Frigidaire FRT21FG4D User manual

Product No. FRT21FG4DW1 FRT21FG4DW2
Series R134a R134a
Color white white
Volts 115 115
Wiring Diagram 240398801 240398801
Owner's Guide 240400111 240400111
Market North America North America
Energy Guide 240585914 240585914
Service Data Sheet 240379014 240379014
Installation Instructions 240568300 240568300
N05L00004.eps N05DBDCKA0.eps N05BBAAAA10.eps N05SACAEF12.eps
N05CAAAAA9.eps 115-1.eps 240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995422960
04/11/29
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21FG4D
Copyright ©2004 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995422960 FRT21FG4D
11/04 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT21FG4D Publication No: 5995422960
# Functional Parts 3 11/04
* Non-Illustrated Parts
DOOR
Model Index: AFRT21FG4D (FRT21FG4DW1)
BFRT21FG4D (FRT21FG4DW2)
POS. NO PART NO. DESCRIPTION
1 # 240514607 A B Gasket, seal, white, frzr door, magnetic
2 # 240514608 A B Gasket, seal, white, refr door, magnetic
4 240534901 A B Rack-door
4B 240534701 A B Rack-door, 4B
7 240337701 A B Door-dairy, w/o graphics, white
8 240534801 A B Rack-door
10 240381301 A B Plug-button, white, hinge brg hole, (2)
11 240450301 A B Door, frzr, white
12 240415201 A B Label-nameplate, white
13 240312403 A B Door Stop, white, ref
13A 240312404 A B Door Stop, white, frzr
14 240494001 A B Plug-button, white
15 240450401 A B Door, refr, white
18A 218428101 A B Handle-door, white, w/block & screw
21 240383401 A B Screw, truss hd quad, #10-16 x .500
21A 240521301 A B Screw, #10-16 x 1/2
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 A B Bearing-hinge, natural color
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995422960 FRT21FG4D
11/04 4
CABINET
83
82
11
10
1
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAAAA10
43 21C
41
41
41
8
8
9
14
81
34
22
21C
40

FRT21FG4D Publication No: 5995422960
# Functional Parts 5 11/04
* Non-Illustrated Parts
CABINET
Model Index: AFRT21FG4D (FRT21FG4DW1)
BFRT21FG4D (FRT21FG4DW2)
POS. NO PART NO. DESCRIPTION
1 240355402 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut, push-on
4 241523701 A B Damper-fan cover
5 5308000010 A B Fan Blade, red, evaporator fan
8 5300157666 A B Bushing-motor mtg, (2)
9 5303292396 A B Bracket-motor mtg, front
10 240313610 A B Cover-evap coil, w/o light
10* 240568606 A B Seal-coil cover
10*# 240524701 A B Wiring Harness, freezer section
11 5303208309 A B Plug-hole, factory test
13 240369702 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg, rear
14* 240433201 A B Screw, hex washer head, 8-18 x 0.375
18 240411901 A B Support-evap cover, (2)
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 A B Plug-button, white, upr hinge holes
28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314002 A B Bracket-lower hinge, white
34 240311303 A B Washer, hinge, nylon, (2)
35 240313802 A B Bracket-ctr hinge, white
35A 240336802 A B Spacer-hinge, center
36 240516401 A B Pin-center hinge
37 240337601 A B Trim-cabinet corner, white, (2)
38 240313701 A B Bracket-upper hinge
40 240354401 A B Cover-upper hinge, white
41 5303001609 A B Grommet, shelf mtg, 0.69", RH
41* 241550801 A B Grommet-shelf mtg, 1.40" long
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B Roller Assy, front, (2)
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw, hex washer head, 8-15A x 0.500
59 240442702 A B Screw-#10-32 X 3/4, white
72 240368205 A B Grille/Kickplate, white
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 A B Cover-access, w/label
89* 241500301 A B Screw, hex washer head, 8-18AB x 0.500
92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 5303305324 A B Paint, touch-up, white

Publication No: 5995422960 FRT21FG4D
11/04 6
SHELVES

FRT21FG4D Publication No: 5995422960
# Functional Parts 7 11/04
* Non-Illustrated Parts
SHELVES
Model Index: AFRT21FG4D (FRT21FG4DW1)
BFRT21FG4D (FRT21FG4DW2)
POS. NO PART NO. DESCRIPTION
11 240358003 A B Shelf, freezer, full-width, wire
11* 5303299664 A B Spacer, shelf
12 240545901 A B Diffuser-air, top
13 240362601 A B Diffuser, air, bottom
14 241554901 A B Switch-light/lamp
15 241555401 A B Light Bulb
16 241500701 A B Socket-light/lamp
17 240368101 A B Control Box
18 240360801 A B Knob, temp control
21 # 5304421256 A B Control, temperature
22A 5303916855 A B Tube, sensor sleeve, plastic, clear
23 # 215846606 A B Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240372407 A B Frame-shelf, sliding, full width
24A 240372408 A B Frame-shelf, sliding, full width, w/hanger tabs
25 240364710 A B Cover, crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper, humidity cont.
26 240343801 A B Pan-crisper, (2)
29 240357704 A B Trim-shelf, front
31 240530901 A B Pan-meat
34 240385201 A B Container, ice bin
40 240443310 A B Glass-shelf, full shelf
41 240561502 A B Trim-shelf, rear
42 240530601 A B Track, meat pan hanger, LH
42 240530701 A B Track, meat pan hanger, RH
47 240350609 A B Insert-pan cover, glass
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438

