Frigidaire FRS26KF5C User manual

N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SACAAD1.eps N58TAAAAB3.eps N58CAAAAA3.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
Product No. FRS26KF5CS0
Series R134a
Color stain/blk
Volts 115
Wiring Diagram 241526901
Owner's Guide 240581300
Market North America
Energy Guide 240598634
Service Data Sheet 240389615
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995418356
04/10/08
(EN/SERVICE/DCS)
357
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26KF5C
Copyright ©All rights reserved.

Publication No: 5995418356 FRS26KF5CS0
10/04 2
FREEZER DOOR
21C
21
21
21
21C
21C
21
74
74
74
72
72
73
73
73
18
37
22C
11
1
4A
68
4B
4B
13A
22A
21A
N58FCCBBB2

FRS26KF5CS0 Publication No: 5995418356
# Functional Parts 3 10/04
* Non-Illustrated Parts
FREEZER DOOR
POS. NO PART NO. DESCRIPTION
1 # 240390606 Gasket-frzr door, black, magnetic
4A 240334201 Bin-door, frzr-upper
4B 240351601 Bin-door
11 240554228 Door-frzr, stainless steel, complete assy
13A 240581906 Door Stop, black, frzr
18 240359108 Handle-door, black, LH
21 218781100 Screw, pan head, 8-18 x 0.625
21A 240598401 Screw, 10-32 x 1/2
21C 240521302 Screw, #8-18 x 3/4
22A 240328202 Bearing-hinge(frz), closer
22C 240328404 Bearing-hinge, black, upper
37 240359203 Trim-handle, 30.13", black, lower
68 240467701 Chute-ice
72 240421701 Button-handle mtg, dovetail
73 218396700 Block-handle mtg, dovetail
74 215503200 Screw, cr pan hd, 10-16 x 0.500
* 218490900 Cleaner, stainless steel
* 240352102 Connector-water, straight
* 240552101 Harness-wiring, door
* 5303918256 Dispenser heater kit

Publication No: 5995418356 FRS26KF5CS0
10/04 4
REFRIGERATOR DOOR
21C
21
21
21
21C
21C
21
74
74
74
21A
22
13
72
72
73
73
73
18
37
15
22B
2
7
49
49
4
4
N58RCCBBB5

FRS26KF5CS0 Publication No: 5995418356
# Functional Parts 5 10/04
* Non-Illustrated Parts
REFRIGERATOR DOOR
POS. NO PART NO. DESCRIPTION
2 240390605 Gasket-refr door, black, magnetic
4 240323001 Bin-door, pseudo, bottom
7 240326203 Door-dairy
13 240581905 Door Stop, black, ref
15 240451982 Door-refr, stainless steel, complete assy
18 240359103 Handle-door, black, RH
21 218781100 Screw, pan head, 8-18 x 0.625
21A 240598401 Screw, 10-32 x 1/2
21C 240521302 Screw, #8-18 x 3/4
22 240328201 Bearing-hinge(ref), closer
22B 240328403 Bearing-hinge, black, upper
37 240359203 Trim-handle, 30.13", black, lower
49 240356401 Bin-door, gallon
72 240421701 Button-handle mtg, dovetail
73 218396700 Block-handle mtg, dovetail
74 215503200 Screw, cr pan hd, 10-16 x 0.500
* 218490900 Cleaner, stainless steel

Publication No: 5995418356 FRS26KF5CS0
10/04 6
CABINET

FRS26KF5CS0 Publication No: 5995418356
# Functional Parts 7 10/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
10 240435904 Cover-air duct
10A 240475904 Cover-evap coil, lower
11 5303208309 Plug-hole, factory test
14 240505801 Switch, light/lamp
14A# 215486600 Switch-light/lamp
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 240457701 Plate-door closer
23 240402701 Screw-#10-32 x 1/4 flat hd
28 240335501 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240419103 Bracket-lower hinge, ref
30A 240419104 Bracket-lower hinge
37 240337603 Trim-cabinet corner, black, (2)
38 240327202 Bracket-upper hinge
40 240327007 Cover-upper hinge, black
41 240358701 Grommet-shelf mtg, 1.40" long
41* 240358801 Grommet-shelf mtg, .875" long
42 240578901 Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 Roller Assy, front, (2)
45 241500301 Screw, hex washer head, 8-18AB x 0.500
47 218659500 Channel-shelf mtg, side, (2)
58 218781100 Screw, pan head, 8-18 x 0.625
66B 240374301 Diffuser-air
66B* 240518802 Pin-push, push-in, plastic
72 240324406 Grille/Kickplate, black
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326104 Cover, access, system compt, with label
90 218249808 Seal-coil cover
91 240380101 Duct-ice maker
92 216850900 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
100 240423701 Support, crisper cover, front, (4)
100* 240350802 Support, crisper cover, rear, (4)
150 240368701 Guide-control bulb
* 240396801 Clamp, tube/wiring, nylon, black/natural
* 240479601 Plug, button, cab liner holes, (2)
* 240481601 Shim-lower hinge
* 5303305345 Paint, touch-up, black

Publication No: 5995418356 FRS26KF5CS0
10/04 8
SHELVES

FRS26KF5CS0 Publication No: 5995418356
# Functional Parts 9 10/04
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
2 241510604 Trim-basket
11 240338802 Shelf-freezer, flip-up
11A 240338702 Shelf-freezer, fixed wire
11B 240338704 Shelf-freezer, fixed wire
15A 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16A# 241513901 Socket-light
16A* 241537602 Harness-wiring
24 240355208 Shelf-"Spill-Safe", fixed
24A 240350108 Shelf-"Spill-Safe", cantilever, sliding
25 240350702 Cover-crisper pan, upper
25* 240362101 Clip-slide, cover-crisper
25A 240350902 Cover-crisper pan, lower
26 240351005 Pan-crisper, upper
26* 240349801 Clip-slide, pan-crisper
26A 240362201 Control-humidity
27 240351206 Pan-crisper, lower
39 240430706 Trim-shelf, 11.21", front
39B 240430702 Trim-shelf, 12.39", front
42 240356501 Track, meat pan hanger, RH
42 240365401 Track, meat pan hanger, LH
47 240350633 Insert-pan cover, glass
47A 240350603 Insert-pan cover, glass
49 240530402 Basket-sliding
51 240343002 Hanger-basket, RH
52 240343102 Hanger-basket, LH
62 240342806 Pan-meat
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
97 240545303 Water Tank Assy, coiled tubing, front filter
100 240326302 Cover-water tank
101 218493100 Screw, hex washer head, 8-18AB x 1-3/4
109 240351301 Base-crisper light socket
123 215005100 Screw, hanger/rlr mtg, 8-10 x 0.438
126 218867405 Channel, auger mtg, LH
126 218867406 Channel, auger mtg, RH
140 240430501 Channel, wtr tube cover

Publication No: 5995418356 FRS26KF5CS0
10/04 10
CONTROLS
