Basic Information
1-1
Safe Servicing Practices For All Appliances
Avoid personal injury and/or property damage by observing important Safe Servicing Practices.
Following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and
satisfactory manner.
2. Do not exceed maximum recommended wattage on light bulb replacements. Doing so could blow fuses and/or
damage transformers.
3. Before servicing or moving an appliance:
• Remove power cord from the electrical outlet, trip circuit breaker to the OFF position, or remove fuse.
• Turn off water supply if applicable.
• Turn off gas supply if applicable.
4. Never interfere with the proper operation of any safety device.
5. Use ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE. Substitutions may defeat compliance
with safety standards set for home appliances.
6. GROUNDING: The standard color coding for safety ground wires is GREEN, or GREEN with YELLOW STRIPES.
Ground leads are not to be used as current carrying conductors. It is EXTREMELY important that the service
technician reestablish all safety grounds prior to completion of service. Failure to do so will create a hazard.
7. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high-temperature components,
and moving parts.
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal
parts and panels.
• All safety grounds (both internal and external) are correctly and securely connected.
• All panels are properly and securely reassembled.
© 2011 Electrolux Home Products, Inc.
ATTENTION
This service manual is intended for use by persons having electrical and mechanical training and a level
of knowledge of these subjects generally considered acceptable in the appliance repair trade. Electrolux
Home Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any kind
arising from the use of this manual.

Basic Information
Table of Contents
1-2
Section 1 Basic Information .........................................
Safe Servicing Practices For All Appliances..................... 1-1
Table of Contents......................................................... 1-2
Important Safety Instructions ....................................... 1-4
Child Safety................................................................. 1-5
Proper Disposal of Refrigerators/Freezers ...................... 1-5
Model Number Matrix................................................... 1-6
Serial Number Matrix.................................................... 1-6
Basic Information......................................................... 1-7
Data Sheets................................................................. 1-10
Section 2 Installation ...................................................
Location ..................................................................... 2-1
Installation Clearance .................................................. 2-1
Installation Checklist .................................................. 2-1
Leveling Freezer Drawer............................................... 2-2
Level Refrigerator & Adjust Doors................................. 2-2
Getting Through Narrow Spaces ... .............................. 2-5
Door Handle Mounting Instructions Gallery ................... 2-7
Door Handle Mounting instructions Professional............. 2-8
Connecting Water Supply ............................................ 2-9
Section 3 Electronic Control..........................................
Control Layout ............................................................. 3-1
Pro-Select Display Operation ........................................ 3-2
Express-Select Display Operation (Dispenser Models) .... 3-3
Express-Select Display Operation (Non-Dispenser Models)
3-4
Sabbath Mode.............................................................. 3-5
Showroom Mode.......................................................... 3-5
Manual Defrost Mode .................................................. 3-5
Alarms......................................................................... 3-6
Error Codes ................................................................ 3-6
Entering Service Mode ................................................. 3-7
Tests .......................................................................... 3-7
Ice and Water Troubleshooting Guide............................ 3-8
Ice and Water Troubleshooting Flow Charts................... 3-10
Variable Capacity Compressor Electrical Components...... 3-18
To Check/Replace the Inverter...................................... 3-18
Testing the Compressor................................................ 3-19
Lighting System ........................................................... 3-20
Voltage Flow Chart....................................................... 3-22
Section 4 Ice Maker ....................................................
Fresh Food Compartment Ice Maker (Flex Tray)
Operation................................................................. 4-1
Defrost Water Drain.................................................. 4-2
About Ice Cube Production........................................ 4-3
Ice Size Selection...................................................... 4-3
Diagnostic Service Mode............................................ 4-4
Diagnostic Service Mode Test Sequence ..................... 4-4
Diagnostic Flow Charts ............................................. 4-6
Fresh Food Compartment Ice Maker (Finger Evaporator)
Operation................................................................. 4-9
Defrost Water Drain.................................................. 4-10
About Ice Cube Production........................................ 4-11
Section 4 Ice Maker - continued....................................
Freezer Recovery Mode............................................. 4-12
Error Codes.............................................................. 4-12
Diagnostic Service Mode............................................ 4-12
Diagnostic Service Mode Test Sequence ..................... 4-13
No Ice Conditions .................................................... 4-16
Diagnostic Flow Charts ............................................. 4-17
Ice Maker Exploded View ......................................... 4-39
Freezer Ice Maker
Operation................................................................. 4-42
Ice Maker Components.............................................. 4-42
Installing Water SUpply Line to Ice Maker.................. 4-44
Water Valve Switch - Water Fill Volume...................... 4-44
Fault Diagnosis......................................................... 4-45
Operating Cycle Illustrations - Manual Cycle ............... 4-45
Operating Cycle Illustrations - Electrical...................... 4-47
Operating Cycle Illustrations - Mechanical................... 4-52
Ice Maker Exploded View .......................................... 4-54
Section 5 Water System ..............................................
Operation .................................................................... 5-1
Water Filter.................................................................. 5-2
Water Tank.................................................................. 5-2
Water Schematic (Dispensing Models)........................... 5-2
Water Schematic (Non-Dispensing Models).................... 5-3
Testing Water Fill System.............................................. 5-4
Section 6 Component Teardown ...................................
Dispenser Frame.......................................................... 6-2
Control Assembly ......................................................... 6-2
Ice Chute Extension .................................................... 6-3
Control Assembly (Non-Dispenser Models) .................... 6-3
Door Components ....................................................... 6-4
Door Mullion................................................................ 6-5
Door Hinges and Doors ................................................ 6-5
Freezer Components .................................................... 6-7
Toe Grille..................................................................... 6-8
Anti-Tip Leg................................................................. 6-8
Eyebrow Trim............................................................... 6-8
Light Switch ................................................................ 6-9
Humidity Sensor........................................................... 6-9
Interior Components .................................................... 6-10
Shelves.................................................................... 6-10
Deli Keeper and Crisper............................................. 6-10
Water Filter.............................................................. 6-10
Air Filter................................................................... 6-11
Fresh Food Thermistor ............................................. 6-11
Light Shield.............................................................. 6-12
Air Duct ................................................................... 6-12
Upper Light Fixture................................................... 6-12
Freezer Light Switch.................................................. 6-12
Freezer Thermistor.................................................... 6-13
Freezer Drawer Rails................................................. 6-13
LED Assembly........................................................... 6-14
Lighting Control........................................................ 6-14
Ice Maker Air Duct.................................................... 6-15
Ice Maker and Mounting Plate ................................... 6-15

