Frigidaire FRT21NNGB1 User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21NNGB1 FRT21NNG R134a System black 115
FRT21NNGD1 FRT21NNG R134a System almond 115
FRT21NNGW1 FRT21NNG R134a System white 115
Publication No.
5995310009
980707
-EN/SERVICE /JLT
357
REFRIGERATOR
Model No.
FRT21NNGW1
FRT21NNGD1
FRT21NNGB1
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218755000
OWNER’S GUIDE - # 218613700
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624

07/98 2
Publication No. FRT21NNGW1, FRT21NNGD1, FRT21NNGB1
5995310009
1
9
58 6A
8
5A
5A
8
6A
61
62
7
49
49
49
49
58
3
P05D0560
2
14A
21C
12
10
22
13A 14
18
22
14A
14B 14
15
13
21C
14
21C
21C
18
21C 37
21C
11
37A
DOOR

# = Fast-moving Parts 3 07/98
* = Non-Illustrated Parts
FRT21NNGW1, FRT21NNGD1, FRT21NNGB1 Publication No.
5995310009
DOOR
A = FRT21NNG (FRT21NNGB1)
B = FRT21NNG (FRT21NNGD1)
C = FRT21NNG (FRT21NNGW1)
POS. NO PART NO DESCRIPTION
1 # 215608923 A - - Gasket-frzr door,black ,magnetic
1 215608903 - B - Gasket-frzr door,almond ,magnetic
1 215608913 - - C Gasket-frzr door,white ,magnetic
2 # 218730622 A - - Gasket-refr door,black ,magnetic
2 # 218730610 - B - Gasket-refr door,almond ,magnetic
2 # 218730609 - - C Gasket-refr door,white ,magnetic
3 5303275674 A B C Panel-inner door,refr
5A 5303323480 A B C Support-door rack,white ,RH
6A 5303323481 A B C Support-door rack,white ,LH
7 5303308336 A B C Door-dairy,12.25" wide
8 215474045 A B C Rack-door,26.28" x 1.10"
9 5303206631 A B C Panel-inner door,frzr
10 5303272397 A - - Plug-button,black ,hinge brg hole
10 5303001308 - B - Plug-button,almond ,hinge brg hole
10 5308000134 - - C Plug-button,white ,hinge brg hole
12 218156532 A - - Nameplate Assy,black ,with magnet
12 218156513 - B - Nameplate Assy,almond ,with magnet
12 218156512 - - C Nameplate Assy,white ,with magnet
11 5303918031 A - - Panel-frzr door,black ,w/insulation
11 5303917827 - B - Panel-frzr door,almond ,w/insulation
11 5303917826 - - C Panel-frzr door,white ,w/insulation
12* 215518000 A B C * Magnet-nameplate
13 5303212491 A B C Door Stop,refr section
13A 218249003 A - - Door Stop,black ,frzr section
13A 218249002 - B - Door Stop,almond ,frzr section
13A 218249001 - - C Door Stop,white ,frzr section
14 5303272396 A - - Plug-button,black ,handle/dr stop
14 5308000181 - B - Plug-button,almond
14 5308000090 - - C Plug-button,white
14A 215352218 A - - Plug-button,black ,handle mtg ,
refr door front
14A 215352211 - B - Plug-button,almond ,handle mtg ,
refr door front
14A 215352201 - - C Plug-button,white ,handle mtg ,
refr door front
14B 218074001 A B C Plug-button,white ,refr door front ,
lower
14B 218074002 A B C Plug-button,almond ,refr door front ,
lower
14B 218074003 A B C Plug-button,black ,refr door front ,
lower
15 5303918030 A - - Panel-refr door,black ,w/insulation
15 5303917829 - B - Panel-refr door,almond ,w/insul & brace
15 5303917828 - - C Panel-refr door,white ,w/insul & brace
18 218668003 A - - Handle-door,black
18 218668002 - B - Handle-door,almond
18 218668001 - - C Handle-door,white
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x .5
22 218519300 A B C Bearing-hinge
37 215867060 A - - Trim-handle,4.97" ,black ,w/band & lock
37 215867059 - B - Trim-handle,4.97" ,almond ,
w/band & lock
37 215867058 - - C Trim-handle,4.97" ,white ,w/band & lock
37A 215867072 A - - Trim-handle,29.84" ,black ,
w/band & locks
37A 215867071 - B - Trim-handle,29.84" ,almond ,
w/band & locks
37A 215867070 - - C Trim-handle,29.84" ,white ,
w/band & locks
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 215940700 A B C Lock-handle trim,stick-on
37A* 218676001 A B C Band-decorative,chrome
49 215441513 A B C Bin-door,gallon
58 218749600 A B C Screw,#10 pan hd ,8-18 x .5
61 5308017047 A B C Nut,self-threading ,1/8
62 5303275673 A B C Divider-dairy compt
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

