Frigidaire FGHS2655PF0 User manual

F IGIDAI E
TABLE OF
Important Safety Instructions ...................... 2
Features at a Glance ................................... 4
Installation ................................................ 5
Door Removal ]:nstrucbons .......................... 7
Handle Installatuon ..................................... 9
Connecting Water Supply .......................... 10
Controls ................................................... 12
www.frlgida]re.com USA 1-800-944--9044
CONTENTS
Storage Features ...................................... 15
Automatuc Ice & Water Dispenser .............. 17
Changing the F_lter................................... 20
Normal Operating Sounds and Sights ......... 22
Care and Cleaning .................................... 23
Before you Call......................................... 28
Major Apphance Warranty ......................... 32
www.frigidaire.ca Canada 1-800-265-8352
hJ
O0
Ixa
oo
('b
hJ
v

Please read all instructions before using this Doors
refrigerator. [] Handles are secure and tight
ii _i i!
FOr YOUr Safe_ [] Door seals completely to cabinet on
all sides
• DO NOT store or use gasoline, or other [] Freezer door is level across the top
flammable liquids in the vicinity of this or
any other appliance. Read product labels
for warnings regarding flammability and
other hazards.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts of
automatic ice maker.
• Remove all staples from the carton. Staples
can cause severe cuts, and also destroy
finishes if they come in contact with other
appliances or furniture.
Definitions
This is the safety alert symbol. It is
used to alert you to potential personal injury
hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
eath ........................................................................................................
WARNING indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
IMPORTANT indicates installation, operation
or maintenance information which is
important but not hazard-related.
Leveling
[] Refrigerator is level, side-to-side and
tilted 1/4" (6mm) front-to-back
D Toe grille is properly attached
to refrigerator
[] Cabinet is setting solid on all corners
Electrical Power
[] House power turned on
[] Refr,geratorp uggedin
Ice Maker
[] House water supply connected
to refrigerator
[] No water leaks present at all connections
- recheck in 24 hours
[] Ice maker is turned ON
[] Ice & water dispenser operates correctly
[] Front filter must be flush with filter
housing (select models)
Final Checks
[] Shipping material removed
[] Fresh food and freezer temperatures set
[] Crisper humidity controls set
[] Registration card sent in
Child Safety
Destroy or recycle the carton, plastic bags, and
any exterior wrapping material immediately
after the refrigerator is unpacked. Children
should NEVER use these items to play.
Cartons covered with rugs, bedspreads, plastic
sheets or stretch wrap may become airtight
chambers, and can quickly cause suffocation.
Proper Disposal of your
Refrigerator or Freezer
Risk ef child entrapment
Child entrapment and suffocation are not
problems of the past. 3unked or abandoned
refrigerators or freezers are still dangerous

