Product No. PLCS388ECA
37957361J63S1
Series 30" slide-in
Color stainless
Market North America
Wiring Diagram 318271904
Owner's Guide 318203862
Installation Instructions 318201671
Service Data Sheet 318127021
Timer Guide 318204100
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995468054
06/06/13
(EN/SERVICE/ECL)
377
30-INCH SLIDE-IN GAS
RANGE
Model No.
PLCS388E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995468054 PLCS388ECA
06/06 2
BACKGUARD

PLCS388ECA Publication No: 5995468054
# Functional Parts 3 06/06
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
16 318299102 Console, assy., black
19 318312242 Control Panel Assembly, w/membrane, stainless
19A 318224404 Panel, control mtg.
20 # 316418731 Clock/Timer, electronic, ES510
20* 5304453707 Screw, control mtg.
35 318233720 Retainer, control panel, black
36 318319302 Knob, control, black, (4)
42 318298001 Trim, vent, black, upper
99A 318223900 Gasket, dark grey
100 318233800 Nut, hex
101 318233400 Bushing, retainer
* # 318224813 Harness, wiring, timer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303311333 Screw, 8-32 x 3/8

Publication No: 5995468054 PLCS388ECA
06/06 4
BURNER

PLCS388ECA Publication No: 5995468054
# Functional Parts 5 06/06
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 318305600 Manifold, right side
1A 318305601 Manifold, left side
1B 318305410 Tube, manifold, 3/8, interconnect
2 # 318233930 Valve, top burner, 14000 BTU
2A # 318233940 Valve, top burner, 17000 BTU
2B # 318233900 Valve, top burner, 5000 BTU
2C # 318233910 Valve, top burner, 9500 BTU
3 # 318232600 Wiring Harness, w/igntr switch
10 # 316223400 Burner, sealed, 14K
10A# 316223300 Burner, sealed, 17K
10B# 316206400 Burner, sealed, 5K
10C# 316212400 Burner, sealed, 9.5K
11 318306106 Ignitor Assembly, 14K, left rear, w/tube & holder
11A 318306107 Ignitor Assembly, 16K, right front, w/tube & holder
11B 318306108 Ignitor Assembly, 5K, right rear, w/tube & holder
11C 318306104 Ignitor Assembly, 9.5K, left front, w/tube & holder
12 318369900 Bracket, support, (2)
13 318305110 Tube, regulator, to manifold
14 # 318122700 Regulator, pressure
14* 5303311306 Screw, 8-18 x 0.375, (3)
16 318590002 Panel, regulator mtg.
37 5303307980 Screw, 8-32 x 0.437, (4)
44 316237900 Orifice, top burner, 14K
44A 316237912 Orifice, top burner, 16K
44B 316237903 Orifice, top burner, 5K
44C 316237902 Orifice, top burner, 9.5K
72 316215600 Screw, valve mtg., 1/4 - 20
77 318192606 Bracket, burner mtg, (4)
300 318322300 Bracket, inlet, long, door
301 318322301 Bracket, inlet, short, block
* 318186909 LP Conversion Kit
* 318199725 Wiring Harness, ignitor
* 08011955 Screw, 10-24 x 0.375, square drive
* 5303211311 Screw, 8 x 0.500

Publication No: 5995468054 PLCS388ECA
06/06 6
BODY

PLCS388ECA Publication No: 5995468054
# Functional Parts 7 06/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 318259204 Back, main
1A 318225110 Panel, main back, upper
2 318258902 Shield, insulation, upper
3 318225210 Panel, bodyside, upper RH
3A 318225211 Panel, bodyside, upper LH
5 318175503 Screw, leveling
6 318345208 Rack, oven
6A 318219500 Rack, broiler pan
8 318262001 Cover, element
8A 318318600 Bracket, element, hidden bake
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 5303935061 Terminal Block Kit
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
63 318264200 Plate, grounding strap
66 # 318255600 Element, broil, 2750W
67 318254901 Element, bake, 3400W, 8 pass
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258708 Shield, insulation, lower
83 318261400 Liner, oven assy
86 5303310524 Receptacle, hinge
87 318260609 Bracket, cable mtg.
87A 318111804 Plate, cord set mtg
89 # 318261209 Motor, latch assy
90 318296904 Panel, filler, black, RH
90A 318296905 Panel, filler, black, LH
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 318249401 Tube, protector
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer

