Frigidaire FRT8G6F User manual

N05L00006.eps N05DAACKA1.eps N05BBAABA22.eps N05SAAAEF16.eps
N05CAAAAA18.eps 240398801.eps 240398601.eps
Product No. FRT8G6FQ0 FRT8G6FW0 FRT8G6FMB0
Series R134a R134a R134a
Color bisque white silvermist
Volts 115 115 115
Wiring Diagram 240398801 240398801 240398801
Owner's Guide 241694400 241694400 241694400
Market North America North America North America
Energy Guide 241613725 241613725 241613725
Service Data Sheet 240379018 240379018 240379018
Installation Instructions 240568301 240568301 240568301
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995462867
06/03/07
(EN/SERVICE/DCS)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT8G6F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995462867 FRT8G6F
03/06 2
DOOR
10
22
22
10
22
22
22
11
12
18
21
37
21
22
22
13A
13
21C
21C
21
37
18
22
1
7
2
N05DAACKA1
15
8
4
4
4B
14
14

FRT8G6F Publication No: 5995462867
# Functional Parts 3 03/06
* Non-Illustrated Parts
DOOR
Model Index: AFRT8G6F (FRT8G6FQ0)
BFRT8G6F (FRT8G6FW0)
CFRT8G6FM (FRT8G6FMB0)
POS. NO PART NO. DESCRIPTION
1 240542115 A B - Gasket-frzr door, white,magnetic
1 240542121 - - C Gasket-frzr door, black, magnetic
2 240542118 A B - Gasket-refr door, white, magnetic
2 240542124 - - C Gasket-refr door, black, magnetic
4 240534901 A B C Rack-door
4B 240534701 A B C Rack-door, 4B
7 240337703 A B C Door-dairy, w/o graphics, clear
8 240534801 A B C Rack-door
10 240381302 A - - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - B - Plug-button, white, hinge brg hole, (2)
10 240381306 - - C Plug-button, silver mist, hinge brg hole
11 240410202 A - - Door-frzr, bisque, complete assy
11 240410201 - B - Door-frzr, white, complete assy
11 240409921 - - C Door-frzr, silver mist, complete assy
12 240415203 A - - Label-nameplate, bisque
12 240415201 - B - Label-nameplate, white
12 240415204 - - C Label-nameplate, black
13 240312407 A - - Door Stop, bisque, ref
13 240312403 - B - Door Stop, white, ref
13 240312405 - - C Door Stop, black, refr
13A 240312408 A - - Door Stop, bisque, frzr
13A 240312404 - B - Door Stop, white, frzr
13A 240312406 - - C Door Stop, black, frzr
14 240494002 A - - Plug-button, bisque
14 240494001 - B - Plug-button, white
14 240494006 - - C Plug-button, silver mist
15 240410302 A - - Door-refr, bisque, complete assy
15 240410301 - B - Door-refr, white, complete assy
15 240410134 - - C Door-refr, silver mist, complete assy
18 218668004 A - - Handle-door, bisque
18 218668001 - B - Handle-door, white
18 218668003 - - C Handle-door, black
21 240383401 A B C Screw, truss hd quad, #10-16 x .500
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 A B - Bearing-hinge, natural color
22 240527102 - - C Bearing-hinge, black
37 215870633 A - - Trim-handle, 2.47", bisque, w/satin AL band
37 215870629 - B - Trim-handle, 2.47", white, w/satin AL band
37 215870636 - - C Trim-handle, 2.47", black, w/satin AL band
37* 218676004 A B C Band-decorative, satin aluminum, handle trim

Publication No: 5995462867 FRT8G6F
03/06 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA22
43 21C
41
41
41
8
8
9
14
81
34
22
21C
89
28

FRT8G6F Publication No: 5995462867
# Functional Parts 5 03/06
* Non-Illustrated Parts
CABINET
Model Index: AFRT8G6F (FRT8G6FQ0)
BFRT8G6F (FRT8G6FW0)
CFRT8G6FM (FRT8G6FMB0)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut, push-on
4 241523701 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade, red, evaporator fan
8 5300157666 A B C Bushing-motor mtg, (2)
9 5303292396 A B C Bracket-motor mtg, front
10 241652210 A B C Cover-evap coil
10* 240568601 A B C Seal-coil cover
10* 241520701 A B C Harness-wiring, freezer
11 5303208309 A B C Plug-hole, factory test
12 241557601 A B C Plug-ice maker harness, rectangular
12A 240374401 A B C Plug-wtr inlet tube, round, 1"
12A* 241586701 A B C Plug-foam-wtr-inlet, round
13 240369702 A B C Motor-evap fan
13* 215474201 A B C Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433202 A B C Screw, hex washer head, 8-18 x 5/16
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 215774919 A - - Plug-button, bisque, upr hinge holes
22 215774901 - B - Plug-button, white, upr hinge holes
22 215774918 - - C Plug-button, black, upr hinge holes
28 240335501 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314001 A B - Bracket-lower hinge, zinc
30 240314003 - - C Bracket-lower hinge, black
34 240311303 A B C Washer, hinge, nylon, (2)
35 240313801 A B - Bracket-ctr hinge, zinc
35 240313803 - - C Bracket-ctr hinge, black
35A 240336802 A B C Spacer-hinge, center
36 240516401 A B C Pin-center hinge
37 241611304 A - - Trim-cabinet corner, bisque, (2)
37 241611301 - B - Trim-cabinet corner, white, (2)
37 241611303 - - C Trim-cabinet corner, black, (2)
38 241622604 A - - Upper hinge, plastic, bisque
38 241622601 - B - Upper hinge, plastic, white
38 241622603 - - C Upper hinge, plastic, black
41 5308009759 A B C Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 A B C Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B C Roller Assy, adjustable, front, (2)
56 240516501 A B C Pin-lower hinge
58 5303001343 A B C Screw, hex washer head, 8-15A x 0.500
59 240442701 A B - Screw-#10-32 X 3/4, zinc
59 240442703 - - C Screw-#10-32 X 3/4, black
72 240368206 A - - Grille/Kickplate, bisque
72 240368205 - B - Grille/Kickplate, white
72 240368207 - - C Grille/Kickplate, black
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995462867 FRT8G6F
03/06 6
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA22
43 21C
41
41
41
8
8
9
14
81
34
22
21C
89
28

