Frigidaire Compact Refrigerator User manual

P/N 241721200 (May 2006)
READ AND SAVE THESE INSTRUCTIONS
Refrigerator
Side by Side
Welcome 2
3Safety Instructions
4 - 5
Installation --
Includes Connecting
Ice Maker To Water Supply
7
Features at a Glance
8 - 9Temperature Controls
18
Food Storage
& Energy Saving Tips
13 - 17
Automatic Ice and Water
Dispenser
20 - 21
Care & Cleaning
22
Warranty
23 - 26
Before You Call
Solutions to
Common Problems
6
Door Removal
Instructions
19Normal Operating Sounds
10 - 12
Looking Inside
Español 27
With Electronic Controls
Questions? 1-800-944-9044
1-800-668-4606
(United States)
(Canada)
Visit the Frigidaire Elements Web Site at:
http://www.frigidaireelements.com

2
Welcome & Congratulations
Congratulations on your purchase of a new refrigerator! We
here at Electrolux Home Products are very proud of our
product and we are completely committed to providing you
with the best service possible. Your satisfaction is our #1
priority.
Please read this Use & Care Manual very carefully. It contains
valuable information on how to properly maintain your new
refrigerator.
We know you’ll enjoy your new refrigerator and Thank You
for choosing our product.We hope you consider us for future
purchases.
PLEASE READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating
instructions for your model. Use your refrigerator only as
instructed in this manual. These instructions are not meant
to cover every possible condition and situation that may
occur. Common sense and caution must be practiced when
installing, operating and maintaining any appliance.
Please record your model and serial numbers below for
future reference.This information is found on the serial
plate located inside the refrigerator compartment.
NOTE: Use only soap and water to clean serial plate.
Model Number:
Serial Number:
Purchase Date: Please attach sales receipt
here for future reference.
ExtendYourWarranty Protection
With An
Extended Service Contract
CALL 1-800-944-9044
To Enjoy These Benefits:
• Total freedom from repair bills so
unexpected repairs won’t upset your
budget.
• Fast, convenient toll-free service is just
a phone call away.
• Top-quality repairs by factory-trained
experts.
• Quick access to genuine replacement
parts so you can rest assured your
refrigerator is repaired with the proper
components.
Please complete and mail in the Product
Registration Card included with your
refrigerator.

3
Important Safety Instructions
Please Read All Instructions Before Using This Refrigerator.
FOR YOUR SAFETY
• Do not store or use gasoline, or other flammable liquids
in the vicinity of this or any other appliance. Read
product labels for warnings regarding flammability and
other hazards.
• Do not operate the refrigerator in the presence of
explosive fumes.
• Avoid contact with any moving parts of automatic ice
maker.
• Remove all staples from the carton. Staples can cause
severe cuts, and also destroy finishes if they come in
contact with other appliances or furniture.
CHILD SAFETY
Destroy or recycle the carton, plastic bags, and any exterior
wrapping material immediately after the refrigerator is
unpacked. Children should NEVER use these items to play
with. Cartons covered with rugs, bedspreads, plastic sheets
or stretch wrap may become airtight chambers, and can
quickly cause suffocation.
These Guidelines Must Be Followed To Ensure That Safety Mechanisms In This Refrigerator
Will Operate Properly.
PROPER DISPOSAL OF YOUR REFRIGERATOR
OR FREEZER
Risk of child entrapment
Child entrapment and suffocation
are not problems of the past.
Junked or abandoned refrigerators
or freezers are still dangerous –
even if they will sit for “just a few
days.” If you are getting rid of your
old refrigerator or freezer, please
follow the instructions below to
help prevent accidents.
Before you throw away your old refrigerator/ freezer:
• Remove doors.
• Leave shelves in place so children may not easily climb
inside.
• Have refrigerant removed by a qualified service
technician.
ELECTRICAL INFORMATION
•The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Hz., AC only electric outlet.
The power cord of the appliance is equipped with a
three-prong grounding plug for your protection against
electrical shock hazards. It must be plugged directly
into a properly grounded three-prong receptacle.The
receptacle must be installed in accordance with local
codes and ordinances. Consult a qualified electrician.
Do not use an extension cord or adapter plug.
• If the power cord is damaged, it should be replaced by the
manufacturer, service technician or a qualified person to
prevent any risk.
• Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly, and pull straight out
from the receptacle to prevent damaging the power cord.
• Unplug the refrigerator before cleaning and before
replacing a light bulb to avoid electrical shock.
• Performance may be affected if the voltage varies by
10% or more. Operating the refrigerator with insufficient
power can damage the compressor. Such damage is
not covered under your warranty.
• Do not plug the unit into an outlet controlled by a wall
switch or pull cord to prevent the refrigerator from being
turned off accidentally.
• Avoid connecting refrigerator to a Ground Fault Interruptor
(GFI) circuit.
IMPORTANT: Pressing the On/Off button on the
control panel (at the top of the fresh food compartment)
disables your refrigerator’s cooling system but does
not disconnect power to lights and other electrical
components.To turn off power to your refrigerator you
must unplug the power cord from the wall outlet.

