Frigidaire FRTD2021AS Owner's manual

Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
use &care
REFRIGERATOR
A22278101 (July 2021)
Introduction.......................................................2
Important Safety information.....................3
Features..............................................................6
Installation .........................................................7
Door Removal/Reversal................................9
Door Handle Installation............................. 12
Water Supply Connection..........................14
Ice Maker .......................................................... 16
Controls and Settings ................................. 17
Storage Features........................................... 18
Normal Operating Sounds........................20
Care and Cleaning ........................................ 21
Troubleshooting .......................................... 23
Limited Warranty ......................................... 24

2INTRODUCTION
Doors
Handles are secure and tight
Refrigerator door seals completely
to cabinet on all sides
Freezer door is level from side to
side across the top
Leveling
Refrigerator is level side-to-side and
tilted ¼" (6 mm) front-to-back
Cabinet is set solid on all corners
Toe grille is properly attached
to refrigerator
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker (some models)
House water supply connected
to refrigerator (Warning: Potable
water supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Final Checks
Shipping material removed
Refrigerator and freezer tempera-
tures set to recommended setting
Crisper humidity controls set
Registration card sent in
Installation Checklist

Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
FPO
Serial location
Serial Number Location
Serial Plate

3
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
WARNING
Please read all instructions before using
this appliance.
IMPORTANT SAFETY INFORMATION
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be re-
paired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.

4IMPORTANT SAFETY INFORMATION
Proper Disposal of your Appliance
Before you throw away your old unit:
• Remove doors.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant
removed by a
qualified service
technician.
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned appliances are still dangerous –
even if they will sit for “just a few days”. If
you are getting rid of your old unit, please
follow the instructions below to help pre-
vent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with your utility company or visit
energystar.gov/recycle for more informa-
tion on recycling your old appliance.
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a cooling
system that used CFCs or HCFCs (chlo-
rofluorocarbons or hydrochlorofluoro-
carbons). CFCs and HCFCs are believed
to harm stratospheric ozone if released
to the atmosphere. Other refrigerants
may also cause harm to the environment
if released to the atmosphere.
If you are throwing away your old refrig-
erator, make sure the refrigerant is re-
moved for proper disposal by a qualified
technician. If you intentionally release
refrigerant, you may be subject to fines
and imprisonment under provisions of
environmental legislation.
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids, or aerosols
within or in the vicinity of this or any
other appliance. Read product labels
for warnings regarding flammability
and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after you unpack the
refrigerator. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.

5
WARNING
Follow these guidelines to ensure
safety mechanisms in this appliance will
operate properly.
Electrical information
• Plug the unit into its own dedi-
cated 115 Volt, 60 Hz., 15 Amp, AC
only electrical outlet. The power
cord of the appliance is equipped
with a 3-prong grounding plug for
your protection against electrical
shock hazards. Plug it directly into a
properly grounded 3-prong recep-
tacle. You must install the recepta-
cle in accordance with local codes
and ordinances. Consult a qualified
electrician. Avoid connecting the unit
to a Ground Fault Interrupter (GFI)
circuit. Do not use an extension cord
or adapter plug.
• If the power cord is damaged, an
authorized service technician should
replace it to prevent any risk.
• Never unplug the refrigerator by pull-
ing on the power cord. Always grip
the plug firmly, and pull it straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the appliance before clean-
ing and before replacing the AC LED
light bulb to avoid electrical shock.
Use only a 5-watt or less AC LED
light bulb.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the refrigerator with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the unit from
being turned o accidentally.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT
Turning the Refrigerator controls to
“OFF” will disable your refrigerator’s
cooling system, but does not disconnect
the power to the light bulb and other
electrical components. To turn o power
to your refrigerator you must unplug the
power cord from the electrical outlet.
IMPORTANT SAFETY INFORMATION

6FEATURES
*Features may vary according to model
AToe Grille
BCrisper Drawers
CCrisper Cover
DDeli Drawer*
EGlass Shelves
FRefrigerator Control
GFreezer Control
HFreezer Shelf
IIce Bucket* (optional accessory)
JIce Maker* (optional accessory)
KDoor Racks
LDairy Bin
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
A
B
C
D
E
E
F
G
H
I
J
K
K
K
K
K
L

