas supplier.
• Remove all tape and packaging before using the range.
Destroy the carton and plastic bags after unpacking the range.
Never allow children to play with packaging material.
• Proper Installation--Re sure your appliance is properly
installed and grounded by aqualified technician in
accordance with the National Fuel Gas Code ANSI Z223.-
latest edition, or in Canada CAN/CGA B149.1, and CAN/
CGA B149.2, and the the National Electrical Code ANSI/
NFPA No.7g-latest edition, or in Canada CSA Standard
C22.1, Canadian Electrical Code, Part 1, and local code
requirements. Install only per installation instructions
provided in the literature package for this range.
Ask your dealer to recommend a qualified technician and an
authorized repair service. Know how to disconnect the power
to the range at the circuit breaker or fuse box in case of an
emergency.
• User servicing--Do not repair or replace any part of the
appliance unless specifically recommended in the manuals.
All other servicing should be done only by a qualified
technician, This may reduce the risk of personal injury and
damage to the range.
• Never modify or alter the construction of a range by
removing leveling legs, panels, wire covers, anti-tip
brackets/screws, or any other part of the product.
• All ranges can tip.
• Injury to persons could result.
• Install anti-tip device packed with range.
• See Installation Instructions.
F!_,W'J:t_II_(el To reduce the risk of
tipping, the range must be secured by
properly installed anti-tip bracket provided
with the range. To check ifthe bracket is
installed properly, visually check that rear
leveling leg is inserted into and fully
secured by the anti-tip bracket by
removing lower panel or storage drawer.
For models with a warmer drawer, grasp
the top rear edge of the range and
carefully attempt to tilt it forward. Refer to
the Installation Instructions for proper
anti-tip bracket installation.
Stepping, leaning or sitting on the doors or
drawers of this range can result in serious injuries and also
cause damage to the range. Do not allow children to climb or
play around the range. The weight of a child on an open door
may cause the range to tip, resulting in serious burns or other
injury.
Do not use the oven or warmer drawer (if
equipped) for storage.
Do not store items of interest to children in
the cabinets above a range or on the backguard of a range.
Children climbing on the range to reach items could be
seriously injured.
Never Use Your Appliance for Warming or
Heating the Room.
• Storage in or on Appliance--Flammable materials should
not be stored in an oven, warmer drawer, near surface
burners or in the storage drawer. This includes paper, plastic
and cloth items, such as cookbooks, plasticware and towels,
as well as flammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.
3

•Do Not Leave Children Alone--Children should not be left
alone or unattended in the area where appliance is in use.
They should never be allowed to sit or stand on any part of the
appliance.
• DO NOT TOUCH SURFACE BURNERS, AREAS NEAR
THESE BURNERS, OVEN BURNERS OR INTERIOR
SURFACES OF THE OVEN. Both surface and oven burners
may be hot even though flames are not visible. Areas near
surface burners may become hot enough to cause burns.
During and after use, do not touch, or let clothing or other
flammable materials touch these areas until they have had
sufficient time to cool. Among these areas are the cook top,
surfaces facing the cook top, the oven vent openings and
surfaces near these openings, oven door and window.
•Wear Proper Apparel--Loose-fitting or hanging garments
should never be worn while using the appliance. Do not let
clothing or other flammable materials contact hot surfaces.
• Do Not Use Water or Flour on Grease Fires--Smother the
fire with a pan lid, or use baking soda, a dry chemical or
foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat or grease
may catch fire if allowed to become too hot.
• Use Only Dry Potholders--Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let
potholders touch hot heating burners. Do not use a towel or
other bulky cloth instead of a potholder.
• Do Not Heat Unopened Food Containers--Buildup of
pressure may cause container to burst and result in injury.
•Remove the oven door from any unused range if it is to be
stored or discarded.
IMPORTANT--ELECTRIC IGNITION MODELS ONLY: Do not
attempt to operate the oven during a power failure. If the power
fails, always turn off the oven. If the oven is not turned off and
the power resumes, the oven will begin to operate again. Once
the power resumes, reset the clock and oven function.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
Use Proper Flame Size--Adjust flame size so
it does not extend beyond the edge of the utensil. The use of
undersized utensils will expose aportion of the burner flame to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to flame will also improve efficiency.
• Know which knob controls each surface burner. Place a pan
of food on the burner before turning it on, and turn the burner
off before removing the pan.
•Always turn knob to the full LITE position when igniting top
burners. Visually check that burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
• Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Burners--To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
that it is turned inward, and does not extend over adjacent surface
burners.
• Never Leave Surface Burners Unattended at High Heat
Settings--Boilovers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
•Protective Liners--Do not use aluminum foil to line surface
burner pans, or oven bottom, except as suggested in this
manual. Improper installation of these liners may result in risk
of electric shock, or fire.
•Glazed Cooking Utensils--Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cooktop service without breaking due to the
sudden change in temperature. Check the manufacturer's
recommendations for cooktop use.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
•Use Care When Opening Oven Door or Warmer Drawer--
Stand to the side of the range when opening the door of a hot
oven. Let hot air or steam escape before you remove or
replace food in the oven.
•Keep Oven Vent Ducts Unobstructed. The oven vent is
located below the backguard. Touching the surfaces in this
area when the oven is operating may cause severe burns.
Also, do not place plastic or heat-sensitive items on or near
the oven vent. These items could melt or ignite.
• Placement of Oven Racks. Always place oven racks in
desired location while oven is cool. If rack must be moved
while oven is hot use extreme caution. Use potholders and
grasp the rack with both hands to reposition. Do not let
potholders contact the hot heating elements in the oven.
Remove all utensils from the rack before moving.
•Do not use the broiler pan without its insert. The broiler pan
and its insert allow dripping fat to drain and be kept away from
the high heat of the broiler.
• Do not cover the broiler insert with aluminum foil. Exposed
fat and grease could ignite.
• Cold temperatures can damage the electronic control. When
using the appliance for the first time, or when the appliance
has not been used for an extended period of time, be certain
the unit has been in temperatures above 32°F (0°C) for at
least 3 hours before turning on the power to the appliance.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR RANGE
• Clean the range regularly to keep all parts free of grease
that could catch fire. Pay particular attention to the area
underneath each surface element. Do not allow grease to
accumulate. Refer to the range manufacturer's instructions for
cleaning.
•Kitchen cleaners and aerosols--Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and injury.
SELF CLEANING OVENS
• Clean in the self-cleaning cycle only the parts listed in this
Owner's Guide. Before self cleaning the oven, remove the
broiler pan and any utensils or foods from the oven.
• Do Not Use Oven Cleaners--No commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
• Do Not Clean Door Gasket--The door gasket is essential for
a good seal. Care should be taken not to rub, damage or
move the gasket.