4
This Owner’s Guide provides specific operating instructions
for your model. Use the refrigerator only as instructed in this
Use & Care Manual. Before starting the refrigerator, follow
these important first steps.
LOCATION
• Choose a place that is near a grounded electrical outlet.
Do Not use an extension cord or an adapter plug.
• If possible, place the refrigerator out of direct sunlight
and away from the range, dishwasher or other heat
sources.
• The refrigerator must be installed on a floor that is level
and strong enough to support a fully loaded refrigerator.
• Consider water supply availability for models equipped
with an automatic ice maker.
INSTALLATION
Do Not install the refrigerator where
the temperature will drop below 55°F (13°C) or rise
above 110°F (43°C). The compressor will not be able
to maintain proper temperatures inside the
refrigerator.
Do Not block the toe grille on the
lower front of your refrigerator. Sufficient air circulation
is essential for the proper operation of your
refrigerator.
Installation Clearances
• Allow the following clearances for ease of installation,
proper air circulation, and plumbing and electrical
connections:
Sides & Top --------------- 3/8”
Back ------------------------ 1”
DOOR OPENING
NOTE: If your refrigerator is placed with the door hinge
side against a wall, you may have to allow additional
space so the door can be opened wider.
Your refrigerator should be positioned to allow easy access to
a counter when removing food. For best use of drawers and
freezer baskets, the refrigerator should be in a position where
both the refrigerator and freezer doors can be fully opened.
Installation
TOE GRILLE INSTALLATION / REMOVAL
To Remove Toe Grille:
1. Open freezer and fresh food compartment doors.
2. Working from left side of toe grille, slip your fingers
between top of toe grille and cabinet. Gently pull
forward until first set of tabs are free. Slide your hand
down past the free tabs and pull forward again until the
second set of tabs are free. Continue this process until
all tabs are free and the toe grille can be removed. (See
graphic at top of page in right column.)
3. Check both doors to be sure seals touch cabinet on all four
sides.
LEVELING
All four corners of your refrigerator must rest firmly on a solid floor.
Your refrigerator is equipped with adjustable front rollers to help
level your unit.To ensure proper door seal and assist door closing,
the refrigerator should be tilted 1/4” (6 mm), front to back.
To Level Your Refrigerator:
1. Remove toe grille. (See “To Remove Toe Grille” .)
2. Use flat-blade screwdriver or 3/8” socket wrench to adjust
front rollers.
NOTE: The refrigerator doors are designed to shut by
themselves within a 20 degree opening.
To Install Toe Grille:
1. Open freezer and
fresh food
compartment doors.
2. Line up toe grille at
base of refrigerator,
making sure the four
bottom tabs are
resting through holes
at base of cabinet.
3. Starting from left side
of toe grille, press in on first top tab using your thumb
and push toe grille forward until it snaps in place. Continue
this process until all tabs aresnapped in place and toe
grille is secured to refrigerator.

