Frigidaire FRT22RRHW3 User manual

Product Registration ........................ 2
Versión en español........................... 2
Important Safety Instructions.......... 2
First Steps........................................ 3
Energy Saving Ideas......................... 4
Setting the Controls ........................ 4
Temperatures.............................. 4
Moisture Reduction Switch......... 4
Fresh Food Storage....................... 5-6
Care and Cleaning........................ 6-7
Automatic Ice Maker.................... 7-8
Door Reversal Instructions.......... 9-11
Avoid Service Checklist ............ 12-14
Normal Operating Sounds.............. 14
Warranty........................................ 15
Service Information in Canada ...... 16
P/N 218971802 (0101)

2
Record the Model Number and Serial Number of this refrigerator in the space
providedbelow.Thesenumbersarefoundontheserialplatelocatedonthetopleft
wallof therefrigeratorcompartment.
ModelNumber:
SerialNumber:
Register Your Product
Theself-addressed PRODUCTREGISTRATION CARD shouldbefilledincompletely,
signed and returned to Electrolux Home Products.
Product Registration
Versión en español
Si desea obtener una copia en español
de este Manual del Usuario, sírvase
escribir a la dirección que se incluye a
continuación.Solicitela P/N 218971801.
SpanishOwner'sGuides
ElectroluxHomeProducts
P.O.Box 212378
Augusta,GA 30917
Important Safety
Instructions
Proper Disposal of
Your Refrigerator/Freezer
DANGER
Riskofchildentrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandoned refrigerators or freezers are
still dangerous — even if they will sit for
"justafewdays."Ifyouaregettingridof
your old refrigerator or freezer, please
followinstructionsbelowtohelpprevent
accidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
* Take off
doors.
* Leave
shelves
in place,
so
children
may not
easily
climb
inside.
Avoid fire hazard or
electric shock. Do not use an extension
cordoranadapterplug.Donotremove
anyprong fromthe powercord.
© 2001 White Consolidated Industries, Inc.
All rights reserved.
Read all instructions before using this refrigerator.
For Your Safety
Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityof
this or any other appliance. Read product labels for flammability and other warnings.
Child Safety
• Destroy carton, plastic bags, and any exterior wrapping material immediately
aftertherefrigeratorisunpacked.Childrenshouldneverusetheseitemsforplay.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
become airtight chambers and can quickly cause suffocation.
• Remove all staples from the carton. Staples can cause severe cuts and destroy
finishes if they come in contact with other appliances or furniture.
• Anempty,discardedicebox,refrigeratororfreezerisaverydangerousattraction
to children. Remove the door of any appliance that is not in use, even if
it is being discarded.
Electrical Information
Theseguidelinesmustbefollowedtoensure thatsafetymechanismsinthe
design of this refrigerator will operate properly.
•The refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a 3-prong
grounding plug for your protection against shock hazards. It must be plugged
directly into a properly grounded 3-prong receptacle. The receptacle must be
installed in accordance with local codes and ordinances. Consult a qualified
electrician. Do Not Use An Extension Cord Or An Adapter Plug.
• Ifvoltagevariesby10percent ormore,performanceofyourrefrigeratormaybe
affected. Operating the refrigerator with insufficient power can damage the
compressor.Suchdamageisnotcoveredunderyourwarranty.Ifyoususpectyour
voltage is high or low, consult your power company for testing.
• Topreventtherefrigeratorfrombeingturnedoffaccidentally,donotplugtheunit
into an outlet controlled by a wall switch or pull cord.
• Do not pinch, knot, or bend the power cord in any manner.
Other Precautions
• Neverunplugtherefrigeratorbypullingonthepowercord.Alwaysgripthe plug
firmly and pull straight out from the receptacle.
• To avoid electrical shock, unplug the refrigerator before cleaning and before
replacingalightbulb.Note:TurningthecontroltoOFFturnsoffthecompressor,but
doesnotdisconnect power to thelightbulb or otherelectricalcomponents.
• Do not operate the refrigerator in the presence of explosive fumes.