Grounding type
wall receptacle
f
Do not, under any
circumstance, cut,
remove, or bypass
the grounding prong.
Power supply cord
with 3-prong
grounding plug
See the INSTALLATION INSTRUCTIONS packaged with this
range for complete installation and grounding instructions.
GROUNDING INSTRUCTIONS
(electric ignition models only)
Avoid fire hazard or electrical shock. Do not
use an adapter plug, an extension cord, or remove grounding
prong from electrical power cord. Failure to follow this warning
can cause serious injury, fire or death.
This appliance is equipped with a 3-prong
grounding plug for your protection against shock hazard and
should be plugged directly into a properly grounded receptacle.
DO NOT cut or remove the grounding prong from this plug.
For personal safety, the range must be properly grounded. For
maximum safety, the power cord must be plugged into an
electrical outlet that is correctly polarized and properly
grounded.
If a 2-prong wall receptacle is the only available outlet, it is the
personal responsibility of the consumer to have it replaced with
aproperly grounded 3-prong wall receptacle installed by a
qualified electrician.
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances
known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of
potential exposure to such substances.
CONVERSIONTO LIQUIFIED PETROLEUM (L.P.) GAS
The range is designed to allow for conversion to Liquified Petroleum (L.P.) Gas. Contact your qualified appliance distributor to
obtain the proper L.P. Kit. Follow the L.P. Kit Installation Instructions carefully.
READ AND SAVE THESE INSTRUCTIONS
5

Your Gas Range
Features
At a Glance
ConvectionRoasting
Rack
Automatic
OvenDoor
Intsdor
Ught
(1)Broil Pan and
(1) Broil Pan Insert
Storage Drawer
ManualOven ElectzonicOven Control
UghtSwitch withClockand tOtchenTimer "Ultrasoff'Style
(somemodels) (colorwillvaryby model) Control Panel
ix ............................................................................................Easy to Clean
.........._S_ladcooktopBurner
Surface Bumer
Door Latch
OvenInterior
Convection Bake
Fan with Assist
Element
Adjustable
Intedor
Oven Racks
Piece
Door Handle
(style varies
with model)
Glass Oven Door
with Large
Window s
or Warmer Drawer
(some models) Gas Cooktop ;and
Anti-tipBracket(included)
12k "Power"
Sealed Bumer
(LP convertible) ._.
Removable
Surface Burner
"Pro" Grates
9_a_St al_udran_r"
(LP convertible
Removable Center Burner "Pro" Grate
(stylesand color willvary by model)
I
5k Simmer
Sealed Burner
•(LP convertible)
_14k Power Plus"
Sealed Burner
(LP convertible)
6

