Frigidaire FES300WC User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FES300WCWC 37954310A5013 WHITE U.S.A.
FES300WCWE 37954310A5015 WHITE U.S.A.
FES300WCDC 37954310A5033 ALMOND U.S.A.
FES300WCDE 37954310A5035 ALMOND U.S.A.
ELECTRIC - RANGE
Model No.
FES300WC
©1998 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC SLIDE-IN RANGE
WIRING DIAGRAM # - 318045000
OWNER’S GUIDE # - 318200805
TIMER INSTRUCTION GUIDE # - 318200104
INSTALLATION INSTR. # - 318104602
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995315040
981117
-EN/SERVICE
377

Publication No. FES300WCW/D
5995315040
11/98 2
BACKGUARD
LAP23G0003B
28
12
54A
54A
23
14A
64
14
69
18A
54 14
54
21
102
18
36
36
36
42
36
19
20
32
24
46
46

FES300WCW/D Publication No.
5995315040
# = Functional Part 311/98
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
12# 5303311369 AB C D Thermostat-oven
14 5303051533 AB C D Light/Lamp
14A 3051539 AB C D Light-lamp-oven indicatrice
18 5303300160 AB C D End Cap black RH
18A 5303300161 AB C D End Cap black LH
19 5303311121 AB C D Panel-control
20# 318012300 AC Clock/Timer
20# 318011401 B D Clock/Timer
21 318027800 AC Trim-backguard
21 318027803 B D Trim-backguard
23 318015001 AB C D Bracket-clock mtg
24 # 316005602 AB C D Switch-rocker black
28 5303311122 AC Knob-clock
28 5303272306 B D Knob-clock
32 318016306 AB C D Knob-thermostat
36 5303299751 AB C D Knob-control black
42 318106900 AC Trim-vent black
42 318106903 B D Trim-vent black
46 5308006417 AB C D Lens-light/lamp
54 # 318120501 AB C D Switch-surface unit
54A# 5303311186 AB C D Switch, surface unit
64 318112200 AB C D Plate
69 5303305528 AB C D Screw, switch mtg
102 318055600 AB C D Bracket-mounting
* 5303323145 AB C D Nut
* 5303311124 AB C D Screw 6-20 X ½
*5303211311 AB C D Screw, #8 X ½
A= FES300WC (FES300WCWC)
B= FES300WC (FES300WCWE)
C= FES300WC (FES300WCDC)
D= FES300WC (FES300WCDE)

FES300WCW/D Publication No.
5995315040
11/98 4
BODY
63
68
170
170A
5
3B
102 62
71
87
80
LAP23V0072B
6
67
25
83
58B
58A
10
9
127
12
70
191
3
70
114
114
1A
62
14
54 15 16
17
81
81
1
192
146
59
56
56
41
86
86
76
217
41
66
3A
5
102
5
145
58D
4134
27

FES300WCW/D Publication No.
5995315040
# = Functional Part 511/98
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
1 5303310527 AB C D Back-main
1A 5303311161 AB C D Panel-back
3 5303300143 AB C D Panel-bodyside
3A 5303280349 AB C D Panel-bodyside RH
3B 5303280351 AB C D Panel-bodyside LH
4318133400 AB C D Burner box
5 318175500 AB C D Screw-leveling
6 5303310522 AB C D Rack-oven
9 5303317977 AB C D Pan-broiler
10 5303317976 AB C D Insert-broiler pan
12 # 5301314211 AB C D Switch-light
14 5308011085 AB C D Socket-light/lamp
15 3201908 AB C D Lamp-oven light
16 3201911 AB C D Glass-oven light lens
17 5304400195 AB C D Retainer-lens
25 5303311141 AB C D Shield-heat
27 5303284616 AB C D Clip-thermo bulb
41 5303310526 AB C D Cover-hinge cutout
54 5303310514 AB C D Housing-oven light
56 318002602 A B Trim-oven front white
56 318002603 C D Trim-oven front almond
58A 5303310519 AB C D Insulation wrapper
58B 5303310516 AB C D Insulation oven back
58D 3008673 AB C D Insulation
59 5303311139 AB C D Tube-oven vent
62 # 5303310518 AB C D Terminal Block
63 5303310517 AB C D Plate-ground strap
66 # 5303310513 AB C D Element-broil
67 # 5303310512 AB C D Element-bake
68 5304403015 AB C D Support-element
70 5303300142 AB C D Shield-insulation
71 5303310515 AB C D Cover-wiring
76 318124101 AB C D Front-oven
80 5303324473 AB C D Bracket-oven
81 5303301261 AB C D Spring-oven
83 318089600 AB C D Liner-oven
86 5303310524 AB C D Channel-hinge
87 318111800 AB C D Plate-mounting
102 5303311142 AB C D Support-oven front
114 3051827 AB C D Plate-filler
127 5303310542 AB C D Adapter assy
134 5303319029 AB C D Shield rear wall
145 5303311108 AB C D Weight
146 318038500 AB C D Cover weight
170 3203576 AB C D Anti-tip bracket right
170A 3203575 AB C D Anti-tip bracket left
191 5303304030 AB C D Bracket
192 318042600 AB C D Plate-renforcement
217 316042301 AB C D Plaque warning
* 5303211311 AB C D Screw #8 X ½
*5303325173 AB C D Cap-plug
A= FES300WC (FES300WCWC)
B= FES300WC (FES300WCWE)
C= FES300WC (FES300WCDC)
D= FES300WC (FES300WCDE)