• Iftherefrigeratorhasanautomaticicemaker,avoidcontactwithanymovingparts.

3
First Steps ThisOwner’sGuideprovidesspecificoperatinginstructionsforyourmodel.Usethe
refrigeratoronlyasinstructedinthisOwner’sGuide.Beforestartingtherefrigerator,
follow these important first steps.
Location
• Choose a place that is near a grounded electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of direct sunlight and away from the
range, dishwasher or other heat sources.
• The refrigerator must be installed on a floor that is level and strong enough to
supporta fully loaded refrigerator.
• Consider water supply availability for models equipped with an automatic ice
maker.
Installation
• Do not install the refrigerator where temperature will drop below 60°F (15°C)
or rise above 110°F (43°C).The compressor will not be able to maintain proper
temperatures.
• Allow space around the unit for good air circulation. Leave a 1 inch (25 mm)
space behind and a 3 inch (75 mm) space above the refrigerator for adequate
circulation.
• In a recessed installation, allow an extra 1/2 inch (10-15 mm) on each side, for
ease of installation.
• For best circulation, elevate the unit 1 inch (25 mm) from the floor, especially
if the floor is carpeted.
Door Opening
The doors should open to allow easy access to a counter when removing food.
• Do not position the refrigerator so you have to walk around the refrigerator
doors.
• Reverse the doors, if necessary. See Door Reversal Instructions.
Leveling
All four corners of refrigerator must rest firmly on a solid floor.
To adjust front rollers:
1. Open refrigerator door and remove Toe Grille. (Figure 1)
2. Use an adjustable wrench to adjust rollers. (Figure 2)
3. Turn Roller Adjusting Bolt clockwise to raise and counter-clockwise to lower.
Raise the front of cabinet enough so doors will close freely when opened
halfway.
4. Level cabinet side to side.
5. Replace Toe Grille. (Figure 1)
Cleaning
• Wash the inside, all removable parts, and the outside with mild detergent and
warm water. Wipe dry. Do Not use harsh cleaners on these surfaces.
• Do not use razor blades or other sharp instruments that can scratch appliance
surface, when removing adhesive labels. Any glue left from tape or energy
label can be removed with a mixture of warm water and mild detergent, or
touch residue with sticky side of tape already removed.
•Do not remove the Serial Plate.
To Remove Toe grille:Grip sides ofToe
Grilleand pullstraight off.
To Replace Toe Grille:Line up clips with
holesand pushstraight on.
Replacing Toe Grill
(Figure 1)
(Figure 2)

4
Energy Saving Ideas
Setting the Controls
G05C0086
Refrigerator Control
• Install the refrigerator in the coolest part of the room, out of direct sunlight and
away from heating ducts or registers. Do not place the refrigerator next to
heat-producing appliances such as a range, oven or dishwasher. If this is not
possible, a section of cabinetry or an added layer of insulation between the
two appliances will help the refrigerator operate more efficiently.
• Level the refrigerator so the doors close tightly.
• Referto this Owner's Guide forthe suggested refrigeratorsettings.
• Periodic cleaning of the condenser will help the refrigerator run more
efficiently. See “Outside” in the Care and Cleaning section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigerator to run longer and use more energy. Shelves should not be lined
with aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Cover foods and wipe containers dry before placing them in the refrigerator.
Thiscuts down on moisture build-up inside theunit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Cool Down Period
To ensure safe food storage, allow the refrigerator to operate with the
doors closed for a least 8 to 12 hours before loading with food.
Refrigerator & freezer controls
Note: When first setting the controls or when changing a setting, wait 24
hours for the temperature to stabilize before making additional changes.
Temperatures
• After 24 hours, adjust the controls as needed. Adjusttemperatures one
increment at a time.
• For colder temperatures, turn the dial a notch towards COLDER.
• For warmer temperatures, turn the dial a notch towards WARMER. The
temperature will increase, but not necessarily by 1,2, or 3°.