Your Gas Range
Features
At a Glance
(Stainless Steel
models only)
Convection Roasting
Rack
Automatic
OvenDoor
U_lht
Switch
Intedor
Ught
(1)Broil Pan and
(1) Broil Pan Insert
ManualOven WarmerDrawer
LightSwitch Controland
(somemodels) IndicatorLight
\
Electronic Oven Control
with Clock and Kitchen "Rmer
(color will vary by model)
Brushed Aluminum
"Uitraso|t" Style
Con_ol Panel
Easy to Clean
Sealed Burner
Cooktop
Brushed
Aluminum
Surface Burner
Controls
Self-Clean
Door Latch
ig
OvenInterior
Convection Bake
Fan with Assist
Element
Adjustable
Interior
Oven Racks
sStainless
1 Piece
Door Handle
Warmer Drawer
(shown) and Rack
with Stainless Steal
Handle Gas Cooktop
Stainless Steel
Oven Door
with Ladle
Window
Ig Legs and
Anti-tip Bracket (included)
12k"Power'
SealedBurner 5k Simmer
Sealed Burner
Removable
Surface Burner
"Pro" Grates
(styles and color
will van
9.5k Standard "
Sealed Burner
(LPconvertible)
Removable Center Burner "Pro" Grate
(styles and color willvary by model)
14kPower Plus"
Sealed Bumar
(LP convertible)

Sizes of the Surface Gas Burners (1) Center
Grate
(4) Surface
Burner Grates
Orifice
Holder
Figure 2
Electrode must be
located properly inslot
at each Burner Head
¸
Centergrateshould
Figure 3
"POWER"
BurnerHead
Burner Cap
,_<-_ LeftRear
OdflceHolder
Standard --_
BurnerHead ._
(9,500 BTU) _, ExtraLarge
Left Front Burner Ca'_,.,.,_ _
Odflce Holder
"POWER PLUSTM" .......
BurnerHead
0/'_ (14,000BTU) "
RightFront
OdficeHolder
Figure 1
Small
_)<--"SIMMER"
BurnerHead
(5,000 B'R.J)
/
Right Rear
BurnerPort
Your gas range was supplied with 4 different surface gas burners; a
"SIMMER" Burner (5,000 BTU), a STANDARD burner (9,500 BTU), a
"POWER" Burner (12,000 BTU) and a POWER PLUS TM Burner (14,000 BTU).
When setting up the gas range for the first time, make sure that the correct
Burner Heads, Burner Caps and Burner Grates are correctly (See Fig. 1).
Assembly of the Surface Burner Heads, Burner Caps and
Burner Grates:
It isvery important to makes sure that all of the Surface Burner Heads,
Surface Burner Caps and Surface Burner Grates are installed correctly and in
the correct locations.
1. Place all 4 Burner Heads in the correct locations (See Fig. 1). Make sure
that the correct Burner Head isplaced with the corresponding Orifice
Holder and that the Electrode is located properly in the slot provided of
each Burner Head (See Fig. 2). Proper Burner Head placement insures that
each Burner will have the correct spark required for gas ignition.
2. Place the correct Burner Caps at each of the burner locations. Each of the
4 Burner Heads MUST have a Burner Cap installedto insure proper ignition
and gas flame size before placing the Burner Grates (See Fig. 2).
3. Place the 4 cast iron surface Burner Grates supplied with the range. After
the surface grates been installed place the center grate between the four
grates and be sure to interlock the grates correctly (See Fig. 3).
REMEMBER -- DO NOT ALLOW SPILLS, FOOD, CLEANING AGENTS OR
ANY OTHER MATERIAL TO ENTER THE GAS ORIFICE HOLDER
OPENING. Always keep the Burner Caps and Burner Heads inplace whenever
the surface burners are in use.

