Frigidaire FRT21PRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21PRHD2 FRT21PRH R134a almond 115
FRT21PRHW2 FRT21PRH R134a white 115
FRT21IPRHD2 FRT21IPRH R134a almond 115
FRT21IPRHW2 FRT21IPRH R134a white 115
MARKET
North America
Publication No.
5995325262
990629
-EN/SERVICE/KB
357
REFRIGERATOR
Model No.
FRT21PRH
FRT21IPRH
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 193832
OWNER’S GUIDE - # 218942600
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624

06/99 2
Publication No. FRT21PRH & FRT21IPRH
5995325262
DOOR

# = Fast-moving Parts 3 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
DOOR
A = FRT21PRH (FRT21PRHD2)
B = FRT21PRH (FRT21PRHW2)
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
1 215608903 A - C - Gasket-frzr door,almond ,magnetic
1 215608913 - B - D Gasket-frzr door,white ,magnetic
2 # 218730610 A - C - Gasket-refr door,almond ,magnetic
2 # 218730609 - B - D Gasket-refr door,white ,magnetic
3 215393201 A B C D Panel-inner door,refr
4 218763644 A B C D Rack-door,23.09" x 2.04"
4A 218763643 A B C D Rack-door,22.51" x 2.04"
4B 218763642 A B C D Rack-door,9.24" x 2.04"
5 218758601 A B C D Support-door rack,RH/LH
5A 218809701 A B C D Support-door rack,LH
5B 218809801 A B C D Support-door rack,RH
7 5303304569 A B C D Door-dairy,12.96" wide
8 218763645 A B C D Rack-door,23.47" x 2.04" ,(2)
9 215530301 A B C D Panel-inner door,frzr
10 5303001308 A - C - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D Plug-button,white ,hinge brg hole
11 5303917827 A - C - Panel-frzr door,almond ,w/insulation
11 5303917826 - B - D Panel-frzr door,white ,w/insulation
12 218917602 A - C - Label-nameplate,almond
12 218917601 - B - D Label-nameplate,white
13 218800300 A B C D Door Stop,plated
13A 218249002 A - C - Door Stop,almond ,frzr section
13A 218249001 - B - D Door Stop,white ,frzr section
14 218915702 A - C - Plug-button,almond
14 218915701 - B - D Plug-button,white
14A 215352211 A - C - Plug-button,almond ,handle mtg, refr door front
14A 215352201 - B - D Plug-button,white ,handle mtg, refr door front
14B 218074002 A - C - Plug-button,almond ,refr door front, lower
14B 218074001 - B - D Plug-button,white ,refr door front, lower
15 5303917829 A - C - Panel-refr door,almond ,w/insul & brace
15 5303917828 - B - D Panel-refr door,white ,w/insul & brace
18 218668002 A - C - Handle-door,almond
18 218668001 - B - D Handle-door,white
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D Bearing-hinge
37 218811622 A - C - Trim-handle,almond ,upper, w/band & snap-on lock
37 218811621 - B - D Trim-handle,white ,upper ,w/chrome band
37A 218811614 A - C - Trim-handle,almond ,lower, w/band & snap-on lock
37A 218811613 - B - D Trim-handle,white ,lower ,w/chrome band
37A* 215782300 A B C D Lock-handle trim,snap-in
37A* 218906701 A B C D Lock-handle trim,stick-on
58 218781100 A B C D Screw,pan head ,8-18 x 0.625
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

06/99 4
Publication No. FRT21PRH & FRT21IPRH
5995325262
CABINET

# = Fast-moving Parts 5 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
CABINET
A = FRT21PRH (FRT21PRHD2)
B = FRT21PRH (FRT21PRHW2)
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
1 5304402655 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 218802800 A B C D Cover-evap coil
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B - - Plug-harness hole,round
12 215079100 A B - - Plug-wtr inlet tube,round
13 218895003 A B C D Motor-evap fan
14 5303322992 A B C D Bracket-motor mtg,rear
17 5303001470 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
20 5303001286 A B C D Ferrule-inner
21 5303001287 A B C D Ferrule-outer
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303210377 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D • Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
26 218605102 A - C - Base-cabinet,almond
26 218605101 - B - D Base-cabinet,white
27 5303212922 A B C D Screw-leveling
28 5303271412 A B C D Bolt-roller adj,hex hd sems, 1/4-28 x 2.750,(2)
29 218666700 A B C D Washer,.28 x .62 x .03 ,nylon
29* 218875801 A B C D Washer,nylon ,0.245 ID w/nibs
29* 5308011326 A B C D Washer,.34 x .62 x .02 ,nylon
30 218220202 A B C D Bracket-lower hinge,zinc chromate
30* 218605200 A B C D Tapping Plate/Gusset,RH
30* 218605300 A B C D Tapping Plate/Gusset,LH
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light grey
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,LH
43 218703001 A B C D Roller Assy,front ,(2)
44 218713600 A B C D Roller Assy,rear ,(2)
45 218754500 A B C D Screw,hex hd ser wshr ,8-18 x 0.375
46 5308009762 A B C D Bolt-roller mtg,hex wshr hd, 1/4-28 x 0.500,(2)
47 218233300 A B C D Channel-shelf mtg,side ,(2)
48 5303292395 A B C D Channel-shelf mtg,center
49 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
56 218220300 A B C D Pin-lower hinge
58 5303001343 A B C D Screw,hex wshr hd ,8-15A x 0.500 ,spec
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625, hinge/mull, thrd forming
71 218896704 A B C D Fastener-grille,clip ,(2)
72 218916405 A - C - Grille/Kickplate,almond ,w/fasteners
72 218916404 - B - D Grille/Kickplate,white ,w/fasteners
78 5303274237 A B C D Screw-bracket,hex wshr hd, 8-32CA x 0.500

