Frigidaire GLGFZ376F User manual

GLGFS75DC.eps T24G0009.eps T24B0002.eps T24V0026.eps T24T0058.eps
T24D0026.eps 316417808d.eps 316417808s.eps
Product No. GLGFZ376FCA
Series 30" f/s gas
Color stainless
Market North America
Wiring Diagram 316417808
Owner's Guide 316417129
Installation Instructions 316259336
Service Data Sheet 316417603
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995471652
06/08/03
(EN/SERVICE/BJH)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
GLGFZ376F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995471652 GLGFZ376FCA
08/06 2
BACKGUARD

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 3 08/06
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
2 316051600 Shield, backguard, inner
2A 316235100 Shield, top, inner
14A 316022500 Light/Lamp, indicator, 125 V
15 316411405 Support, backguard, black, RH
15A 316411404 Support, backguard, black, LH
19 316424128 Panel, control, black
20 # 316418303 Clock/Timer, electronic, ES330
20A 316419300 Overlay, clock, black, ES330
24C 316259800 Switch-rocker, black
36 316220002 Knob, top valve, black, 4
40 316447300 Panel, manifold, black
42 316416200 Trim, extrusion, black
46 316040201 Lens, indicator light, red
56 316230701 Shield, backguard, inner
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995471652 GLGFZ376FCA
08/06 4
BURNER

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 5 08/06
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 316219500 Pipe, manifold
2A # 5303935236 Valve, 14K burner, w/mtg screw
2B # 5303935235 Valve, 5K burner, w/mtg screw
2C # 5303935234 Valve, 9.5K burner, w/mtg screw
3 # 316219004 Wiring Harness, w/igntr switch
8 # 316135701 Module, spark
10A# 316223400 Burner, sealed, 14K
10B# 316206400 Burner, sealed, 5K
10C# 316212400 Burner, sealed, 9.5K
11 # 316237701 Ignitor/orifice assy., top burner, rear, 9.5K, w/holder, tube
11A# 316272000 Ignitor/orifice assy., top burner, front
11B# 316237700 Ignitor/orifice assy., top burner, rear, 5K, w/holder, tube
11C# 316237800 Ignitor/orifice assy., top burner, front
13 # 316405300 Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 Regulator, pressure
14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 Bracket, regulator
16 # 316405500 Tube, valve to regul., 3/8
17 # 316404901 Valve, safety
17* 08068018 Shield, wire, safety valve
18 # 316404400 Burner, oven
19 # 316428501 Ignitor, oven burner
20 316401401 Baffle, oven burner
21 5303013272 Nut, hex head sems
22 # 316405401 Tube, valve to mixer
23 # 316404300 Burner, broiler
24 # 316409700 Elbow, mixer
25 316401301 Baffle, broil burner
26 # 316428601 Ignitor, burner
26* 316401500 Cover, broil Ignitor
37 316240600 Screw, assy mtg, ignitor/orifice
44A 316237900 Orifice, top burner, 14K
44B 316237903 Orifice, top burner, 5K
44C 316237902 Orifice, top burner, 9.5K
47 GRLP2 LP Conversion Kit, w/instructions
47* 316248105 Instructions, LP kit
* # 316253700 Wiring Harness, ignitor module
* 316215600 Screw, valve mtg., 1/4 - 20
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995471652 GLGFZ376FCA
08/06 6
BODY

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 7 08/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401600 Back, main
2 316402201 Shield, oven top
2* 316437100 Brace, oven top
3 316400118 Panel, bodyside, black, RH
3 316400119 Panel, bodyside, black, LH
4 316201403 Burner Box
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316407201 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 Rack, oven
8 316400603 Panel, oven bottom
12 316445500 Switch, oven light, door frame
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
25 316406200 Shield, heat, lower
29 316407301 Glide, drawer, front
30 316217700 Bracket, hinge, RH, main top
30A 316217701 Bracket, hinge, LH, main top
33 316402500 Shield, rear wall
35 316116600 Gasket, flue
36 316208901 Flue
37 # 316217001 Probe, oven temp
39 3202006 Cord, electric power
42 316400703 Shield, wool, lower
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316246501 Spacer, oven door
49 316234200 Clip, maintop mtg, (2)
54 316404200 Shield, heat
55 316404800 Shield, flue
58A 316403700 Insulation, oven wrapper
58B 316403600 Insulation, oven back
58G 08067973 Insulation, main front
82 316400801 Shield, bake burner
82* 316432800 Clip, wire
86 316441300 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316401200 Bracket, harness
88 316232700 Rod, auto latch
89 # 316464300 Motor-latch
90 316401100 Shield, main front
91 316401000 Shield, front, burner
106 316404100 Bracket, motor mtg.
107 316026701 Cover, fan
108# 316415700 Motor, convection
109 316136400 Blade, fan
110 316136500 Washer, flat
111 316136600 Nut, fan retainer
151 316404600 Shield, bodyside

Publication No: 5995471652 GLGFZ376FCA
08/06 8
BODY

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 9 08/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
264 316404700 Bracket, air dam
* # 316416603 Harness, wiring, main
* 316231800 Cover, hole, conv. element
* 5303321321 Paint, touch-up, black
* 316021132 Screw, 8-18 X 11/16, black
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995471652 GLGFZ376FCA
08/06 10
TOP/DRAWER
T24T0058
20
20
22B
22C
22C
22A
16
88
1
2
4
7
39

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 11 08/06
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316408701 Drawer, utility
2 316403200 Liner, drawer
4 316409306 Panel, drawer, stainless, outer
7 316407400 Glide, drawer, rear
16 316202349 Main Top, black
20 316202400 Grate, black
22A 316206600 Cap, 5K burner, black
22B 316219900 Cap, 14K burner, black
22C 316213500 Cap, 9.5K burner, black
39 316270200 Handle, door, black
39* 316437500 Screw, handle mtg., 10 14 x .4 trus, (2)
88 316099500 Pin, guide, (2)
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995471652 GLGFZ376FCA
08/06 12
DOOR

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 13 08/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316452701 Glass, oven door, black, outer
6 316402307 Shield, wool
7 316403900 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 316423801 Liner, oven door
10 316433303 Screw, 10-14 x 1.820", handle mtg.
12 316403101 Seal, oven door
13 316407809 Panel, oven door, stainless
17 316402403 Spacer, door glass, (2)
20 316408600 Spacer, door handle, (2)
23 316456302 Hinge, oven door, red titan, (2)
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316270200 Handle, door, black
53 316408101 Shield, filler, door, (2)
55 316408300 Bracket, glass support, (4)
60B 316021110 Screw, 8-18 x 0.5, black
* 316433603 Label, anti-tip
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995471652 GLGFZ376FCA
08/06 14
WIRING SCHEMATIC

GLGFZ376FCA Publication No: 5995471652
# Functional Parts 15 08/06
* Non-Illustrated Parts
WIRING DIAGRAM