Control Locations of the Gas Surface
Burners
Your range is equipped with gas surface burners
with 4 different BTU ratings. The ability to heat
food quicker and in larger volumes increases as
the burner size increases.
The smaller SIMMER burner is best used for
simmering delicate sauces, etc. This burner is
located at the right rear burner position on the
cooktop (See Fig. 1).
The STANDARD size burner can be used for
most surface cooking needs. This burner is
located at the left front burner position on the
_,_, ,,,_,_ cooktop (See Fig. 1).
po_T burney
.front O0 _0
• 0 O0 tear
pewer ptu$ burney Simmer burner
_,nt O0 00
Q@ OO r_ar
Left front Left rear Right front Right rear
Burner Burner Burner Burner
Figure 1
Operating the Gas Surface Burner Controls:
1. Place cooking utensil on surface burner.
2. Push the surface control knob in and turn counterclockwise out
of the OFF position (See Fig. 2).
3. Release the knob and rotate to the LITE position. Note: All four
electronic surface ignitors will spark at the same time. However,
only the burner you are turning on will ignite.
4. Visually check that the burner has a flame.
5. Turn the control knob counterclockwise to the desired flame
size. The control knobs do not have to be set at a particular
setting. Use the knob indicator settings to adjust the flame as
needed. DO NOT cook with the surface control knob in the LITE
position. (The electronic ignitor will continue to spark if the knob
is left in the LITE position.)
The larger 2 POWER and POWER PLUS TM
burners are best used for bringing large quantities
of liquid rapidly up to temperature or when
preparing larger quantities of food. The two
POWER and POWER PLUS TM Burners are
located at the left rear and right front burner (See
positions on the cooktop as shown in Fig. 1).
Do not place plastic items such as salt and
pepper shakers, spoon holders or plastic wrappings on top of
the range when it is in use. These items could melt or ignite.
Potholders, towels or wood spoons could catch fire ifplaced too
close to a flame.
OFF ..LITE..hi 6 5 4 3 2Io
Figure 2
9

Setting Proper Surface Burner Flame Size
Correct
Incorrect
Never extend the flame beyond the
outer edge of the utensil. A higher
flame simply wastes heat and energy,
and increases the risk of being burned
by the gas fame.
For most cooking - start on the highest control setting and then turn to a
lower one to complete the process. Use the recommendations below as a
guide for determining proper flame size for various types of cooking. The size
and type of utensil used and the amount of food being cooked will influence the
setting needed.
*Flame Size
High Flame
Medium Flame
Low Flame
Type of Cooking
Start most foods; bring water to a boil; pan broiling.
Maintain a slow boil; thicken sauces, gravies; steaming.
Keep foods cooking; poach; stewing.
For deep fat frying - use a thermometer and adjust the surface control knob
accordingly. If the fat is too cool, the food will absorb the fat and be greasy. If
the fat is too hot, the food will brown so quickly that the center will be
undercooked. Do not attempt to deep fat fry too much food at once as the food
will neither brown nor cook properly.
*Note: Settings are based on using medium-weight metal or aluminum
pans, Settings may vary when using other types of pans. The color of the
flame is the key to proper burner adjustment. A good flame is clear, blue and
hardly visible in a well-lighted room. Each cone of flame should be steady and
sharp. Adjust or clean burner ifflame is yellow-orange.
10

Arranging the Oven Racks
ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO
OPERATING THE OVEN). Always use oven mitts when the oven is hot.
Oven Vent Location
The oven vent is located below the
backguard. When the oven is on, hot
air is released through the vents. This
venting isnecessary for proper air
circulation in the oven and good baking
results.
OVEN VENT
r
Removing and Replacing Oven
Racks
To remove, pull the rack forward until
it stops. Lift up front of rack and slide
out. To replace, fit the rack onto the
guides on the oven walls. Tilt the front
of the rack upward and slide the rack
back into place.
Arranging Oven Racks
To bake on a single rack, place the
rack in position 4. To bake on 2
racks, place the racks in positions 2
and 4. To bake on 3 racks, place the
racks in positions 1,3 and 5.
1st Rack Position
F2nd Rack Position
_3rd Rack Position
4th Rack Position
-- 5th Rack Position
_6th Rack Poeition
{for roasting largs
food Items only)
Rack RECOMMENDED RACK POSITIONS FOR
BROILING, BAKING & ROASTING
Food Rack Position
Broiling meats, chicken or fish 1,2 or 3
Cookies, cakes, pies, biscuits & muffins 3 or 4
Frozen pies, angel food cake, yeast, bread, 5
casseroles, small cuts of meat or poultry
Turkey, roast or ham 6
Note: Always use caution when removing food from the lower rack
positions,
Air Circulation in the Oven
If using 1 rack, place in center of oven. If using multiple
racks, stagger cookware as shown.
For best air circulation and baking results allow 2-4" (5-10 cm)
around the cookware for proper air circulation and be sure
pans and cookware do not touch each other, the oven door,
sides or back of the oven cavity. The hot air must circulate
around the pans and cookware in the oven for even heat to
reach around the food.
1 Oven Rack
z
/
Multiple Oven Racks
11