Basic Information
1-3
Evaporator Cover...................................................... 6-16
Evaporator Fan Motor................................................ 6-16
Evaporator Defrost Thermostat.................................. 6-17
Defrost Heater.......................................................... 6-17
Fresh Food Compartment Ice Maker (Flex Tray)............. 6-18
Ice Bucket ............................................................... 6-18
Ice Maker ................................................................ 6-18
Ice Maker Housing ................................................... 6-19
Fill Funnel ............................................................... 6-19
Fill Tube .................................................................. 6-19
Air Handler............................................................... 6-20
Auger Motor, Crusher Solenoid, and Fan .................... 6-21
Evaporator Housing................................................... 6-21
Heater and Bimetal Thermostat ................................ 6-22
Replacement of Components .................................... 6-23
Fresh Food Compartment Ice Maker (Finger Evaporator) 6-26
Ice Maker Control Cover............................................ 6-26
Ice Maker Control..................................................... 6-26
Ice Bucket ............................................................... 6-26
Ice Bin Housing ....................................................... 6-26
Ice Maker Left and Right Mold Switch ....................... 6-27
Bail Arm Ice Level Switch ......................................... 6-27
Ice Maker Drive Motor............................................... 6-27
Ice Maker Gear Box ................................................. 6-27
Ice Maker Side Plate................................................. 6-28
Ice Mold, Heater and Defrost Limiter for Finger Evap.. 6-28
Ice Maker Defrost Heater.......................................... 6-29
Ice Maker Suction Line Thermistor ............................ 6-29
Dispenser Auger Motor & Solenoid Assembly.............. 6-30
To Test Auger Motor.................................................. 6-30
To Test Solenoid Assembly......................................... 6-30
Ice Maker Evaporator Fan Motor & Defrost Limit
Thermostat............................................................... 6-31
Ice Maker Frame Assembly........................................ 6-31
Ice Auger and Crusher Assembly .............................. 6-32
Freezer Ice Maker........................................................ 6-33
Compressor Area.......................................................... 6-36
Section 7 Sealed System............................................... 7-1
Safe Servicing Practices For All Appliances...................... 7-2
Introduction.................................................................. 7-3
Compressor .................................................................. 7-3
Refrigeration Systems.................................................... 7-3
Sealed System Repair.................................................... 7-3
Definitions.................................................................... 7-4
Equipment Needed for Evacuation & Recharging............. 7-4
Charging Sealed Systems............................................... 7-5
Soldering...................................................................... 7-5
Basic Components......................................................... 7-6
Recovering Refrigerant .................................................. 7-7
Low/High Side Leak or Undercharge............................... 7-8
Testing for Refrigerant Leaks ......................................... 7-8
Checking For Internal Leaks........................................... 7-8
Compressor Replacement .............................................. 7-9
Flushing The System With Nitrogen................................ 7-9
Installing a New Compressor ......................................... 7-10
Freezer Evaporator and Suction Line Replacement........... 7-11
Freezer Heat Exchanger Replacement (Finger IM Evap.).. 7-13
Ice Maker Evaporator Replacement (Finger IM Evap.)...... 7-13
Ice Maker Heat Exchanger Rep. (Finger IM Evap.)........... 7-14
Freezer Heat Exchanger Rep. (Flex Tray IM Evap.) .......... 7-15
Ice Maker Evaporator Rep. (Flex Tray IM Evap.).............. 7-16
Ice Maker Jumper Tube Rep. (Flex Tray IM Evap.)........... 7-17
Condenser Replacement................................................ 7-18
Filter-Drier Installation................................................... 7-18
Perimeter Hot Tube Repair Kit........................................ 7-20
Installing Evacuation and Recharging Equipment............. 7-21
Evacuating the System .................................................. 7-22
Charging The System................................................... 7-24
Final Leak Test............................................................. 7-24
Dedicated Equipment ................................................... 7-24
Vacuum Pump Maintenance.......................................... 7-25
Service Diagnostic Tips................................................. 7-26
HFC 134a Comparison With CFC 12............................... 7-27
Inhalation Toxicity........................................................ 7-27
Cardiac Sensitization .................................................... 7-27
Skin and Eye Contact ................................................... 7-27
Refrigerant Leaks......................................................... 7-28
Spills or Leaks ............................................................ 7-28
Combustibility of HFC-134a........................................... 7-29
Leak Testing ................................................................ 7-29
Bulk Delivery and Storage............................................. 7-29
Filling and Charging Operations..................................... 7-29
Refrigerant Recovery Systems....................................... 7-29
Thermal Decomposition. .............................................. 7-29
R-134a Physical Properties............................................ 7-30
HFC-134a, CFC-12 Pressure
HFC-134a, CFC-12 Pressure Temperature Chart ............. 7-31
Glossary of Terms ........................................................ 7-31
Section 8 Air Circulation................................................ 8-1
Principles Of Automatic Defrost Operation .................... 8-1
Air Circulation Patterns ................................................ 8-1
Section 9 Wiring Schematics.........................................
ERF2500++ Control Schematic Flex-Tray Dispenser Models ...... 9-1
ERF2500++ Control Schematic Finger Evap. Dispenser Models 9-2
ERF2500++ Control Schematic Non-Dispenser Models ............ 9-3
Flex-Tray Dispenser Models Fold-Out Schematic ..................... 9-4
Finger Evaporator Dispenser Models Fold-Out Schematic .......... 9-5
Non-Dispenser Models Fold-Out Schematic ........................... 9-6