5
Installation - Connecting Ice Maker To Water Supply
To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator
from electrical power before connecting a water supply line to the refrigerator.
To Avoid Property Damage:
•Copper tubing is recommended for the water supply line.Water supply tubing made of ¼” plastic is not
recommended since it greatly increases the potential for water leaks. Manufacturer will not be responsible
for any damage if plastic tubing is used for supply line.
• DO NOT install water supply tubing in areas where temperatures fall below freezing.
• Chemicals from a malfunctioning softener can damage the ice maker. If the ice maker is connected to soft
water, ensure that the softener is maintained and working properly.
IMPORTANT: Ensure that your water supply line connections comply with all local plumbing codes.
NOTE: Water line kit number 5303917950, available from your appliance dealer at additional cost, contains 25 feet (7.6
meters) of ¼ inch OD copper tubing, a saddle type shutoff valve (nonpiercing), (2) ¼ inch brass compression nuts, (2)
ferrules/sleeves, and instructions for installing a water supply line.
Before InstallingThe Water Supply Line,You Will Need
•BasicTools: adjustable wrench, flat-blade screwdriver, and PhillipsTM screwdriver
• Access to a household cold water line with water pressure between 30 and 100 psi.
• A water supply line made of ¼ inch (6.4 mm) OD, copper tubing.To determine the length of copper tubing needed,
you will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water
pipe.Then add approximately 7 feet (2.1 meters), so the refrigerator can be moved out for cleaning (as shown).
• A shutoff valve to connect the water supply line to your household water system. DO NOT use a self-piercing type
shutoff valve.
• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.
IMPORTANT: It takes approximately 24 hours for the ice maker to begin producing ice. Air in new plumbing lines may
cause ice maker to cycle two or three times before making a full tray of ice. New plumbing may cause ice to be
discolored or have poor flavor. Discard ice made during the first 24 hours.
To Connect Water Supply Line To Ice Maker Inlet Valve
1. Disconnect refrigerator from electric power source.
2. Place end of water supply line into sink or bucket. Turn ON water supply
and flush supply line until water is clear. Turn OFF water supply at shut
off valve.
3. Unscrew plastic cap from water valve inlet and discard cap.
4. Slide brass compression nut, then ferrule (sleeve) onto water supply line,
as shown.
5. Push water supply line into water valve inlet as far as it will go (¼ inch).
Slide ferrule (sleeve) into valve inlet and finger tighten compression nut
onto valve.Tighten another half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to rear panel of
refrigerator as shown.
7. Coil excess water supply line (about 2½ turns) behind refrigerator as shown
and arrange coils so they do not vibrate or wear against any other surface.
8. Turn ON water supply at shutoff valve and tighten any connections that
leak.
9. Reconnect refrigerator to electrical power source.
10. Make sure ice maker power switch is turned On (See page 14 for location of
power switch).

6
Door Removal Instructions
DOOR REMOVAL INSTRUCTIONS:
Before you start:
1Make sure the electrical power cord is unplugged from the wall outlet.
2Remove any food from the door shelves.
3Close the doors.
To remove the hinge cover:
1Remove the three screws from the cover over the top door hinges.
2Pull the cover forward about a half inch and lift it off.
To remove the refrigerator door:
1Trace lightly around the door’s top hinge with a pencil. This makes reinstallation easier.
2Remove the two screws from the top hinge. Lift the door off of the bottom hinge and set it
aside.
3Remove the three bottom hinge screws and hinge, if necessary.
To remove the freezer door:
1Detach the multi-wire cable connector located above the top hinge. Grasp both sides of
the connector firmly and pull apart.
2Trace lightly around the door’s top hinge with a pencil. This makes reinstallation easier.
3Detach the water tube from the connector located below
the freezer door. The connector releases when you press
its outer sleeve inward.
4Remove the screws from the top hinge and pull the
multi-wire cable through it.
5Lift the door off of the bottom hinge. Lay the door on its
side to avoid damage to the Remove the three bottom
hinge screws and hinge, if necessary.
To reinstall the refrigerator and freezer doors, reverse the
above steps.
Cover
Screws
Hinge Cover

7
Features At A Glance
Features may vary according to model

8
Temperature Controls
COOL DOWN PERIOD
To ensure safe food storage, allow the refrigerator to operate with the doors closed for at least 6 hours before loading it
with food.
REFRIGERATOR & FREEZER CONTROLS
NOTE: When changing control settings, wait 24 hours before making additional adjustments.
TEMPERATURE ADJUSTMENT
After 24 hours, adjust the controls as
needed. Make your adjustments small and
gradual; allowing time for temperatures to
change and stabilize. Refer to the adjacent
guidelines for temperature settings.
To adjust the temperature to a higher or
lower setting, press the Up or Down button
closest to the display. The first time you
press the button, the display shows the last
setting you entered. Each press of the
button after that increments the setting by
one degree.
The display shows your new setting
momentarily, then changes back to the
current temperature.
IF TEMPERATURE DISPLAYS
FLASH...
If ever you see both temperature displays
continously flashing, it may indicate that
the control system has detetcted a
performance problem. Call your Frigidaire
service representative, who can interpret
the flashing message.
To maintain temperatures, a fan circulates
air in the refrigerator and freezer
compartments. For good circulation, do not
block cold air vents with food items.
Temperature Control Range
Freezer Fresh Food
Fahrenheit Centigrade Fahrenheit Centigrade
Warmest 6°-14°47°8°
Warmer
Factory Setting Midpoint 0°-18°37°3°
Coldest -6°-21°33°1°
Colder
Temperature Adjustment Guide
If Fresh Food compartment is too warm
Adjust Fresh Food control one degree
colder by pressing Down Arrow button.
If Fresh Food compartment is too cold
Adjust Fresh Food control one degree
warmer by pressing the Up Arrow button.
If Freezer compartment is too warm
Adjust Freezer control one degree colder
by pressing Down Arrow button.
If Freezer compartment is too cold
Adjust Freezer control one degree warmer
by pressing the Up Arrow button.