Arranging Warming Drawer Rack Positions
The rack can be used in 2 ways:
• In the upright position to allow low profile food items to be placed both under and on top of the rack (for example,
rolls or biscuits on top of the rack and a casserole dish underneath).
• In the downward position to allow you to place light weight food items and empty cookware (for example, rolls or
pastries and dinner plates) on the rack. ....
Set the Warming Drawer rack in either position as shown below (Fig. 1).
_Warming Drawer
JRack in upward
position
To Operate the Warming Drawer Figure 1
J
J
_" Warming Drawer
Rack in downward
position
The purpose of the Warming Drawer isto keep hot cooked foods at serving
temperature. Always start with hot food. It is not recommended to heat cold
food inthe Warming Drawer.
All food placed inthe Warming Drawer should be covered with a lid or
aluminum foil to maintain quality. Do not use plastic wrap to cover food.
Plastic may melt onto the drawer and be very difficult to clean. Use only
utensils and cookware recommended for oven use in the Warming Drawer.
To Set theWarming Drawer Control:
The control is used to select the temperature of the Warming Drawer. It is
located on the control panel. To set the control, push in and turn the knob to
the desired setting. The temperatures are approximate, and are designated by
HI (high), MED (medium) and LO (low).
1. Turn the knob to select the desired temperature setting.
2. For best results, preheat the drawer before adding food. An empty drawer
will preheat in approximately 15 minutes.
3. When done, turn the control to OFF.
Warming DrawerTemperature Selection
Recommended Warming Drawer food settings are shown in Figure 3. If a
particular food is not listed, start with the MED setting. If more crispness is
desired, remove the lid or aluminum foil from the food. Most foods can be kept
at serving temperatures on the MED setting. When a combination of foods are
to be kept warm (for example, a meat with 2 vegetables and rolls) use the HI
setting. To avoid heat loss, do not open the Warming Drawer while in use.
Figure 2
Warming Dra_r_l_commended
Food Settings Table
Food Item Setting
Warming Drawer Indicator Light
The Warming Drawer indicator light is located above the Warming Drawer
control knob (See Fig. 2). It turns on when the control is set, and stays on until
the control is turned off. The warmer drawer will not operate during the self-
clean cycle. Figure 3
Always use pot holders or oven mitts when removing food from the warmer drawer as cookware and plates
will be hot and you can be burned.
Bacon HI
Hamburger Patties HI
Poultry HI
Pork Chops HI
Fried Foods HI
Pizza HI
Gravies MED
Casseroles MED
Eggs MED
Roasts (Beef, Pork, Lamb) MED
Vegetables MED
Biscuits MED
Rolls, hard MED
Pastries MED
Rolls (soft) LO
Empty Dinner Plates LO
12

READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become
familiar with the various features and functions of the oven as described below. Detailed instructions for each feature
and function follow later in this Use & Care Manual.
CONVECTION
BAKE-- Use to select
the Convection Bake
feature (See page 24).
CONVECTION OVEN LIGHT--
ROAST-- Use to Use to turn the
select the Convection oven light on and
Roast feature (See off (See page 30).
OVEN LOCKOUT-- CLOCK--
Use to disable all Use to set
oven features (See the time of
page 16). day. (See
page 14).
0 THRU 9
NUMBER PADS
-- Used to enter
temperature and
times.
BAKE--Use to
enter the normal
baking feature.
(See page 19).
PREHEAT-- Use to
bring the oven
temperature up
before placing food
(See page 16).
Minimum
and
Maximum
Control
Pad
Settings
CLEAN-- Use to
select the Self-
Cleaning feature
(See page 26).
TIMER ON/
OFF-- Use to
set or cancel
the kitchen
timer. The
kitchen timer
does not start
or stop cooking
(See page 15).
\
COOK TIME--
Use to enter the
length of the
baking time.
STOP TIME-- Use
with BAKE,
COOK TIME, and
CLEAN to
program a
delayed baking or
delayed self-
cleaning cycle
stop time.
CLEAR/OFF--Use START--
to cancel any oven Use to start
mode previously all oven
entered except the features
oven lock out, time (not used
of day and minute with Oven
timer. Press Light).
CLEAR/OFF to stop
cooking.
All of the features listed have minimum and maximum time or temperature settings
that may be entered intothe control. An ENTRY acceptance beep will sound each
time a control pad is touched (the Oven Lockout pad is delayed by 3 seconds).
An ENTRY ERROR tone (3 short beeps) will sound ifthe entry of the temperature
or time isbelow the minimum or above the maximum settings for the feature.
FEATURE MIN. TEMP./TIME MAX. TEMP./TIME
PREH EAT TEM P. 170°F /77°C 550°F /288°C
BAKE TEMP. 170°F /77°C 550°F/288°C
BROIL TEMP. 400°F/205°C HI-550°F/288°C
KITCHENTIMER 12Hr. 0:01 Min. 11:59Hr./Min.
24Hr. 0:01 Min. 11:59 Hr./Min.
CLOCKTIME 12Hr. 1:00 Hr./Min. 12:59 Hr./Min.
24 Hr. 0:00 Hr./Min. 11:59 Hr./Min.
OVEN COOK TIME 12Hr. 0:01 Min. 11:59 Hr./Min.
24Hr. 0:01 Min. 23:59 Hr./Min.
STOP TIME 12 Hr. 1:00 Hr./Min. 12:59 Hr./Min.
24 Hr. 0:00 Hr./Min. 23:59 Hr./Min.
CLEAN TIME 2 hours 4 hours
CONVECTION BAKE 300°F /149°C 550°F /288°C
13

