Frigidaire PRO-GALLERY FRT22TSE User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT22TSEB2 FRT22TSE PRO-GALLERY stainless/black 115V
FRT22TSEB3 FRT22TSE PRO-GALLERY stainless/black 115V
FRT22TSEK2 FRT22TSE PRO-GALLERY stainless/black 115V
FRT22TSEK3 FRT22TSE PRO-GALLERY stainless/black 115V
Publication No.
5995311643
980821
-EN/SERVICE /JLT
357
REFRIGERATOR
Model No.
FRT22TSE
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218671900
OWNER’S GUIDE - # 218758300
SERVICE DATA SHEET - # 218771600
101 Masters Blvd.
Anderson, SC 29624

08/98 2
Publication No. FRT22TSE
5995311643
DOOR

# = Fast-moving Parts 3 08/98
* = Non-Illustrated Parts
FRT22TSE Publication No.
5995311643
DOOR
A = FRT22TSE (FRT22TSEB2, FRT22TSEK2)
B = FRT22TSE (FRT22TSEB3, FRT22TSEK3)
POS. NO PART NO DESCRIPTION
1 # 215608925 A B Gasket-frzr door,black ,magnetic
2 # 5303299063 A B Gasket-refr door,black ,magnetic
3 215784001 A B Panel-inner door,refr
4 218763602 A B Rack-door
5 218758601 A B Support-door rack,RH/LH
7 5303308347 A B Door-dairy
9 5303292371 A B Panel-inner door,frzr
11 218626330 A B Panel-frzr door,stainless steel ,
w/foam insulatn
12 218395401 A B Nameplate,black
13 5303289522 A B Door Stop
13A 215030018 A B Door Stop,black ,frzr
15 218626436 A B Panel-refr door,stainless steel ,
w/foam insulatn
18 218756502 A B Handle-door,stainless steel ,
with insert,& set screw
21A 218578600 A B Screw-door stop mtg,phl truss hd ,
10-16 x 3/4
22 5303289320 A B Bearing-hinge
26 3204522 A B Container-egg
27 218370101 A B Snugger-door bin,"paddle type" ,
gallon door bin
34 218783202 A B Bumper-light switch,black
49 218592305 A B Bin-door,gallon ,with trim
58 218749600 A B Screw,#10 pan hd ,8-18 x .5
76 218423900 A B Rack-microwave dish
77 218423502 A B Dish-microwave,(2)
79 218755401 A B Screw-set,10-32 x .375
80 218755501 A B Screw-shoulder,#10 AB ,handle mounting
* 218490900 A B Cleaner,stainless steel
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