Basic Information
1-4
Important Safety Instructions
Safety Precautions
Do not attempt to install, operate or service the unit until
you have read the safety precautions in this manual.
Safety items throughout this manual are labeled with a
Danger, Warning, or Caution based on the risk type.
Definitions
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or
death.
General Safety
• Do not store or use gasoline or other flammable
liquids near this or any other appliance. Read product
labels for warnings regarding flammability and other
hazards.
• Do not operate the refrigerator in the presence of explo-
sive fumes.
• Avoid contact with any moving parts of the automatic
ice maker.
• Remove all staples from the carton to avoid injury.
Staples can also damage finishes if they come in contact
with other appliances or furniture.
Child Safety
Packing Materials:
• Packing cartons covered with rugs, bedspreads,
plastic sheets, or stretch wrap may become airtight
chambers and can quickly cause suffocation.
• Destroy or recycle the product’s carton, plastic bags,
and any other exterior wrapping material immediately
after the refrigerator is unpacked. Children should
never play with these items.
Child Entrapment and Suffocation:
• These problems are not limited to the past. Whether
junked, abandoned, or temporarily stored (even for a
few hours), unattended refrigerators and freezers are
dangerous. Please take the precautions listed below.
Proper Disposal of Refrigerators/Freezers
Electrolux Home Products Inc. strongly encourages
responsible appliance recycling/disposal methods.
Check with your utility company or visit www.recyclemy-
oldfridge.com for more information on recycling your old
refrigerator.
Before you recycle or dispose of your old refrigerator/
freezer:
• Remove the doors.
• Leave the shelves and baskets in place so children
may not easily climb inside.
• Have refrigerant and compressor oil removed by a
qualified service technician.
DANGER INDICATES AN IMMINENTLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
WILL RESULT IN DEATH OR SERIOUS INJURY.
WARNING INDICATES A POTENTIALLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
COULD RESULT IN DEATH OR SERIOUS INJURY.
CAUTION indicates a potentially hazardous situ-
ation which, if not avoided, may result in minor or
moderate injury.
Indicates installation, operation, or maintenance
information which is important but not hazard
related.

