Frigidaire F44N21CE User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21LRFD1 FRT21LRF R134a System almond 115
FRT21LRFW1 FRT21LRF R134a System white 115
FRT21NRFD1 FRT21NRF R134a System almond 115
FRT21NRFW1 FRT21NRF R134a System white 115
F44N21CED2 F44N21CE Crown R134a almond 115
F44N21CEW2 F44N21CE Crown R134a white 115
MARKET
North America
Publication No.
5995350419
010227
-EN/SERVICE /KC
357
REFRIGERATOR
Model No.
FRT21LRF
FRT21NRF
F44N21CE
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 193832
OWNER’S GUIDE - # 218613700 B
SERVICE DATA SHEET - # 218755000
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
This Publication Supercedes
Publication # 5995296232

02/01 2
Publication No. FRT21LRF, FRT21NRF & F44N21CE
5995350419
DOOR

# = Fast-moving Parts 3 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
DOOR
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
1 # 215608903 A - C - E - Gasket-frzr door,almond ,magnetic
1 # 215608913 - B - D - F Gasket-frzr door,white ,magnetic
2 # 218730610 A - C - E - Gasket-refr door,almond ,magnetic
2 # 218730609 - B - D - F Gasket-refr door,white ,magnetic
3 215393201 A B C D E F Panel-inner door,refr
4 218763617 A B C D E F Rack-door,23.09" x 2.04"
4A 218763616 A B C D E F Rack-door,22.51" x 2.04"
4B 218763615 A B C D E F Rack-door,9.24" x 2.04"
5 218758701 A B C D E F Support-door rack,RH/LH
5A 218758601 A B C D E F Support-door rack,RH/LH
7 5303310094 A B C D E F Door-dairy
8 218763618 A B C D E F Rack-door,23.47" x 2.04" ,(2)
9 215530301 A B C D E F Panel-inner door,frzr
10 5303001308 A - C - E - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D - F Plug-button,white ,hinge brg hole
11 5303917811 A - C - E - Panel-frzr door,almond ,w/insulation
11 5303917810 - B - D - F Panel-frzr door,white ,w/insulation
12 218364002 A - C - E - Frame-nameplate,almond
12 218364001 - B - D - F Frame-nameplate,white
12* 215008608 A - C - - - Label-nameplate,almond
12* 215008607 - B - D - - Label-nameplate,white
12* 215008617 - - - - E - Label-nameplate,almond ,Crown
12* 215008616 - - - - - F Label-nameplate,white ,Crown
12* 215518000 A B C D E F Magnet-nameplate
13 5303212491 A B C D E F Door Stop,refr section
13A 218249002 A - C - E - Door Stop,almond ,frzr section
13A 218249001 - B - D - F Door Stop,white ,frzr section
14 5308000181 A - C - E - Plug-button,almond
14 5308000090 - B - D - F Plug-button,white
14A 215352211 A - C - E - Plug-button,almond ,refr door front ,handle mtg hole
14A 215352201 - B - D - F Plug-button,white ,refr door front ,handle mtg hole
15 5303917813 A - C - E - Panel-refr door,almond ,w/insul & brace
15 5303917812 - B - D - F Panel-refr door,white ,w/insul & brace
18 218668002 A - C - E - Handle-door,almond
18 218668001 - B - D - F Handle-door,white
21A 218251900 A B C D E F Screw,#8 oval head ,10-32CA x 0.625 ,crss rcssd
21C 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D E F Bearing-hinge
26 3204522 A B C D E F Container-egg
37 215867059 A - C - E - Trim-handle,4.97" ,almond ,w/band & lock
37 215867058 - B - D - F Trim-handle,4.97" ,white ,w/band & lock
37* 215782300 A B C D E F Lock-handle trim,snap-in
37* 215940700 A B C D E F Lock-handle trim,stick-on
37* 218676001 A B C D E F Band-decorative,chrome ,handle trim
58 218749600 A B C D E F Screw,#10 pan hd ,8-18 x .5
* 5303917276 A B C D E F Insulation-door,fiberglass ,(bulk)