08/98 4
Publication No. FRT22TSE
5995311643
CABINET

# = Fast-moving Parts 5 08/98
* = Non-Illustrated Parts
FRT22TSE Publication No.
5995311643
A = FRT22TSE (FRT22TSEB2, FRT22TSEK2)
B = FRT22TSE (FRT22TSEB3, FRT22TSEK3)
POS. NO PART NO DESCRIPTION
1 215937600 A B Shroud-evap fan mtg
5 # 5303292398 A B Fan Blade
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 5304402185 A B Cover-evap coil
11 5303208309 A B Plug-hole,factory test
12 215230400 A B Plug-harness hole
13 # 218661700 A B Motor-evap fan
13* 215474201 A B Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B Bracket-motor mtg,rear
15 215812200 A B Light Bulb/Lamp,25W
15A 218708700 A B Light Bulb/Lamp,crisper light ,(2)
16 # 5308000129 A B Socket-light/lamp
16A# 5303299157 A B Socket-light/lamp,crisper light
17 5303292408 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
22 215774918 A B Plug-button,black ,upr hinge holes
23 215266301 A B Tube-drain,w/seal ring
24 5303207353 A B * Seal Ring,drain tube
25 5303292412 A B Spout-drain tube
28 5303289062 A B Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215003200 A B Washer,.40 x .63 x .16 ,nylon
29 215314301 A B Washer,.40 x .75 x .06 ,nylon
30 5303289060 A B Bracket-lower hinge,w/hinge pin
30* 218730700 A B Tapping Plate,LH
30* 218730800 A B Tapping Plate,RH
34 218737000 A B Washer-ctr hnge pin
35 215002618 A B Bracket-ctr hinge,black
36 215095900 A B Pin-center hinge
37 5303321083 A B Trim-cabinet corner,black
38 218215216 A B Bracket-upper hinge,with closer ,black ,LH
38* 5304403492 A B Tapping Plate,upper hinge ,(2)
39 08006983 A B Spacer-divider
40 218374409 A B Cover-upper hinge,black
43 218615300 A B Roller Assy,front ,(2)
43* 5308017044 A B Screw-roller mtg,spcl ind hex hd ,5/16-18(23)x7/8
44 218738300 A B Roller Assy,rear ,(2)
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B Channel-shelf mtg,side ,(2)
47A 215209100 A B Channel-shelf mtg,side,frzr
48 218487200 A B Channel-shelf mtg,center
48A 215209200 A B Channel-shelf mtg,center,frzr
52 215454600 A B Tube-water inlet
58 5308002748 A B Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
71 218515401 A B Clip-grille
72 218359612 A B Grille/Kickplate,black
74 215423500 A B Shield-light,frzr
78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B Bracket-connector
89 5303288947 A B Cover-machine compt
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
93 218362603 A B Plug-grille,black
94 5303319993 A B Cover-air duct
94* 218044800 A B Seal-air duct cover
95 218663100 A B Gasket-air duct cvr
96 215775901 A B Cover-fan access
97 5303289299 A B Bracket-IM plug
98 215099718 A B Plug-button,black ,ctr hinge hole
100 5303288973 A B Support-pan cover
107 218188800 A B Shield-light,crisper
108 218834202 A B Cover-wiring,crisper light
114# 5303299156 A B Switch-light/lamp,black
* 5303001361 A B Pin-mounting,push-in ,plastic
* 5308016571 A B Plug-button,cabinet liner
CABINET