Basic Information
1-5
noitacifitnedItcudorP
rotaregirf
e
R=A
srezeerF=B
srehsaW=C
s
reyrD=
D
sr
etneCyrdnuaL
=E
s
egnaR=F
reh
s
aw
h
s
i
D=
H
evaworciM=P/G
r
e
ifidimuhe
D
=
N
4A11
22 3345
Model Number Matrix
Serial Number Matrix
FG
HB
23
44
L
F
BRAND
PRODUCT
CATEGORY
CAPACITY
FEATURE
LEVEL
YEAROF
INTRODUCTION
COLOR
Brand
FG – FrigidaireGallery
FP – Frigidaire Professional
LG – Lowe’s Gallery
Product
Category
HB – High Efficiency Bottom Freezer
HN – High Efficiency Non-Dispensing Bottom Freezer
HF – High Efficiency Bottom Freezer Counter Depth
HG – High Efficiency Non-Dispensing Bottom Freezer Counter Depth
Capacity
23 – 23 cu. ft. Refrigerators
26 – 26 cu. ft. Refrigerators
28 – 28 cu. ft. Refrigerators
Feature Level
2 – digit scale with 99 being the highest
Yearof
Introduction
L – 2010
M – 2011
Color
F – Stainless Steel
P– Pearl White (Smooth), Plastic
E– Ebony Black (Smooth)
M – Silver Mist

1-6
Basic Information
Models with Fresh Food Ice Maker
NOTE: Features may vary according to model
Toe
Grille
SpillSafe
TM
Shelves
Dairy
Compartment
Ice
Bin Ice
Maker
SpillSafe
TM
Shelves
Freezer Baskets
Crisper
Drawer
Crisper
Drawer
Water
Filter
Adjustable
Hinges
Incandescent Light (select models)
LED Light (select models)
Door
Bin
Flipper Guide
Flipper
Mullion
Store-More
Drawer
Can
Rack
Air Filter
TM
(select models)

1-7
Basic Information
Models with Fresh Food and Freezer Ice Makers
NOTE: Features may vary according to model

1-8
Basic Information
Models with Freezer Ice Maker
NOTE: Features may vary according to model

1-9
Basic Information
PERFORMANCE DATA NO LOAD & NO DOOR OPENINGS AT 37°/0° CONTROL SETTING
Type A with Run/Start Capacitor 65°F (18°C) Ambient 90°F (32°C) Ambient
Operating Time 74 to 84% 100%
Freezer Temperature -5° to 2° F (-20° to -17° C) -1° to 3° F (-18° to -16° C)
Refrigerator Temperature 34° to 39° F (1° to 4° C) 34° to 39° F (1° to 4° C)
Low Side Pressure (cut-in) 5 to 12 psig (34 to 83 kPa) N/A
Low Side Pressure (cut-out) -2 to 2 psig ( -14 to 14 kPa) -2 to 2 psig (-14 to 14 kPa)
High Side Pressure (last 1/3 cycle) 85 to 95 psig (586 to 655 kPa) 120 to 135 psig (827 to 931 kPa)
Wattage (last 1/3 cycle) 45 to 55 60 to 70
Amps (running) .6 to 1.1 .7 to .9
Base Voltage 115 vac (127 vac max)
DEFROST SPECIFICATIONS
Cabinet Size
Thermostat Heater
Cut-in Cut-out Watts Ohms
26’ & 28’ SD, 23’ CD 25° F (-4° C) 47° F (8° C) 500 31
Electronic Timer - (ADC) Defrost 24 minutes every 6-96 hours of compressor run time.
CONDENSER FAN MOTOR
Watts RPM Amps
3.1 1100 CW Opposite Shaft 0.03 Running
ICE MAKER SPECIFICATIONS
Electrical 115 vac (127 vac max)
Thermostat Opens at 48° F ( 9° C), Closes at 15° F ( -9° C)
Heater Voltage 85 vac
ICE MAKER CONNECTOR PLUG CONNECTIONS
Wire Number Wire Color Connects to:
1 Green/Yellow Ground
2 Yellow Water Valve
3 Black Line
4 Light Blue Neutral
Models With Dispenser and Fresh Food Compartment Ice Maker