7
INSTALLATION
IMPORTANT
Cleaning your Refrigerator
Remove tape and glue residue from
surfaces before turning the refriger-
ator on. Rub a small amount of liquid
dish soap over the adhesive with your
fingers. Rinse with warm water and dry
with a soft cloth.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of
your refrigerator.
After you remove all of the package ma-
terials, clean the inside of your refriger-
ator before using it. See the CARE AND
CLEANING section in this manual.
This Use & Care Manual provides general
operating instructions for your model. Use
the appliance only as instructed in this
Use & Care Manual. Before starting the
unit, follow these important first steps.
Installation
Location
• Choose a place near a grounded
electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator
out of direct sunlight and away
from the range, dishwasher or other
heat sources.
• The refrigerator must be installed on
a floor that is level and strong enough
to support a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automat-
ic ice maker. If you do not hook up
water to the refrigerator, remember
to turn the ice maker o.
CAUTION
Do not install the refrigerator where the
temperature will drop below 50°F (10°C)
or rise above 110°F (43°C). The compres-
sor will not be able to maintain proper
temperatures inside the refrigerator.
Do not block the toe grille on the lower
front of your refrigerator. Sucient air
circulation is essential for the proper
operation of your refrigerator.
WARNING
This appliance is intended to be used
in household and similar applications
such as:
• sta kitchen areas in shops, oces
and other working environments;
• farm houses and by clients in hotels,
motels and other residential type
environments;
• bed and breakfast type environments;
• catering and similar non-
retail applications.
WARNING
Installation clearances
Allow the following clearances
for ease of installation, proper air
circulation, and plumbing and electrical
connections:
Sides & Top ⅜”
Back 1”
NOTE
If your refrigerator is placed with the
door hinge side against a wall, you may
have to allow additional space for the
handle so the door can be opened wider.

8
Guidelines for final positioning of
your refrigerator:
• All 4 corners of the cabinet must rest
firmly on the floor.
• The cabinet should be level at the
front and rear.
• The sides should tilt ¼" (6 mm) from
front to back (to ensure that doors
close and seal properly).
• Doors should align with each other
and be level.
INSTALLATION
NOTE
Raise the front of the refrigerator
enough so the doors close freely when
opened halfway. The refrigerator should
slope ¼" to ½" from front-to-back. Then
level the refrigerator from side-to-side.
To level the cabinet using the front rollers:
Raise
9/16"
(14 mm)
Max
Figure 3
9/16"
(14 mm)
Max
Raise
Figure 2
3. Use an adjustable wrench to adjust
leveling screws. Lower the leveling
screws on each side clockwise until
they contact the floor (Figure 3). Do
not raise the cabinet more than 9/16".
1. Remove the toe grille (Figure 1).
2. Use a flat-blade screwdriver or ⅜"
socket wrench to raise or lower the
front rollers (Figure 2). Do not raise
the cabinet more than 9/16".
Figure 1

9
DOOR REMOVAL/REVERSAL
IMPORTANT
Before you begin, turn the refrigerator
temperature control to “0” and remove
the electrical power cord from the
wall outlet. Remove any food from
door shelves.
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Bottom
Hinge
Screw
Top
Hinge
Screw
Adjustable
Wrench
Socket
Wrench Set
3/8" (10mm)
Fixed
Wrench
Tools Necessary:
PhillipsTM
Head
or
or
1. Remove the toe grille.
2. Remove the top hinge cover. Trace
around the hinge with a soft lead
pencil. This makes reinstallation
easier. Remove the top hinge and lift
the door o the center hinge pin. Sit
the door aside.
Door removal and
reversal instructions:
Top
Hinge
Cover
Top
Hinge
3. Unscrew the center hinge pin using
an adjustable wrench and save it
for reassembly. Ensure the plastic
washer stays on the hinge pin.
4. Lift the refrigerator door o the
bottom hinge and sit aside.
5. Remove the center hinge and shim
by removing the inside screw and
loosening the 2 outside screws
enough to allow the hinge and shim
to slide out. Tighten screws.
NOTE
The direction in which your refriger-
ator doors open (door swing) can be
reversed, from left to right or right to
left, by moving the door hinges from
one side to the other. Reversing the
door swing should be performed by a
qualified person.