Turningtherefrigeratorcontrolmaychangetemperaturesinbothcompartments.For
example, if the refrigerator control is turned to a colder setting, the freezer control
may have to be adjusted to a warmer one. Turning the freezer control will change
only the freezer temperature.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air vents with food items.
IMPORTANT:IftherefrigeratorcontrolisturnedtoOFF,coolingstopsinboth
compartments.
Moisture Reduction Switch (some models)
Ifmoisture forms on the metalbetween the twodoors, setthe Moisture Reduction
Switch (located on the control box in the refrigerator compartment) to the “ON”
position. A heater will warm the surface and allow moisture to evaporate.
Moisture Reduction Switch
Freezer Control

5
Fresh Food Storage
Cantilever Shelf
Shelf Adjustment
Refrigeratorshelvesareeasilyadjustedtosuitindividualneeds.
Some models have sliding shelves, others have cantilever
shelves.Beforeadjustingshelves,removeallfood.Theshipping
clipsthatstabilizetheshelvesforshippingmayberemovedand
discarded.
Toadjustcantilevershelves(shelvessupportedattherearofthe
refrigerator),liftthebackofthe shelfupandout. Replaceshelf
byinsertinghooksatrearintoslots.Lowerandlockintoposition.
SpillSafeTMglassshelves(somemodels)catchandholdaccidental
spills. In some models, the SpillSafeTM shelves slide out for easy
access to food and fast cleaning. The shelves slide out
independentlyofthecantileverbrackets.Justpullfrontofshelf
forward. Shelf can be extended as far as stopper will allow.
Door Storage
Door bins and shelves provide convenient storage of jars, bottles, and cans. Items
used often are available for quick selection.
Thedoorbinscanbemovedtosuitindividualneeds.Removebinsbyliftingstraight
up. Place bins in the desired position and lower over the supports.
The Dairy Compartment(s) is warmer than the general food storage section and is
intended for short term storage of cheese, spreads, or butter.
Tall Bottle Retainer (some models)
The Tall Bottle Retainer keeps tall containers in the bin from falling forward when
openingorclosingtherefrigeratordoor.Toinstall,holdtheretaineratthetop,and
slideitovertheoutsidewallofthebin,asshown.Notethattheretainerworksbest
with the use of a bin snugger.
Micro-Serve Dishes (some models)
Food can be stored, cooked*, and served in Micro-Serve Dishes provided in some
models.Thesedishesslideeasilyintotheirowntray,whichhangsbelowadoorgallon
binasshownbelow,convenientlyfreeingshelfspaceforotheritems. Note: Donot
hang tray below the bin in front of the ice maker.
*Remove plastic lid before cooking. Lid is intended for storage only.
Crispers
The Crispers, located under the bottom refrigerator shelf, are designed for storing
fruits, vegetables, and other fresh produce. Wash items in clear water and remove
excesswaterbeforeplacingintheCrispers.Itemswithstrongodorsorhighmoisture
shouldbewrappedbeforestoring.
TheHumidityControls allow you to adjustthehumiditywithintheCrisper.Thiscan
extend the life of fresh vegetables which keep best in high humidity. Leafy
vegetables,however,keepbestwhenstoredwiththeHumidityControlsetonhigh
moisture, or in a drawer without a Humidity Control. This keeps incoming air to a
minimumand maintains maximum moisture content.
Humidity Control
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
Micro-Serve Dishes
Bin Snugger
Micro-Serve Dish Tray
Tall Bottle Retainer
WINE RACK (some models)
The Wine Rack stores bottles of wine, or 2-liter plastic bottles of juice or
soda pop. To install, slide the wine rack onto the shelf with the curve facing
in. To remove, slide the wine rack out.
Wine Rack

6
Care and Cleaning
To avoid damage and help
the refrigerator run as efficiently as
possible, clean the condenser and air
vents periodically.
Keepyourrefrigeratorandfreezercleantopreventodorbuild-up.Wipeupanyspills
immediatelyandcleanbothsectionsatleasttwiceayear.Neverusemetallicscouring
pads, brushes,abrasive cleanersor strong alkaline solutionson any surface. Do not
wash any removable parts in a dishwasher.