08/98 6
Publication No. FRT22TSE
5995311643
SHELVES

# = Fast-moving Parts 7 08/98
* = Non-Illustrated Parts
FRT22TSE Publication No.
5995311643
A = FRT22TSE (FRT22TSEB2, FRT22TSEK2)
B = FRT22TSE (FRT22TSEB3, FRT22TSEK3)
POS. NO PART NO DESCRIPTION
1 5303299280 A B Mullion,black
5 # 218752300 A B Heater-mullion
6 218845600 A - Tapping Plate,mullion mtg ,(2)
6 218845602 - B Tapping Plate,mullion mtg ,(2)
7 218646702 A B Top Panel-refr
7* 5303001380 A B Screw,truss head ,8-10 x 1.750
8 215062700 A B Divider,styrofoam
9 215058300 A B Bottom Panel-frzr
11 5303292383 A B Shelf-freezer,cantilever ,wide ,(2)
11A 5303292384 A B Shelf-freezer,cantilever ,narrow
12 218634902 A B Deflector-air,"paddle"
12* 215363801 A B Spacer-air deflectr
12* 215363901 A B Washer-air deflectr
13 218629900 A B Cover-air deflector
13* 5308016567 A B Nut-anchor
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16 # 5308000129 A B Socket-light/lamp
16A# 5308000815 A B Socket-light/lamp
17 215932905 A B Control Box
17* 215935700 A B Nut-anchor
18 5303310731 A B Knob-temp control,refr
18A 5303310732 A B Knob-temp control,(damper)
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5304403880 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22 218660701 A B Tube,insulator ,plastic ,on temp sensor
23 # 5303321915 A - Timer-defrost,10 hr ,115V
23 # 215846606 - B Timer-defrost
23* 215277000 A B Cover-defrost timer,top
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B Shield-defrost timr,btm
25 215216634 A B Cover-crisper pan,with beam ,rollers,trim,and humid cont
25A 5303308349 A B Trim-crisper cover
25B 5303307881 A B Control-humidity
26 5303292386 A B Pan-crisper,(2)
31 5303304632 A B Pan-meat
34 5303289069 A B Container-ice
36 215406115 A B Shelf-"Spill-Safe",fixed ,teal graphics
39 5303284480 A B Trim-frzr shelf,wide
39A 215217539 A B Trim-frzr shelf,narrow
42 215002301 A B Hanger-pan/tray,LH
42 * 215002401 A B Hanger-pan/tray,RH
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
46 218278401 A B Front-crisper pan,(2)
47 218390564 A B Insert-pan cover,glass ,teal graphics
51 215132809 A B Duct-meat keeper,upper
51* 215133200 A B Insulation-air duct,rear
51* 215133300 A B Insulation-air duct,front
52 215132901 A B Control-damper,meat kpr duct
52* 215133000 A B Damper-air,meat kpr duct
54 215133100 A B Duct-meat keeper,lower
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
59* 215069518 A B Cap-mullion screw,black
59* 218188500 A B Screw-mullion mtg,LH,cr spcl oval hd ,10-32 x 0.75,thread forming
66 5304402116 A B Rack-wine
67 218278701 A B Front-meat pan
77 5303001216 A B Washer-nylon,3/16 x 5/8 OD
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
119 215132700 A B Cap-air duct
120 218019201 A B Seal-refr top
121 215364001 A B Cable-damper contrl
121* 215209400 A B Nut,push-on ,damper cable
122 218561202 A B Block-air deflector,RH
122 218561204 A B Block-air deflector,LH
123 215005100 A B Screw-roller/hanger,8-10 x .438
129 5303299152 A B Roller-hanger
129* 5303299153 A B Bearing-roller
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in
* 215339100 A B Seal-divider throat
* 215339900 A B Clip-shelf
* 215359900 A B Seal-divider front
* 215848000 A B Spacer-air channel
SHELVES

08/98 8
Publication No. FRT22TSE
5995311643
SYSTEM

# = Fast-moving Parts 9 08/98
* = Non-Illustrated Parts
FRT22TSE Publication No.
5995311643
SYSTEM
A = FRT22TSE (FRT22TSEB2, FRT22TSEK2)
B = FRT22TSE (FRT22TSEB3, FRT22TSEK3)
POS. NO PART NO DESCRIPTION
1 # 218787700 A B Condenser
1* 5303289026 A B Spacer-tube
2 5303289029 A B Clip-cond mtg,(4)
4 # 218541000 A B Drier-filter
5 # 218671800 A B Harness-wiring,main
5* # 218463600 A B Harness-wiring,crisper lights
6 # 215633901 A B Harness-wiring,machine compt
7 # 215459201 A B Cord-electric power
8 218803400 A B Cover-wiring
13 # 218168602 A B Heat Exchanger,suction line
14 # 5317842502 A B Heater-defrost
15 # 5303321220 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum
17 5316651102 A B Insulator-evap,plastic
18 5303292407 A B Insulation Block,RH
19 5303001198 A B Tube,rubber
20 5303292406 A B Insulation Block,LH
20A 5303292405 A B Insulation Plug,LH
21 # 5316269001 A B Thermostat-defrost
22 218811100 A B Base-compressor mtg,(drain pan)
23 218513300 A B Grommet-compr mtg,(4)
25 215014200 A B Clip-compressor mtg
29 # 5303917934 A - Compressor,R134a System ,w/electricals
29 # 218374514 - B Compressor,R134a ,W/O ELECTRICALS
30 # 218721101 - B Starter/Overload Assy
30 # 216008904 A - Starter-PTC
31 # 5303321892 A - Overload Protector
32 218762900 A - Wire-bale
32 218740800 - B Wire-bale
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500 ,
serrated head
43 215174700 A B Clamp-service cord,strain relief ,
galv steel
43* 5303001199 A B Clamp-wiring harness,strain relief ,
galv steel
43* 5308000133 A B Clamp,nylon ,.75 OD tube
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 218769200 A B Screw,hx wshr hd spec ,#6-32 x .5
45* 5300141713 A B Screw,hex wshr hd ,8-32 x .625 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
45* 5303210353 A B Screw,hex wshr hd ,8-32CA x .5
54 5303289027 A B Rail-cabinet base,rear
54A 5303289311 A B Rail-compr support
54B 5303289292 A B Rail-cabinet base,front
55 # 218764601 A - Capacitor-run
55 # 216236200 - B Capacitor-run
56 218769300 A - Insert-compressor mtg
56 215014100 - B Pin-compressor mtg
57 218247300 A B Clip-wiring harness
58 215004600 A B Screw-cond fan mtr,hx serr wshr hd ,
8-36 x 7/16,(2)
59 5303289031 A B Shroud-cond fan mtr
59* 215226700 A B Seal-foam,cond fan shroud
60 # 215501901 A B Motor-condenser fan
61 5303289032 A B Blade-cond fan
61* 215004700 A B Nut,speed
61* 215004800 A B Grommet-silencer
* 5303917214 A B Hot Tube Repair Kit,Service