9
Temperature Controls
OTHER CONTROL FEATURES
TURNING THE COOLING SYSTEM ON AND OFF
You can disable the cooling system in your refrigerator
by pressing the On/Off button located on the left side of
the temperature control panel.To ensure that you do not
accidentally turn off the cooling system, the button does
not work unless you press and hold it for three seconds.
Once you disable the cooling system, all refrigeration to
the freezer and fresh food compartments stops.To turn
the cooling system back on, you must again press and
hold the On/Off button for three more seconds.
SYSTEM MONITORING ALARMS (Select Models)
The electronic control system continuously monitors
yourrefrigerator/freezer for temperature consistency,
doorsleftajar,and power failures. Variancesfrom
normaloperatingconditionsarecommunicatedby
audible tones and a set of four status indicator lights.
USING THE ALARM RESET BUTTON
You can disable or activate the alarm system by
pressing andholdingtheReset buttonforthree
seconds. Use it, for example, to turn off audible tones
and/orflashingindicatorlights.
Once you disable the alarm system, you must again
pressand hold theAlarm Reset button for three more
seconds to reset (activate) the alarm system.
Cooling System On/Off Button
TheOn indicatorlightremainsoff while the freezer and
refrigeratorcompartmentscooltoward the current cooling
settings. When temperature settings are reached, the On
light displays green to indicate an active alarm system.
RESPONDING TO ALARMS (Audible Tones &
Indicator Lights)
Yourrefrigerator’scontrol system can convey the following
informationthroughaudibletones and the alarm indicator
lights.
IMPORTANT: Pressing the On/Off button on the control
panel disables your refrigerator’s cooling system but does
not disconnect power to lights and other electrical
components. To turn off power to your refrigerator you
must unplug the power cord from the wall outlet.
NOTE: Each time you make settings on the control panel,
a single audible tone acknowledges your input.
The alarm system does not
automatically reset if you disconnect and reconnect
your refrigerator’s power cord. It can only be
reactivated by pressing the Alarm Reset button.
Alarm Light Tone Condition How To Respond
On (light is
off) Alarm systemis not active while
freezer and
refrigerator
compartments
are cooling
toward the
current
temperature
settings.
If freezer and refrigerator
compartments do not match
your temperature settings in
three hours, expect the
control system to signal other
conditions. If cooling does
not stabilize toward your
current settings call for
assistance, using the phone
number on the back page of
this Use & Care Guide.
Steady
Green Alarm systemis active. No response required.
Door
Ajar Flashing Green 9Freezer or refrigerator
door has been
open for over
five minutes.
Close door to disable and reset
alarm.
High
Temp Flashing Amber 9Freezer or refrigerator
compartment
has been too
warm (7.2°C
or higher) for
over an hour.
Press AlarmReset button to
turn off alarm. If
temperatures do not
improve, call for assistance,
using the phone number on
the back page of this Use &
Care Guide.
Power
FailureFlashing Amber A power outage was detected. Press Alarm Reset button to turn off alarm and press
again to reset. Check if the
power failure lasted long
enough to affect stored food
temperatures.
Alarm Reset Button Indicator Lights

10
Looking Inside
Ice Cream Shelf
ICE CREAM SHELF (SOME MODELS)
This shelf attaches to the top of the ice dispenser container. It allows storage
of both round and rectangular cartons of your favorite ice cream.
To avoid personal injury or property damage, handle
tempered glass shelves carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden temperature change.
Cantilever Sliding Glass Shelf
1
2
Cantilever Glass Shelf
1
2
* WhiteWestinghouse - SpillFreeTM
CANTILEVER SHELF ADJUSTMENT
Refrigerator shelves are easily adjusted to suit individual needs. Before
adjusting the shelves, remove all food. Cantilever shelves are supported at
the back of the refrigerator.
To adjust cantilever shelves:
1Lift front edge up.
2 Pull shelf out.
Replace the shelf by inserting the hooks at rear of the shelf into the wall
bracket. Lower the shelf into the desired slots and lock into position.
* SpillSafe
TM
glass shelves (some models) catch and hold accidental spills.
In some models, the * SpillSafe
TM
shelves slide out for easy access to
food and for fast cleaning. The shelves slide out independently of their
mounting brackets. Just pull the front of the shelf forward. Shelves can be
extended as far as the stopper will allow but are not removable from their
mounting brackets.