;i'i177!!!!!¸!!!!!!!!!!!!7!!¸!!¸!!!!!7!7!@!!¸!{!¸!!!i{!!!{!!!!i!!!7!¸!!!{!@i!!!it!it!it!it!!!!!ii!i!!i!!i!!i!!i!!i!!i!!i!!_!{!{!{!{!{!{!{!{!{!_!!{{t!{!!{t!{!!{t!{!!{t!{!!!_!!!!!!{{t!{!!{t!{!!{t!t_!!!!!!!!i!!!!!!!!!!!!!!i!!!7!7!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!i!7!i,7i_iiii_i_!@i!:i7!:i7!:i7!:i7!:i7!:i7!:i7!:i7!:i7!:@!@i!:i7!:@:!:@7!;;7!;¸7!;;7!;¸7!;;7!;¸7!;;7!;¸7!;;7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!;¸7!i@i!i_i;iiT!i!_!i(i!_i!!_i7!_i!@@!!!
iiiii_i{:i¸;¸ __ _ off
Setting the Clock
The CLOCK @ pad isused to set the clock. The clock may be
set for 12 or 24 hour time of day operation. The clock has been
preset at the factory for the 12 hour operation. When the range is
first plugged in, or when the power supply to the range has been
interrupted, the timer in the display will flash with "PF" (power
failure, See Fig. 1). INSTRUCTIONS
Figure 1
To set the clock (example below for 1:30):
1. Press @. "CLO" will appear in the display (Fig. 2).
2. Press @@@padstosetthetimeofdaytol:30(Fig.
3). "CLO" will appear in the display. Press ,@. "CLO" will
disappear and the clock will start (Fig. 4).
Changing between 12 or 24 hour time of day display:
1. Press and hold @ for 6 seconds (Fig. 3). While holding the
pad down, the current time of day will remain and "CLO" will
disappear from the display (Fig. 4). CONTINUE holding the pad
until the a beep is heard.
PRESS DISPLAY
2. The display will show either "12:00" (Fig. 5) or "24:00" (Fig. 6).
A
3. Press li_l to switch between the 12 and 24 hour time of day
display. The display will show either "12:00" (Fig. 5) or "24:00"
(Fig. 6).
4. Press Ito accept the change or press _ to reject the
change.
for 6 seconds
5. Reset the correct time as described in To set the Clock above.
Please note that if the 24 hour time of day mode was chosen,
the clock will now display time from 0:00 through 23:59 hours.
14
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6

Setting Continuous Bake or 12 Hour Energy Saving
The KITCHEN TIMER _ and CLEAN ) pads control the Continuous Bake or 12 Hour Energy Saving features. The
oven control has a factory preset built-in 12 Hour Energy Saving feature that will shut off the oven if the oven control is left
on for more than 11 hours and 59 minutes. The oven can be programmed to override this feature for Continuous Baking.
INSTRUCTIONS PRESS DISPLAY
To set the control for Continuous Bake or 12 Hour
Energy Saving features:
1. Press and hold _ for 7 seconds (Fig.l). ":12" or ":- -" will
appear in the display and the control will beep once.
2, Press ) to switch between the 12 Hour Energy Saving and
continuous bake features. Note: ":12" in the display indicates
the control is set for the 12 Hour Energy Saving mode and ":- -"
indicates the control is set for the Continuous Bake feature
(Figures 2 and 3).
3. Press Ito accept the change (Fig. 4; display will return to
_for 7 seconds
@
Figure 1
time of day) or press _ to reject the change.
Figure 2
Oct _ Figure 3
Figure 4
Setting Kitchen Timer
The KITCHEN TIMER _ pad controls the Kitchen Timer feature. The Kitchen Timer serves as an extra timer in the
kitchen that will beep when the set time has run out. It does not start or stop cooking. The Kitchen Timer feature can be
used during any of the other oven control functions. Refer to the "Minimum and Maximum Control Pad Settings" on page
15 for the time amount settings.
INSTRUCTIONS
To set the Kitchen Timer (example for 5 minutes):
1. Press @. "0:00" will appear and "TIMER" will flash in the
display (Fig. 5).
PRESS DISPLAY
2. Press the number pads to set the desired time inthe display
(example (_). Press i_1. The time will begin to count down
(Fig. 6) and "TIMER" will appear in the display. Note: If I_) is
not pressed the timer will return to the time of day.
3. When the set time has run out, "End" will show in the display
(Fig. 7), and 3 beeps every 60 seconds will sound until @ is
pressed.
®O
@
To cancel the KitchenTimer before the set time has
run out:
Press _. The display will return to the time of day. @
15
Figure 5
Figure 6
Figure 7