FES300WCW/D Publication No.
5995315040
11/98 6
TOP/DRAWER
143
17
18
18
16
19A
93
93
93
93
27
27
15A
15
15A
15
19
19A
19
LAP23T0002
28
28
28
28
1
4
11
11
13
70
72
13A
72
71

FES300WCW/D Publication No.
5995315040
# = Functional Part 711/98
* = Non-Illustrated Part
TOP/DRAWER
POS. NO PART NO DESCRIPTION
1 5303310500 AB C D Drawer-utility
4 5303311126 A B Panel-drawer white
45303311131 C D Panel-drawer almond
11 5303311125 AB C D Bracket-drawer
13 5303311129 AB C D Channel-drawer RH
13A 5303311130 AB C D Channel-drawer LH
15# 5303309001 AC Element-surface 2600W
15# 5308011964 B D Element-surface 2100W
15A# 5303309000 AC Element-surface 1500W
15A# 5303299749 B D Element-surface 1250W
16 5303300166 A B Main Top white
16 5303300167 C D Main Top almond
17 3051554 AB C D Rod-maintop support
18 5303305530 AB C D Bracket-hinge main top
19 318067010 AB C D Pan-surface element
19A 5303280336 AB C D Pan-surface element
27# 5303323704 AB C D Terminal block
28 5303301461 AB C D Medaillon surface element
70 5303311143 AB C D Bracket-slide
71 5303311144 AB C D Magnet & spring assy
72 5303311145 AB C D Bracket & wheel assy
93 318122500 AB C D Support terminal block
143 5303300148 AB C D Bracket-hinge
*5303211311 AB C D Screw, #8 x ½
*5303320848 AB C D Screw, 6-20 X ¼
A= FES300WC (FES300WCWC)
B= FES300WC (FES300WCWE)
C= FES300WC (FES300WCDC)
D= FES300WC (FES300WCDE)

Publication No. FES300WCW/D
5995315040
11/98 8
DOOR
54
10
5
15
13
23
23
20
32
39
16
22
22
55
50
18
50
18
15A
9
12
20
LAP23CD004A

FES300WCW/D Publication No.
5995315040
# = Functional Part 911/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
55303310508 AB C D Glass-oven door
9 318112910 AB C D Liner-oven door
10 5303324305 AB C D Screw handle
12 318053301 AB C D Seal-oven door
13 318009026 A B Panel oven door white
13 318009027 C D Panel oven door almond
15 5303311136 AB C D Bracket-glass mtg RH
15A 5303311137 AB C D Bracket-glass mtg LH
16 5303310507 AB C D Glass-oven door
18 5303310505 AB C D Seal-rope
20 318014301 A B Spacer-handle white
20 318014302 C D Spacer-handle almond
22 5303310511 AB C D Retainer-glass
23 5303310506 AB C D Hinge
23* 3201899 AB C D Washer
32 318057202 AB C D Deflector-handle
39 31609119 A B Handle-door white
39 316091120 C D Handle-door almond
50 318144900 AB C D Strenchening glass
54 5303317175 AB Screw 8-18 X ½ white
54 5303300265 C D Screw 8-18 X ½
55 318122300 AB C D Bracket-glass
* 5303307980 AB C D Screw 8-32 X 7/16
*5303211311 AB C D Screw, #8 x ½
*08016432 AB C D Screw, 8-18 X 3/8
A= FES300WC (FES300WCWC)
B= FES300WC (FES300WCWE)
C= FES300WC (FES300WCDC)
D= FES300WC (FES300WCDE)

Publication No. FES300WCW/D
5995315040
11/98 10