10 DOOR REMOVAL/REVERSAL
6. Loosen the 2 outside screws on
the opposite side of refrigerator.
Remove the inside screw and install
the center hinge.
7. Remove the 2 screws on the bottom
hinge with a ⅜" socket wrench.
8. Install the bottom hinge on the
opposite side with the 2 screws
removed from step 7.
Door
Stop
Shim
Washer
Hinge
Pin
Center
Hinge
Screws
Hinge
Hole
Plug Handle
Hole
Plug
Door
Stop
Screw
Washer
Hinge
Pin
Bottom
Hinge
Screws
Toe
Grille
Door Stop
Screw
Door
Stop
9. Unscrew the bottom hinge pin
using an adjustable wrench. Move
the hinge pin to the other hole
in the hinge and tighten with the
adjustable wrench.
10. Reverse door handles (see
instruction on the next page).
11. Move the freezer and refrigerator
door stops to the opposite side.
Before starting the screws, use an
awl to puncture the foam.
12. Position the refrigerator door onto
the bottom hinge pin and screw the
center hinge pin through the center
hinge into the top of the door. Close
the refrigerator door to help align
the hinge hole.
13. Tighten the center hinge pin with an
adjustable wrench.
14. Remove the cabinet and the
hinge hole plugs, and move to the
opposite side.
15. Lower the freezer door onto the
center hinge pin.
16. Close the freezer door. Lift up on
handle side of the door and grasp
the thinnest part of the top hinge
cover (which was removed in Step 2)
and insert the thickest part between
the doors on the handle side
approximately 3" from the outside
edge. This will ensure proper spacing.

11
DOOR REMOVAL/REVERSAL
17. Tighten the top hinge screws and
check the door gasket for an open
seal condition (gap between the
gasket and the cabinet flange).
Look for open areas between the
gasket and the cabinet flange.
Gasket should seal against the
cabinet all the way around including top
and bottom
18. Should an open seal condition exist,
try to massage the gasket to make
sure it is seated into the channel.
19. If the open seal condition still exists,
you may need to flip the gasket. In
this case, remove the gasket from
the door by pulling it out. Rotate
the gasket half a turn (180 degrees).
Reinstall the gasket by inserting the
corners first, and then work toward
the middle assuring it is fully seated
in the channel.
20. Flip the toe grille and reinstall.
21. Plug in the electrical power cord and
turn the refrigerator temperature
control to the center. Adjust the
setting as necessary.
IMPORTANT
If the condition still exists, try heating
the gasket with a hair dryer with the
door closed. Use caution and be careful
not to damage the interior door panel
or gasket by applying too much heat.

12 DOOR HANDLE INSTALLATION
To attach the metal refrigerator handle:
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the two holes
in the top of the handle with the two
holes in the top of the door. Do not
tighten the set screw yet.
2. Install the 2 screws into the top of
the handle.
3. Tighten the set screw on the
rounded part of the handle until the
handle is flush with the door, and
then tighten another ½turn.
CAUTION
Wear gloves and use extreme CAUTION
when installing these handles. The
rounded end of the handles may be sharp.
Screw
Handle
Button
Plug
Set
Screw
Shoulder
Screw
Shoulder
Screw
Nameplate
Handle
Set Screw
Screw
To attach the metal freezer handle:
1. Place the rounded part of the handle
onto the shoulder screw on face of
door and align the 2 holes in the
bottom of the handle with the 2
holes in the bottom of the door. Do
not tighten the set screw yet.
2. Install the 2 screws into the bottom
of the handle.
3. Tighten the set screw on the
rounded part of the handle until the
handle is flush with the door, and
then tighten another ½turn.
IMPORTANT
To ensure proper installation of the
handles, please review these instruc-
tions and illustrations thoroughly prior
to installing the handles.
Additionally, before installing the door
handles, make sure the door swing is
correct. Your model will have either a
right hand or left hand door swing. Fol-
low instructions in the Use & Care Man-
ual to reverse the doors, if necessary.

