Frigidaire FRT21C5A User manual

03/01 2
Publication No. FRT21C5A
5995351722
DOOR

# = Fast-moving Parts 3 03/01
* = Non-Illustrated Parts
FRT21C5A Publication No.
5995351722
A = FRT21C5A (FRT21C5AQ0)
B = FRT21C5A (FRT21C5AQ1)
C = FRT21C5A (FRT21C5AW0)
D = FRT21C5A (FRT21C5AW1)
POS. NO PART NO DESCRIPTION
1 # 240390702 A B C D Gasket-frzr door,white ,magnetic
2 # 240390701 A B C D Gasket-refr door,white ,magnetic
4 240331401 A B C D Rack-door,20.27" x 1.72"
5 240311502 A B C D Support-door rack,2 liter ,RH
5A 240331502 A B C D Support-door rack,gallon ,RH
6 240311501 A B C D Support-door rack,2 liter ,LH
6A 240331501 A B C D Support-door rack,gallon ,LH
7 240337703 A B C D Door-dairy,w/o graphics ,clear
8 240331402 A B C D Rack-door,17.99"
10 240381302 A B - - Plug-button,hinge brg hole ,bisque ,(2)
10 240381301 - - C D Plug-button,hinge brg hole ,white ,(2)
11 240450305 A B - - Panel-frzr door,bisque ,complete assy
11 240450301 - - C D Panel-frzr door,white
12 240415203 A B - - Label-nameplate,bisque
12 240415201 - - C D Label-nameplate,white
13 240312407 A B - - Door Stop,bisque ,ref
13 240312403 - - C D Door Stop,white ,ref
13A 240312408 A B - - Door Stop,bisque ,frzr
13A 240312404 - - C D Door Stop,white ,frzr
14 218915704 A B - - Plug-button,bisque
14 218915701 - - C D Plug-button,white
14A 240428302 A B - - Plug-button,screw type ,bisque
14A 240428301 - - C D Plug-button,screw type ,white
15 240450405 A B - - Panel-refr door,bisque ,complete assy
15 240450401 - - C D Panel-refr door,white ,complete assy
18A 218428119 A B - - Handle-door,bisque ,w/block & screw
18A 218428101 - - C D Handle-door,white ,w/block & screw
21 240383401 A B C D Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A B C D Bearing-hinge,natural color ,(8)
72 218397000 A B C D Button-handle mtg,dovetail
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500
96 240345501 A B C D Plug-foam hole,white
DOOR

03/01 4
Publication No. FRT21C5A
5995351722
CABINET

# = Fast-moving Parts 5 03/01
* = Non-Illustrated Parts
FRT21C5A Publication No.
5995351722
A = FRT21C5A (FRT21C5AQ0)
B = FRT21C5A (FRT21C5AQ1)
C = FRT21C5A (FRT21C5AW0)
D = FRT21C5A (FRT21C5AW1)
POS. NO PART NO DESCRIPTION
1 240355402 A B C D Cover-fan
2 240367001 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 240367401 A B C D Damper-fan cover
5 # 5308000010 A B C D Fan Blade,red ,evaporator fan
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
10 240313606 A B C D Cover-evap coil
10* 240371303 A B C D Seal-coil cover
10*# 240385401 A B C D Wiring Harness,freezer section
11 5303208309 A B C D Plug-hole,factory test
12 240366801 A B C D Plug-ice maker harness,rectangular
12A 240374401 A B C D Plug-wtr inlet tube,round ,1"
13 # 240369701 A B C D Motor-evap fan
13* 218931001 A B C D Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C D Bracket-motor mtg,rear
14* 240433201 A B C D Screw-8-18 x 3/8
18 240345801 A B C D Support-evap cover,(2)
21C 218252200 A B C D Screw, #8 truss hd, 10-32CA x 0.500
22 215774919 A B - - Plug-button, bisque, upr hinge holes
22 215774901 - - C D Plug-button, white, upr hinge holes
28 240335501 A B C D Bolt-roller adj, hex wshr hd, 1/4-20 x 4.020, (2), special
30 240314004 A B - - Bracket-lower hinge
30 240314002 - - C D Bracket-lower hinge
34 240311301 A B C D Washer,hinge ,nylon ,(2)
35 240313804 A B - - Bracket-ctr hinge,bisque
35 240313802 - - C D Bracket-ctr hinge,white
35A 240336801 A B C D Spacer-hinge,center
36 240313901 A B C D Pin-center hinge
37 240337604 A B - - Trim-cabinet corner,bisque ,(2)
37 240337601 - - C D Trim-cabinet corner,white ,(2)
38 240313701 A B C D Bracket-upper hinge
40 240354403 A B - - Cover-upper hinge,bisque
40 240354401 - - C D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B C D Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D Roller Assy,front ,(2)
56 240314101 A B C D Pin-lower hinge
58 5303274237 A B C D Screw-bracket,hex wshr hd, 8-32CA x 0.500
59 218188000 A B C D Screw, pan hd, 10-32 x 0.625, hinge/mullion, thrd forming
59 240442704 A B - - Screw-#10-32 X 3/4,bisque
59 240442702 - - C D Screw-#10-32 X 3/4,white
72 240368202 A B - - Grille/Kickplate,bisque
72 240368201 - - C D Grille/Kickplate,white
81 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
82 5304418225 A B C D Roller-rear,comp base ,(2)
83 215164200 A B C D Pin-roller,(2)
89 240326102 A B C D Cover-access,w/ label
89 240345702 A - C - Screw-compr plate mtg, truss hd, #10-16 x .500
89 5308000007 A - C - Washer,.34 x .62 x .05 ,nylon
89 241500301 - B - D Screw,#8 18 x .500 ,(3)
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 5304414035 A B - - Paint,touch-up ,bisque
* 5303305324 - - C D Paint,touch-up ,white
* 5308016571 A B C D Plug-button,cab liner holes
CABINET

