Frigidaire FRT18TRC User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18TRCD7 FRT18TRC R134a System almond 115
FRT18TRCW7 FRT18TRC R134a System white 115
MARKET
North America
Publication No.
5995317921
990205
-EN/SERVICE /ECL
390
REFRIGERATOR
Model No.
FRT18TRC
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218613700
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

02/99 2
Publication No. FRT18TRC
5995317921
DOOR

# = Fast-moving Parts 3 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
DOOR
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 # 215608916 A - Gasket-frzr door,white ,magnetic
1 # 215608906 - B Gasket-frzr door,almond ,magnetic
2 # 218730605 A - Gasket-refr door,white ,magnetic
2 # 218730606 - B Gasket-refr door,almond ,magnetic
3 218360001 A B Panel-inner door,refr
4 218763614 A B Rack-door,(2)
5 218809701 A B Support-door rack,LH
5 218809801 A B Support-door rack,RH
5A 218758601 A B Support-door rack,RH/LH
7 218287906 A B Door-dairy,10.71" wide
8 218763613 A B Rack-door
9 218360101 A B Panel-inner door,frzr
10 5308000134 A - Plug-button,white ,hinge brg hole
10 5303001308 - B Plug-button,almond ,hinge brg hole
11 5303917805 A - Panel-frzr door,white ,w/insulation
11 5303917807 - B Panel-frzr door,almond ,w/insulation
12 218425004 A - Nameplate Assy,white
12 218425005 - B Nameplate Assy,almond
12* 215008607 A - Label-nameplate,white
12* 215008608 - B Label-nameplate,almond
12* 218364001 A - Frame-nameplate,white
12* 218364002 - B Frame-nameplate,almond
12* 5315340712 A B Tape,adhesive ,12" long ,foam ,double-faced
12* 215518000 A B Magnet-nameplate
13 218800300 A B Door Stop,plated
13A 218249001 A - Door Stop,white ,frzr section
13A 218249002 - B Door Stop,almond ,frzr section
14 5308000090 A - Plug-button,white
14 5308000181 - B Plug-button,almond
14A 218110901 A - Plug-button,white ,refr door front ,upper
14A 218110902 - B Plug-button,almond ,refr door front ,upper
15 5303917806 A - Panel-refr door,white ,w/insul & brace
15 5303917808 - B Panel-refr door,almond ,w/insul & brace
18 218668001 A - Handle-door,white
18 218668002 - B Handle-door,almond
21A 218251900 A B Screw,#8 oval hd ,10-32CA x .625 ,cross recess
21C 218252200 A B Screw,#8 truss hd ,10-32CA x .5
22 218519300 A B Bearing-hinge
37A 215870619 A - Trim-handle,2.47" ,white ,w/chrome band
37A 215870620 - B Trim-handle,2.47" ,almond ,w/chrome band
58 218699800 A B Screw,truss head ,8-15A x 0.500
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

02/99 4
Publication No. FRT18TRC
5995317921
CABINET

# = Fast-moving Parts 5 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
CABINET
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
6 218448301 A - Cover,white ,lwr hinge hole
6 218448302 - B Cover,almond ,lwr hinge hole
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 3206451 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
13 # 218878701 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218725700 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774901 A - Plug-button,white ,upr hinge holes
22 215774911 - B Plug-button,almond ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
29* 5308011326 A B Washer,.34 x .62 x .02 ,nylon
30 5304409595 A B Bracket-lower hinge
30* 215882300 A B Tapping Plate,lower hinge ,(2)
30* 218368500 A B Shim-lower hinge
32 215217701 A - Plug-button,white ,cabinet base ,(2)
32 215217703 - B Plug-button,almond ,cabinet base ,(2)
35 218220101 A - Bracket-ctr hinge,light grey
35 218220102 - B Bracket-ctr hinge,almond
36 218251300 A B Pin-center hinge
37 5303321081 A - Trim-cabinet corner,white
37 5303321082 - B Trim-cabinet corner,almond
38 3206100 A B Bracket-upper hinge
39 5303001037 A B Shim-upper hinge
40 3206101 A - Cover-upper hinge,white
40 3206105 - B Cover-upper hinge,almond
41 5303001609 A B Grommet,shelf/rod mtg ,RH
41* 5308009759 A B Grommet,shelf mtg ,LH
42 215880100 A B Screw-hinge mtg,hex wshr hd ,1/4-20 x 0.685,(2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B Roller
43* 5308000186 A B Washer,.34 x .62 x .10 ,nylon
43* 5308009761 A B Bolt-roller adj
43* 5308009790 A B Spring-roller adj
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 215507300 A B Screw,hex washer head ,8-18AB x 1-1/2
56 218220300 A B Pin-lower hinge
58 5308002748 A B Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd form
78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875 ,(6)
98 215099701 A - Plug-button,white ,ctr hinge hole
98 215099711 - B Plug-button,almond ,ctr hinge hole
* 5303305324 A - Paint,touch-up ,white
* 5303305325 - B Paint,touch-up ,almond