07/98 4
Publication No. FRT21NNGW1, FRT21NNGD1, FRT21NNGB1
5995310009
CABINET
17
14
8
13
11
9
5
78
83
12
10
858 4
40
38
37
92
41
18
1920
21
24
22 47
47
81
25
23
45
28
43
26
44
46
45
P05B0328
100
98
92
30
56
36
59
35
29
2
3
1
81
27
6

FRT21NNGW1, FRT21NNGD1, FRT21NNGB1 Publication No.
5995310009
# = Fast-moving Parts 5 07/98
A = FRT21NNG (FRT21NNGB1)
B = FRT21NNG (FRT21NNGD1)
C = FRT21NNG (FRT21NNGW1)
POS. NO PART NO DESCRIPTION
1 5304402655 A B C Cover-fan
2 5303307351 A B C Knob-damper control
3 5303001028 A B C Nut,push-on
4 218722200 A B C Damper-fan cover,black
5 # 218649000 A B C Fan Blade,black
6 5303001388 A B C Plug-button,white
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
10 218802800 A B C Cover-evap coil
11 5303208309 A B C Plug-hole,factory test
12 215079000 A B C Plug-harness hole,round
12 215079100 A B C Plug-wtr inlet tube,round
13 # 218718403 A B C Motor-evap fan
14 5303322992 A B C Bracket-motor mtg,rear
17 5303001470 A B C Trough-drain
18 215245000 A B C Support-evap cover,(2)
19 5303001198 A B C Tube,rubber
20 5303001286 A B C Ferrule-inner
21 5303001287 A B C Ferrule-outer
22 215774918 A - - Plug-button,black ,upr hinge holes
22 215774911 - B - Plug-button,almond ,upr hinge holes
22 215774901 - - C Plug-button,white ,upr hinge holes
23 5303210377 A B C Tube-drain,w/seal ring
24 5303207353 A B C * Seal Ring,drain tube
25 215774100 A B C Spout-drain tube,w/mounting pins
26 218605103 A - - Base-cabinet,black
26 218605102 - B - Base-cabinet,almond
26 218605101 - - C Base-cabinet,white
27 5303212922 A B C Screw-leveling
28 5303271412 A B C Bolt-roller adj,hex hd sems ,1/4-28 x 2.75,(2)
29 218666700 A B C Washer,.28 x .62 x .03 ,nylon
30 218220200 A B C Bracket-lower hinge
30* 215005000 A B C Screw,hex wshr hd ,8-18AB x 0.750 ,gusset/hanger
30* 218605200 A B C Tapping Plate/Gusset,RH
30* 218605300 A B C Tapping Plate/Gusset,LH
35 218220103 A - - Bracket-ctr hinge,black
35 218220102 - B - Bracket-ctr hinge,almond
35 218220101 - - C Bracket-ctr hinge,light grey
36 218251300 A B C Pin-center hinge
37 5303321083 A - - Trim-cabinet corner,black
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321081 - - C Trim-cabinet corner,white
38 3206100 A B C Bracket-upper hinge
38* 5308012296 A B C Tapping Plate,upper hinge ,(2)
40 5304400454 A - - Cover-upper hinge,black
40 3206105 - B - Cover-upper hinge,almond
40 3206101 - - C Cover-upper hinge,white
41 5303001609 A B C Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C Grommet,shelf mtg ,LH
43 218703001 A B C Roller Assy,front ,(2)
44 218713600 A B C Roller Assy,rear ,(2)
45 5303001343 A B C Screw,hex wshr hd ,8-15A x .5 ,spec
46 5308009762 A B C Bolt-roller mtg,hex wshr hd ,1/4-28 x .5,(2)
47 218233300 A B C Channel-shelf mtg,side ,(2)
56 218220300 A B C Pin-lower hinge
58 5308002748 A B C Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B C Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099718 A - - Plug-button,black ,ctr hinge hole
98 215099711 - B - Plug-button,almond ,ctr hinge hole
98 215099701 - - C Plug-button,white ,ctr hinge hole
100 5303288973 A B C Support-pan cover
* 218750100 A B C Cover-sound insul,pressboard/foam ,machine compt
* 5308016571 A B C Plug-button,cabinet liner
* 5303305345 A - - Paint,touch-up ,black
* 5303305325 - B - Paint,touch-up ,almond
* 5303305324 - - C Paint,touch-up ,white
CABINET