Always unplugthe powercord fromthe wall outletbefore cleaning. Turning
therefrigeratorcontroltoOFFdoesnotdisconnectpowertothecontrols,lightbulb,
orotherelectricalcomponents.
Inside
Wash inside surfaces of the refrigerator and freezer with a solution of 2 tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring
excess water out of sponge or cloth before cleaning around the controls, light
bulb, or any electrical parts.
Washremovablepartssuchasshelvesanddrawerswithbakingsodasolutionormild
detergentandwarmwater.DONOTUSEHARSHCLEANERSONTHESESURFACES.
Rinseanddrythoroughly.Cleanthedoorgasketswithmildsuds,rinsewithclearwater
andwipe dry. Do not userazor blades orother sharpinstruments which canscratch
theappliancesurfacewhenremovingadhesivelabels.Anyglueleftfromthetapeor
energy label can be removed with a mixture of warm water and mild detergent, or,
touch the residue with the sticky side of tape already removed.DO NOT REMOVE
THESERIALPLATE.
Outside
Washthecabinetandhandleswithwarmwaterandmildliquiddetergent.Rinsewell
and wipe dry with a clean soft cloth. Do not use commercial household cleaners,
ammonia, or alcohol to clean handles.
Removeanydustordirtfromthefrontofthetoegrillusingavacuumcleanerwithits
dustingtoolattachment.Removethetoegrillbypullingitstraightout.Whilethegrill
isremoved, vacuum the backside of the grilland wipe with a sudsy cloth orsponge.
Periodically clean the condenser (black tubes and wires beneath the refrigerator,
behindthetoegrill).Donotallowlintordusttoaccumulateonthecoils.Insertalong
handledbrushorvacuumattachmentbetweenthetwocoilstobringthelintforward.
Damp objects stick to cold
metalsurfaces.Donottouchrefrigerated
surfaces with wet or damp hands.
Meat Keeper (some models)
ThetemperatureintheMeatKeeperdrawercanbemadecolderthantherestofthe
refrigeratorcompartmentbyadjustingtheChilledAirControl.Meatwillbepartially
frozen and may be kept fresh longer than if stored on a refrigerator shelf.
Beforeplacingitems in the MeatKeeper,follow these stepstokeep the meat fresh:
1. Carefully handle meat with clean hands and always keep the compartment
clean.
2. Store meat in its original wrapper. If necessary, overwrap in plastic wrap or foil
topreventdrying.Wrapfishtightly to prevent odortransfertootherfoods.
3. If spoilage ever occurs, disinfect the compartment with liquid chlorine bleach
followinglabeldirections.Then,rinsewithasolutionofbakingsodaandwater.
Rinse with clear water and dry.
Adjustable Chilled Air Duct (some models)
The Chilled Air Duct, which distributes cold air to the Meat Keeper drawer, can be
adjustedtoaccommodaterepositioningoftheshelf.However,theshelfhasalimited
range of positions in which the Chilled Air Duct will reach.
TheChilledAirDuctcanalsoswitchsides,shouldyouwishtomovethesplitcantilever
shelf. To change sides:
1. RemovetheMeatKeeperdrawerandshelf.Grasptheairductneartopandslide
toward you until duct is free from grooves.
2. Slide off hole cover on opposite side. Insert the lip of the air duct in grooves of
new hole and slide back.
3. Slide hole cover over original hole.
4. Replace shelf and insert drawer.
Adjusting the Chilled Air Duct
Hole Cover
Air Duct
Lower portion of
air duct slides up
or down.
Air Outlet Box
Hole cover and air duct
slide into grooves on
bottom of air outlet box.
Fresh Food Storage
(continued)
Chilled Air Control

7
Care and Cleaning
(continued)
To replace the toe grill, line up tabs with holes and push grill straight on.
Usecautionwhencleaningintheareaofthecoils.Surfacesthere
may be sharp.