Publication No: 5995422960 FRT21FG4D
11/04 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA9
22
23
23
30
32
85
55
4
6
29
26
45
57
25
25
86

FRT21FG4D Publication No: 5995422960
# Functional Parts 9 11/04
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT21FG4D (FRT21FG4DW1)
BFRT21FG4D (FRT21FG4DW2)
POS. NO PART NO. DESCRIPTION
1 # 240444401 A B Condenser, dynamic
4 # 218944001 A B Drier-filter, R134a System
6 # 240496101 A B Wiring Harness, machine compt, w/electric cord
6* # 240388701 A B Wiring Harness, control box
6* # 240524701 A B Wiring Harness, freezer section
14 # 5303918247 A B Defrost Heater Kit
15 # 5303918274 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater, aluminum, (2)
17 241551801 A B Trough-drain
20 240518402 A B Insulation, evap block, foam, LH/RH
21 # 5303918202 A B Thermostat-defrost, kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B Grommet-compr mtg, (4)
25 240491501 A B Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332602 A B Pan-defrost drain
29 5303918291 A - Compressor, w/electricals
29 # 5303918303 - B Compressor, w/electricals
30# 218721119 A - Starter, PTC
30# 218721133 - B Starter-PTC
32 218973501 A - Clamp, elec cont mtg, compressor
32 240553401 - B Clamp, elec cont mtg, compressor
34 240405201 A B Grommet, rubber, black, cond tube/wire
41 240555001 A B Screw-#8-32 X 3/8
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 241500301 A B Screw, hex washer head, 8-18AB x 0.500
55 218909913 A B Capacitor-run, 220 VAC, 15 microfarad
57 240542601 A B Clip-wiring harness
58 215004600 A B Screw, hx serr wshr hd, 8-36 x 7/16, cond fan motor, (2)
58 218897002 A B Screw, hex washer head, 8-32 x 0.375
59 240315501 A B Shroud-cond fan
59 5304430246 A B Bracket-cond motor assy
59* 240346501 A B Bracket-support, cond mtr, (3)
59* 240346601 A B Grommet-bracket, (3)
59* 240346701 A B Tape-foam seal, shroud
59* 240359401 A B Screw-fan shroud, (2)
60 # 240525401 A B Motor-condenser fan
61 # 240524101 A B Fan Blade, galv steel, condenser fan
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
85 240346201 A - Tube-connector, suction
85 240553501 - B Tube-connector, suction
86 240409302 A B Spacer-cond tube, black
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* 240409301 A B Spacer-cond tube, black
* 5303918210 A B Heat Exchanger Kit, suction line
* 5303918222 A B Hot Tube Repair Kit, service

Publication No: 5995422960 FRT21FG4D
11/04 10
ICE MAKER

FRT21FG4D Publication No: 5995422960
# Functional Parts 11 11/04
* Non-Illustrated Parts
ICE MAKER
Model Index: AFRT21FG4D (FRT21FG4DW1)
BFRT21FG4D (FRT21FG4DW2)
POS. NO PART NO. DESCRIPTION
1* 218976901 A B Tube-water inlet, inlet valve, to ice maker
1* 240561701 A B Seal-water inlet, inlet valve, to ice maker
2 5304420650 A B Spring, shut-off arm
3 3206299 A B Label, ID plate
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire, 8-32 x 0.250
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-hold switch
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff, ICE MAKER, complete assy
12 # 5304420651 A B Wiring Harness, ICE MAKER, internal, with plug
12* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500
13 # 3206322 A B Thermostat Assy, ICE MAKER
14 5304420652 A B Screw, 4 x 0.750, switch mtg.
15 # 3206324 A B Switch, (3)
16 5304420653 A B Support, phenolic
17 # 5303320545 A B Mold-ice maker, Radius Cube, with heater
18 3206328 A B Ejector-ice
19 3206330 A B Bearing & Inlet
20 5304408581 A B Screw, 8-32 x 0.375
21 3206332 A B Ice Stripper
22 3206333 A B Shut-off Arm
23 5304408582 A B Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B Lever Arm
25 3206336 A B Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B Screw-thermo/sprt, 4-24 x 0.375, (4)
27 3206338 A B Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B Screw-timing stop, 4-40 x 0.375
29 3206323 A B Screw, 4-24 x 0.750, (6)
30 3206341 A B Screw-timing adj, 8-32 x 1.000
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 5304408583 A B Spring-timing adj
34 5304420655 A B Screw, plazscrew, 8-10, (3)
35 5304408585 A B Screw
36 3206347 A B Cover-ice maker
46 5303001193 A B Clamp, .50 ID, steel, water tube
49 218362500 A B Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
51 240387101 A B Tube-water, ice mold fill, extension
51 241523501 A B Tube-water, ice mold fill, extension
55 # 240519601 A B Valve-water, single solenoid, 60 Hz, 105/120 V
58 5303001343 A B Screw, hex washer head, 8-15A x 0.500
61 218721500 A B Bracket-leveling, ICE MAKER
62 218737900 A B Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5303001549 A B Clamp, 0.31 ID, steel, copper wtr line
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
* 218888001 A B Adapter-water supply, nut & sleeve, compression ftg
* 240352409 A B Ice Maker, Radius Cube, 115 V, no instl parts

Publication No: 5995422960 FRT21FG4D
11/04 12
WIRING SCHEMATIC

FRT21FG4D Publication No: 5995422960
# Functional Parts 13 11/04
* Non-Illustrated Parts
WIRING DIAGRAM