07/98 6
Publication No. FRT21NNGW1, FRT21NNGD1, FRT21NNGB1
5995310009
SHELVES

# = Fast-moving Parts 7 07/98
* = Non-Illustrated Parts
FRT21NNGW1, FRT21NNGD1, FRT21NNGB1 Publication No.
5995310009
A = FRT21NNG (FRT21NNGB1)
B = FRT21NNG (FRT21NNGD1)
C = FRT21NNG (FRT21NNGW1)
POS. NO PART NO DESCRIPTION
1 218651902 A - - Mullion,black
1 218651901 - B - Mullion,almond
1 218651900 - - C Mullion,white
5 # 218781002 A B C Heater-mullion
6 218845600 A B C Tapping Plate,mullion mtg ,(2)
7 218866101 A B C Top Panel-refr
7* 5303001380 A B C Screw,truss head ,8-10 x 1.750
8 218866000 A B C Divider,styrofoam
8* 3205266 A B C Edge Protector,wiring harness
8* # 218767600 A B C Harness-wiring,control/divider
9 218865900 A B C Bottom Panel-frzr
10 215667501 A B C Tray-ice,plastic
11 5303288243 A B C Shelf-freezer,fixed/flat ,full width ,wire
11* 218159700 A B C Spacer-shelf
12 218730000 A B C Deflector-air
13 218631001 A B C Cover-air deflector
14 # 5309918806 A B C Switch-light/lamp
15 5303001179 A B C Light Bulb/Lamp,40 W
16A# 5308000815 A B C Socket-light/lamp
17 5303321455 A B C Control Box
18 5303311079 A B C Knob-temp control
19 # 5303286905 A B C Switch-energy saver,rocker type
21 # 5304403736 A B C Control-temperature
21* 5303001260 A B C Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B C Tube,PVC ,white ,@ air deflector ,insulator
23 # 5303321915 A B C Timer-defrost,10 hr ,115V
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438
24 215919117 A B C Frame-full shelf,cantilever
24A 215919170 A B C Frame-pan mtg shelf,cantilever ,full width,w/hanger tabs
25 5303206538 A B C Cover-crisper pan
25A 5303311411 A B C Trim-crisper cover
25B 5303311404 A B C Control-humidity
26 215791938 A B C Pan-crisper,11.34" wide
26 5303323459 A B C Pan-crisper,14.34" wide
27 5303205987 A B C Support-crisper cvr,adjustable
28 3201150 A B C End Cap-shelf,protector ,upper fzr shelf
29 215919405 A B C Trim-glass shelf,26.80" ,front
31 5303323460 A B C Pan-meat
33 5303200329 A B C Gasket-pan cover,13.25" ,RH
34 5303212918 A B C Container-ice
40 218390524 A B C Glass-shelf,26.76" x 14.57"
41 215919805 A B C Trim-glass shelf,26.80" ,rear
42 5303298718 A B C Hanger-pan/tray,LH
42 5303298719 A B C Hanger-pan/tray,RH
47 218390523 A B C Insert-pan cover,glass
59 218188000 A B C Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
60 5303207328 A B C Screw,hex wshr hd ,8-15A x 1
61 215781501 A B C Shelf-ice tray,wire
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 A B C Screw-roller/hanger,8-10 x .438
145 218660800 A B C Clip,plastic ,temp sensor mtg ,snap-in
SHELVES