- eveniftheywillsitfor"justafewdays':If
youaregettingridofyouroldrefrigeratoror
freezer,pleasefollowtheinstructionsbelowto
helppreventaccidents.
Proper Disposal of Refrigerators/Freezers
We strongly encourage responsibleappliance
recycling/disposal methods. Check with your utility
company or visit www.energystar.gov/recycle for
more information on recycling your old refrigerator.
Before you throw away your old
refrigerator/freezer:
.Remove doors.
*Leave shelves in
place so children
may not easily
climb inside.
*Have refrigerant
removed by a
qualified service
technician.
Avoid connecting refrigerator to a Ground
Fault[nterrupter (GFI) circuit. Do not use an
extension card or adapter plug.
*If the power cord is damaged, it should be
replaced by an authorized service technician
to prevent any risk.
*Never unplug the refrigerator by pulling on the
power cord. Always grip the plug firmly, and
pull straight out from the receptacle to prevent
damaging the power cord.
Unplug the refrigerator before cleaning
and before replacing a light bulb to avoid
electrical shock.
Performance may be affected if the voltage
varies by 10% or more. Operating the
refrigerator with insufficient power can
damage the compressor. Such damage is not
covered under your warranty.
*Do not plug the unit into an electrical outlet
controlled by a wall switch or pull cord to
prevent the refrigerator from being turned
off accidentally.
CFC/HCFC Disposal
Your old refrigerator may have a cooling system
that used CFCsor HCFCs(chlorofluorocarbons
or hydrochlorofluorocarbons). CFCsand HCFCs
are believed to harm stratospheric ozone if
released to the atmosphere. Other refrigerants
may also cause harm to the environment if
released to the atmosphere.
:If you are throwing away your old refrigerator,
make sure the refrigerant is removed for
proper disposal by a qualified technician. If
you intentionally release refrigerant, you may
be subject to fines and imprisonment under
provisions of environmental legislation.
These guidelines must be followed to ensure
that safety mechanisms in this refrigerator
wi!! °Perate pr°Per!Y: ..........................................................................................................................
Electrical information
• The refrigerator must be plugged into its
own dedicated :[15 Volt, 60 Hz., :[5 Amp,
AC only electrical outlet. The power cord
of the appliance is equipped with a three-
prong grounding plug for your protection
against electrical shock hazards. It must be
plugged directly into a properly grounded
three prong receptacle. The receptacle must
be installed in accordance with local codes
and ordinances. Consult a qualified electrician.
Pressing and holding the On/Off button for
three seconds, located on the temperature
controlpanel (Electronic controls), or turning
the Freezer and Fresh Food controlsto
"0" (Mechanical controls) will disable your
refrigerator's coolingsystem, but does not
disconnect the power to the light bulb and
other electrical components. To turn off power
to your refrigerator you must unplug the
power cord from the electrical outlet.
Grounding type Wa!l receptacle
(/ //_1_ I _ anyeircumstanees, I
I/_ _zIi I _ cut, remove, |
I [;,_/#_' I_ or bypass the |
To avoid personal injury or property damage,
handle tempered glass shelves carefully. Shelves
may break suddenly if nicked, scratched, or
exposed to sudden temperature change.

Features may vary according to model
Fixed
Door Bin --
Ice
Container -
Shelf --
Tilt Out
Door Bin --
Small Basket
Large
Glide Out
Basket
Ice Cream Shelf_
Ice Maker_ \
i
_AFqFqfqNFqlq
IillIIIIIIIIIII
=,
SpillSafe ®
--Adjustable Shelf
Filter Filter
_ Dairy
Compartment
- Door Bin
_ SpilISafe ®
Adjustable Shelf
--Wine Rack
- Tall Bottle
Retainer
- Door Bin
Special Item
Rack
_ Meat Keeper
and Cover
- Can Rack
Crisper Pan
- and Cover
_ Fixed
Door Bin
_Toe Grille
Features not included with your refrigerator can be purchased at
www.Mgidaire.com or by calling 1-800-944-9044.
ii

This Use & Care Guide provides general
operating instructions for your model. Use the
refrigerator only as instructed in this Use & Care
Guide. Before starting the refrigerator,
follow these important first steps.
Location
• Choose a place that is near a grounded
electrical outlet. Do Not use an extension
cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher or other heat sources.
• The refrigerator must be installed on a floor
that is level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic ice
maker. If you do not hook up water to
the refrigerator, remember to turn the ice
maker off.
DoNot install the refrigerator where
the temperature will drop below 55° F
(13 ° C) or rise above 110° F (43 ° C). The
compressor will not be able to maintain
proper temperatures inside the refrigerator.
Do Not block the toe grille on the lower front
of your refrigerator. Sufficient air circulation
is essential for the proper operation of
your refrigerator,
Installation
Installation clearances
• Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top 3/8inch
Back 1 inch
Toe Grille Installation and Removal
To install toe grille
1 Open both doors. Slide left and right sides of
toe grille over lower hinges of refrigerator.
2 While pushing toe grille firmly against
cabinet, fasten bottom clips of toe grille
to cabinet.
3 Fasten top clips to cabinet.
4 Close the doors. Fasten right and left side
clips into groove of bottom hinge.
lnstallinc Toe Grille
To remove toe grille
1 With both doors closed, unfasten right
and left side clips of toe grille from bottom
hinge groove.
2 Open both doors. Press firmly on top of
toe grille until top of toe grille pops off.
3 Pull toe grille outward toward your body
and off of lower hinges.
Removing Toe Grille
Tf your refrigerator is placed with the door
hinge side against a wall, you may have to
allow additional space so the door can be
openedw der.

