Frigidaire PLGF390D User manual

PLGF390DC.eps T24G0015.eps T24B0007.eps T24V0030.eps T24T0031.eps
T24D0013.eps 316417806d.eps 316417806s.eps
Product No. PLGF390DCA
Series 30" f/s gas
Color stainless
Market North America
Wiring Diagram 316417806
Owner's Guide 316417103
Installation Instructions 316259336
Service Data Sheet 316417610
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995420816
04/11/03
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
PLGF390D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995420816 PLGF390DCA
11/04 2
BACKGUARD

PLGF390DCA Publication No: 5995420816
# Functional Parts 3 11/04
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
2 316051600 Shield, backguard, inner
2A 316235100 Shield, top, inner
13A 316095500 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316411405 Support, backguard, black, RH
15A 316411404 Support, backguard, black, LH
19 316424129 Panel, control, stainless
20 # 316418701 Clock/Timer, electronic, ES510
20A 316419700 Overlay, clock, black, w/mini oven, ES510
31 316223002 Knob, control, black
36 316220002 Knob, top valve, black, (4)
40 316249005 Panel, manifold, stainless steel
42 316416200 Trim, extrusion, black
46 316040201 Lens, indicator light, red
56 316230701 Shield, backguard, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995420816 PLGF390DCA
11/04 4
BURNER

PLGF390DCA Publication No: 5995420816
# Functional Parts 5 11/04
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 316219501 Pipe, manifold
2 # 5303935233 Valve, 17K burner, w/mtg screw
2A # 5303935235 Valve, 5K burner, w/mtg screw
2B # 5303935232 Valve, 9.5k/12k burner, w/mtg screw
2C # 5303935234 Valve, 9.5K burner, w/mtg screw
* 316215600 Screw, valve mtg., 1/4 - 20
3 # 316219006 Wiring Harness, w/igntr switch
8 318079001 Module, spark
10 # 316223300 Burner, sealed, 17K
10A# 316206400 Burner, sealed, 5K
10B# 316212300 Burner, sealed, 12K
10C# 316212400 Burner, sealed, 9.5K
11 # 316430500 Ignitor/orifice assy., top burner, right front, 16K, w/holder, tube
11A# 316430800 Ignitor/orifice assy., top burner, right rear, 5K, w/holder, tube
11B# 316430401 Ignitor/orifice assy., top burner, left rear, 12K, w/holder, tube
11C# 316430600 Ignitor/orifice assy., top burner, left front, 9.5K, w/holder, tube
11D# 316430700 Ignitor/orifice assy., top burner, center, 9.5K, w/holder, tube
13 # 316405300 Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 Regulator, pressure
14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 Bracket, regulator
16 # 316405500 Tube, valve to regul., 3/8
17 # 316404900 Valve, safety
17* 08068018 Shield, wire, safety valve
18 # 316404400 Burner, oven
19 # 316428500 Ignitor, oven burner
20 316401401 Baffle, oven burner
21 5303013272 Nut, hex head sems
22 # 316405400 Tube, valve to mixer
23 # 316404300 Burner, broiler
24 # 316409700 Elbow, mixer
25 316401301 Baffle, broil burner
26 # 316428600 Ignitor, burner
26* 316401500 Cover, broil Ignitor
37 316240600 Screw, assy mtg, ignitor/orifice
44 316237912 Orifice, top burner, 16K
44A 316237903 Orifice, top burner, 5K
44B 316237901 Orifice, top burner, 12K
44C 316237902 Orifice, top burner, 9.5K
47 GRLP2 LP Conversion Kit, w/instructions
47* 316248105 Instructions, LP kit
* # 316253702 Wiring Harness, ignitor module
* 316064103 Wire, ground assembly
* 316001003 Screw, ground wire
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995420816 PLGF390DCA
11/04 6
BODY