13
DOOR HANDLE INSTALLATION
To reverse the metal refrigerator/
freezer handles:
Handles may be easier to reverse while
the doors are o. Reverse the freezer and
refrigerator handles as shown.
CAUTION
Be sure doors are placed in a secure
position where they cannot fall and
cause personal injury.
CAUTION
Do not use an electric screwdriver to
attach handles; overtightening handles
may crack them. Use a handheld
screwdriver only.
These screws are
packaged with the
handles.
To attach the plastic refrigerator handle:
1. With the door open, place the
end of the handle on the dove tail
mounting screw and pull it down to
secure it in place.
2. Align the handle base with holes in
top of the door.
3. Install the screws packaged with
the handle.
Handle
Manija
Poignée
Screws
Los tornillos
Vis Handle Base
Base de mango
Base de poignée
To attach the plastic freezer handle:
1. With the door open, place the
end of the handle on the dove tail
mounting screw and push up to
secure in place.
2. Align the handle base with holes in
the bottom of the door.
3. Install the screws packaged with
the handle.
Mounting Screw
Handle Base
Screws
Handle

14 WATER SUPPLY CONNECTION
WARNING
To avoid electric shock, which can cause
death or severe personal injury, dis-
connect the refrigerator from electrical
power before connecting a water supply
line to the refrigerator.
CAUTION
To Avoid Property Damage:
• Use stainless steel braided tubing
for the water supply line. Do not
use water supply tubing made of
¼" plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to
soft water, ensure the softener is
maintained and working properly.
NOTE
Check with your local building
authority for recommendations on
water lines and associated materials
prior to installing your new refrigerator.
Depending on your local/state building
codes, Frigidaire recommends for
homes with existing valves its Smart
Choice®water line kit 5304437642
(with a 6' Stainless Steel Water Line)
and for homes without an existing
valve, Frigidaire recommends its
Smart Choice®water line kit
5304493869 (with a 6’ Polyline
Waterline). Please refer to
Frigidaire.com for more information.
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools: adjustable wrench, flat-blade
screwdriver, and Phillips screwdriver
• Access to a household cold water
line with water pressure between 30
and 100 psi.
• A water supply line made of stainless
steel tubing. To determine the length
of tubing needed, measure the dis-
tance from the ice maker inlet valve
at the back of the refrigerator to your
cold water pipe, so the refrigerator
can be moved out for cleaning.
• A shuto valve to connect the water
supply line to your household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
Ice Maker Models Only
NOTE
Automatic ice makers are optional acces-
sories that you may install in most models
at any time. Visit Frigidaire.com for infor-
mation about Ice Maker Kit IMKTF20A.
To Connect the Water Supply Line To the
Ice Maker Inlet Valve
1. Disconnect the refrigerator from the
electrical power source.
2. Place the end of the water supply
line into a sink or bucket. Turn ON
the water supply and flush the supply
line until the water is clear. Turn OFF
the water supply at the shuto valve.
3. Remove the plastic cap from the wa-
ter valve inlet and discard the cap.
IMPORTANT
Ensure your water supply line connections
comply with all local plumbing codes.