Door Opening
The refrigerator doors are designed to shut
by themselves within a 20 degree opening.
Your refrigerator should be positioned to
allow easy access to a counter or table when
removing food. For best use of drawers and
freezer baskets, the refrigerator should be
in a position where both the refrigerator and
freezer doors can be fully opened.
Guidelines for final positioning of
your refrigerator:
* All four corners of the cabinet must rest
firmly on the floor.
* The cabinet should be level at the front
and rear.
* The sides should tilt 1/4inch (6 mm) from
front to back (to ensure that doors close
and seal properly).
* Doors should align with each other and
be level.
All of these conditions can be met by raising
or lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1 Open both doors and remove the toe
grille (see "Toe Grille Installation and
Removal" in the "Installation" section).
2 Close the doors and use a flat-blade
screwdriver or 3/8inch socket wrench to
raise or lower the front rollers.
3Ensure both doors are bind-free with their
seals touching the cabinet on all four sides.
Raise
To level the doors using the adjustable
lower hinge (some models):
1 Before leveling either door, remove set
screw that locks door height into position.
(The door cannot be adjusted without set
screw removed).
2 If the refrigerator door is lower than the
freezer door, raise the refrigerator door by
turning the adjustment screw clockwise
using a 7/i6 inch wrench. (See illustration.)
3If the freezer door is lower than the
refrigerator door, raise the freezer door by
turning the adjustment screw clockwise
using a 7/16inch wrench. (See illustration.)
/
Raise Raise
Door Door
After leveling, verify door stop contacts
lower hinge and top of door does
not contact upper hinge through full
movement of door (from fully closed to
fully open).
Reinstall set screw, locking the
door height.
Open Door
Door Stop ]
Flange "_;_,- Hinge
S_ __,,_:_[[X_ Flange
Atl\SetSorew
(some models)
Hinge
and
3/32" Hex Key
(some models)
Replace the toe grille by fitting it into
place (see "Toe Grille installation and
Removal" in the "]:nstallation" section).

Tools Necessary:
PhillipsTM _
Head
Top Hinge Top Hinge
Cover Front,, C¢_ _ver Rear
Screw _ _ Screw
Top
Hinge Bottom
Screw Hinge
Screw
Getting through narrow spaces
If your refrigerator will not fit through an
entrance area, you can reduce its size by
removing the doors. Check first by measuring
the entrance.
To prepare for removing the doors:
1 Make sure the electrical power cord is
unplugged from the wall outlet.
2 Open both doors and remove the toe grille
(as explained in the Installation Instructions
that came with your appliance).
3 Remove any food from the door shelves.
4 Close the doors.
To remove the refrigerator top
hinge cover:
1 Remove the three screws from each cover
over the top door hinges.
2 Lift hinge cover straight up and off.
Rear Cover Front Cover
Screw Screws
Cover
Hinge
Screws
Top
Hinge
/
To remove the refrigerator door:
1 Trace lightly around the door's top hinge with
a pencil. This makes reinstallation easier.
2 Remove the two screws from the top
hinge. Lift the door off of the bottom
hinge and set it aside.

Removethetwobottomhingescrewsand 2
hingeifnecessary. 31
Screws -
Adjustable Hinge (some models)
To reinstall the refrigerator door, reverse the
above steps.
To remove the freezer top hinge cover:
i Remove the two screws from each cover
over the top door hinges.
2 Lift hinge cover straight up and off.
Front Rear
Cover Screws Cover
rew
Top
Multi-Wire
Cable |
4
To remove the freezer door:
i Detach the multi-wire cable connector
located above the top hinge. Grasp both
sides of the connector firmly and pull apart.
Trace lightly around the hinge with a
pencil. This makes reinstallation easier.
Detach the water tube from the connector
located below the freezer door. The
connector releases when you press its
outer sleeve inward.
Remove the screws from the top hinge
and pull the multFwire cable through it.
Lift the door off of the bottom hinge.
Remove the two bottom hinge screws and
hinge if necessary.
To Disconnect
1. Press outer ring against face
of fitting_
_2. Pullto
remove tube
push until mark touches face of fitting
Adjustable Hinge (some models)
Door
>, > Water
Tub!ng
Hinge \
Assembly Screws
Non=Adjusting Hinge (some models)
6Lay the door on its side to avoid damage
to the water tube extending from the
bottom hinge.
To reinstall the freezer door,reverse the above steps.
Besure doors are set aside ina secure position
where they cannot fall and cause personal injury.