Publication No: 5995468054 PLCS388ECA
06/06 8
BODY

PLCS388ECA Publication No: 5995468054
# Functional Parts 9 06/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
112# 318112703 Relay
119# 318005202 Switch, thermal cutout
125# 316415800 Motor, fan
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
161# 318255503 Element, convection, 350 W
163 318014110 Spacer, (6)
166 318298410 Bracket, base support, (2)
166A 318298403 Bracket, base support, lower, (2)
170 318335500 Anti-tip & accessories
185 318165800 Spacer
200 318298201 Frame, drawer, black, front
201 318298210 Frame, drawer
219# 318003614 Thermostat, safety
219A 318003613 Thermostat, safety, 1.375" mtg, 105/120
263 316136500 Washer, flat
* # 318224936 Harness, wiring, main
* 318235300 Connector assy., w/3 lugs, & instructions
* 3051050 Screw, shoulder
* 3201861 Screw, 6 x 0.375, (4)
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303307980 Screw, 8-32 x 0.437, (4)
* 5303323129 Screw, 8 X 0.750
* 5304415832 Screw, 8-18 x 0.406
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995468054 PLCS388ECA
06/06 10
TOP

PLCS388ECA Publication No: 5995468054
# Functional Parts 11 06/06
* Non-Illustrated Parts
TOP
POS. NO PART NO. DESCRIPTION
1 318304401 Drawer, body assembly
1A 318300000 Panel, warmer drawer, side, (2)
1C 318300300 Panel, warmer drawer, rear
2 318303901 Panel, drawer, black, inner
4 318298800 Panel, drawer, stainless, front
8 # 316135701 Module, spark
13 318259507 Glide, warmer, inner RH
13A 318259506 Glide, warmer, inner LH
16 318320002 Maintop Assembly, black
20 # 316424203 Grate, black, (2)
20A 318221724 Grate, black, center
22 316219905 Cap, 14K burner, black
22A 316271904 Cap, 17K burner, black
22B 316206604 Cap, 5K burner, black
22C 316213505 Cap, 9.5K burner, black, (2)
29 318147430 Bumper, (2)
39 318219802 Handle, door/drawer, stainless
46 318291401 Box, burner
50 318328500 Cover, burner box
57 318295611 Panel, service
60 5303311174 Screw, 10-24 x 3/8
81 # 318255300 Element, warmer drawer
84 # 318005108 Thermostat
85 318257600 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 318300100 Panel, warmer drawer, lower
95 318303800 Shield, wire
124 316105501 Glide, outer/RH & LH, (2)
165 318227504 Plate, mounting
* 318199749 Wiring Harness, drawer
* 5303325171 Washer, plastic
* 318163600 Cleaner, cooktop
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303311333 Screw, 8-32 x 3/8

Publication No: 5995468054 PLCS388ECA
06/06 12
DOOR

PLCS388ECA Publication No: 5995468054
# Functional Parts 13 06/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260520 Baffle, door
7 318285057 Insulation, oven door
7A 318285062 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, door
10 5303311174 Screw, 10-24 x 3/8
12 318053120 Seal, door, upper oven
13 318272156 Door Assy, w/nameplate, stainless steel, outer, w/tape & foil
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, door, (2)
24 318260301 Trim, door, black, lower
39 318219802 Handle, door/drawer, stainless
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 316221001 Label, anti-tip
* 5304415832 Screw, 8-18 x 0.406

Publication No: 5995468054 PLCS388ECA
06/06 14
WIRING DIAGRAM