15
4. If you use copper tubing, slide the
brass compression nut, and then
the ferrule (sleeve) onto the water
supply line. Push the water supply
line into the water valve inlet as far
as it will go (¼" / 6.4 mm). Slide the
ferrule (sleeve) into the valve inlet
and finger tighten the compression
nut onto the valve. Tighten another
½turn with a wrench; DO NOT over-
tighten. See below.
If you use braided flexible stain-
less steel tubing, the nut is already
assembled on the tubing. Slide the
nut onto the valve inlet and finger
tighten the nut onto valve. Tighten
another ½turn with a wrench; DO
NOT overtighten. See below.
5. With the steel clamp and screw,
secure the water supply line (copper
tubing only) to the rear panel of
refrigerator as shown.
6. Coil the excess water supply line
(copper tubing only), about 2½
turns, behind the refrigerator as
shown and arrange the coils so they
do not vibrate or wear against any
other surface.
7. To turn the ice maker on, press the
ice maker’s On/O power switch so
the LED is illuminated.
8. Turn ON the water supply at the
shuto valve and tighten any con-
nections that leak.
9. Reconnect the refrigerator to the
electrical power source.
WATER SUPPLY CONNECTION
Parts
A Clamp
B Brass compression nut
C Ferrule sleeve
D Copper line
E Water line
F Water valve bracket
G Water valve inlet
H Water valve
I Copper water line from household
water supply
J 6' (1.8 m) minimum braided flexible
stainless water line from household
water supply
Include enough tubing in loop to allow
moving the refrigerator out for cleaning.
Units with
copper tubing A
B
D
F
G
H
I
C
Units with braided
flexible stainless
steel tubing
E
J
B
F
G
H

16
ICE PRODUCTION: WHAT
TO EXPECT
The ice maker will produce 1.5 to 2 lbs
of ice every 24 hours depending on use
conditions. Ice is produced at a rate of 10
cubes every 100 to 160 minutes.
CAUTION
Do Not place the ice container in
your dishwasher.
ICE MAKER
If your refrigerator has an automatic ice
maker, it will produce minimal ice during
the first 24 hours of operation. Air in the
new plumbing lines may cause the ice mak-
er to cycle 2 or 3 times before making a full
tray of ice. With no use, it will take approxi-
mately 1 to 2 days to fill the ice container.
New plumbing connections may cause
the first production of ice cubes to be
discolored or have an odd flavor. Discard
ice made during the first 24 hours.
Turning Your Ice Maker On
After completely connecting the
plumbing, you must open the water
supply valve. Place the ice container
under the ice maker, pushing it as far back
as possible. Press the ice maker’s On/O
button.
Turning Your Ice Maker O
To stop the ice maker, press the ice mak-
er’s On/O button. The ice maker regu-
lates the ice production and stops making
ice when full and starts again when ice is
low in the ice container.
NOTE
Automatic ice makers are optional acces-
sories you may install in most models at
any time. Visit Frigidaire.com for informa-
tion about Ice Maker Kit IMKTF20A.
NOTE
Set the freezer to a colder setting to in-
crease the output of the ice maker. Allow
24 hours for the temperature to stabilize.
IMPORTANT
The ice maker is shipped in the On
position. To ensure proper function for
your ice maker, hook up the water sup-
ply immediately or turn the ice maker
O. If the ice maker is on and the water
supply is not connected, the water
valve will make a loud chattering noise.

17
CONTROLS AND SETTINGS
NOTE
When first turning refrigerator on, adjust
control to recommended. This is the
recommended initial setting. After 24
hours, adjust the controls as needed.
Refrigerator Control
Auxiliary Freezer Control
Temperature Adjustment
• Adjust temperature gradually:
adjust the knob in small increments,
allowing the temperature to stabilize.
• For colder temperatures, adjust the
knob toward coldest.
• For warmer temperatures, adjust the
knob toward cold.
Adjusting the refrigerator control will
change temperatures in both compart-
ments. The auxiliary freezer control can be
left at the factory pre-set (mid position)
or adjusted as desired; it has no eect on
electrical power to the refrigerator.
To maintain temperatures, a fan circulates
air in the refrigerator and freezer
compartments. For good circulation, do
not block cold air vents with food items.
Cool Down Period
To ensure safe food storage, allow the
refrigerator to operate with the doors
closed for at least 8 hours before loading
it with food.
CAUTION
Do not install the refrigerator where
the temperature will drop below 50°F
(10°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the refrigerator.
Refrigerator & Freezer Controls
IMPORTANT
Adjusting the refrigerator temperature
control to OFF turns o the compressor
and prevents the refrigerator from cool-
ing, but does not disconnect the power
to the light bulb and other electrical
components. To turn o power to your
refrigerator, you must unplug the power
cord from the wall outlet.
IMPORTANT
If you install your refrigerator in a ga-
rage or other unheated area, you may
experience freezer temperature prob-
lems during the winter months when
temperatures dip below 50°F (10°C).
If your unit is in a garage or area where
the temperature is below 50°F (10˚ C),
adjust the freezer control to the coldest
setting to improve performance.