Wear gloves and safety goggles and
use extreme CAUTION when installing
these handles. The rounded end of the
To ensure proper installation of
handles, please review these
instructions and illustrations thoroughly
prior to installing the handles. ......
i
2
Remove handles from carton and
any other protective packaging.
Position freezer handle end caps
over upper and lower pro-installed
shoulder bolts (A) that are fastened
into door, ensuring the holes for the
set screws are facing towards the
refrigerator door.
While holding handle firmly against
door, fasten upper and lower Allen set
screws (B) with supplied Allen wrench.
Repeat steps 2 and 3 to install
refrigerator handle. Ensure the
holes for the set screws are facing
towards the freezer door.
All set screws should be tightened
and sub-flush (Allen set screw should
be seated just below the surface of
the end cap) of handle end cap. The
end caps should be drawn tight to
freezer and refrigerator doors with
no gaps.
Ensure Hanc le Set Screw,'
are Facing Each Other
with Doors Closed
Frigidaire Professional ®
Freezer Upper Refrigerator Upper
End Cap End Cap
Freezer Lower
End Cap Refrigerator Lower End Cap
Frigidaire Gallery ®
Freezer Upper Refrigerator Upper
End Cap End Cap
Freezer Lower Refrigerator Lower
End Cap End Cap

To avoid electric shock, which can cause
death or severe personal injury, disconnect
the refrigerator from electrical power
before connecting a water supply line to the
e
e
A shutoff valve to connect the water supply
line to your household water system. Do
not use a self-piercing type shutoff valve.
Do not re-use compression fitting or use
thread seal tape.
A compression nut and ferrule (sleeve) for
connecting a copper water supply line to
the ice maker inlet valve.
To Avoid Property Damage:
*Copper or Stainless Steel braided tubing
is recommended for the water supply
line. Water supply tubing made of 1/4
inch plastic is not recommended to be
used. Plastic tubing greatly increases
the potential for water leaks, and the
manufacturer will not be responsible for
any damage if plastic tubing is used for
the supply line.
*DO NOT install water supply tubing in
areas where temperatures fall
below freezing.
*Chemicals from a malfunctioning softener
can damage the ice maker. If the ice
maker is connected to soft water, ensure
that the softener is maintained and
working properly.
Ensure that your water supply line
connections comply with all local
plumbing codes.
Before Instelling The Water Supply Line, You
Will Need"
*Basic Tools: adjustable wrench, fiat-blade
screwdriver, and PhillipsTM screwdriver
*Access to a household cold water line with
water pressure between 30 and 100 psi.
*A water supply line made of 1/4inch
(6.4 mm) OD, copper or stainless steel
tubing. To determine the length of tubing
needed, measure the distance from the
ice maker inlet valve at the back of the
refrigerator to your cold water pipe. Then
add approximately 7 feet (2.1 meters),
so the refrigerator can be moved out for
cleaning (as shown).
Check with your local building authority
i! for recommendations on water lines and
associated materials prior to installing your
new refrigerator. Depending on your local/
state building codes, Frigidaire recommends
for homes with existing valves its Smart
Choice® water line kit 5305513409 (with
a 6 ft. Stainless Steel Water Line) and for
homes without an existing valve, Frigidaire
recommends its Smart Choice® water line kit
5305510264 (with a 20 ft. copper water line
with self-tapping saddle valve). Please refer
to www.frigidaire.com/store for
more information.
To Connect Water Supply Line To Ice Maker
Inlet Valve
I Disconnect refrigerator from electric
power source.
Place end of water supply line into sink or
bucket. Turn ON water supply and flush
supply line until water is clear. Turn OFF
water supply at shutoff valve.
3Remove plastic cap from water valve inlet
and discard cap.
If you use copper tubing - Slide brass
compression nut, then ferrule (sleeve)
onto water supply line. Push water supply
line into water valve inlet as far as it
will go (1/4inch/6.4 mm). Slide ferrule
(sleeve) into valve inlet and finger tighten
compression nut onto valve. Tighten
another half turn with a wrench; DO NOT
over tighten. See Figure 1.
If you use stainless steel tubing - The
nut and ferrule are already assembled on
the tubing. Slide compression nut onto
valve inlet and finger tighten compression
nut onto valve. Tighten another half turn
with a wrench; DO NOT over tighten. See
Figure 2.