Setting Oven Lockout Feature
The _ pad controls the Oven Lockout feature. The Oven Lockout feature automatically locks the oven door and
prevents the warmer drawer and ESEC Control from being turned on. It does not disable the clock, Kitchen Timer, Warmer
Zone or the interior oven lights.
INSTRUCTIONS PRESS DISPLAY
To activate the Oven Lockout feature:
1. Press and hold @ for three seconds (Fig. 1).
2. After 3 seconds the lock icon light ( I1_ ) will appear, a beep will
sound and "DOOR LOCKED" will flash in the display. Once the
oven door islocked the "DOOR LOCKED" indicator will stop
flashing and remain on along with the lock iconlight.
To reactivate normal oven operation:
1. Press and hold _ for three seconds. A beep will sound. The
"DOOR LOCKED" will continue to flash until the oven door has
completely unlocked and the lock icon light ( I1_ ) will clear
(See Fig. 2).
for 3 seconds
2. The range isagain fully operational.
SettingTemperature Display -- Fahrenheit or Celsius
The BROIL O and CLEAN 6) pads control the Fahrenheit or Celsius
temperature display modes. The oven control can be programmed to display
temperatures in Fahrenheit or Celsius. The oven has been preset at the factory to
display inFahrenheit.
INSTRUCTIONS PRESS
To change display from Fahrenheit to Celsius or
Celsius to Fahrenheit:
Figure 1
Figure 2
DISPLAY
A
1. To tell if the display is set for Fahrenheit or Celsius press I_
(Fig. 3) and hold for 7 seconds. A beep will then sound. If "F"
appears, the display is set to show temperatures in Fahrenheit
(Fig. 4). If "C" appears, the display is set to show temperatures
in Celsius (Fig. 5).
2. Press ) to switch between Fahrenheit or Celsius display
modes. The display will show either "F" (Fig. 4) or "C" (Fig. 5).
3. Press O)to accept the change or press @ to reject the
change.
Ofor 7seconds
@
@or@
16
Figure 3
Figure 4
Figure 5

iii_}i_i_i_!i_il¸_i_Ji_i¸!i_!i_i¸_i_!i_il¸!i_!i_il¸!i_!i_il¸!i_!i_il¸!i_!i_il¸!i_i_i!_i!i!_i_!i!i_!i!_i!i!_i_!i!i_!i!_i!i!_i_!i!i_!i!_i!i!_i_!i!i_!i!_i!i!_i_!i!_!i_!i_ii_i_1_1_1_1_1_1_1_1_i_i_i_i_i_i_i_iiiiiiiiiiiiiiii_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_1_1_1_i!ii!ii!ii!ii!ii!ii!ii!ii!ii!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_i!i_
Setting Silent Control Operation
The STOP TIME @_ and CLEAN !1_ pads control the Silent Control operation feature. The Silent Control operation
feature allows the oven control to be operated without sounds or beeps whenever necessary. If desired the control can be
programmed for silent operation and later returned to operating with all the normal sounds and beeps.
INSTRUCTIONS PRESS DISPLAY
To change control from normal sound operation to
silent control operation:
1. To tell if your range is set for normal or silent operation press
and hold _ for 7 seconds. "DELAY" will appear and flash in
the display (Fig. 1). If ":SP" appears (Fig. 2), the control will
operate with normal sounds and beeps. If ":- -" appears (Fig.3),
the control is in the silent operation mode.
2. Press ,OI to switch between normal sound operation and silent
operation mode. The display will show either ":SP" (Fig. 2) or ":-
-" (Fig. 3).
_for 7seconds
@
4. Press Ito accept the change or press _ to reject the
change.
17
Figure 1
Figure 2
Figure 3

