Frigidaire FRT17A2A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT17A2AZ2 FRT17A2A R134a, Static white 115
MARKET
North America
Publication No.
5995389458
030425
-EN/SERVICE /DCS
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT17A2A
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
ENERGY GUIDE - 218791450
OWNER’S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010

04/03 2
Publication No. FRT17A2AZ2
5995389458
DOOR

# = Fast-moving Parts 3 04/03
* = Non-Illustrated Parts
FRT17A2AZ2 Publication No.
5995389458
POS. NO PART NO DESCRIPTION
1 # 240542101 Gasket,frzr door seal ,white ,magnetic
2 # 240542104 Gasket-refr door,white ,magnetic
4 240535101 Rack-door
7 240337701 Door-dairy,w/o graphics ,white
8 240535001 Rack-door
10 240381301 Plug-button,white ,hinge brg hole ,(2)
11 240433501 Panel-frzr door,white ,complete assy
12 240415201 Label-nameplate,white
13 240312403 Door Stop,white ,ref
13A 240312404 Door Stop,white ,frzr
15 240428801 Panel-refr door,white ,complete assy
21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500
22 240527101 Bearing-hinge,natural color
DOOR

03/02 4
Publication No. FRT17A2AZ2
5995389458
CABINET

# = Fast-moving Parts 5 03/02
* = Non-Illustrated Parts
FRT17A2AZ2 Publication No.
5995389458
POS. NO PART NO DESCRIPTION
1 240355401 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut,push-on
4 240367401 Damper-fan cover
5 # 5308000010 Fan Blade,red ,evaporator fan
8 5300157666 Bushing-motor mtg,(2)
9 5303292396 Bracket-motor mtg,front
10 240462011 Cover-evap coil
10* 240568601 Seal-coil cover
10*# 240524701 Wiring Harness,freezer section
11 5303208309 Plug-hole,factory test
12 240366801 Plug-ice maker harness,rectangular
12A 240374401 Plug-wtr inlet tube,round ,1"
13 # 240369702 Motor-evap fan
13* 215474201 Washer,"slinger" ,nylon ,evap fan shaft
13* 218931001 Clamp-motor wiring,nylon ,w/adhesive tape
14 5303292397 Bracket-motor mtg,rear
18 240411901 Support-evap cover,(2)
21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500
22 215774901 Plug-button,white ,upr hinge holes
28 240335501 Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special
30 240357102 Bracket,bottom hinge ,white
34 240311301 Washer,hinge ,nylon ,(2)
35 240357002 Bracket,center hinge ,white
35A 240336801 Spacer-hinge,center
36 240516401 Pin-center hinge
37 240337601 Trim-cabinet corner,white ,(2)
38 240356901 Bracket,upper hinge
41 5303001609 Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 Grommet,shelf mtg ,1.25" ,LH
42 240423601 Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 Roller Assy,front ,(2)
56 240516501 Pin-lower hinge
58 5303001343 Screw,hex washer head ,8-15A x 0.500
59 240442702 Screw-#10-32 X 3/4,white
72 240368301 Grille/Kickplate,white
78 240433201 Screw,hex washer head ,8-18 x 0.375
81 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile
82 5304418225 Roller,compressor base ,rear ,(2)
83 5303316859 Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
92 5303001479 Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 218843800 Screw,hex wshr hd ,8-15A x 0.500
* 240479601 Plug,button ,cab liner holes
* 5303305324 Paint,touch-up ,white
CABINET

04/03 6
Publication No. FRT17A2AZ2
5995389458
SHELVES

# = Fast-moving Parts 7 04/03
* = Non-Illustrated Parts
FRT17A2AZ2 Publication No.
5995389458
POS. NO PART NO DESCRIPTION
12 240545001 Diffuser,air ,top
13 240362601 Diffuser,air ,bottom
14 240505801 Switch,light/lamp
15 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature
16 241500701 Socket-light/lamp
17 240368001 Control Box
17*# 240388701 Wiring Harness,control box
18 240360801 Knob,temp control
21 # 5304421256 Control,temperature
22A 240468201 Tube,sensor sleeve ,31 inch ,plastic ,white
23 # 215846606 Timer,defrost ,60 Hz ,0.25 W ,120 V ,10 hour/30 min
23* 5303001259 Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 240360902 Shelf,sliding ,wire
25 240364706 Cover,crisper pan
26 240397701 Pan-crisper,full-width
81 5308016566 Screw,hex washer head ,8-15A x 0.625 , low profile
* 218791450 Energy Guide
SHELVES

04/03 8
Publication No. FRT17A2AZ2
5995389458
SYSTEM

# = Fast-moving Parts 9 04/03
* = Non-Illustrated Parts
FRT17A2AZ2 Publication No.
5995389458
POS. NO PART NO DESCRIPTION
1 # 240406405 Condenser,static
1* 240405201 Grommet,rubber ,black ,cond tube/wire
1* 5303208866 Spacer,condenser tube ,black
2 5308000296 Bracket,condenser mtg ,(4)
2* 5308009617 Washer,ext tooth lock ,#10 ,grounding
4 # 218944001 Drier-filter,R134a System
6 # 240375401 Wiring Harness,machine compt ,w/service cord
6* # 240388701 Wiring Harness,control box
6* # 240524701 Wiring Harness,freezer section
14 # 5303918203 Defrost Heater Kit
15 # 5303918275 Evaporator Kit
16 5308000110 Strap-evap/heater,aluminum ,(2)
17 240434001 Trough-drain
20 240518402 Insulation,evap block ,foam ,LH/RH
21 # 5303918202 Thermostat-defrost,kit
22 240330005 Base-compressor
22* 218252200 Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 Grommet-compr mtg,(4)
25 240491501 Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332605 Pan-defrost drain
29 # 5303918264 Compressor,w/electricals
30 # 218721120 Starter,PTC
32 240493301 Clamp,elec cont mtg ,compressor ,bale wire
41 240433202 Screw,hex washer head ,8-18 x 5/16
44 5303001199 Clamp-wiring harness,strain relief ,galv steel
45 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile
55 # 218909901 Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
57 240542601 Clip-wiring harness
82 5304418225 Roller,compressor base ,rear ,(2)
83 5303316859 Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
84 240500801 Tube-drain,rubber ,lower
85 240493101 Tube-connector,suction
87 240533004 Tube-Condensate,87
* 218843800 Screw,hex wshr hd ,8-15A x 0.500
* 240396801 Clamp,tube/wiring ,nylon ,black/natural
* # 5303918234 Hot Tube Repair Kit,Service
* # 5303918263 Heat Exchanger Kit,suction line
SYSTEM

04/03 10
Publication No. FRT17A2AZ2
5995389458
WIRING SCHEMATIC

# = Fast-moving Parts 11 04/03
* = Non-Illustrated Parts
FRT17A2AZ2 Publication No.
5995389458
WIRING DIAGRAM
