Frigidaire FRT18C2J Manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18C2JW1 FRT18C2J R134a System white (right) 115
FRT18C2JZ1 FRT18C2J R134a System white (left) 115
MARKET
North America
Publication No.
5995344446
001009
-EN/SERVICE/KHB
390
REFRIGERATOR
Model No.
FRT18C2J
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - #218758400
OWNER’S GUIDE - # 218989100
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624

10/00 2
Publication No. FRT18C2J
5995344446
DOOR

# = Fast-moving Parts 3 10/00
* = Non-Illustrated Parts
FRT18C2J Publication No.
5995344446
DOOR
A = FRT18C2J (FRT18C2JW1)
B = FRT18C2J (FRT18C2JZ1)
POS. NO PART NO DESCRIPTION
1 # 215608916 A B Gasket-frzr door,white ,magnetic
2 # 218730605 A B Gasket-refr door,white ,magnetic
3 218360003 A B Panel-inner door,refr
4 218027022 A B Rack-door,23.81" x 1.62"
5 215267701 A B Support-door rack,"2-liter" ,RH/LH
5A 215473602 A B Support-door rack,RH/LH
9 218360101 A B Panel-inner door,frzr
10 5308000134 A B Plug-button,white ,hinge brg hole
11 5303917805 A B Panel-frzr door,white ,w/insulation
12 218439152 A B Nameplate Assy, Frigidaire, white, w/mtg tape
12 316095402 A B • Label-nameplate, Frigidaire, white
13 218800300 A B Door Stop,plated
13A 218249001 A B Door Stop,white ,frzr section
14 218915701 A B Plug-button,white
15 5303917806 A B Panel-refr door,white ,w/insul & brace
18A 218428101 A B Handle-door,white ,w/block & screw
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B Bearing-hinge
58 218749600 A B Screw,#10 pan hd ,8-18 x .5
72 218397000 A B Button-handle mtg,dovetail
73 218396700 A B Block-handle mtg,dovetail
74 215503200 A B Screw,cr pan hd ,10-16 x 0.500
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

10/00 4
Publication No. FRT18C2J
5995344446
CABINET

# = Fast-moving Parts 5 10/00
* = Non-Illustrated Parts
FRT18C2J Publication No.
5995344446
A = FRT18C2J (FRT18C2JW1)
B = FRT18C2J (FRT18C2JZ1)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
6 218448301 A B Cover,white ,lwr hinge hole
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 218985301 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 # 218878701 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218973201 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774901 A B Plug-button,white ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
29* 5308000186 A B Washer,.34 x .62 x .10 ,nylon
30 5303917777 A B Bracket-lower hinge,zinc plate
30* 215882300 A B Tapping Plate,lower hinge ,(2)
32 215217701 A B Plug-button,white ,cabinet base ,(2)
35 218998901 A B Bracket-ctr hinge,light gray
36 218251300 A B Pin-center hinge
37 5303321081 A B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
40 3206101 A B Cover-upper hinge,white
42 215880100 A B Screw-hinge mtg, hex washer head, 1/4-20 x 0.685, (2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B Roller
43* 5308009761 A B Bolt-roller adj
43* 5308009790 A B Spring-roller adj
43* 5308011326 A B Washer,.34 x .62 x .02 ,nylon
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
56 218220300 A B Pin-lower hinge
59 218188000 A B Screw,pan hd ,10-32 x 0.625, hinge/mull, thrd forming
78 5303274237 A B Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099701 A B Plug-button,white
* 5303305324 A B Paint,touch-up ,white
* 5308016571 A B Plug-button,cab liner holes
CABINET

10/00 6
Publication No. FRT18C2J
5995344446
SHELVES

# = Fast-moving Parts 7 10/00
* = Non-Illustrated Parts
FRT18C2J Publication No.
5995344446
SHELVES
A = FRT18C2J (FRT18C2JW1)
B = FRT18C2J (FRT18C2JZ1)
POS. NO PART NO DESCRIPTION
1 218874301 A B Mullion,white
5 # 218781003 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Panel-top,refr cavity
8 218872903 A B Divider,styrofoam ,w/foil tape
8* # 218878500 A B Wiring Harness,control/divider
9 218814700 A B Panel-bottom,frzr cavity
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 # 5303001179 A B Light Bulb/Lamp,40 W
16A# 218906801 A B Socket-light/lamp
17 5304414816 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 5303321453 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B Tube, PVC, white, @ air deflector, insulator
23 # 215846605 A B Timer-defrost, 60 Hz, 120 V, 10 hour/21 min
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 5303307451 A B Shelf,sliding ,wire ,refr section
25 5303207340 A B Cover-crisper pan, with beam, less insert
26 3206438 A B Pan-crisper
46 5303304709 A B Front-crisper pan
47 5303281398 A B Insert-pan cover,glass
59 218188000 A B Screw, pan hd, 10-32 x 0.625, hinge/mull, thrd forming
81 5303001380 A B Screw,truss head ,8-10 x 1.625
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in

10/00 8
Publication No. FRT18C2J
5995344446
SYSTEM

# = Fast-moving Parts 9 10/00
* = Non-Illustrated Parts
FRT18C2J Publication No.
5995344446
SYSTEM
A = FRT18C2J (FRT18C2JW1)
B = FRT18C2J (FRT18C2JZ1)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
1* 5303208866 A B Spacer-cond tube,black
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10 ,grounding
4 # 218944001 A B Drier-filter,R134a System
5 218878500 A B Wiring Harness,control/divider
6 # 215257004 A B Wiring Harness,compressor
7 # 5316254901 A B Cord-electric power
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 218955901 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 218973101 A B Insulator-evap
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 218969902 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846902 A B Compressor,R134a ,w/o electricals
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Clamp,elec cont mtg ,compressor
41 5308000039 A B Screw, hex wshr hd, 8-32CA x 0.500, (7),serrated hd
43 5303001199 A B Clamp-wiring harness, strain relief, galv steel
44 5308000133 A B Clamp,nylon ,.625 ID
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
45* 218843800 A B Screw,hex wshr hd, 8-15A x 0.500, wiring clamps
45* 5300141713 A B Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 218909901 A B Capacitor-run,220 VAC ,15 microfarad
* # 3916557 A B Hot Tube Repair Kit,Service