03/01 6
Publication No. FRT21C5A
5995351722
SHELVES

# = Fast-moving Parts 7 03/01
* = Non-Illustrated Parts
FRT21C5A Publication No.
5995351722
A = FRT21C5A (FRT21C5AQ0)
B = FRT21C5A (FRT21C5AQ1)
C = FRT21C5A (FRT21C5AW0)
D = FRT21C5A (FRT21C5AW1)
POS. NO PART NO DESCRIPTION
10 215667501 A B C D Tray-ice,plastic
11 240358003 A B C D Shelf-freezer
11* 5303299664 A B C D Spacer-shelf
12 240380201 A B C D Diffuser-air,top
13 240362601 A B C D Diffuser-air,top
13* 240392601 A B C D Seal-diffuser
14 # 5309918806 A - C - Switch-light/lamp
14 240413601 - B - D Switch-light/lamp
15 # 5303001179 A B C D Light Bulb/Lamp,40 W
16 5303289050 A - C - Socket-light/lamp
16 241500701 - B - D Socket-light/lamp
17 240368101 A B C D Box-control
17*# 240388701 A B C D Wiring Harness,control box
18 240360801 A B C D Knob-control
21 # 5304418228 A B C D Control-temperature
22A 5303916855 A B C D Tube, sensor sleeve, plastic, clear
22B 218731105 A B C D Tube, PVC ,white, @ air diffuser, insulator
23 # 215846606 A B C D Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 5303001259 A B C D Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360903 A - C - Shelf-sliding,refr
24 240360904 - B - D Shelf-sliding,refr
25 240364717 A B C D Cover-crisper pan
25B 240361202 A B C D Control-humidity
25C 240361301 A B C D Damper-humidity control
26 240343801 A B C D Pan-crisper,(2)
28 3201150 A B C D End Cap-shelf,protector ,frzr shelf
30 240361801 A B C D Hanger-meat pan,drop thru
31 240354203 A B C D Pan-meat,w/o graphics ,clear
47 240350609 A B C D Insert-pan cover,glass
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
SHELVES

03/01 8
Publication No. FRT21C5A
5995351722
SYSTEM

# = Fast-moving Parts 9 03/01
* = Non-Illustrated Parts
FRT21C5A Publication No.
5995351722
A = FRT21C5A (FRT21C5AQ0)
B = FRT21C5A (FRT21C5AQ1)
C = FRT21C5A (FRT21C5AW0)
D = FRT21C5A (FRT21C5AW1)
POS. NO PART NO DESCRIPTION
1 # 240345601 A B C D Condenser,dynamic
4 # 218944001 A B C D Drier-filter,R134a System
6 # 240375301 A B C D Wiring Harness, machine compt, w/service cord
6* # 240385401 A B C D Wiring Harness,freezer section
6* # 240388701 A B C D Wiring Harness,control box
14 # 5303918247 A B C D Defrost Heater Kit
15 # 5303918205 A - C - Evaporator Kit
15 # 5303918250 - B - D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 240434002 A B C D Trough-drain
18 240362301 A B C D Insulation Block,RH
20 240362401 A B C D Insulation Block,LH
21 # 5303918202 A B C D Thermostat-defrost,kit
22 240330001 A B C D Plate-compr mtg
22* 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C D Grommet-compr mtg,(4)
25 240330402 A B C D Screw-shoulder, hex hd, 1/4-28 shoulder, (3)
26 240332602 A B C D Pan-defrost drain
29 5303918209 A - C - Compressor,w/electricals
29 # 5303918249 - B - D Compressor,w/electricals
30 # 218721112 A - C - Starter-PTC
30 # 218721113 - B - D Starter-PTC
32 218740800 A B C D Clamp,elec cont mtg ,compressor
34 240405201 A B C D Grommet-cond mtg,(4)
41 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
44 5303001199 A B C D Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
55 # 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
57 240403601 A B C D Clip-wiring harness
58 215004600 A B C D Screw-cond fan mtr, hx serr wshr hd, 8-36 x 7/16,(2)
59 240315501 A B C D Shroud-cond fan
59* 240346701 A B C D Tape-foam seal,shroud
59* 240359401 A B C D Screw-fan shroud,(2)
59A 240346501 A B C D Bracket-support,cond mtr ,(3)
59B 240346601 A B C D Grommet-bracket,(3)
60 # 240334001 A B C D Motor-condenser fan
61 # 240315401 A B C D Fan Blade,galv steel ,condenser fan
61A 215004700 A B C D Nut,speed
61B 215004800 A B C D Grommet-silencer
82 5304418225 A B C D Roller-rear,comp base ,(2)
83 215164200 A B C D Pin-roller,(2)
84 240359601 A B C D Tube-drain,lower
85 240346201 A B C D Tube-connector,suction
86 240409301 A B C D Spacer-cond tube,black
* # 5303918210 A B C D Heat Exchanger Kit,suction line
* 5304421289 A B C D Hot Tube Repair Kit,Service
SYSTEM

03/01 10
Publication No. FRT21C5A
5995351722
WIRING SCHEMATIC

# = Fast-moving Parts 11 03/01
* = Non-Illustrated Parts
FRT21C5A Publication No.
5995351722
WIRING DIAGRAM