02/01 4
Publication No. FRT21LRF, FRT21NRF & F44N21CE
5995350419
CABINET

# = Fast-moving Parts 5 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
CABINET
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
1 5303307435 A B C D E F Cover-fan
2 5303307351 A B C D E F Knob-damper control
3 5303001028 A B C D E F Nut,push-on
4 218722200 A B C D E F Damper-fan cover,black
5 # 218649000 A B C D E F Fan Blade,black
6 5303001389 A - C - E - Plug-button,almond
6 5303001388 - B - D - F Plug-button,white
8 5300157666 A B C D E F Bushing-motor mtg,(2)
9 5303205118 A B C D E F Bracket-motor mtg,front
10 218802800 A B C D E F Cover-evap coil
11 5303208309 A B C D E F Plug-hole,factory test
12 215079000 A B C D E F Plug-harness hole,round
12 215079100 A B C D E F Plug-wtr inlet tube,round
13 # 218718403 A B C D E F Motor-evap fan
14 5303205119 A B C D E F Bracket-motor mtg,rear
17 5303001470 A B C D E F Trough-drain
18 215245000 A B C D E F Support-evap cover,(2)
19 5303001198 A B C D E F Tube,rubber
20 5303001286 A B C D E F Ferrule-inner
21 5303001287 A B C D E F Ferrule-outer
22 215774911 A - C - E - Plug-button,almond ,upr hinge holes
22 215774901 - B - D - F Plug-button,white ,upr hinge holes
23 5303210377 A B C D E F Tube-drain,w/seal ring
24 5303207353 A B C D E F • Seal Ring,drain tube
25 215774100 A B C D E F Spout-drain tube,w/mounting pins
26 218605102 A - C - E - Base-cabinet,almond
26 218605101 - B - D - F Base-cabinet,white
27 5303212922 A B C D E F Screw-leveling
28 5303271412 A B C D E F Bolt-roller adj,hex hd sems ,1/4-28 x 2.750,(2)
29 218666700 A B C D E F Washer,.28 x .62 x .03 ,nylon
29 5308011326 A B C D E F Washer,.34 x .62 x .02 ,nylon
30 218220200 A B C D E F Bracket-lower hinge
30* 218605200 A B C D E F Tapping Plate/Gusset,RH
30* 218605300 A B C D E F Tapping Plate/Gusset,LH
* 215005000 A B C D E F Screw,hex wshr hd ,8-18AB x 0.750 ,gusset/hanger
35 218220102 A - C - E - Bracket-ctr hinge,almond
35 218220101 - B - D - F Bracket-ctr hinge,light gray
36 218251300 A B C D E F Pin-center hinge
37 5303321082 A - C - E - Trim-cabinet corner,almond
37 5303321081 - B - D - F Trim-cabinet corner,white
38 3206100 A B C D E F Bracket-upper hinge
38* 5308012296 A B C D E F Tapping Plate,upper hinge ,(2)
40 3206105 A - C - E - Cover-upper hinge,almond
40 3206101 - B - D - F Cover-upper hinge,white
41 5303001609 A B C D E F Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D E F Grommet,shelf mtg ,1.25" ,LH
43 218703001 A B C D E F Roller Assy,front ,(2)
44 218713600 A B C D E F Roller Assy,rear ,(2)
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
46 5308009762 A B C D E F Bolt-roller mtg,hex wshr hd ,1/4-28 x 0.500,(2)
47 218233300 A B C D E F Channel-shelf mtg,side ,(2)
48 5303292395 A B C D E F Channel-shelf mtg,center
49 215507300 A B C D E F Screw,hex washer head ,8-18AB x 1-1/2
56 218220300 A B C D E F Pin-lower hinge
58 5308002748 A B C D E F Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B C D E F Screw,pan hd ,10-32 x 0.625 ,hng/mln,thrd frmng

02/01 6
Publication No. FRT21LRF, FRT21NRF & F44N21CE
5995350419
CABINET

# = Fast-moving Parts 7 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
CABINET
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
78 5303274237 A B C D E F Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C D E F Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C D E F Bracket-connector
92 5303001479 A B C D E F Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - C - E - Plug-button,almond
98 215099701 - B - D - F Plug-button,white
100 5303288973 A B C D E F Support-pan cover
110 215363501 A B C D E F Support-crisper rod
116 215426703 A B C D E F Rod-crisper support
* 5308016571 A B C D E F Plug-button,cab liner holes
* 5303305325 A - C - E - Paint,touch-up ,almond
* 5303305324 - B - D - F Paint,touch-up ,white

