Frigidaire FRT18KS5A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18KS5AQ4 FRT18KS5A R134a bisque 115
FRT18KS5AW4 FRT18KS5A R134a white 115
PRODUCT NO. MARKET INSTL INSTR ICE MAKER
FRT18KS5AQ4 USA 240379102 IM115
FRT18KS5AW4 USA 240379102 IM115
Publication No.
5995360079
011018
-EN/SERVICE /DJH
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KS5A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - 240379007
OWNER’S GUIDE - # 240400103
SERVICE DATA SHEET - 240379007

10/01 2
Publication No. FRT18KS5A
5995360079
DOOR

# = Fast-moving Parts 3 10/01
* = Non-Illustrated Parts
FRT18KS5A Publication No.
5995360079
A = FRT18KS5A (FRT18KS5AQ4)
B = FRT18KS5A (FRT18KS5AW4)
POS. NO PART NO DESCRIPTION
1 # 240370905 A B Gasket-frzr door,white ,magnetic
2 # 240370906 A B Gasket-refr door,white ,magnetic
7 240337703 A B Door-dairy,w/o graphics ,clear
10 240381302 A - Plug-button,hinge brg hole ,bisque ,(2)
10 240381301 - B Plug-button,hinge brg hole ,white ,(2)
11 240409902 A - Panel-frzr door,bisque ,complete assy
11 240409901 - B Panel-frzr door,white ,complete assy
12 240415203 A - Label-nameplate,bisque
12 240415201 - B Label-nameplate,white
13 240312407 A - Door Stop,bisque ,ref
13 240312403 - B Door Stop,white ,ref
13A 240312408 A - Door Stop,bisque ,frzr
13A 240312404 - B Door Stop,white ,frzr
14 218915704 A - Plug-button,bisque
14 218915701 - B Plug-button,white
18 218668004 A - Handle-door,bisque
18 218668001 - B Handle-door,white
21 240383401 A B Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A B Bearing-hinge,natural color ,(8)
37 215870633 A - Trim-handle,2.47" ,bisque ,w/satin AL band
37 215870629 - B Trim-handle,2.47" ,white ,w/satin AL band
37* 218676004 A B Band-decorative,satin aluminum ,handle trim
48 240338101 A B Bin-door,Pseudo ,bottom
48A 240337901 A B Bin-door,ref
48B 240338001 A B Bin-door,Pseudo ,gallon ,refr
49 240337801 A B Bin-door,Pseudo ,frzr
96 240345503 A B Plug-foam hole,white
DOOR

10/01 4
Publication No. FRT18KS5A
5995360079
CABINET

# = Fast-moving Parts 5 10/01
* = Non-Illustrated Parts
FRT18KS5A Publication No.
5995360079
A = FRT18KS5A (FRT18KS5AQ4)
B = FRT18KS5A (FRT18KS5AW4)
POS. NO PART NO DESCRIPTION
1 240355401 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 240367401 A B Damper-fan cover
5 # 5308000010 A B Fan Blade,red ,evaporator fan
6* # 240385301 A B Wiring Harness,freezer section
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240462005 A B Cover-evap coil
10* 240371302 A B Seal-coil cover
10*# 240385401 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
12 240366801 A B Plug-ice maker harness,rectangular
12A 240374401 A B Plug-wtr inlet tube,round ,1"
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring,nylon ,w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw-8-18 x 3/8,hex washer head ,8-18 x 0.375
18 240345801 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774919 A - Plug-button,bisque ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special
30 240314001 A B Bracket-lower hinge,zinc
30 240314004 A - Bracket-lower hinge,bisque
30 240314002 - B Bracket-lower hinge,white
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313804 A - Bracket-ctr hinge,bisque
35 240313802 - B Bracket-ctr hinge,white
35A 240336801 A B Spacer-hinge,center
36 240313901 A B Pin-center hinge
37 240337604 A - Trim-cabinet corner,bisque ,(2)
37 240337601 - B Trim-cabinet corner,white ,(2)
38 240313701 A B Bracket-upper hinge
40 240354403 A - Cover-upper hinge,bisque
40 240354401 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240423601 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
56 240314101 A B Pin-lower hinge
58 5308002748 A B Screw,hex wshr hd ,8-15A x 0.500 ,special
59 240442704 A - Screw-#10-32 X 3/4,bisque
59 240442702 - B Screw-#10-32 X 3/4,white
72 240368202 A - Grille/Kickplate,bisque
72 240368201 - B Grille/Kickplate,white
81 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
89 240326102 A B Cover-access,w/ label
89* 241500301 A B Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 240479601 A B Plug,button ,cab liner holes
* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500
* 5304414035 A - Paint,touch-up ,bisque
* 5303305324 - B Paint,touch-up ,white
CABINET

