Frigidaire GL30WC41E User manual

Product No. GL30WC41EB GL30WC41ES GL36WC41EB GL36WC41ES PL30WC41EC PL36WC41EC
Market North America North America North America North America North America North America
Color black white black white stainless steel stainless steel
Exhaust-CFM 400 CFM 400 CFM 400 CFM 400 CFM 400 CFM 400 CFM
Volts 120 120 120 120 120 120
Owner's Guide 628015en 628015en 628015en 628015en 628015en 628015en
Installation Instructions 628015 628015 628015 628015 628015 628015
Wiring Diagram 5995460895 5995460895 5995460895 5995460895 5995460895 5995460895
GL30WC41E Cover.eps GL30WC41E Parts.eps GL30WC41E Wiring.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995460895
06/02/20
(EN/SERVICE/KC)
099
RANGE HOOD
Model No.
GL30WC41E /
GL36WC41E /
PL30WC41E /
PL36WC41E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995460895 GL30WC41E / GL36WC41E / PL30WC41E / PL36WC41E
02/06 2
REPLACEMENT PARTS

GL30WC41E / GL36WC41E / PL30WC41E / PL36WC41E Publication No: 5995460895
# Functional Parts 3 02/06
* Non-Illustrated Parts
REPLACEMENT PARTS
Model Index: AGL30WC41E (GL30WC41EB)
BGL30WC41E (GL30WC41ES)
CGL36WC41E (GL36WC41EB)
DGL36WC41E (GL36WC41ES)
EPL30WC41E (PL30WC41EC)
FPL36WC41E (PL36WC41EC)
POS. NO PART NO. DESCRIPTION
1 5304452401 A B C D E F Plate, round duct, 7 inch dia.
2 5304454175 A B C D E F Connector, damper/duct
3 5304454176 A B C D E F Screw, hex head, 8-18 x 1/4, 2-pk
4 # 5304454177 A B C D E F Capacitor, motor, with hardware
5 # 5304454178 A B C D E F Transformer, isolation
6 5304454179 A - C - E F Label, control panel, black
6 5304454180 - B - D - - Label, control panel, white
7 5304454181 A - C - E F Control Panel, black
7 5304454182 - B - D - - Control Panel, white
8 5304454183 A B C D E F Screw, flat head, #6 x 1/2
9 5304454184 A B C D E F Screw, 8-18 x 0.375
10 5304454185 A B C D E F Screw, ground/earth
11 5304454186 A B C D E F Cover, scroll, outlet, w/hardware
12 5304454187 A B C D E F Cover, scroll, front, w/hardware
13 # 5304454188 A - C - E F Control Assembly, black, w/6 & 7
13 # 5304454189 - B - D - - Control Assembly, white, w/6 & 7
14 5304454190 A B C D E F Chute Assembly, air, w/15-baffle
15 5304454191 A B C D E F Baffle, air
16 5304454192 A B C D E F Screw, M4 x 6 mm
17 5304454193 A B C D E F Plate, motor, w/mounting kit
18 5304454194 A B C D E F Mounting Kit, motor plate
19 # 5304454195 A B C D E F Motor, fan, w/16-screw
20 # 5304454196 A B C D E F Blower Wheel, fan, w/21-ring
21 5304454197 A B C D E F Ring, retainer, blower wheel
22 # 5304454198 A B C D E F Receptacle, lamp socket
23 5304454199 A - - - - - Panel, lamp, 30 inch, black
23 5304454200 - B - - - - Panel, lamp, 30 inch, white
23 5304454202 - - C - - - Panel, lamp, 36 inch, black
23 5304454203 - - - D - - Panel, lamp, 36 inch, white
23 5304454201 - - - - E - Panel, lamp, 30 inch, stainless
23 5304454204 - - - - - F Panel, lamp, 36 inch, stainless
24 5304454205 A B C D E F Hole Plug
26 5304454206 A B C D E F Spring Kit, filter retainerMount with 3 pop rivets -0.125 dia. Purchase locally
28 # 5304454207 A B C D E F Transformer, auto, w/hardware
29 # 5304454208 A B - - E - Filter, 30 inch, aluminum mesh
29 # 5304454209 - - C D - F Filter, 36 inch, aluminum mesh
30 # 5304454210 A B C D E F Blower Wheel Assy, non-ducted
* # 5304454211 A B C D E F Wiring Harness
* # 5304454212 A B C D E F Fuse, control, 10 amp
* 5304454213 A - C - - - Nameplate, black, Gallery
* 5304454214 - B - D - - Nameplate, white, Gallery
* 5304454215 - - - - E F Nameplate, stainless steel, Prof.

Publication No: 5995460895 GL30WC41E / GL36WC41E / PL30WC41E / PL36WC41E
02/06 4
WIRING DIAGRAM