02/01 8
Publication No. FRT21LRF
5995350419
SHELVES

# = Fast-moving Parts 9 02/01
* = Non-Illustrated Parts
FRT21LRF Publication No.
5995350419
SHELVES
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
POS. NO PART NO DESCRIPTION
1 218651901 A - Mullion,almond
1 218651900 - B Mullion,white
5 # 218781002 A B Heater-mullion
6 218279800 A B Tapping Plate,mullion mtg ,(2)
7 218738800 A B Top Panel-refr
7* 5303001380 A B Screw,truss head ,8-10 x 1.625
8 218781400 A B Divider,styrofoam
8* # 218767600 A B Wiring Harness,control/divider
* 3205266 A B Edge Protector,wiring harness
9 5303210641 A B Bottom Panel-frzr
10 215667501 A B Tray-ice,plastic
11 5303288243 A B Shelf-freezer,fixed/flat ,full width ,wire
11* 218159700 A B Spacer-shelf
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A# 5308000815 A B Socket-light/lamp
17 5303321455 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5303323457 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B Tube,PVC ,white ,@ air deflector ,insulator
23 # 5303321915 A B Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 5303300042 A B Shelf,cantilever ,full width ,wire
25 215363203 A B Cover-crisper pan,less insert
25A 5303310151 A B Trim-crisper cover
26 215363301 A B Pan-crisper,tilt-out
28 3201150 A B End Cap-shelf,protector ,frzr shelf
29 5303284483 A B Trim-shelf,26.80" ,front
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 5303310497 A B Shelf,cantilever ,half width ,wire
36A 215919121 A B Frame-pan mtg shelf,cantilever,half width,w/hng tabs
37 5303284484 A B Trim-shelf,13.06" ,front
37A 215919411 A B Trim-half shelf,front
42 5303298718 A B Hanger-pan/tray,LH
42 5303298719 A B Hanger-pan/tray,RH
43 218390525 A B Glass-shelf,13.03" x 14.57"
44 215919811 A B Trim-glass shelf,13.07" ,rear
46 215412104 A B Front-crisper pan,(2)
47 218390526 A B Insert-pan cover,glass
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hng/mln,thrd forming
67 215357805 A B Front-meat pan
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
132 215426600 A B Support-crspr cover,rear
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in

02/01 10
Publication No. FRT21NRF & F44N21CE
5995350419
SHELVES

# = Fast-moving Parts 11 02/01
* = Non-Illustrated Parts
FRT21NRF & F44N21CE Publication No.
5995350419
SHELVES
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
1 218651901 - - C - E - Mullion,almond
1 218651900 - - - D - F Mullion,white
5 # 218781002 - - C D E F Heater-mullion
6 218279800 - - C D E F Tapping Plate,mullion mtg ,(2)
7 218738800 - - C D E F Top Panel-refr
7* 5303001380 - - C D E F Screw,truss head ,8-10 x 1.625
8 218781400 - - C D E F Divider,styrofoam
8* # 218767600 - - C D E F Wiring Harness,control/divider
* 3205266 - - C D E F Edge Protector,wiring harness
9 5303210641 - - C D E F Bottom Panel-frzr
10 215667501 - - C D E F Tray-ice,plastic
11 5303288243 - - C D E F Shelf-freezer,fixed/flat ,full width ,wire
11* 218159700 - - C D E F Spacer-shelf
11* 5303299664 - - C D E F Spacer-shelf
12 218730000 - - C D E F Deflector-air
12* 5303001449 - - C D E F Seal-air deflector,foam plastic ,(2)
13 218631001 - - C D E F Cover-air deflector
14 # 5309918806 - - C D E F Switch-light/lamp
15 5303001179 - - C D E F Light Bulb/Lamp,40 W
16A# 5308000815 - - C D E F Socket-light/lamp
17 5303321455 - - C D E F Control Box
17* 5308016567 - - C D E F Nut-anchor
18 5303311079 - - C D E F Knob-temp control
19 # 5303286905 - - C D E F Switch-energy saver,rocker type
21 # 5303323457 - - C D E F Control-temperature
21* 5303001260 - - C D E F Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 - - C D E F Tube,sensor sleeve ,plastic ,clear
22B 218731104 - - C D E F Tube,PVC ,white ,@ air deflector ,insulator
23 # 5303321915 - - C D E F Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 5303001259 - - C D E F Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 215919117 - - C D E F Frame-full shelf,cantilever
24A 215919122 - - C D E F Frame-pan mtg shelf,cantilever,full width,w/hngr tabs
25 215363203 - - C D E F Cover-crisper pan,less insert
25A 5303310151 - - C D E F Trim-crisper cover
26 215363301 - - C D E F Pan-crisper,tilt-out
28 3201150 - - C D E F End Cap-shelf,protector ,frzr shelf
29 215919405 - - C D E F Trim-glass shelf,26.80" ,front
31 215742602 - - C D E F Pan-meat
34 5303212918 - - C D E F Container-ice
40 218390524 - - C D E F Glass-shelf,26.76" x 14.57"
41 215919805 - - C D E F Trim-glass shelf,26.80" ,rear
42 5303298718 - - C D E F Hanger-pan/tray,LH
42 5303298719 - - C D E F Hanger-pan/tray,RH
46 215412104 - - C D E F Front-crisper pan,(2)
47 218390526 - - C D E F Insert-pan cover,glass
59 218188000 - - C D E F Screw,pan hd ,10-32 x 0.625 ,hng/mln,thrd forming
67 215357805 - - C D E F Front-meat pan
81 5308016566 - - C D E F Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 - - C D E F Screw-roller/hanger,8-10 x 0.438
132 215426600 - - C D E F Support-crspr cover,rear
145 218660800 - - C D E F Clip,plastic ,temp sensor mtg ,snap-in