1-10
Basic Information
PERFORMANCE DATA NO LOAD & NO DOOR OPENINGS AT 37°/0°
CONTROL SETTING
Variable Speed Compressor 65°F (18°C) Ambient 90°F (32°C) Ambient
Operating Time 32 to 40% 100%
Freezer Temperature -6° to 6° F
-21° to -14° C -6° to 6° F -21° to -14° C
Refrigerator Temperature 33° to 46° F
0.5° to 8° C 33° to 46° F 0.5° to 8° C
Low Side Pressure
(cut-in) 5 to 12 psig 34 to 83 kPa N/A
Low Side Pressure
(cut-out) -2 to 2 psig -14 to 14 kPa -2 to 2 psig -14 to 14 kPa
High Side Pressure 85 to 95 psig
586 to 655 kPa 120 to 135 psig 827 to 931 kPa
Wattage 40 to 55 60 to 70
Amps (running) .5 to 1.1 .7 to .9
Base Voltage 115 vac (127 vac max)
DEFROST SPECIFICATIONS
Cabinet Size Thermostat Heater
Cut-in Cut-out Watts Ohms
26’ & 28’ SD, 23’ CD 25° F
(-4° C) 47° F (8° C) 500 26
Electronic Timer - (ADC) Defrost 24 minutes every 6-96 hours of compressor run time.
CONDENSER FAN MOTOR
Watts RPM Amps
3.1
(Energy Star, some models) 1100 CW Opposite Shaft 0.03 Running
ICE MAKER SPECIFICATIONS
Electrical 115 vac (127 vac max)
Thermostat Opens at 48° F (9° C), Closes at 15° F (-9° C)
Heater Voltage 85 vac
ICE MAKER CONNECTOR PLUG CONNECTIONS
Wire Number Wire Color Connects to:
1 Green/Yellow Ground
2 Yellow Water Valve
3 Black Line
4 Light Blue Neutral
Models With Freezer Compartment Ice Maker And Without Dispenser

Installation Information
2-1
CAUTION
Do Not install the refrigerator where the temperature
will drop below 55°F (13°C) or rise above 110°F
(43°C). The compressor will not be able to maintain
proper temperatures inside the refrigerator.
Do Not block the toe grille on the lower front of your
refrigerator. Sufficient air circulation is essential for the
proper operation of your refrigerator.
This Use & Care Guide provides general installation and
operating instructions for your model. We recommend
using a service or kitchen contracting professional to
install your refrigerator. Use the refrigerator only as
instructed in this Use & Care Guide. Before starting
the refrigerator, follow these important first steps.
Location
• Choose a place that is near a grounded, non-GFCI,
electrical outlet. Do Not use an extension cord or
an adapter plug.
• If possible, place the refrigerator out of direct
sunlight and away from the range, dishwasher, or
other heat sources.
• The refrigerator must be installed on a floor that is
level and strong enough to support a fully loaded
refrigerator.
• Consider water supply availability for models
equipped with an automatic ice maker.
Installation
• Allow the following clearances for ease of
installation, proper air circulation, and plumbing
and electrical connections:
Sides & Top 3/8inch (9.5 mm)
Back 1 inch (25.4 mm)
Door opening
Your refrigerator should be positioned to allow easy
access to a counter when removing food. For best use of
refrigerator drawers and freezer baskets, the refrigerator
should be in a position where both can be fully opened.
Required Tools
You will need the following tools:
ÍNOTE
If your refrigerator is placed with the door hinge side
against a wall, you may have to allow additional space
so the door can be opened wider.
ÍNOTE
The refrigerator doors are designed to shut by
themselves within a 20 degree opening.