Withsteelclampandscrew,securewater
supplyline(coppertubingonly]torear
panelofrefrigeratorasshown.
Coilexcesswatersupplyline(copper
tubingonly),about21/2turns,behind
refrigeratorasshownandarrangecoilsso
theydonotvibrateorwearagainstany
othersurface.
7 TurnONwatersupplyatshutoffvalveand
tightenanyconnectionsthatleak.
8 Reconnectrefrigeratortoelectrical
powersource.
9 Toturnicemakeron,lowerwiresignal
arm(sidemounted)orsettheicemaker's
on/off power switch to the 'T' position
(rear mounted).
Plastic Water
Tubing to Ice P
Maker Fill ,Brass
Compression
Nut
JJ _ -Copper
water line
!,b// Vater Va w
/-_ _ -t_,Yc'_X Bracket
///
/// -VaIveInIet
l(l__ _ Water Valve
• Copper water line
from household
_ water supply
J (oln_llUdemenough tubing in loop
to allow moving refrigerator out
for cleaning.)
Figure 1
Plasti(
to Ice Maker
11Tube Clamp
3S
Steel
water line
"Water Valve
Bracket
\ Water Valve
6 ft. Stainless Steel water line
:f from household water supply
Figure 2
IMPORTANT
After connecting the water supply, refer to
"How to Prime the Water Supply System"
for important information about priming an
empty water supply system
Your refrigerator's water supply system
includes several tubing lines, a water filter,
a water valve, and a water tank. To ensure
that your water dispenser works properly,
this system must be completely filled
with water when your refrigerator is first
connected to the household water
supply line.

User Interface (varies by model)
Enlarged view of user interface display menu (varies by model)

exit Toggles the options and run
modes.
default
settings While inthe default option, press and hold the set key
for three seconds to reset all
refrigerator settings to their
factory default settings.
quick ice
on off
Toggles dispenser light On
and Off.
Increases the production
of ice. Deactivates after 12
hours.
water Press the "water" key
to select water. A green
indicator light will be
illuminated above the active
feature.
refrigerator
temp Allows the temperature set- points to be adjusted. Control
temperatures range from
+33 ° F/+1 ° C to +47 ° F/
+8° C.
crush Press the "crush" key
to select crushed ice. A
green indicator light will be
illuminated above the active
feature.
mode
oFoC
water filter
Toggles display from Fahrenheit
to Celsius.
Displays the current status of
the water filter (Good, Order, 1
or Replace). To reset the filter
status to "Good'; press and
hold the "set" key for three 2
seconds.
When you first power on the refrigerator,
the temperature displays 0° F and 37° F.
After a few seconds, both of the displays will
switch to "HI': The displays will continue to
show "HI" for 20 minutes. After 20 minutes,
the High Temp alarm will sound and both
displays will show the actual temperature,
Plus (+) and Minus (-) indicators are
located on the right side of the control
panel.
Press the + or - indicator to adjust the
temperature to the desired setting.

