Frigidaire PLHT219TC User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
PLHT219TCB0 PLHT219TC R134a Profesion stain/blk (RH) 115
PLHT219TCK0 PLHT219TC R134a Profesion stain/blk (RH) 115
MARKET
North America
Publication No.
5995380267
021025
-EN/SERVICE/KHB
357
TOP MOUNT
REFRIGERATOR
Model No.
PLHT219TC
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
ENERGY GUIDE - 240465047
OWNER’S GUIDE - 240400107
SERVICE DATA SHEET - 240379010

10/02 2
Publication No. PLHT219TC
5995380267
DOOR

# = Fast-moving Parts 3 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
A = PLHT219TC (PLHT219TCB0)
B = PLHT219TC (PLHT219TCK0)
POS. NO PART NO DESCRIPTION
1 # 240514611 A B Gasket,seal ,black ,frzr door ,magnetic
2 # 240514612 A B Gasket,seal ,black ,refr door ,magnetic
7 240338311 A B Door-dairy
11 240450317 A - Panel-frzr door, stainless steel, complete assy
11 240450318 - B Panel-frzr door, stainless steel, complete assy
12 240558801 A B Nameplate,aluminum
13 240312405 A B Door Stop,black ,refr
13A 240312406 A B Door Stop,black ,frzr
15 240450419 A - Panel-refr door, stainless steel, complete assy
15 240450420 - B Panel-refr door, stainless steel, complete assy
18 240413701 A B Handle-door, stainless steel, with insert
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240527102 A B Bearing-hinge,black
27A 240396105 A B Retainer,tall bottle
48 240338101 A B Bin-door,pseudo ,bottom
48A 240338208 A B Bin-door,gallon ,aqua
49 240495807 A B Bin-door,pseudo ,frzr
79 218755402 A B Screw-set,10-32 x 0.375
80 218755503 A B Screw-shoulder,#10 AB ,handle mounting
* 218490900 A B Cleaner,stainless steel
DOOR

10/02 4
Publication No. PLHT219TC
5995380267
CABINET

# = Fast-moving Parts 5 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
A = PLHT219TC (PLHT219TCB0)
B = PLHT219TC (PLHT219TCK0)
POS. NO PART NO DESCRIPTION
1 240355404 A B Cover-fan
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240313603 A B Cover-evap coil
10* 240371303 A B Seal, insulation, 53.23 in. Long, foam, coil cover
10*# 240524801 A B Wiring Harness, freezer section, with light
11 5303208309 A B Plug-hole,factory test
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw,hex washer head ,8-18 x 0.375
15 215812200 A B Light Bulb/Lamp,25W
16 218906801 A B Socket-light/lamp
18 240411901 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A B Plug-button,black ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex wshr hd, 1/4-20 x 4.020,(2) ,special
30 240314003 A B Bracket-lower hinge,black
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313803 A B Bracket-ctr hinge,black
35A 240336801 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337603 A B Trim-cabinet corner,black ,(2)
38 240313701 A B Bracket-upper hinge
40 240354404 A B Cover-upper hinge,black
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1.250
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw,hex washer head ,8-15A x 0.500
59 240442703 A B Screw-#10-32 X 3/4,black
72 240368207 A B Grille/Kickplate,black
74 240354301 A B Shield-light,frzr
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access,with label
89* 241500301 A B Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
114# 240505801 A B Switch,light/lamp
* 240542601 A B Clip-wiring harness
* 5303305345 A B Paint,touch-up ,black
CABINET

10/02 6
Publication No. PLHT219TC
5995380267
SHELVES

# = Fast-moving Parts 7 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
A = PLHT219TC (PLHT219TCB0)
B = PLHT219TC (PLHT219TCK0)
POS. NO PART NO DESCRIPTION
11 240358003 A B Shelf,freezer ,full-width ,wire
11* 5303299664 A B Spacer,shelf
12 240417802 A B Diffuser-air,top
12* 240466001 A B Seal,air diffuser
13 240362601 A B Diffuser,air ,bottom
14 # 240505801 A B Switch,light/lamp
15 240436702 A B Light Bulb, A-15, clear, 40 W, 120 V, miniature
16 240364201 A B Socket-light/lamp,dual
17 240407301 A B Control Box
17*# 240375501 A B Wiring Harness,control box
18 240360801 A B Knob,temp control
21 # 5304421256 A B Control,temperature
22A 240468201 A B Tube, sensor sleeve, 31 inch, plastic, white
23 # 240545401 A B Control-defrost, adaptive timer, PC board
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240350119 A B Shelf-"Spill-Safe", cantilever, half-width, sliding
24A 240355228 A B Shelf-"Spill-Safe", cantilever, half-width, fixed
25 240364718 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper,humidity cont.
26 240343806 A B Pan-crisper
31 240530909 A B Pan-meat,aqua
34 240385201 A B Container,ice bin
42 240356501 A B Track,meat pan hanger ,RH
42 240365401 A B Track,meat pan hanger ,LH
47 240443301 A B Panel,pan cover ,glass
81 5308016566 A B Screw, hex washer hd, 8-15A x 0.625, low profile
120 240366401 A B Guide-follower,cam follower
121 240366602 A B Cam Follower
122 240366501 A B Cam,damper
123 215005100 A B Screw,hanger/rlr mtg ,8-10 x 0.438
130 240366101 A B Damper-control box
130* 218249806 A B Seal,insulation ,foam ,damper
131 240366201 A B Retainer-damper,damper
132 240366302 A B Control Rod,damper
136 240424505 A B Dispenser-can,auqa
SHELVES