PLGF390DCA Publication No: 5995420816
# Functional Parts 7 11/04
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401600 Back, main
2 316402201 Shield, oven top
2* 316437100 Brace, oven top
3 316400104 Panel, bodyside, black, RH
3 316400105 Panel, bodyside, black, LH
4 316201403 Burner Box
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316407200 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404501 Rack, oven
6A 318219500 Rack, broiler pan
8 316400603 Panel, oven bottom
9 316081900 Pan, broiler
10 316082000 Insert, broiler pan
12 # 316407100 Switch, oven light/door
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, oven light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
30 316217700 Bracket, hinge, RH, main top
30A 316217701 Bracket, hinge, LH, main top
33 316402500 Shield, rear wall
35 316116600 Gasket, flue
36 316208901 Flue
37 # 316217001 Probe, oven temp
39 # 3131425 Cord, electric power
40 316409600 Shield, warmer drawer, upper
41 316409200 Shiled, warmer, RH
41A 316409201 Shield, warmer, LH
42 316400703 Shield, wool, lower
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316246501 Spacer, oven door
49 316234200 Clip, maintop mtg, (2)
54 316404200 Shield, heat
55 316404800 Shield, flue
58A 316403700 Insulation, oven wrapper
58B 316403600 Insulation, oven back
58G 08067973 Insulation, main front
77 316415100 Glide, warmer drawer, outer/RH & LH, (2)
82 316400801 Shield, bake burner
82* 316432800 Clip, wire
86 316407000 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316401200 Bracket, harness
88 316232700 Rod, auto latch
89 # 316415401 Motor, latch/lock
90 316401100 Shield, main front
91 316401000 Shield, front, burner
106 316404100 Bracket, motor mtg.
107 316026701 Cover, fan

Publication No: 5995420816 PLGF390DCA
11/04 8
BODY

PLGF390DCA Publication No: 5995420816
# Functional Parts 9 11/04
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
108# 316415700 Motor, convection
109 316136400 Blade, fan
110 316136500 Washer, fan motor
111 316136600 Nut, fan retainer
151 316404600 Shield, bodyside
161# 316211603 Element, convection fan, 350 W
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
264 316404700 Bracket, air dam
* 316416605 Harness, wiring, main
* 5303305345 Paint, touch-up, black
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 316021132 Screw, 8-18 X 11/16, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420816 PLGF390DCA
11/04 10
TOP/DRAWER

PLGF390DCA Publication No: 5995420816
# Functional Parts 11 11/04
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316408901 Drawer, warmer
2 316403203 Liner, black, drawer
4 316409300 Panel, drawer, stainless, outer
13 316415000 Glide, warmer, inner RH
13A 316415001 Glide, warmer, inner LH
16 316411216 Maintop, black
20 # 316424203 Grate, black, (2)
20A 316424403 Grate, black, center
22 316271900 Cap, 17K burner, black
22A 316206600 Cap, 5K burner, black
22B 316213600 Cap, 12K burner, black
22C 316213500 Cap, 9.5K burner, black
39 316246100 Handle, door/drawer, stainless
81 # 316239201 Element, warmer drawer
82 316093200 Bracket, element mtg
83 316093300 Shield, terminal, warmer drawer
84 316093501 Thermo disc, warmer drawer
85 316425900 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 316091900 Base, warmer drawer
88 316099500 Pin, guide, (2)
96 316122000 Clip, lock, warmer drawer
97 316003802 Screw, Hex HD 3/16", 6 x 3/8
* 316001917 Harness, warmer drawer
* 316279700 Cleaner, stainless steel
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995420816 PLGF390DCA
11/04 12
DOOR

PLGF390DCA Publication No: 5995420816
# Functional Parts 13 11/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316408501 Glass, door front, black
6 316402307 Shield, wool
7 316403900 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 316423801 Liner, oven door
10 316001002 Screw, wafer head, 10-24 x 1.81, (2), handle mtg.
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316403101 Seal, oven door
13 316407801 Panel, oven door, stainless
14 316102208 Foil, 1.5" x 29", aluminum, black
14A 316102205 Foil, 4" x 5.5", aluminum, black, (2)
17 316402403 Spacer, door glass, (2)
20 316408600 Spacer, door handle, (2)
23 316406909 Hinge, oven door
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316246100 Handle, door/drawer, stainless
53 316408101 Shield, filler, door, (2)
53* 316422201 Screw, mach, 10-24 x 1.72", (2)
55 316408300 Bracket, glass support, (4)
60B 316021110 Screw, 8-18 x 0.5, black
* 316433603 Label, anti-tip
* 316279700 Cleaner, stainless steel
* 316431100 Baffle, fish paper, (2)
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420816 PLGF390DCA
11/04 14
WIRING SCHEMATIC

PLGF390DCA Publication No: 5995420816
# Functional Parts 15 11/04
* Non-Illustrated Parts
WIRING DIAGRAM