18 STORAGE FEATURES
Shelf Adjustment
Refrigerator shelves are easily adjusted to
suit individual needs. Before adjusting the
shelves, remove all food.
To adjust sliding shelves:
1. Remove the shelf by pulling it
forward to stop position.
2. Lift the front edge up and pull it out.
To replace the shelf, rest side edges on
any pair of shelf rails and carefully push
the shelf back into position.
Door Rack
Door storage
Door bins, shelves, and racks are provided
for convenient storage of jars, bottles,
and cans. Frequently used items can be
quickly selected.
The dairy compartment, which is warmer
than the general food storage section, is
intended for short term storage of cheese,
spreads, or butter.
Door rack
Some models have door racks or bins that
can accommodate gallon-sized plastic
drink containers and economy-sized jars
and containers.
To remove the door rack:
1. Push on the rack sides to release it
from the locking tabs.
2. Pull it straight out.
To install the door rack:
1. Lower the door rack down into place.
2. Make sure tabs lock into place.
CAUTION
Do not clean glass shelves or covers
with warm water when they are
cold. Shelves and covers may break
if exposed to sudden temperature
changes or impact, such as bumping.
Tempered glass is designed to shatter
into many small, pebble-size pieces.
This is normal. Glass shelves and
covers are heavy. Use both hands when
removing them to avoid dropping.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to
sudden temperature change.

19
STORAGE FEATURES
NOTE
Leafy vegetables keep best when
stored with the Humidity Control set on
High Humidity, or in a drawer without a
Humidity Control. This keeps incoming
air to a minimum and maintains maxi-
mum moisture content. Store non-leafy
vegetables and fruits still in their skins
at the low humidity setting.
Crisper Humidity Control
The crisper humidity control allows
you to adjust the humidity within the
crisper. This can extend the life of fresh
vegetables that keep best in
high humidity.
Low
Humidity
High
Humidity
Higher Humidity Lower Humidity
Crispers
The crispers, located under the bottom
refrigerator shelf, are designed for
storing fruits, vegetables, and other fresh
produce. Wash items in clear water and
remove excess water before placing them
in the crispers. Items with strong odors or
high moisture content should be wrapped
before storing.

20 NORMAL OPERATING SOUNDS
NOTE
Rigid foam insulation is very energy
ecient but is not a sound insulator.
Understanding the sounds you
may hear
Your new, high-eciency refrigerator
may introduce unfamiliar sounds. These
sounds normally indicate your refrigerator
is operating correctly. Some surfaces on
floors, walls, and kitchen cabinets may
make these sounds more noticeable.
Following is a list of major components
in your refrigerator and the sounds they
can cause:
A Evaporator Refrigerant through the
evaporator may create a boiling or
gurgling sound.
B Evaporator fan You may hear
air being forced through the
refrigerator by the evaporator fan.
C Defrost heater During defrost
cycles, water dripping onto the
defrost heater may cause a hissing
or sizzling sound. After defrosting, a
popping sound may occur.
D Automatic ice maker When ice has
been produced, you will hear ice
cubes falling into the ice bin.
E Automatic Defrost control These
parts can produce a snapping or
clicking sound when turning the
cooling system on and o.
F Condenser fan You may hear air
being forced through the condenser.
G Compressor Modern, high-eciency
compressors run much faster than
in the past. The compressor
may have a high-pitched hum or
pulsating sound.
H Water valve If your refrigerator is
equipped with an automatic ice
maker, you will hear a buzzing sound
as the water valve opens to fill the
ice maker during each cycle.
I Drain pan (not removable) You may
hear water dripping into the drain
pan during the defrost cycle.
J Condenser May create minimal
sounds from forced air.
IMPORTANT
During the automatic defrost cycle, you
may notice a red glow in the vents on the
back wall of your freezer compartment.
This is normal during the defrost cycle.
AB
C
D
E
F
G
H
I
J