06/99 6
Publication No. FRT21PRH & FRT21IPRH
5995325262
CABINET

# = Fast-moving Parts 7 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
CABINET
A = FRT21PRH (FRT21PRHD2)
B = FRT21PRH (FRT21PRHW2)
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625, low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - C - Plug-button,almond
98 215099701 - B - D Plug-button,white
100 5303288973 A B C D Support-pan cover
110 215363501 A B C D Support-crisper rod
116 215426703 A B C D Rod-crisper support
* 218905701 A B C D Cover-sound insul,pressboard/foam ,machine compt
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white
* 5308016571 A B - - Plug-button,cab liner holes

06/99 8
Publication No. FRT21PRH & FRT21IPRH
5995325262
SHELVES

# = Fast-moving Parts 9 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
SHELVES
A = FRT21PRH (FRT21PRHD2)
B = FRT21PRH (FRT21PRHW2)
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
1 218651901 A - C - Mullion,almond
1 218651900 - B - D Mullion,white
5 # 218781002 A B C D Heater-mullion
6 218845602 A B C D Tapping Plate,mullion mtg ,(2)
7 218866101 A B C D Top Panel-refr
8 218909702 A B C D Divider,styrofoam ,w/foil tape
8* 218878600 A B C D Harness-wiring,control/divider
9 218865900 A B C D Bottom Panel-frzr
10 215667501 A B - - Tray-ice,plastic
11 5303288243 A B C D Shelf-freezer,fixed/flat ,full width, wire
11* 5303299664 A B C D Spacer-shelf
12 218730000 A B C D Deflector-air
13 218631001 A B C D Cover-air deflector
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A 218906801 A B C D Socket-light/lamp
17 5303321455 A B C D Control Box
17* 5308016567 A B C D Nut-anchor
18 5303311079 A B C D Knob-temp control
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 # 5304403736 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C D Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B C D Tube,PVC ,white ,@ air deflector, insulator
23 # 215846606 A B C D Timer-defrost
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
24 215919117 A B C D Frame-full shelf,cantilever
25 215363203 A B C D Cover-crisper pan,less insert
25A 5304412423 A B C D Trim-crisper cover
25B 5303301393 A B C D Control-humidity
26 215363301 A B C D Pan-crisper,tilt-out
28 3201150 A B C D End Cap-shelf,protector ,frzr shelf
29 215919405 A B C D Trim-glass shelf,26.80" ,front
31 215742602 A B C D Pan-meat
34 5303212918 A B C D Container-ice
36 215919115 A B C D Frame-half shelf,cantilever
36A 215919121 A B C D Frame-pan mtg shelf,cantilever, half width,w/hanger tabs
37 215919411 A B C D Trim-half shelf,front
40 218498176 A B C D Glass-shelf,26.76" x 14.57"
41 215919805 A B C D Trim-glass shelf,26.80" ,rear
42 5304404462 A B C D Hanger-pan/tray,LH
42 5304404463 A B C D Hanger-pan/tray,RH
43 218498175 A B C D Glass-shelf,13.03" x 14.57"
44 215919811 A B C D Trim-glass shelf,13.07" ,rear
46 215363406 A B C D Front-crisper pan
47 218498178 A B C D Insert-pan cover,glass
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625, hinge/mull, thrd forming
61 215781501 A B - - Shelf-ice tray,wire
67 5303307363 A B C D Front-meat pan
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625, low profile
123 215005100 A B C D Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in
* 3205266 A B C D Edge Protector,wiring harness