Installation Information
2-2
ÍNOTE
DO NOT remove center screw from freezer drawer.
This is a factory adjustment.
To level the cabinet using the front rollers (select
models):
1Slightly open freezer drawer. Lift the toe grille and
gently pull forward (see illustration).
Leveling Freezer Drawer (if necessary) Level Refrigerator & Adjust
Doors (if necessary)
Guidelines for final positioning of your refrigerator:
• All four corners of the cabinet must rest firmly on
the floor.
• The sides should tilt 1/4inch (6 mm) from front to
back (to ensure that doors close and seal properly).
• Doors should align with each other and be level.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1 You can raise or lower each door. use a 3/8 inch
socket wrench to turn the adjustment screws (1
per side).
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw counterclockwise.
2Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
3After unit is leveled, lower anti-tip leg until it
contacts the floor.
2Check gasket seal around top, bottom, and sides of
freezer drawer.
3If gasket is not sealed, open drawer and slightly
loosen four (4) drawer screws (two (2) on each
side) to allow drawer to rotate.
4Close drawer and recheck the seal on the gasket
(A). Open the drawer grabbing by the sides in the
center (B). Be careful not to rotate the drawer.
5Tighten four (4) drawer screws.
6Recheck gasket seal.
7Install the toe grille by fitting into place.
AB

Installation Information
2-3
To adjust the door stop:
Door stop is adjustable between 85 to 145 degrees.
1Open door to provide access to screw.
2Loosen screw.
3Adjust door to desired location.
4Rotate door stop until it makes contact with the
lower hinge.
5Re-tighten screw.
Loosen/Remove Screw
6Ensure door stops in desired location before
resuming normal use.
To level the doors using the adjustable lower
hinge (select models):
1Remove all food items from door bins on door
being adjusted.
2Open doors to 90 degrees.
3Loosen or remove screw.
Adjusting Door
Re-tighten Screw
Adjustable Door Stop
ÍNOTE
View shown is looking up at the bottom of the
refrigerator door.
ÍNOTE
Adjustable hinge should only be used after doors have
been leveled with rollers.

Installation Information
2-4
Adjusting Flipper Mullion Screw
To adjust the flipper mullion:
1 Loosen the screw located on the flipper mullion
hinge.
2Adjust flipper mullion height. For proper
connection with the flipper mullion guide, there
should be a separation about the thickness of a
coin (0.060 inches, or 1.5 mm) between the guide
and flipper mullion.
3Re-tighten screw.
4Lift the door while adjusting the washer. To raise
the door, rotate washer clockwise (when viewed
from the bottom). To lower door, rotate washer
counter-clockwise (when viewed from the bottom).
5Re-tighten the screw, ensuring it is between the
spokes of the washer. Screw will not be tight, just
insert until it is flush with the hinge.
Adjusting Flipper Mullion Height
Raising/Lowering Door
Screw
ÍNOTE
If after adjusting doors higher the door makes a
popping/clicking sound, remove screw and replace with
the longer one supplied in the handle package.

Installation Information
2-5
To remove the refrigerator doors:
1Trace lightly around the door’s top hinges with a
pencil. This makes reinstallation easier.
2Disconnect the harness by grasping both sides of
the connector firmly, depress the latch, and pull
apart. Remove the two (2) screws from the top
hinge. Lift the door off of the bottom hinge and set
it aside.
3Detach the water tube from the connector
located behind the refrigerator and pull the tube
back out to the front of the unit. The connector
releases when you press inward on the outer
sleeve while pushing the tube toward the
connector then while continuing to hold in the
sleeve, pull the tube away.
Getting through narrow spaces
If your refrigerator will not fit through an entrance area,
you can remove the doors. Check first by measuring the
entrance.
To prepare for removing the doors:
1Make sure the electrical power cord is unplugged
from the wall outlet.
2Open the freezer drawer and remove the toe grille
(see “Installation” section).
3Remove any food from the door shelves and close
the doors.
To remove the top hinge covers:
1Remove the two (2) screws from each cover over
the top door hinges.
2Lift inside edge of hinge cover and tilt back.
ÍNOTE
DO NOT remove the ground screw from hinge.

