FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF305PHDA FEF305PH ALMOND USA
FEF305PHWA FEF305PH WHITE USA
Publication No.
5995323846
990526
-EN/SERVICE /SBR
369
WIRING DIAGRAM # - 316002675
OWNER’S GUIDE # - 316000629
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF305PHDA
FEF305PHWA

07/98 2
Publication number
5995323846 FEF305PHDA, FEF305PHWA
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FEF305PHDA, FEF305PHWA 5995323846
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF305PH (FEF305PHDA)
B = FEF305PH (FEF305PHWA)
POS. NO PART NO DESCRIPTION
* 316002675 A B Diagram-wiring
* 316000629 A B Owner’s Guide
* 316003025 A B Installation Instructions
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316112500 A B Template, Anti-tip bracket
* 5303272555 A B Clip-backguard
1 3131123 A B Shield-backguard,rear wall
9 316043601 - B Trim-splasher,white
9 316043602 A - Trim-splasher,almond
11 316057002 A B Trim-wrapper
12 # 5303212745 A B Thermostat-oven
14 3201726 A B Light/Lamp,indicator ,blue ,250 V
15 5303131237 A B Support-backguard,(2)
16 316042602 A B Plate,instrument mtg
19 316034120 A B Panel-control,metal
30A 316064300 A B Nut,nylon
32 316123301 A B Knob-thermostat
36 316123303 A B Knob-infinite switch, black
40 316064009 A B Panel-manifold,black
44 3131468 A B Bracket,backguard
45A 316056902 A B Bolt-fastener,nylon
46 316065801 A B Lens-light/lamp,indicator ,red
50 316096900 A B Bezel-nameplate,black
51 316095420 A B Nameplate,black
54 # 5303285142 A B Switch-6" element
54A# 5303285143 A B Switch-8" element

07/98 4
Publication number
5995323846 FEF305PHDA, FEF305PHWA
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 5 07/98
Publication number
FEF305PHDA, FEF305PHWA 5995323846
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF305PH (FEF305PHDA)
B = FEF305PH (FEF305PHWA)
POS. NO PART NO DESCRIPTION
* 3051367 A B Clip-wire
* 3203550 A B Plug-button
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 5303051099 A B Nut,hex ,#10-32
* 5303284616 A B Clip-thermo bulb
* 5308014215 A B Screw,8-X 1/2 ,(4)
*# 316001559 A B Harness-main
1 316080804 A B Back-main, short,dipped ,black
3 316081034 - B Panel-bodyside, white ,RH
3 316081035 - B Panel-bodyside, white , LH
3 316081036 A - Panel-bodyside,almond ,RH
3 316081037 A - Panel-bodyside,almond ,LH
4 5303271756 A B Burner Box
5 316107300 A B Screw-leveling
6 316067902 A B Rack-oven
7 316007007 A B Hinge-oven door,(2)
8 3203540 A B Panel-oven bottom
9 316081900 A B Pan-broiler
10 316082000 A B Insert-broiler pan
21 3014099 A B Spacer-bodyside, (8)
27 5303284616 A B Clip-thermo bulb
29 3051162 A B Glide-drawer,front
41 3131570 A B Cover-hinge cutout
44 3131903 A B Bumper-door/drawer, rubber
57 316081101 A B Cover-access
58 3200847 A B Insulation,oven bottom
58A 316047707 A B Insulation, 1" ,oven wrapper
58B 316054202 A B Insulation, 1" ,oven back
59 316073601 A B Tube-oven vent
62 # 5303935061 A B Terminal Block
63 5301145190 A B Plate-ground strap
66 # 5303051140 A B Element-broil
67 # 316075102 A B Element-bake,lower oven
68 316075300 A B Support-element, broil
69 3051218 A B Plate-oven light
71 316015805 A B Shield-rear wall
82 5303289913 A B Shield-insulation
87 316081200 A B Bracket-cable mtg
170 316107200 A B Anti-tip bracket
170* 316116000 A B Screw-Anti tip, 1.75" concrete

07/98 6
Publication number
5995323846 FEF305PHDA, FEF305PHWA
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 7 07/98
Type your model numbers here
CAUTION: Use the Kenmore part number on all orders, not the position number.
TOP/DRAWER
A = FEF305PH (FEF305PHDA)
B = FEF305PH (FEF305PHWA)
POS. NO PART NO DESCRIPTION
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316021112 - B Screw-8-18x1/2 Tr Sqd White
* 316021113 A - Screw-8-18x1/2 Tr Sqd Almond
* 316089600 A B Spacer-drawer,(2)
* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)
* 5308014215 A B Screw,8-X 1/2 ,(4)
* # 316001731 A B Harness-wiring,surface element
1 316011501 A B Drawer-utility
2 3131975 A B Shield-panel
4 316084405 - B Panel-drawer,white
4 316084406 A - Panel-drawer,almond
4* 08067785 A - Screw,hex washer head ,8-18AB x 1/2
7 3051163 A B Glide-drawer,rear
15 # 3051450 A B Element-surface, 8" , large
15A# 3051449 A B Element-surface,6”, small
16 3013512 A - Main Top,almond
16 5303013511 - B Main Top,white
17 316066900 A B Rod-maintop support
18 08067747 A B Bracket-hinge,main top RH
18A 08067746 A B Bracket-hinge,main top LH
19 # 316048413 A B Pan-surface element,chrome ,
large/8 inch,(2)
19A# 316048414 A B Pan-surface element,chrome ,
small/6 inch,(2)
27 # 5303912666 A B Terminal Block Kit,surface element
28 5303017715 A B Medallion,1 1/2"dia ,black ,
surface element

07/98 8
Publication number
5995323846 FEF305PHDA, FEF305PHWA
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 9 07/98
Publication number
FEF305PHDA, FEF305PHWA 5995323846
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FEF305PH (FEF305PHDA)
B = FEF305PH (FEF305PHWA)
POS. NO PART NO DESCRIPTION
* 316021110 A B Screw-8-18x1/2 Tr Sqd black
* 316102200 A B Foil-aluminum
* 5303212762 A - Screw,8-18 X 1/2
* 5303271648 A B Screw, wafer hd sq dr , 8-18AB x 1/2
* 316071608 A B Anti-tip label
* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)
9 316066611 A B Liner-oven door
10 5303281378 A B Screw-handle mtg,wafer head ,10-24F x 3
12 5303202011 A B Seal-oven door,non self-clean
13 3202315 - B Panel-oven door,white
13 3202316 A - Panel-oven door,almond
39 316020204 A B Handle-door,black ,oven
39* 316008401 A B Washer,3/4 x 1/4 ,steel
49 3016755 A B End Cap,black ,(2)

07/98 10
Publication number
5995323846 FEF305PHDA, FEF305PHWA
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