FRT8G6F Publication No: 5995462867
# Functional Parts 7 03/06
* Non-Illustrated Parts
CABINET
Model Index: AFRT8G6F (FRT8G6FQ0)
BFRT8G6F (FRT8G6FW0)
CFRT8G6FM (FRT8G6FMB0)
POS. NO PART NO. DESCRIPTION
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 A B C Cover-access, w/label
89* 241500302 A B C Screw, hex washer head, 8-18AB x 0.625
92 241624301 A B C Screw-hinge mtg, hex head, 1/4-20 x 1.00
* 240479601 A B C Plug, button, cab liner holes, (2)
* 5304414035 A - - Paint, touch-up, bisque
* 5303321319 - B - Paint, touch-up, white
* 5303321321 - - C Paint, touch-up, black

Publication No: 5995462867 FRT8G6F
03/06 8
SHELVES
25 47
26
26
N05SAAAEF16
23
21
22A
13
12
14
18
17
15
16
81
81
41
29
40
24A
42
31
42
123
41
29
40
24
10
10
11
25C

FRT8G6F Publication No: 5995462867
# Functional Parts 9 03/06
* Non-Illustrated Parts
SHELVES
Model Index: AFRT8G6F (FRT8G6FQ0)
BFRT8G6F (FRT8G6FW0)
CFRT8G6FM (FRT8G6FMB0)
POS. NO PART NO. DESCRIPTION
10 215667501 A B C Tray, ice cube, plastic
11 240358005 A B C Shelf, freezer, full-width, wire
12 241542001 A B C Diffuser, air, top
13 240362601 A B C Diffuser, air, bottom
14 241554901 A B C Switch-light/lamp
15 241555401 A B C Light Bulb
16 241559801 A B C Socket-light
17 240352701 A B C Control Box
17* 240568607 A B C Seal
17*# 240388701 A B C Wiring Harness, control box
18 240360801 A B C Knob, temp control
21 # 5304421256 A B C Control, temperature
22A 240468201 A B C Tube, sensor sleeve, 31 inch, plastic, white
23 241621501 A B C Timer-defrost
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240372409 A B C Frame, sliding shelf, full width
24A 240372410 A B C Frame, sliding shelf, full width, w/hanger tabs
25 240364713 A B C Cover-crisper pan, with beam, humid cont
25C 241613502 A B C Control-humidity, LH
26 240337107 A B C Pan-crisper, clear, (2), no graphics
29 240357704 A B C Trim-shelf, front
31 240530810 A B C Pan, meat bin
40 240350620 A B C Glass-shelf, 23.78" x 16.34"
41 240561502 A B C Trim-shelf, rear
42 240530601 A B C Track, meat pan hanger, LH
42 240530701 A B C Track, meat pan hanger, RH
47 240350608 A B C Insert-pan cover, 23.82" x 15.50", glass
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
123 215005100 A B C Screw, hanger/rlr mtg, 8-10 x 0.438

Publication No: 5995462867 FRT8G6F
03/06 10
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA18
22
23
23
30
32
85
55
4
6
29
26
84
45
57
25
25

FRT8G6F Publication No: 5995462867
# Functional Parts 11 03/06
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT8G6F (FRT8G6FQ0)
BFRT8G6F (FRT8G6FW0)
CFRT8G6FM (FRT8G6FMB0)
POS. NO PART NO. DESCRIPTION
1 # 241682901 A B C Condenser, dynamic
4 # 218944001 A B C Drier-filter, R134a System
6 # 241607001 A B C Harness-wiring, machine compt
6* 241520701 A B C Harness-wiring, freezer
6* # 240388701 A B C Wiring Harness, control box
14# 240356214 A B C Heater-defrost
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater, aluminum, (2)
17 241551801 A B C Trough-drain
20 241551901 A B C Insulation Block
21 # 5303918202 A B C Thermostat-defrost, kit
22 241665501 A B C Base-compressor
22* 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg, (4)
25 240491501 A B C Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332608 A B C Pan-defrost drain
29 # 5303918325 A B C Compressor, w/electricals
30 216954201 A B C Controller, compressor
32 216954300 A B C Clip, controller
34 240405201 A B C Grommet, rubber, black, cond tube/wire
41 240433202 A B C Screw, hex washer head, 8-18 x 5/16
44 5303001199 A B C Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
55 218909913 A B C Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B C Clip-wiring harness
58 218897002 A B C Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B C Bracket-cond motor assy
59* 240346701 A B C Tape-foam seal, shroud
59* 240359401 A B C Screw-fan shroud, (2)
60 # 240525402 A B C Motor, condensor fan
61 240524101 A B C Fan Blade, galv steel, condenser fan
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C Tube-drain, rubber, lower
85 241665801 A B C Tube-connector, suction
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* # 5303918263 A B C Heat Exchanger Kit, suction line
* 5303918222 A B C Hot Tube Repair Kit, service

Publication No: 5995462867 FRT8G6F
03/06 12
WIRING SCHEMATIC

FRT8G6F Publication No: 5995462867
# Functional Parts 13 03/06
* Non-Illustrated Parts
WIRING DIAGRAM