Theairventsontheloweraccesspanelattherearoftherefrigeratorshouldbecleaned
periodically. Clean the vents by using a vacuum cleaner with its dusting tool
attachment. When moving the refrigerator, pull straight out. Do not shift the
refrigerator from side to side as this may tear or gouge the floor covering. If the
refrigerator has an automatic ice maker, be careful not to move the refrigerator
beyondplumbingconnections.
Replacing the Light Bulb
To replace the light bulb:
1. Unplugtherefrigerator.
2. Wear gloves as protection against possible broken glass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Remember to plug the refrigerator back in.
Vacation and Moving Tips
Shortvacations: Leavetherefrigeratoroperatingduringvacationsof1to3weeks.
Useupallperishableitemsfromtherefrigeratorsection.Wrapandstoreotheritems
in the freezer. If the unit has an automatic ice maker, turn off the ice maker.
Longvacations: Removeallfoodandiceifyouwillbegone1monthormore.Turn
the refrigerator control to OFF and disconnect the power. If the unit has an
automaticicemaker,turnofftheicemakerandturnthewatersupplyvalvetothe
closedposition.Defrostandcleantheinteriorthoroughly.Leavebothdoorsopen
to prevent odor and mold buildup. Block open if necessary.
Moving: Whenmovingtherefrigerator,followtheseguidelinestopreventdamage:
• Remove all food and other items from both the refrigerator and freezer
compartments. Empty the ice storage bin. Defrost and clean the interior
thoroughly.
• If a hand truck is used in moving, load the refrigerator from the side.
• Turnfrontrollersasfarupaspossible.Thiswillprotectthemduringslidingor
moving.
• The cabinet should be well padded and handled with care. DO NOT DROP.
Automatic Ice Maker
Wire
Signal Arm
Ifyourrefrigeratorhasanautomaticicemaker,itwillprovideacontinuoussupplyof
ice for normal use. The automatic ice maker is an optional accessory which may be
installed in most models at any time. Call your local dealer for installation.
Aftertheplumbingconnectionshavebeen completed,thewatersupply valvemust
be opened. Place the ice container under the ice maker, pushing it as far back as
possible. Lower the wire signal arm to its “down” or ON position. Because of new
plumbingconnections,thefirstproductionoficecubesmaybediscoloredorhavean
oddflavor. Theseshouldbediscardeduntilthecubesmadearefreeofdiscoloration
and taste.
To stop the ice maker, lift the wire signal arm until it clicks and locks in the “up” or
OFFposition.Theicemakerturnsoffautomaticallywhentheicecontainerisfull.Ifyour
modelhasanadjustablefreezershelf,placetheshelfsothewiresignalarmwillhitthe
ice when the ice container is full.
Remember, water quality
determines your ice quality. It is best to
connect the ice maker to water that is not
softened. Chemicalsfromamalfunctioning
softener can damage the ice maker. If ice
maker is connected to soft water, ensure
the softener is maintained and working
properly.

8
Ice maker tips
1. Ice cubes stored too long may develop an odd flavor. Empty the container and
be sure the wire signal arm is in its “down” or ON position. The Ice Maker will
then produce more ice.
2. Occasionally shake the container to keep ice separated.
3. Keep the wire signal arm in its “up” or OFF position untilthe refrigeratoris
connected to the water supply or whenever the water supply is turned off.
4. Certain sounds are normal when the Ice Maker is operating. They are:
• Motoroperation
• Ice being loosened from the tray
• Icedropping into the storage bin
• Runningwater
• Water valve opening or closing
For more information on these operations, see Normal Operating Sounds.
5. Wash ice container in warm water with mild detergent. Rinse well and dry.
6. Stop the Ice Maker when cleaning the freezer or for short vacations.
7. If the Ice Maker is to be turned off for a long period of time, turn the water
supply valve to the closed position.
Automatic Ice Maker
(continued)

9
G05I0006
G05I0098
G05I0013 G05I0003
Yourrefrigeratorisequippedwithconvertibledoorhinges.Hingingofthedoorcan
be changed to the opposite side any time you wish. An envelope containing extra
plastic hole plugs is included in some models. Turn the refrigerator control to OFF.