08/98 10
Publication No. FRT22TSE
5995311643
ICEMAKER

# = Fast-moving Parts 11 08/98
* = Non-Illustrated Parts
FRT22TSE Publication No.
5995311643
ICEMAKER
A = FRT22TSE (FRT22TSEB2, FRT22TSEK2)
B = FRT22TSE (FRT22TSEB3, FRT22TSEK3)
POS. NO PART NO DESCRIPTION
1 5314368805 A B Tube-valve to IM,plastic ,cut to length
2 3206348 A B Spring,shut-off arm
3 3206299 A B Plate-I.D.
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 1/4
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-holding sw
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff Assy
12 3206321 A B * Connector Plug,wiring harness
12 # 3206349 A B Harness-wiring,IM internal ,with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 3206323 A B Screw-switch mtg,4-24 x 3/4 ,
sw to support,(2)
15 # 3206324 A B Switch,(3)
16 3206326 A B Support
17 # 5303320545 A B Mold-ice maker,with heater ,radius cube
18 3206328 A B Ejector
19 3206330 A B Bearing & Inlet
20 3206331 A B Screw,8-18 x 3/8 ,(2)
21 3206332 A B Ice Stripper
22 3206333 A B Arm,shut-off
23 3206334 A B Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 A B Lever-arm
25 3206336 A B Screw-arm levr/sprt,8-18 x 9/16
26 3206337 A B Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 A B Screw-sw&spcr/plate,4-40 x 1
28 3206339 A B Screw-timing stop,4-40 x 3/8
29 3206340 A B Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 A B Screw-timing,8-32 x 1
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 3206344 A B Spring
34 3206345 A B Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 A B Screw-gear/cam,6-20 x 0.437
36 3206347 A B Cover-complete
37 5303320544 A B Data Sheet,ice maker
38 5303207445 A B Envelope-data sheet
39 # 5303289065 A B Harness-wiring,IM to refr
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
46 5303001193 A B Clamp-inlet tube,metal
47 5308000205 A B Adapter-water sply,straight
48 5308000200 A B Nut,7/16 x 20 ,nylon
51 215811600 A B Tube-fill
55 # 218720400 A B Valve-water,115V
59 5303001191 A B Sleeve-tube insert
60 5303207328 A B Screw,hex wshr hd ,8-15A x 1
61 218721500 A B Bracket-leveling,ice maker
62 218737900 A B Screw-IM mtg brkt,hex hd ,#8-32 x 3/8
64 5303001549 A B Clamp-copper tube,steel
* 5303289069 A B Container-ice
