Frigidaire FRT18PRG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18PRGD1 FRT18PRG R134a System almond 115
FRT18PRGW1 FRT18PRG R134a System white 115
MARKET
North American
Publication No.
5995316923
990113
-EN/SERVICE/KB
390
REFRIGERATOR
Model No.
FRT18PRG
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - 218758400
OWNER’S GUIDE - 218613700
SERVICE DATA SHEET - 218758400
101 Masters Blvd.
Anderson, SC 29624

01/99 2
Publication No. FRT18PRG
5995316923
DOOR

# = Fast-moving Parts 3 01/99
* = Non-Illustrated Parts
FRT18PRG Publication No.
5995316923
DOOR
A = FRT18PRG (FRT18PRGD1)
B = FRT18PRG (FRT18PRGW1)
POS. NO PART NO DESCRIPTION
1 # 215608906 A - Gasket-frzr door,almond ,magnetic
1 # 215608916 - B Gasket-frzr door,white ,magnetic
2 # 218730606 A - Gasket-refr door,almond ,magnetic
2 # 218730605 - B Gasket-refr door,white ,magnetic
3 218360701 A B Panel-inner door,refr
5A 218758602 A B Support-door rack,RH/LH
7 5303308341 A B Door-dairy,12.96" wide
8 218763613 A B Rack-door
9 218360101 A B Panel-inner door,frzr
10 5303001308 A - Plug-button,almond ,hinge brg hole
10 5308000134 - B Plug-button,white ,hinge brg hole
11 5303917796 A - Panel-frzr door,almond ,with insulation
11 5303917795 - B Panel-frzr door,white ,with insulation
12 218425005 A - Nameplate Assy,almond
12 218425004 - B Nameplate Assy,white
12* 215008608 A - Label-nameplate,almond
12* 215008607 - B Label-nameplate,white
12* 215518000 A B Magnet-nameplate
12* 218364002 A - Frame-nameplate,almond
12* 218364001 - B Frame-nameplate,white
13 218800300 A B Door Stop,plated
13A 218249002 A - Door Stop,almond ,frzr section
13A 218249001 - B Door Stop,white ,frzr section
14 218915702 A - Plug-button,almond
14 218915701 - B Plug-button,white
14A 218110902 A - Plug-button,almond ,refr door front, upper
14A 218110901 - B Plug-button,white ,refr door front, upper
14B 218074002 A - Plug-button,almond ,refr door front, lower
14B 218074001 - B Plug-button,white ,refr door front, lower
15 5303917798 A - Panel-refr door,almond ,w/insul & brace
15 5303917797 - B Panel-refr door,white ,w/insul & brace
18 218668002 A - Handle-door,almond
18 218668001 - B Handle-door,white
21C 218252200 A B Screw,#8 truss hd ,10-32CA x .5
22 218519300 A B Bearing-hinge
37 215870620 A - Trim-handle,2.47" ,almond, w/chrome band
37 215870619 - B Trim-handle,2.47" ,white, w/chrome band
37* 218807701 A B Lock-handle trim,stick-on
37A 215867071 A - Trim-handle,29.84" ,almond, w/band & locks
37A 215867070 - B Trim-handle,29.84" ,white, w/band & locks
37A* 215782300 A B Lock-handle trim,snap-in
37A* 215940700 A B Lock-handle trim,stick-on
37A* 218676001 A B Band-decorative,chrome
48 215441811 A B Bin-door
49 215441513 A B Bin-door,gallon
58 218699800 A B Screw,truss head ,8-15A x 0.500
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