06/99 10
Publication No. FRT21PRH & FRT21IPRH
5995325262
SYSTEM

# = Fast-moving Parts 11 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
SYSTEM
A = FRT21PRH (FRT21PRHD2)
B = FRT21PRH (FRT21PRHW2)
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C D Condenser
1* 5304406039 A B C D Spacer-tube,5/8 OD x 3" lg
1* 5304406040 A B C D Spacer-tube,5/8 OD x 12" lg
1* 5304406721 A B C D Spacer-cond tube,round ,5/8 OD x .81"lg
1* 5304406722 A B C D Spacer-tube,5/8 OD x 2" lg
2 5308000296 A B C D Bracket,condenser mtg ,(4)
4 # 218541000 A B C D Drier-filter,R134a System
5 218878600 A B C D Harness-wiring,control/divider
6 215257001 A B C D Harness-wiring,compressor
7 # 5316254901 A B C D Cord-electric power
8 5303001197 A B C D Cover-wiring
13 # 215076405 A B C D Heat Exchanger,suction line
14 # 5317842502 A B C D Heater-defrost
15 # 218765400 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5316651102 A B C D Insulator-evap,plastic
18 218773700 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 5308017227 A B C D Insulation Block,LH
21 # 5316269001 A B C D Thermostat-defrost
22 5308013663 A B C D Plate-compr mtg
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
26* 5308017610 A B C D Sound Tape,defrost pan
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 218374515 A B C D Compressor,R134a ,w/o electricals
30 # 218721101 A B C D Starter/Overload Assy
32 218740800 A B C D Wire-bale
41 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500, serrated head
43 5303001199 A B C D Clamp-wiring harness,strain relief, galv steel
44 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 218754500 A B C D Screw,hex hd ser wshr ,8-18 x 0.375
45* 5300141713 A B C D Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
* 218750100 A B C D Cover-sound insul,pressboard/foam, machine compt
* # 5300189383 A B C D Hot Tube Repair Kit,Service

06/99 12
Publication No. FRT21IPRH
5995323325
ICE MAKER

# = Fast-moving Parts 13 06/99
* = Non-Illustrated Parts
FRT21IPRH Publication No.
5995323325
ICE MAKER
C = FRT21IPRH (FRT21IPRHD2)
D = FRT21IPRH (FRT21IPRHW2)
POS. NO PART NO DESCRIPTION
1 5303015131 - - C D Tube-water,71" ,valve-to-IM
1* 5314368805 - - C D Tube-valve to IM,plastic ,cut to length
2 3206348 - - C D Spring,shut-off arm
3 3206299 - - C D Plate-I.D.
4 3206301 - - C D Gear
5 3206303 - - C D Plate-mounting
6 3206305 - - C D Screw-ground wire,8-32 x 1/4
7 # 3206306 - - C D Motor-ice maker
8 3206312 - - C D Spacer-holding sw
9 3206313 - - C D Cam
10 3206315 - - C D Clamp
11 # 3206319 - - C D Thermal Cutoff,icemaker ,complete assy
12 # 3206349 - - C D Harness-wiring,IM internal ,with plug
12 3206321 - - C D • Connector Plug,wiring harness
13 # 3206322 - - C D Thermostat Assy,ice maker
14 3206323 - - C D Screw-switch mtg,4-24 x 3/4 , sw to support,(2)
15 # 3206324 - - C D Switch,(3)
16 3206326 - - C D Support
17 # 5303320545 - - C D Mold-ice maker,radius cube ,with heater
18 3206328 - - C D Ejector
19 3206330 - - C D Bearing & Inlet
20 3206331 - - C D Screw,8-18 x 0.375 ,(2)
21 3206332 - - C D Ice Stripper
22 3206333 - - C D Arm,shut-off
23 3206334 - - C D Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 - - C D Lever-arm
25 3206336 - - C D Screw-arm levr/sprt,8-18 x 9/16
26 3206337 - - C D Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 - - C D Screw-sw&spcr/plate,4-40 x 1
28 3206339 - - C D Screw-timing stop,4-40 x 3/8
29 3206340 - - C D Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 - - C D Screw-timing,8-32 x 1
31 3206342 - - C D Insulator
32 3206343 - - C D Plate-valve switch
33 3206344 - - C D Spring
34 3206345 - - C D Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 - - C D Screw-gear/cam,6-20 x 0.437
36 3206347 - - C D Cover-ice maker,complete
37 5303320544 - - C D Data Sheet,ice maker
38 5303207445 - - C D Envelope-data sheet
39 # 3206358 - - C D Harness-wiring,ice maker
40 5305877995 - - C D Sealing Strip
41 5308000039 - - C D Screw,hex wshr hd ,8-32CA x 0.500, serrated head
43 5303001199 - - C D Clamp-wiring harness,strain relief, galv steel
44 5308000133 - - C D Clamp,nylon ,.75 OD tube
45 5303001343 - - C D Screw,hex wshr hd ,8-15A x 0.500 ,spec
46 5303001193 - - C D Clamp-inlet tube,metal
47 3206360 - - C D Adapter-water sply
48 5308000200 - - C D Nut,7/16 x 20 ,nylon
49 5303001147 - - C D Plug-harness hole,(2)
52 218462000 - - C D Tube-water inlet
55 # 218720300 - - C D Valve-water,120 V 60 Hz, flow restricter
55* 5303015102 - - C D Cap-water valve
59 5303001191 - - C D Sleeve-tube insert
60 218362500 - - C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 - - C D Bracket-leveling,ice maker
62 218737900 - - C D Screw-IM brkt mtg,hex hd ,8-32 x 0.375
64 5303001549 - - C D Clamp-copper tube,steel
* 218699501 - - C D Icemaker,radius cube ,no instl parts
* 08000185 - - C D Tape,foam ,adhesive

06/99 14
Publication No. FRT21PRH & FRT21IPRH
5995325262
WIRING SCHEMATIC

# = Fast-moving Parts 15 06/99
* = Non-Illustrated Parts
FRT21PRH & FRT21IPRH Publication No.
5995325262
WIRING DIAGRAM
W193832
