Frigidaire FRTB7B4E Instruction Manual

N05L00015.eps N05DDDCMA1.eps N05BBAABA25.eps N05SADAJY2.eps
N05CAABAD1.eps 240398801.eps 240398601.eps
Product No. FRTB7B4EMB2
Series beverage center
Color silver mist
Volts 115
Wiring Diagram 240398801
Owner's Guide 241695500
Market North America
Service Data Sheet 240379018
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995489324
07/04/20
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRTB7B4E
Copyright ©All rights reserved.

Publication No: 5995489324 FRTB7B4EMB2
04/07 2
DOOR
10
22
22
11
12
22
22
22
13A
13
21C
21C
10
22
74
22
1
2
22
N05DDDCMA1
15
8
4
4B
504
509
505
506
507
508
56
23A
44
503
503A
505
301
302
300
23
89
89
74
88

FRTB7B4EMB2 Publication No: 5995489324
# Functional Parts 3 04/07
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 # 240542119 Gasket-frzr door, black, magnetic
2 240542122 Gasket, refr door seal, black, magnetic
4 240535101 Rack-door
4B 240535201 Rack-door
8 240535001 Rack-door
10 240381303 Plug-button, black, hinge brg hole
11 240433503 Door-frzr, silver mist, complete assy
12 241808601 Label-nameplate
13 240312405 Door Stop, black, refr
13A 240312406 Door Stop, black, frzr
15 240428803 Door-refr, silver mist, complete assy
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 Bearing-hinge, black
23 241662501 Sump-dispenser, black
23A 241662701 Drip Tray, black
44 241662601 Cover-module, black
56 5304451131 Drain Sump Kit
74 240383403 Screw, truss hd quad, #10-16 x .500, black
88 241672601 Nut, hex jam, 1/4-18
89 241672501 Washer, Neoprene
300 218515401 Clip
301 5304443662 Hose, delivery, 3/16" ID x 5'
302 5304443664 Washer, sealing, Neoprene, (2)
503 5304443658 Faucet, standard
503A 5304443659 Knob, faucet, black
504 5304451133 Shank Assembly, faucet
505 5304443667 Flange, sealing, plastic, black
506 5304443668 Nut, faucet coupling, chrome
507 5304443669 Sleeve
508 5304443670 Snap Ring
509 5304443672 Lock Nut
* 241669301 Ferrule-inner
* 241669401 Ferrule-outer
* 5304443671 Cleaning Kit, deluxe
* 5304451132 Regulatory washer kit
* 5304451963 Drain Sump Hose Kit

Publication No: 5995489324 FRTB7B4EMB2
04/07 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA25
43 21C
41
41
41
8
8
9
14
81
34
22
21C
89

FRTB7B4EMB2 Publication No: 5995489324
# Functional Parts 5 04/07
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 241652301 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut, push-on
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 241652215 Cover-evap coil
10* 240568601 Seal-coil cover
10*# 241520701 Harness-wiring, freezer
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 240369702 Motor-evap fan
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 Plug-button, black, upr hinge holes
30 240357103 Bracket, bottom hinge, black
34 240311303 Washer, hinge, nylon, (2)
35 240357003 Bracket, center hinge, black
35A 240336803 Spacer-hinge, center, black
36 240516402 Pin-center hinge
37 241611303 Trim-cabinet corner, black, (2)
38 240356901 Bracket, upper hinge
40 240354404 Cover-upper hinge, black
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 241559604 Roller Assy, fixed, front LH
43* 241559603 Roller Assy, fixed, front RH
56 240516502 Pin-lower hinge
58 5304456287 Screw, hex washer head, 8-15A x 0.500
59 240442707 Screw-#10-32 X 3/4, black
72 240368303 Grille/Kickplate, black, lower front
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241733906 Cover-access, with label
89* 241500304 Screw, hex washer head, 8-18AB x 0.625
92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 218515401 Clip
* 240479601 Plug, button, cab liner holes
* 5303321321 Paint, touch-up, black
* 5304451343 Castor Kit

Publication No: 5995489324 FRTB7B4EMB2
04/07 6
SHELVES
302
300 301
11
12
13
17
75
81
15
16
81
14
23
22A
21
18
24
78
78A
78A
74
74 25
27
27
85
81
27A
27A
26
N05SADAJY2
26
24A

FRTB7B4EMB2 Publication No: 5995489324
# Functional Parts 7 04/07
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
11 240358004 Shelf, freezer
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240368001 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 Timer-defrost
23* 5304455649 Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 241667701 Shelf-fixed, white
24A 241662401 Shelf, can tower
25 241665901 Cover, keg support
26 241667601 Basket-sliding, wire
27 241659001 Support, keg plate
27A 241661002 Tape-double faced, 23"
74 215503201 Screw, cr pan hd, 10-16 x 0.500
75 240515601 Shield-light
78 241672701 Plate-skid
78A 241661003 Tape-double faced, 21"
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
85 218644502 Clamp-strain relief
300 5304443657 Coulper, keg
301 5304443660 Gauge, pressure, double, CO2 primary
302 5304443661 Tank, CO2, aluminum

Publication No: 5995489324 FRTB7B4EMB2
04/07 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAABAD1
22
23
23
30
32
85
55
4
6
29
25
25
24
24 25
24
26
84
45
57

FRTB7B4EMB2 Publication No: 5995489324
# Functional Parts 9 04/07
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 241682902 Condenser, dynamic
4 # 218944001 Drier-filter, R134a System
6 # 241607001 Harness-wiring, machine compt
6* 240388701 Wiring Harness, control box
6* 241520701 Harness-wiring, freezer
14 # 240356213 Heater-defrost
15 # 5303918275 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241801302 Trough-drain
20 241551901 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241665605 Base-compressor
22* 218252201 Screw, #8 truss hd, 10-32CA x 0.500
23 241659701 Grommet, compressor
24 241812301 Washer-compr mtg
25 216056401 Clip-compressor mtg
26 241683601 Pan-defrost
29 # 5303918325 Compressor, w/electricals
30 216954201 Controller, compressor
32 216954300 Clip, controller
34 240405201 Grommet, rubber, black, cond tube/wire
41 240433204 Screw, hex washer head, 8-18 x 5/16
44 5304456288 Clamp-wiring harness, strain relief, galv steel
45 241500304 Screw, hex washer head, 8-18AB x 0.625
55 218909913 Capacitor, run, 220 VAC, 15 microfarad
57 240542601 Clip-wiring harness
58 218897004 Screw, hex washer head, 8-32 x 0.375
59 5304430246 Bracket-cond motor assy
59* 240346701 Tape-foam seal, shroud
59* 240359403 Screw-fan shroud, (2)
60 # 240525402 Motor, condensor fan
61 # 240524101 Fan Blade, galv steel, condenser fan
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 Tube-drain, rubber, lower
85 241665801 Tube-connector, suction
* 240396801 Clamp, tube/wiring, nylon, black/natural
* # 5303918263 Heat Exchanger Kit, suction line
* 5303918222 Hot Tube Repair Kit, service

Publication No: 5995489324 FRTB7B4EMB2
04/07 10
WIRING SCHEMATIC

FRTB7B4EMB2 Publication No: 5995489324
# Functional Parts 11 04/07
* Non-Illustrated Parts
WIRING DIAGRAM