Installation Information
2-6
Once both doors are in place, ensure they are aligned
with each other and level (Please see the “Installation”
section for more details), and replace the top hinge
cover.
Lower Hinge Removal
4Unscrew the three (3) lower hinge screws and
hinge if necessary.
To reinstall the right door, reverse the above steps.
Removing Freezer Drawer
1Open freezer drawer.
2Remove drawer screws on right and left sides (two
(2) screws on each side).
3Lift drawer up and out to remove.
Installing Freezer Drawer
1With lower slides pulled out, hang drawer onto
slide brackets ensuring pins on each side are fully
inserted into slots on each side.
6Tighten four (4) drawer screws.
7Recheck gasket seal.
8Install the toe grille by fitting into place.
2Reinstall four (4) drawer screws (two (2) per side),
tighten down, and close drawer (C).
AB
3Check gasket seal around top, bottom, and sides of
freezer drawer.
4If gasket is not sealed, open drawer and slightly
loosen four (4) drawer screws (two (2) on each
side) to allow drawer to rotate.
5Close drawer and recheck the seal on the gasket
(A). Open the drawer grabbing by the sides in the
center (B). Be careful not to rotate the drawer.
ÍNOTE
You will be pulling approximately three (3) feet of
water tube from the back of the refrigerator.
ÍNOTE
DO NOT remove center screw from freezer drawer.
This is a factory adjustment.
CAUTION
Be sure doors are set aside in a secure position where
they cannot fall and cause personal injury, or damage
to the doors or handles.
CAUTION
Drawer is heavy. Use caution when lifting.

Installation Information
2-7
ÍNOTE
All set screws should be tightened so the screw is below the surface of the handle. The handles should be drawn
tight to freezer and refrigerator doors with no gaps. Opening the opposite door while tightening the Allen screw
makes installation easier.
The door handle may loosen over time or if it was installed improperly. If this happens, tighten the set screws on the
handles.
Door Handle Mounting Instructions for Frigidaire Gallery®
1Remove handles from carton and any other protective packaging.
2Position fresh food handle end over upper and lower pre-installed shoulder bolts (A) that are fastened into door,
ensuring the holes for the set screws are facing towards the opposite door.
3While holding handle firmly against door, fasten upper and lower Allen set screws (B) with supplied Allen
wrench.
4Repeat steps 2 and 3 to install opposite handle. Ensure the holes for the set screws are facing towards the first door.
5Position freezer handle end over left and right pre-installed handle mounts that are fastened to the door,
ensuring the holes for the set screws are facing down.
6While holding handle firmly against door, loosely tighten far right Allen set screw (B) with supplied Allen wrench until there
is no gap between handle and door.
7Still holding the handle firmly to the door, firmly tighten far left Allen set screw (B) with supplied Allen wrench.
8Return to the far right Allen set screw (B) and firmly tighten with supplied Allen wrench.
Mounting Refrigerator Handles
Mounting Freezer Handle

Installation Information
2-8
Door Handle Mounting Instructions for Frigidaire Professional®
1Remove handles from carton and any other protective packaging.
2Position fresh food handle end over upper and lower pre-installed shoulder bolts (A) that are fastened into door,
ensuring the holes for the set screws are facing towards the opposite door.
3While holding handle firmly against door, fasten upper and lower Allen set screws (B) with supplied Allen
wrench.
4Repeat steps 2 and 3 to install opposite handle. Ensure the holes for the set screws are facing towards the first door.
5Position freezer handle end over left and right pre-installed handle mounts that are fastened to the door,
ensuring the holes for the set screws are facing down.
6While holding handle firmly against door, loosely tighten far right Allen set screw (B) with supplied Allen wrench until there
is no gap between handle and door.
7Still holding the handle firmly to the door, firmly tighten far left Allen set screw (B) with supplied Allen wrench.
8Return to the far right Allen set screw (B) and firmly tighten with supplied Allen wrench.
9Firmly tighten the inside Allen set screws.
ÍNOTE
All set screws should be tightened so the screw is below the surface of the handle. The handles should be drawn
tight to freezer and refrigerator doors with no gaps. Opening the opposite door while tightening the Allen screw
makes installation easier.
The door handle may loosen over time or if it was installed improperly. If this happens, tighten the set screws on the
handles.
Mounting Refrigerator Handles
Mounting Freezer Handle