Alarms
Power
Failure
Fresh Food
Ternp
Door Ajar
Flapper
In the event of a power failure,
the power fail alert will be
illuminated. Press alarm reset to
acknowledge the alarm. Other
modes may be turned off until
the alarm is acknowledged.
When the power fail alert is
acknowledged, the refrigerator
will resume normal operation.
The high temp alarm may
also be illuminated until a safe
operating range temperature
has been reached.
If the freezer temperature
reaches 26° F or greater,
the alarm will sound and the
temperature will flash. You can
disable the alarm by pressing
the set key but the "High Temp"
indicator will illuminate until the
temperature goes below 26° F.
If the fresh food temperature
reaches 55° F or greater,
the alarm will sound and the
temperature will flash. You can
disable the alarm by pressing
the set key but the "High Temp"
indicator will illuminate until the
temperature goes below 55° F.
If the freezer or fresh food
doors have been left open for
five minutes or more, an alarm
will sound and the door ajar
indicator will illuminate on the
display. Press the set key to
reset any system alarms.
When "Cube" or "Crush" is
selected, if the flapper (or ice
chute door) is being held open
by a jammed ice cube, an alarm
will sound for two minutes.
The alarm will reset after two
minutes or when the ice cube
is removed and the set key is
pressed to reset.
Sabbath Mode
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls
in accordance with observance of the weekly
Sabbath and religious holidays within the
Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
pressing and holding both the "v" and %" for
five seconds. The display shows "Sb" while in
Sabbath mode.
In the Sabbath Mode, the High Temp alarm is
active for health reasons. If a high temperature
alarm is activated during this time, for example
due to a door left ajar, the alarm will sound
intermittently for about two minutes. The
alarm will then silence on its own and a red
high temperature icon will display. The high
temp icon will continue to display, even if
the door is closed, until the Sabbath mode
is exited and the icon reset. The refrigerator
will function normally once the door is closed,
without any violation of the Sabbath/Holidays.
For further assistance, guidelines for proper
usage and a complete list of models
with the Sabbath feature, please visit
the web at http:\\www.star-k.org.
While in Sabbath Mode, neither the lights,
dispenser, nor the control panel will work
until Sabbath Mode is deactivated.
Refrigerator stays in Sabbath Mode
after power failure recovery. It must be
deactivated with the buttons on the
contro! .......................................................................................................................................................................................
Although you have entered the Sabbath
Mode, the ice maker will complete the
cycle it had already initiated. The ice cube
compartment will remain cold and new ice
cubes can be made with standard trays.

Toavoidpersonalinjuryorpropertydamage,
handletemperedglassshelvescarefully.
Shelvesmaybreaksuddenlyifnicked,
scratched,orexposedtosuddentemperature
change.Allowtheglassshelvestostabilize
toroomtemperaturebeforecleaning.Donot
washindishwasher.
Cantilever Shelf Adjustment
Refrigerator shelves are easily adjusted to suit
individual needs. Before adjusting the shelves,
remove all food. Cantilever shelves are
supported at the back of the refrigerator.
To adjust cantilever shelves:
O Lift front edge up.
O Pull shelf out.
Replace the shelf by inserting the hooks at
rear of the shelf into the wall bracket. Lower
the shelf into the desired slots and lock into
position.
SpillSafe TM glass shelves (some models) catch
and hold accidental spills. In some models, the
SpillSafe TM shelves slide out for easy access
to food and for fast cleaning. The shelves slide
out independently of their mounting brackets.
3ust pull the front of the shelf forward.
Shelves can be extended as far as the stopper
will allow but are not removable from their
mounting brackets.
Door storage
Cantilever Sliding
Glass Shelf
Door bins and shelves are provided for convenient
storage of jars, bottles, and cans. Frequently used
items can be quickly selected.
Some models have door bins that can
accommodate gallon-sized plastic drink containers
and economy-sized jars and containers. Some bins
are adjustable for maximum storage capacity.
The dairy compartment, which iswarmer than the
general food storage section, is intendedfor short
term storage of cheese, spreads, or butter.
Fresh Drawers with Humidity
Control (some models)
The fresh drawers, located under the bottom
refrigerator shelf, are designed for storing fruits,
vegetables, and other fresh produce. The fresh
drawers feature humidity control which allows you
to adjust the humidity within the drawer. This can
extend the life of fresh vegetables that keep best
in high humidity. Wash items inclear water and
remove excesswater before placing them in the
crispers. Items with strong odors or high moisture
content should be wrapped before storing.
Crisper Humidity Control
Leafy vegetables keep best when stored
with the humidity control set on Higher
Humidity, or in a drawer without a Humidity
Control. This keeps incoming air to a
minimum and maintains maximum
moisture content.
Crispers
Crispers allow you
the flexibility to store
any manner of items
including fruits,
vegetables, nuts, etc.
Crispers do not feature
humidity controls. Crisper Drawer
Cool Drawer (some models)
Some models are equipped with a Cool Drawer
for storage of luncheon meats, spreads,
cheeses, and other dell items. This drawer
does not have a separate temperature control.