Setting Preheat
The PREHEAT ) pad controls the Preheat feature. The Preheat feature will bring the oven up to temperature and then
indicate when to place the food in the oven. Use this feature when recipes call for preheating. Preheating is not necessary
when roasting or cooking casseroles. The oven can be programmed to preheat at any temperature between 170°F to
550°F. INSTRUCTIONS PRESS DISPLAY
To set the Preheat temperature for 350°F:
1. Arrange the interior oven racks.
2. Press ,,... o,,and "BAKE" will appear inthe display (Fig.
1).
3. Press @ @ @. "350°" and "PRE" will appear in the
display (Fig. 2).
4. Press "PRE" and "BAKE" will appear in the display as the
oven heats and reaches 350°F (Fig 3).
®®®
@
Note: After the oven has reached the desired temperature (this
example, 350°F) the control will beep and the "PRE" light will turn
off and oven temperature will be displayed (Fig. 4). If the beep was
missed, a quick glance at the display with oven temperature
showing in the oven display isa good way to check that the oven
has already reached the preheat temperature. Once the oven has
preheated, PLACE FOOD IN THE OVEN. The "BAKE" light will
stay on.
Press @ when baking is complete or to cancel the preheat
feature. @
To change Preheat temperature while oven is
preheating (example changing from 350 to 425°F):
If it is necessary to change the preheat temperature while the oven
ispreheating to the original temperature:
1. While preheating, press i "- - -°" and "BAKE" will appear in
the display (Fig. 5)
2. Enter the new preheat temperature. Press _ @@.
"425°'' and "BAKE" will appear in the display (Fig. 6).
,
4,
Press "PRE" and "BAKE" will appear in the display as the
oven heats to 425°F (Fig 7). A beep will sound once the oven
temperature reaches 425°F and the display will show "425°`'
and "BAKE".
When baking iscomplete press _.
®®®
@
18
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Figure 8

.......
Setting Bake
The BAKE pad controls normal baking. Ifpreheating isnecessary, refer to the Preheat Feature for instructions.
The oven can be programmed to bake at any temperature from 170°F to 550°F (The sample shown below is for 350°F).
INSTRUCTIONS PRESS DISPLAY
To set the BakeTemperature to 350°F:
1. Arrange interior oven racks and place food in oven.
2. Press ), ,,... o, will appear in the display (Fig. 1).
3. Press @ @ @ (Fig. 2). "BAKE" will flash and "350°" will
appear in the display.
4. Press, "BAKE" and "350 °'' will appear in the display (See
Fig. 3).
Note: A beep will sound once the oven temperature reaches 350 ° F.
Pressing @ will cancel the Bake feature at any time.
®®®
@
To change the BakeTemperature (example chang,ng
from 350 °to 425°F):
1. After the oven has already been set to bake at 350°F and the
2,
3.
oven temperature needs to be changed to 425°F, press
(Fig.4) and "- - - o ,,will show in the display.
Press _ @ @ (Fig. 5). "425°" and "BAKE" will appear in
the display.
Press, "BAKE" and the new oven temperature "425°" will
appear in the display (Fig 6).
®®®
@
19
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6

SettingTimed Bake
The BAKE O and COOK TIME @ pads control the Timed Bake feature. The automatic timer of the Timed Baked
feature will turn the oven off at the time you select in advance.
INSTRUCTIONS PRESS DISPLAY
To program the oven to begin baking immediately
and to shut off automatically: (example below to
bake at 350°F for 50 minutes):
1,
2.
3.
4.
5.
6.
7.
Be sure the clock is set for the correct time of day.
Arrange interior oven rack(s) and place the food inthe oven.
Press ), ,,... o, will appear in the display (Fig. 1).
Press Q @ @ (Fig. 2). "BAKE" will flash and "350°" will
appear in the display.
Press _ "BAKE" and "350 °'' will appear inthe display. (See
Fig. 3).
Press @. "TIMED" will flash; "BAKE", "0:00" and "350 °''
will appear in the display (Fig.4).
Enter the desired baking time by pressing @ @. "TIMED"
i i
will flash and "BAKE", ":50" and "350°'' will appear in the
display (Fig. 5). Note: Baking time can be set for any amount of
time between 1 minute to 11 hours and 59 minutes.
8. Press Both the "TIMED" and "BAKE" icons will remain on
inthe display (Fig. 6). Once the Timed Bake feature has
staffed, the current time of day will appear in the display.
Note: After the Timed Bake feature has activated, press @ to
display the bake time remaining in the Timed Bake mode. Once
Timed Bake has staffed baking, a beep will sound when the oven
temperature reaches the set temperature.
Press @ when baking iscomplete or at any time to cancel the
Timed Bake feature.
®®®
@
®®
@
When the timed bake time runs out:
1. "End" will appear in the display and the oven will shut off
automatically (Fig. 7).
2. The control will beep 4 times. The control will continue to beep
3 times each minute until @ is pressed.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Use caution with the TIMED BAKE or DELAYED TIME BAKE features. Use the automatic timer when
cooking cured or frozen meats and most fruits and vegetables. Foods that can easily spoil such as milk, eggs, fish, meat
or poultry, should be chilled inthe refrigerator first. Even when chilled, they should not stand in the oven for more than 1
hour before cooking begins, and should be removed promptly when cooking iscompleted. Eating spoiled food can result in
sickness from food poisoning.
20