02/01 12
Publication No. FRT21LRF, FRT21NRF & F44N21CE
5995350419
SYSTEM

# = Fast-moving Parts 13 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
SYSTEM
A = FRT21LRF (FRT21LRFD1)
B = FRT21LRF (FRT21LRFW1)
C = FRT21NRF (FRT21NRFD1)
D = FRT21NRF (FRT21NRFW1)
E = F44N21CE (F44N21CED2)
F = F44N21CE (F44N21CEW2)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C D E F Condenser
1* 5303017691 A B C D E F Spacer-tube
2 5308000296 A B C D E F Bracket,condenser mtg ,(4)
* 5308009617 A B C D E F Washer,ext tooth lock ,#10 ,grounding
4 # 218541000 A B C D E F Drier-filter,R134a System
5 # 218767600 A B C D E F Wiring Harness,control/divider
6 # 215257001 A B C D E F Wiring Harness,compressor
7 # 5316254901 A B C D E F Cord-electric power
8 5303001197 A B C D E F Cover-wiring
13 # 215076405 A B C D E F Heat Exchanger,suction line
14 # 5317842502 A B C D E F Heater-defrost
15 # 218765400 A B C D E F Evaporator
16 5308000110 A B C D E F Strap-evap/heater,aluminum ,(2)
17 5316651102 A B C D E F Insulator-evap,plastic
18 218773700 A B C D E F Insulation Block,RH
19 5303007287 A B C D E F Insulation Plug,RH
20 5308017227 A B C D E F Insulation Block,LH
21 # 5316269001 A B C D E F Thermostat-defrost
22 5308013663 A B C D E F Plate-compr mtg
23 218254500 A B C D E F Grommet-compr mtg,(4)
24 5308003633 A B C D E F Washer-compr mtg
25 5308003596 A B C D E F Clip-compressor mtg
26 215372500 A B C D E F Pan-defrost drain
26* 5308017610 A B C D E F Sound Tape,defrost pan
27 5303001348 A B C D E F Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D E F Pan Retainer Kit,Service
29 # 5303917694 A B C D E F Compressor,R134a ,w/ovld & drier
30 # 218721100 A B C D E F Starter/Overload Assy
31 # 5303299560 A B C D E F Overload Protector
32 218740800 A B C D E F Clamp,elec cont mtg ,compressor
41 5308000039 A B C D E F Screw,hex washer head ,8-32CA x 0.500 ,srrt head
43 5303001199 A B C D E F Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C D E F Clamp,nylon ,.625 ID
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
45 5303207328 A B C D E F Screw,hex washer head ,8-15A x 1.000 ,(2)
45* 5300141713 A B C D E F Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 # 216236200 A B C D E F Capacitor-run,180-200 VAC ,15 microfarad
* # 5300189383 A B C D E F Hot Tube Repair Kit,Service

02/01 14
Publication No. FRT21LRF, FRT21NRF & F44N21CE
5995350419
WIRING SCHEMATIC

# = Fast-moving Parts 15 02/01
* = Non-Illustrated Parts
FRT21LRF, FRT21NRF & F44N21CE Publication No.
5995350419
WIRING DIAGRAM
W193832