I ! i !i !! iU iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
Chill Drawer (some models)
Some models are equipped with a Chill Drawer. Chill Drawer temperatures can be adjusted by
sliding the Chill Drawer Temperature Control in either direction. Use this pan for short term
storage of bulk meat items. If meats are to be kept longer than one or two days, they should be
frozen. The Chill Drawer is fixed and cannot be moved up or down. If fruits or vegetables are to
be stored in the Chill Drawer, set the Chill Drawer Temperature Control to a warmer setting to
prevent freezing.
iii
Chill Drawer
with Temperature Control

Priming the Water Supply System
Your refrigerator's water supply system includes
several tubing lines, an advanced water filter,
a distribution valve bank, and a reserve tank
to ensure ample supply to the ice and water
dispenser at all times. This system needs to be
completely filled with water when first connected
to an external supply line.
For proper dispenser operation, recommended
water supply pressure should fall between
30 psi and 100 psi. Excessive pressure may
cause water filter to malfunction.
To prime the water supply system:
1 Begin filling the tank by pressing and holding
a drinking glass against the water dispenser
paddle.
2 Keep the glass in this position until water
comes out of the dispenser. It may take
about 11/= minutes.
Continue dispensing water for about four
minutes to flush the system and plumbing
connections of any impurities (stopping to
empty the glass as necessary).
The water dispenser has a built-in device that
shuts off the water flow after three minutes of
continuous use. To reset this shutoff device,
simply release the dispenser paddle.
Ice Maker Operation &Care
The ice maker, ice bin, and dispenser feeding
mechanism are located in the top of the freezer
compartment. After the refrigerator isinstalled
properly and has cooled for several hours, the ice
maker can produce ice within 24 hours. It can
completely fill an ice bin in about two days.
Ice Production: What to Expect
How Much Ice Will aSide Mounted Ice
Maker Produce in 24 Hours?
A side mounted ice maker will produce 4 to
4.5 pounds of ice every 24 hours, depending on
usage conditions. Ice is produced at a rate of
8 cubes every 75 to 90 minutes.
How Much Ice Will aRear Mounted Ice
Maker Produce in 24 Hours?
A rear mounted icemaker will produce 3 to
4 pounds of ice every 24 hours, depending on
usage conditions. Ice is produced at a rate of
8 cubes every 75 to 90 minutes.
Using the Ice Haker after
Installation
Before making ice for the first time, be sure
to prime the water supply system. Air in new
plumbing lines can result in two or three empty
ice maker cycles. Furthermore, if the system
is not flushed, the first ice cubes may be
discolored or have an odd flavor.
Your ice maker is shipped from the factory
with the wire signal arm in the ON position
(side mounted) or with the switch turned
ON (rear mounted). To ensure proper
function of your ice maker, hook up water
supply immediately or turn ice maker OFF
by lifting the wire signal arm until it clicks
and locks in the UP position (side mounted)
or turn the On/Off switch to the Off (0)
position (rear mounted). :If the ice maker
is not turned off and the water supply
is not connected, the water valve will
makealoudc.atteringnoise

Turning the REAR HOUNTED Ice
Haker On and Off
Ice production is controlled by the ice maker's
ON/OFF power switch. To gain access to the
ice maker, pull the ice cream shelf out. Press
the switch to the "0" position to turn it Off and
press it to the "I" position to turn it On. The
ice maker also has a built-in wire signal arm,
which automatically stops ice production when
the ice bin is full. DO NOT use this signal arm
to manually stop the ice maker,
Wire
Signal Arm
Small ice cubes or ice chips jamming in the
ice maker may be a sign that your water filter
needs changing. ]:fyou have a side mounted
ice maker you may also experience hollow
cubes partially frozen cubes with water inside.
When these cubes are harvested, they break
open and spill water over the other ice cubes
in the ice container, forming a solid mass of
ice. As the water filter nears the end of its
useful life and becomes clogged with particles,
less water is delivered to the ice maker during
each cycle. The ice maker can't fill every cube
in the ice maker mold, leading to small cubes
or chips that can get caught between the ice
ejector blades and the stripper. Remember,
if your ice maker is jamming with small ice
cubes or it's been six months or longer since
you last changed your water filter replace
the water filter with a new one. Poor quality
household water may require the filter to be
changed more frequently.
Ice Maker/Dispenser Tips
= Ice cubes stored too long may develop
an odd flavor. Empty the ice container as
explained below.
Occasionally shake the ice container to
keep ice separated.
If your refrigerator is not connected to a
water supply or the water supply is turned
off, turn Off the ice maker,
, If you need a large quantity of ice at one
time, it is best to get cubes directly from
the ice container.
The following sounds are normal when the
ice maker is operating:
Motor running
Ice dropping into ice container
Water valve opening or closing
Ice loosening from tray
Running water
When dispensing ice, you will hear a
snapping or clicking sound when the ice
chute opens and closes.
Turn Off the ice maker when cleaning the
freezer and during vacations.
If you turn Off the ice maker for a
long period of time, you should also
turn off the water supply valve.
.... Chemicals from a malfunctioning water
.... softener can damage the ice maker. If the
.... water supply to your refrigerator is softened,
be sure the softener is maintained to work
properly.