Removeallfood,bottles,andotheritemsfromthedoor.Beginwithfreezerdoor.
Completely remove one door before beginning the other.
3. Withthe refrigeratordoorclosed, remove
center hinge pin. (Note the arrangement of
the upper and lower washers on the hinge
pin. The washers must be assembled later in
the same manner.) Open refrigerator door
enough to allow door to be lifted off the
lower hinge. Remove the two screws
attaching the center hinge. The third
outermost screw under the center hinge
shouldbeleftinplace.Savehinge,pin,and
washers for reassembly later. Reinstall
screws in original holes.
Reversible Door
Instructions
Hinge Pin
Washer
Screws
Hinge
Washer
Hinge Pin
G05I0008
G05I0007
4. Remove hole plugs from the non-hinge
side of the following:
• the top of the cabinet
• the top of the freezer door
• thethird,outermostscrewholeincentermullion
Reinstallonoppositeside. If damaged from
removal,usenewplugsincludedinliterature
pack (some models).
Washer
Hinge
Bolt
Washer
Hinge
Bolt
5. Remove the toe grille from front of
refrigerator by pulling straight forward.
Remove the two hex head bolts attaching
the lower hinge. Save the hinge and
washer(s)forreassembly.
6. Boltlowerhingetocabinetonopposite
side. Install washer(s) on the lower hinge
pin.
(Third, outer-most
screw is left in place.)
Hole Plug
Hole Plugs
1. Snap off hinge cover at top of cabinet.
With the freezer door closed, remove the
three screws attaching upper hinge to
cabinet.Note: Hingehasaminimalspring
load. Hold bracket when removing last
screw.Liftthehingeupandoff. Besureto
save screws and hinge for reassembly
later.
2. Open the freezer door enough to allow
ittobeliftedoffthecenterhinge.Hingepin
may stick in spin bearing. Use pliers to
remove hinge pin.

10
Reversible Door
Instructions (continued)
G05I0118
7. Reverse handles while doors are off. Remove the two screws
attaching the handle to the bottom of the freezer door. Remove
short trim piece by sliding the trim straight up and off of handle
bracket.Removethescrewattachingthetopofthehandletodoor,
andreinstall on other side, using the holefound behind the self-
adhesive nameplate. To move nameplate to the other side, peel
offthenameplateandreapplyovertheoldhandleholes. Reattach
handletobottomofdoor.Slidethetrimpiecestraightdownonto
handle bracket.
Freezer Door
G05I0111
Refrigerator Door
8. Trim Removal (Full-Length Trim models only)
Insomemodels,therefrigeratordoorhasafulllengthtrim
piecewhichcontinuesfromthebottomofthehandletothe
bottomofthedoor.Thetopofthetrimattachestothehandle
bracket. An adhesive "trim lock" is positioned about half-
way down. The bottom of the trim is held in place by either
anadhesivetrimlock,oratrimlockwithtwoprongsinserted
intoaholeonthefaceofthedoor.Removethetrimbygently
pullingthetrimlockareasoutandawayfromthedoor.When
thetrimisfreefromthedoor,slidethetrimstraightdownand
away from the handle bracket.
For models with short handle trim, removeby sliding the
trim straight down and off of handle bracket.
Toremovehandles:Removethethreescrewsattachingthe
handleto therefrigerator door.Carefully removehole plugs
from corresponding holes on opposite side of doors and
reattach handle.
Toreattachtrim:Slidebothtrimlocksoutoftrim.Insertthe
new adhesive trim locks contained in your literature pack.
NOTE: Trim lock must be removed and installed by sliding
OVER the two donut shaped areas. Install trim to handle by
sliding up over bottom of handle. Carefully align trim and
press down at trim lock locations. Replace hole plug on
opposite side. Use rubbing alcohol to remove any adhesive
residue from old trim lock location(s).
Formodelswithshorthandletrim,slidethetrimstraightup
onto handle bracket.