02/99 6
Publication No. FRT18TRC
5995317921
SHELVES

# = Fast-moving Parts 7 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
SHELVES
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 218874301 A - Mullion,white ,1
1 218874311 - B Mullion,almond ,1
5 # 218781003 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Panel-top,refr cavity
7* 5303001380 A B Screw,truss head ,8-10 x 1.625
8 218872903 A B Divider,styrofoam ,w/foil tape
8* 218878500 A B Harness-wiring,control/divider
9 218814700 A B Panel-bottom,frzr cavity
11 5303288242 A B Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A 218906801 A B Socket-light/lamp
17 5303321455 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5303321453 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B Tube,PVC ,white ,@ air deflector ,insulator
23 # 215267800 A B Timer-defrost
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438
24 215919161 A B Frame-full shelf,cantilever
25 5303207340 A B Cover-crisper pan,with beam ,less insert
26 3206438 A B Pan-crisper
28 3201150 A B End Cap-shelf,protector ,frzr shelf
29 218830303 A B Trim-glass shelf,24.92" ,front
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 215919160 A B Frame-half shelf,cantilever
37 218830309 A B Trim-glass shelf,12.13" ,front
40 218390520 A B Glass-shelf,24.88" x 14.57"
41 215919803 A B Trim-glass shelf,24.92" ,rear
42 5304404462 A B Hanger-pan/tray,LH
42 5304404463 A B Hanger-pan/tray,RH
43 218390517 A B Glass-shelf,12.09" x 14.57"
44 215919809 A B Trim-glass shelf,12.13" ,rear
46 215357606 A B Front-crisper pan
47 218390516 A B Insert-pan cover,glass
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd form
67 215357809 A B Front-meat pan
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 A B Screw-roller/hanger,8-10 x .438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in
* 3205266 A B Edge Protector,wiring harness

02/99 8
Publication No. FRT18TRC
5995317921
SYSTEM

# = Fast-moving Parts 9 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
SYSTEM
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10
4 # 218541000 A B Drier-filter
5 # 218878500 A B Harness-wiring,control/divider
6 # 215257004 A B Harness-wiring,compressor
7 # 5316254901 A B Cord-electric power
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 3206452 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 5303207493 A B Insulator-evap,plastic
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 5316269001 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
22* 3051070 A B Screw 10-24 X 7/16,hex wshr hd ,10-24 x 7/16,
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
26* 5308017610 A B Sound Tape,defrost pan
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846902 A B Compressor,R134a ,w/o electricals
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Wire-bale
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 218843800 A B Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45* 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5300141713 A B Screw,hex wshr hd ,8-32 x .625 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
55 # 216236200 A B Capacitor-run
* # 3916557 A B Hot Tube Repair Kit,Service

02/99 10
Publication No. FRT18TRC
5995317921
ICE MAKER

# = Fast-moving Parts 11 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
ICE MAKER
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 5303015131 A B Tube-water inlet,71" ,valve-to-IM
1* 3206276 A B Tube-valve to IM,plastic
2 3206348 A B Spring,shut-off arm
3 3206299 A B Plate-I.D.
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 1/4
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-holding sw
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff,icemaker ,complete assy
12 3206321 A B Connector Plug,wiring harness
12 # 3206349 A B Harness-wiring,IM internal ,with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 3206323 A B Screw-switch mtg,4-24 x 3/4 ,sw to support,(2)
15 # 3206324 A B Switch,(3)
16 3206326 A B Support
17 # 5303320545 A B Mold-ice maker,radius cube ,with heater
18 3206328 A B Ejector
19 3206330 A B Bearing & Inlet
20 3206331 A B Screw,8-18 x 3/8 ,(2)
21 3206332 A B Ice Stripper
22 3206333 A B Arm,shut-off
23 3206334 A B Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 A B Lever-arm
25 3206336 A B Screw-arm levr/sprt,8-18 x 9/16
26 3206337 A B Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 A B Screw-sw&spcr/plate,4-40 x 1
28 3206339 A B Screw-timing stop,4-40 x 3/8
29 3206340 A B Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 A B Screw-timing,8-32 x 1
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 3206344 A B Spring
34 3206345 A B Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 A B Screw-gear/cam,6-20 x 0.437
36 3206347 A B Cover-ice maker,complete
37 5303320544 A B Data Sheet,ice maker
38 5303207445 A B Envelope-data sheet
39 # 3206358 A B Harness-wiring,ice maker
40 5305877995 A B Sealing Strip
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 218843800 A B Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
46 5303001193 A B Clamp-inlet tube,metal
47 5308000205 A B Adapter-water sply,straight
48 5308000200 A B Nut,7/16 x 20 ,nylon
49 5303001147 A B Plug-harness hole,(2)
52 215456100 A B Tube-water inlet
55 # 218720300 A B Valve-water,120 V 60 Hz ,flow restricter
55* 5303015102 A B Cap-water valve
59 5303001191 A B Sleeve-tube insert
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
61 218721500 A B Bracket-leveling,ice maker
62 215230500 A B Screw-bracket mtg,pan head ,8-32T x 0.375
62 218737900 A B Screw-IM mtg brkt,hex hd ,#8-32 x 3/8
64 5303001549 A B Clamp-copper tube,steel
* 5303212918 A B Container-ice