Cleaning the Ice Maker
Clean the ice maker and ice bin at regular
intervals, particularly before you take a
vacation or move.
To clean the ice maker:
1 Turn Off the ice maker.
2
3
4
5
Remove the ice bin by lifting up and out.
Empty and carefully clean the ice bin with
mild detergent. Rinse with clear water. Do
not use harsh or abrasive cleaners.
Allow the ice bin to dry completely before
replacing in the freezer.
Remove ice chips and clean the ice bin
shelf and the freezer door chute.
6Replace the ice bin. Turn On the ice maker
to resume ice production.
Remove and empty the ice storage bin if:
• An extended power failure (one hour or
longer) causes ice cubes in the ice storage
bin to melt and freeze together, jamming
the dispenser mechanism.
You do not use the ice dispenser frequently.
Ice cubes will freeze together in the bin,
jamming the dispenser mechanism.
Remove the ice storage bin and shake to
loosen the cubes or clean as explained above.
Aug_
\
NEVER use an ice pick or similar sharp
instrument to break up the ice. This could
damage the ice storage bin and dispenser
mechanism,
When removing or replacing the ice bin,
DO NOT rotate the auger in the ice bin. If
the auger is accidentally rotated, you must
realign the auger by turning it in 90 degree
turns (see below) until the ice bin fits into
place with the drive mechanism. If the
auger is not properly aligned when
replacing the ice bin, the refrigerator will
only dispense Crushed Ice. The freezer door
may also not close properly causing warm
air to leak into the freezer.

Locating the Filter
Your refrigerator is equipped with a water
filtering system. The water filter system filters
all dispensed drinking water, as well as the
water used to produce ice.
Air Filter (some models)
The air filter is located at the top of the fresh
food compartment next to the water filter.
Replacing the Air Filter
In general, you should change the air filter
every six months (the filter status light on
the control panel prompts you to replace
the filter after six months) to ensure optimal
filtering of refrigerator odors. You may want
to adjust this time period depending on the
types and amounts of food you typically
store in your refrigerator. To replace your
PureSource Ultra TM air filter:
1 Pull the air filter housing straight out.
2 Remove the old filter and discard it.
3Unpack the new filter and place it inside
the housing.
4 Slide the housing back into position.
Water Filter
The water filter is located at the top right side
of the fresh food compartment.
Replacing the Water Filter
In general, you should change the water
filter every six months to ensure the
highest possible water quality. Water
Filter Status on the user interface prompts
you to replace the filter after a standard
amount of water (200 gallons/757 liters for
PureSeurce Ultra TM) has flowed through the
system.
If your refrigerator has not been used for a period
of time (during moving for example), change the
filter before reinstalling the refrigerator.
Air Filter Ordering Replacement Filters
To order your replacement filters, please visit
our online store at www.frJgJdaire.com/store,
by calling toll-flee at 877-808-4195, or by
visiting the dealer where you purchased your
refrigerator. Frigidaire recommends that you
order extra filters when you first install your
refrigerator, and that you replace your filters at
least once every six months.
Here are the product numbers to request
when ordering:
PureSource Ultra TM Water Filter
Part# ULTRAWF
20