01/99 4
Publication No. FRT18PRG
5995316923
CABINET

# = Fast-moving Parts 5 01/99
* = Non-Illustrated Parts
FRT18PRG Publication No.
5995316923
CABINET
A = FRT18PRG (FRT18PRGD1)
B = FRT18PRG (FRT18PRGW1)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
6 218448302 A - Cover,almond ,lwr hinge hole
6 218448301 - B Cover,white ,lwr hinge hole
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 3206451 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 218878701 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218725700 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774911 A - Plug-button,almond ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
29* 5308000186 A B Washer,.34 x .62 x .10 ,nylon
30 5304409595 A B Bracket-lower hinge
30* 215882300 A B Tapping Plate,lower hinge ,(2)
32 215217703 A - Plug-button,almond ,cabinet base ,(2)
32 215217701 - B Plug-button,white ,cabinet base ,(2)
35 218220102 A - Bracket-ctr hinge,almond
35 218220101 - B Bracket-ctr hinge,light grey
36 218251300 A B Pin-center hinge
37 5303321082 A - Trim-cabinet corner,almond
37 5303321081 - B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
40 3206105 A - Cover-upper hinge,almond
40 3206101 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf/rod mtg ,RH
41* 5308009759 A B Grommet,shelf mtg ,LH
42 215880100 A B Screw-hinge mtg,hex washer head, 1/4-20 x 0.685,(2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B Roller
43* 5308009761 A B Bolt-roller adj
43* 5308009790 A B Spring-roller adj
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
56 218220300 A B Pin-lower hinge
59 218188000 A B Screw,pan hd ,10-32 x 0.625, hinge/mullion,thrd forming
78 5303274237 A B Screw-bracket,hex wshr hd, 8-32CA x 0.500
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625, low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875, (6)
98 215099711 A - Plug-button,almond ,ctr hinge hole
98 215099701 - B Plug-button,white ,ctr hinge hole
* 5303305325 A - Paint,touch-up ,almond
* 5303305324 - B Paint,touch-up ,white

01/99 6
Publication No. FRT18PRG
5995316923
SHELVES

# = Fast-moving Parts 7 01/99
* = Non-Illustrated Parts
FRT18PRG Publication No.
5995316923
SHELVES
A = FRT18PRG (FRT18PRGD1)
B = FRT18PRG (FRT18PRGW1)
POS. NO PART NO DESCRIPTION
1 218874311 A - Mullion,almond ,1
1 218874301 - B Mullion,white ,1
5 # 218781003 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Panel-top,refr cavity
7* 5303001380 A B Screw,truss head ,8-10 x 1.750
8 218872903 A B Divider,styrofoam ,w/foil tape
8* 218814600 A B Divider,styrofoam
8* # 218878500 A B Harness-wiring,control/divider
9 218814700 A B Panel-bottom,frzr cavity
10 215667501 A B Tray-ice,plastic
11 5303288242 A B Shelf-freezer,fixed/flat ,full width, wire
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A 218906801 A B Socket-light/lamp
17 5303321455 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5304404821 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B Tube,PVC ,white ,@ air deflector, insulator
23 # 215267800 A B Timer-defrost
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438
24 215919161 A B Frame-full shelf,cantilever
25 215686501 A B Cover-crisper pan,with beam
25A 218905802 A B Trim-crisper cover
25B 5303308340 A B Control-humidity
26 3206438 A B Pan-crisper
28 3201150 A B End Cap-shelf,protector, upper fzr shelf
29 218830303 A B Trim-glass shelf,24.92" ,front
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 215919160 A B Frame-half shelf,cantilever
37 218830309 A B Trim-glass shelf,12.13" ,front
40 218390520 A B Glass-shelf,24.88" x 14.57"
41 215919803 A B Trim-glass shelf,24.92" ,rear
42 5304404462 A B Hanger-pan/tray,LH
42 5304404463 A B Hanger-pan/tray,RH
43 218390517 A B Glass-shelf,12.09" x 14.57"
44 215919809 A B Trim-glass shelf,12.13" ,rear
46 215357606 A B Front-crisper pan
47 218390516 A B Insert-pan cover,glass
59 218188000 A B Screw,pan hd ,10-32 x 0.625, hinge/mullion,thrd forming
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
61 215781501 A B Shelf-ice tray,wire
67 215357809 A B Front-meat pan
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625, low profile
123 215005100 A B Screw-roller/hanger,8-10 x .438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in

01/99 8
Publication No. FRT18PRG
5995316923
SYSTEM

# = Fast-moving Parts 9 01/99
* = Non-Illustrated Parts
FRT18PRG Publication No.
5995316923
SYSTEMS
A = FRT18PRG (FRT18PRGD1)
B = FRT18PRG (FRT18PRGW1)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10
4 # 218541000 A B Drier-filter
5 # 218878500 A B Harness-wiring,control/divider
6 # 215257004 A B Harness-wiring,compressor
7 # 5316254901 A B Cord-electric power
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 3206452 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum
17 5303207493 A B Insulator-evap,plastic
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 5316269001 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846902 A B Compressor,R134a ,w/o electricals
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Wire-bale
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500, serrated head
43 5303001199 A B Clamp-wiring harness,strain relief, galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 218843800 A B Screw,hex wshr hd ,#8 14 x ½, wiring clamps
45 5300141713 A B Screw,hex wshr hd ,8-32 x .625 ,spec
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
55 # 216236200 A B Capacitor-run
* # 3916557 A B Hot Tube Repair Kit,Service