07/98 8
Publication No. FRT21NNGW1, FRT21NNGD1, FRT21NNGB1
5995310009
45
45
6
43
7
45
43
4
27
26
29
25
24
23
22
55
32
30
28
P05C0101
44
45
13
17
16
21
20
14
19
15
18
1
85
41 2
SYSTEM

# = Fast-moving Parts 9 07/98
* = Non-Illustrated Parts
FRT21NNGW1, FRT21NNGD1, FRT21NNGB1 Publication No.
5995310009
SYSTEM
A = FRT21NNG (FRT21NNGB1)
B = FRT21NNG (FRT21NNGD1)
C = FRT21NNG (FRT21NNGW1)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C Condenser
1* 5303017691 A B C Spacer-tube
2 5308000296 A B C Bracket,condenser mtg ,(4)
2* 5308009617 A B C Washer,ext tooth lock ,#10
4 # 218541000 A B C Drier-filter
5 218767600 A B C Harness-wiring,control/divider
6 215257001 A B C Harness-wiring,compressor
7 # 5316254901 A B C Cord-electric power
8 5303001197 A B C Cover-wiring
8* 218754500 A B C Screw,hex hd ser wshr ,#8-18 x 3/8
13 # 215076405 A B C Heat Exchanger,suction line
14 # 5317842502 A B C Heater-defrost
15 # 218765400 A B C Evaporator
16 5308000110 A B C Strap-evap/heater,aluminum
17 5316651102 A B C Insulator-evap,plastic
18 218773700 A B C Insulation Block,RH
19 5303007287 A B C Insulation Plug,RH
20 5308017227 A B C Insulation Block,LH
21 # 5316269001 A B C Thermostat-defrost
22 5308013663 A B C Plate-compr mtg
23 218254500 A B C Grommet-compr mtg,(4)
24 5308003633 A B C Washer-compr mtg
25 5308003596 A B C Clip-compressor mtg
26 215372500 A B C Pan-defrost drain
26* 5308017610 A B C Sound Tape,defrost pan
27 5303001348 A B C Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C Pan Retainer Kit,Service
29 218374515 A B C Compressor-AMERICOLD, RH108,W/O ELECTRICALS
30 # 218721101 A B C Starter/Overload Assy
32 218740800 A B C Wire-bale
41 5308000039 A B C Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
43 5303001199 A B C Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C Clamp,nylon ,.75 OD tube
45 5303001343 A B C Screw,hex wshr hd ,8-15A x .5 ,spec
45 5303207328 A B C Screw,hex wshr hd ,8-15A x 1
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x .625 ,spec
55 # 216236200 A B C Capacitor-run
* # 5300189383 A B C Hot Tube Repair Kit,Service

07/98 10
Publication No. FRT21NNGW1, FRT21NNGD1, FRT21NNGB1
5995310009
WIRINGDIAGRAM
S193832

# = Fast-moving Parts 11 07/98
* = Non-Illustrated Parts
FRT21NNGW1, FRT21NNGD1, FRT21NNGB1 Publication No.
5995310009
WIRING DIAGRAM
W193832