10/01 6
Publication No. FRT18KS5A
5995360079
SHELVES

# = Fast-moving Parts 7 10/01
* = Non-Illustrated Parts
FRT18KS5A Publication No.
5995360079
A = FRT18KS5A (FRT18KS5AQ4)
B = FRT18KS5A (FRT18KS5AW4)
POS. NO PART NO DESCRIPTION
10 215667501 A B Tray-ice,plastic
11 240358002 A B Shelf-freezer,full width
11* 5303299664 A B Spacer-shelf
12 240362502 A B Diffuser-air,top
13 240362601 A B Diffuser-air,bottom
13* 240392601 A B Seal-diffuser
14 # 240505801 A B Switch-light/lamp
15 240436701 A B Light Bulb/Lamp,A-15 ,40 W ,120 V ,miniature
16 241500701 A B Socket-light/lamp
17 240352701 A B Control Box
17* 5308016567 A B Nut-anchor
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob-control
21 # 5304421256 A B Control-temperature
22A 240468201 A B Tube,sensor sleeve ,31 inch ,plastic ,white
22B 218731105 A B Tube,PVC ,white ,@ air diffuser ,insulator
23 # 215846606 A B Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 240358905 A B Shelf-"Spill-Safe",sliding
24A 240358906 A B Shelf-"Spill-Safe",sliding
25 240364714 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper-humidity control
26 240337103 A B Pan-crisper,clear ,(2) ,no graphics
28 3201150 A B End Cap,freezer shelf ,protector
31 240354203 A B Pan-meat,w/o graphics ,clear
47 240350643 A B Insert-pan cover,glass
58 5308016566 A B Screw,hex washer head ,8-15A x 0.625 low profile
SHELVES

10/01 8
Publication No. FRT18KS5A
5995360079
SYSTEM

# = Fast-moving Parts 9 10/01
* = Non-Illustrated Parts
FRT18KS5A Publication No.
5995360079
A = FRT18KS5A (FRT18KS5AQ4)
B = FRT18KS5A (FRT18KS5AW4)
POS. NO PART NO DESCRIPTION
1 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240375301 A B Wiring Harness,machine comp, w/ service cord
6* # 240388701 A B Wiring Harness,control box
6 *# 240385401 A B Wiring Harness,freezer section
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918250 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation Block,RH
20 240362401 A B Insulation Block,LH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330001 A B Plate-compr mtg
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Scr-compr mtg,hex washer hd 1/4-28 x 1.16
26 240332603 A B Pan-defrost drain
29 5303918249 A B Compressor,w/electricals
30 218721113 A B Starter-PTC
32 218740800 A B Clamp,elec cont mtg ,compressor
34 240405201 A B Grommet,mounting ,rubber ,black ,holds tube/wire
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
41* 5308000039 A B Scr,hex washer hd ,8-32CA x 0.500 ,
44 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
45 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
55* 218897002 A B Screw,hex washer head ,8-32 x 0.375
57 240403601 A B Clip-wiring harness
58 240453400 A B Screw-cond fan mtr,hx serr wshr hd ,
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240453600 A B Motor,condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 240453300 A B Nut,speed
61B 240453500 A B Grommet-silencer
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,
84 240359601 A B Tube-drain,lower
85 240346201 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500
* # 5303918222 A B Hot Tube Repair Kit,Service
* # 5303918207 A B Heat Exchanger Kit,suction line
SYSTEM

10/01 10
Publication No. FRT18KS5A
5995360079
WIRING SCHEMATIC

# = Fast-moving Parts 11 10/01
* = Non-Illustrated Parts
FRT18KS5A Publication No.
5995360079
WIRING DIAGRAM