10/02 8
Publication No. PLHT219TC
5995380267
SYSTEM

# = Fast-moving Parts 9 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
A = PLHT219TC (PLHT219TCB0)
B = PLHT219TC (PLHT219TCK0)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240496101 A B Wiring Harness, machine compt, w/electric cord
6* # 240375501 A B Wiring Harness,control box
6* # 240524801 A B Wiring Harness, freezer section, with light
14 # 5303918247 A B Defrost Heater Kit
15 # 5303918274 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation,evap block ,foam ,RH
20 240518401 A B Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330006 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-compressor mtg,1/4-28 x 1.16, shoulder, typ CF
26 240332602 A B Pan-defrost drain
29 # 5303918251 A B Compressor,w/electricals
30 # 218721119 A B Starter,PTC
32 218973501 A B Clamp,elec cont mtg ,compressor
34 240405201 A B Grommet,rubber ,black ,cond tube/wire
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 5308016566 A B Screw,hex washer head ,8-15A x 0.625, low profile
55 # 216787800 A B Capacitor, run, 50/60 Hz, 220 VAC, 12 microfarad
57 240542601 A B Clip-wiring harness
58 215004600 A B Screw, hx wshr hd, 8-36 x 7/16, cond fan motor, (2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240334001 A B Motor,condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 215004700 A B Nut,speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain,rubber ,lower
85 240493101 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 5308000039 A B Screw,hex wshr hd, 8-32CA x 0.500, serrated head
* # 5303918210 A B Heat Exchanger Kit,suction line
* # 5304421289 A B Hot Tube Repair Kit,Service
SYSTEM

10/02 10
Publication No. PLHT219TC
5995380267
ICE MAKER

# = Fast-moving Parts 11 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
ICE MAKER
A = PLHT219TC (PLHT219TCB0)
B = PLHT219TC (PLHT219TCK0)
POS. NO PART NO DESCRIPTION
1 218976901 A B Tube-water inlet, inlet valve, to ice maker
2 5304420650 A B Spring,shut-off arm
3 3206299 A B Label,ID plate
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 0.250
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-hold switch
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff, ice maker, complete assy
12 # 5304420651 A B Wiring Harness, ice maker, internal, with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 5304420652 A B Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B Switch,(3)
16 5304420653 A B Support,phenolic
17 # 5303320545 A B Mold-ice maker, Radius Cube, with heater
18 3206328 A B Ejector-ice
19 3206330 A B Bearing & Inlet
20 5304408581 A B Screw, 8-32 x 0.375
21 3206332 A B Ice Stripper
22 3206333 A B Shut-off Arm
23 5304408582 A B Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B Lever Arm
25 3206336 A B Screw,8-18 x 0.562 ,lever arm/sprt
26 5304420654 A B Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B Screw,4-40 x 1.000 ,hold switch mtg, (2)
28 3206339 A B Screw-timing stop,4-40 x 0.375
29 3206323 A B Screw,4-24 x 0.750 ,(6)
30 3206341 A B Screw-timing adj,8-32 x 1.000
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 5304408583 A B Spring-timing adj
34 5304420655 A B Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B Screw
36 3206347 A B Cover-ice maker
45 5308016566 A B Screw,hex washer head ,8-15A x 0.625, low profile
51 240387101 A B Tube-water,ice mold fill ,extension
55 # 240519601 A B Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362500 A B Screw,hex washer head ,8-18AB x 1.250
61 218721500 A B Bracket-leveling,ice maker
62 218737900 A B Screw-IM brkt mtg, hex wshr hd, 8-32D x 0.375
64 5303001549 A B Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B Adapter-water supply,nut & sleeve, compression ftg
* 240352409 A B Ice Maker,Radius Cube, 115 V, no instl parts

10/02 12
Publication No. PLHT219TC
5995380267
WIRING SCHEMATIC

# = Fast-moving Parts 13 10/02
* = Non-Illustrated Parts
PLHT219TC Publication No.
5995380267
WIRING DIAGRAM
